Radio Configuration / Diagnostic Utility

User Manual
4 Radio Configuration / Diagnostic Utility
In This Chapter
Radio Status.......................................................................................... 35
Radio Network settings ......................................................................... 41
Security settings .................................................................................... 52
Radio access settings ........................................................................... 55
Apply Changes ...................................................................................... 58
Cancel Changes.................................................................................... 58
Factory Defaults .................................................................................... 58
The RadioLinx Industrial Hotspot radio has a built-in Radio Configuration /
Diagnostic Utility (radio web configuration form) that allows you to configure the
radio from any computer that can connect to the radio, through a wired Ethernet
connection, or through a Wireless connection.
You can use a web browser such as Microsoft Internet Explorer or Firefox on
your network-enabled desktop computer, laptop or Personal Data Assistant
(PDA) to monitor and change the settings within the RadioLinx Industrial Hotspot
radio.
To open the Radio Configuration / Diagnostic Utility
1 In the RadioLinx Industrial Hotspot Browser, select the radio to configure from
the list view or topography view, and then click the right mouse button to
open a shortcut menu.
2 On the shortcut menu, choose Connect. The Radio Configuration / Diagnostic
Utility will open in your web browser.
Or,
Double-click the selected radio to launch the Radio Configuration / Diagnostic
Utility.
ProSoft Technology, Inc.
May 18, 2009
RLXIB-IHW-66 ♦ 802.11a, b, g
Industrial Hotspot
Page 31 of 109
