User Guide
EVALUATION BOARD CONFIGURATION
Table 4. Jumper Configurations
Jumper Position
Disconnected
DE2 VCC
GND
Disconnected
DE3 VCC
GND
Disconnected
DE4 VCC
GND
Disconnected
analog.com
Description
Disconnects the DE1 pin from VCC or GND, which allows the DE1 pin to be controlled from the DE1 connection on
the P3 screw terminal block.
Connects the DE2 pin of the ADN4680E to VCC, which enables the A2 and B2 transmitter if the ENP jumper is
connected to VCC.
Connects the DE2 pin of the ADN4680E to GND, which disables the A2 and B2 transmitter, placing it in a high
impedance state.
Disconnects the DE2 pin from VCC or GND, which allows the DE2 pin to be controlled from the DE2 connection on
the P3 screw terminal block.
Connects the DE3 pin of the ADN4680E to VCC, which enables the A3 and B3 transmitter if the ENP jumper is
connected to VCC.
Connects the DE3 pin of the ADN4680E to GND, which disables the A3 and B3 transmitter, placing it in a high
impedance state.
Disconnects the DE3 pin from VCC or GND, which allows the DE3 pin to be controlled from the DE3 connection on
the P5 screw terminal block.
Connects the DE4 pin of the ADN4680E to VCC, which enables the A4 and B4 transmitter if the ENP jumper is
connected to VCC.
Connects the DE4 pin of the ADN4680E to GND, which disables the A4 and B4 transmitter, placing it in a high
impedance state.
Disconnects the DE4 pin from VCC or GND, which allows the DE4 pin to be controlled from the DE4 connection on
the P5 screw terminal block.
EVAL-ADN4680E
Rev. 0 | 7 of 12
