RLXIB-IHW-66 ♦ 802.11a, b, g
Industrial Hotspot
1.1.1 Specifications
Radio
Frequency Band
(Varies by Country)
Wireless Standards
Transmit Power
(Programmable)
Channel data rates
(Modulation)
Receiver Sensitivity (Typical)
Channels Selection
Security
Physical
Enclosure
Overall Dimensions
Ethernet Ports
Antenna Ports
Weight
Environmental
Operating Temperature
Humidity
External Power
Average Power
Page 8 of 109
802.11b/g:
2.412 to 2.462 GHz (FCC)
2.412 to 2.472 GHz (ETSI)
802.11a:
5.150 to 5.250 GHz (FCC/ETSI)
5.725 to 5.850 GHz (FCC)
802.11a, 802.11b, 802.11g, 802.11i
Up to 50 mW
802.11b: 11, 5.5, 2, 1 Mbps
(DSSS - BPSK, QPSK, CCK)
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
-95 dBm @ 1 Mbps
-90 dBm @ 11 Mbps
-82 dBm @ 24 Mbps
-75 dBm @ 54 Mbps
1 to 13 (802.11b/g)
36, 40, 44, 48, 149, 153, 157, 161, 165 (802.11a)
WPA2/802.11i with 128/192/256 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter
Admin password
IP-66 rated die-cast aluminum with pole mount hardware
6 = Dust tight - No ingress of Dust
6 = Protected against water jets against the enclosure from any
direction shall have no harmful effects.
213 x 178 x 56 mm / 8.4 x 7.0 x 2.2 inches (W x H x D)
Water/Dust Tight M12 connector
IEEE 802.3, 802.3u, 802.3x, 802.3af
(2) N-type female connectors
2.4 lb (1kg)
-30° C to +60° C
To 90% RH, non-condensing
802.3af PoE
<6W
