RLXIB-IHW-66 ♦ 802.11a, b, g
Industrial Hotspot
5.5.5 Zoom In
Use the Z
OOM
the RadioLinx IH Browser window.
Page 76 of 109
Radio not linked; no parent
An Ethernet connection exists to the radio; does not
indicate the number of devices on the connection
Wireless clients (PCMCIA cards) are linked to this
radio; the number of clients linked is indicated by the
number of boxes
Signal strength; the width of the line is not calibrated
Alternate parents.
I command in Topology View to enlarge the size of the items in
N
RadioLinx Industrial Hotspot Browser
User Manual
ProSoft Technology, Inc.
May 18, 2009
