Event Lighting TSUNAMI-IP User Manual page 6

5 5 Beam Duration
6 6 Beam Macro
4 7 7 Plate Red
5 8 8 Plate Green
6 9 9 Plate Blue
7 10 10 Plate Strobe
11 11 Plate Macro
12 12 Plate Macro colour
13 13 Plate Macro Speed
14 14 Reserved
15 Beam Section 1
16 Beam Section 2
17 Beam Section 3
18 Beam Section 4
19 Plate Section 1 Red
20 Plate Section 1
Green
21 Plate Section 1 Blue
... ...
40 Plate Section 8 Red
41 Plate Section 8
Green
42 Plate Section 8 Blue
6
0 255 0-3 sec
0 15 No Macro
16 57 Strobe Macro 1
58 99 Strobe Macro 2
100 141 Strobe Macro 3
142 183 Strobe Macro 4
184 225 Strobe Macro 5
226 255 Strobe Macro 6
0 255 Red Dimmer, 0-100%
0 255 Green Dimmer, 0-100%
0 255 Blue Dimmer, 0-100%
0 9 No Strobe
10 255 Strobe, slow to fast
0 4 No Macro
5 9 Plate Macro 1
10 14 Plate Macro 2
15 19 Plate Macro 3
... ... ...
250 254 Plate Macro 50
255 255 Plate Macro 51
0 255 Plate Macro colour
0 255 Plate Macro Speed
0 255 Reserved
0 255 Beam Section 1 dimmer, 0-100%
0 255 Beam Section 2 dimmer, 0-100%
0 255 Beam Section 3 dimmer, 0-100%
0 255 Beam Section 4 dimmer, 0-100%
0 255 Plate Section 1 Red dimmer, 0-100%
0 255 Plate Section 1 Green dimmer, 0-
100%
0 255 Plate Section 1 Blue dimmer, 0-100%
... ... ...
0 255 Plate Section 8 Red dimmer, 0-100%
0 255 Plate Section 8 Green dimmer, 0-
100%
0 255 Plate Section 8 Blue dimmer, 0-100%
