Replacement Page; Mechanical Parts - Icom IC-7100 Service Manual Addendum

July 2015
SECTION 6.
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510028411 MR-DS-01-2
J2 6510028411 MR-DS-01-2
MF1 2710000790 AFB0512HB-4L50 <USE>HK
W1** 8910000140 FFC-1015 (P0.5N30L80)
W2** 8910000140 FFC-1015 (P0.5N30L80)
W3** 8900016990 OPC-1741 (1.5DCOAXIAL110MM)
W5** 8900019320 OPC-2034
W6** 8600037380 SX3183 J1101*P1102CH
MP1 8010022550 3393 CHASSIS
MP2 8110010360 3393 U-COVER Y2168
MP3 8110010370 3393 L-COVER Y2167
MP4 8210028270 3393 CHASSIS PANEL
MP5 8930086820 3393 FAN HOLDER <KN>
MP6 8310081740 3393 NAME PLATE
MP11 8930087840 3393 ANT PLATE Y1291
MP12 8930066431 2427 A-NET-1
MP13 8930079690 RUBBER STAND (Q)
MP14 8810008661 PHBT M3 X 8 NI-ZC3
MP15 8810008661 PHBT M3 X 8 NI-ZC3
MP16 8810008661 PHBT M3 X 8 NI-ZC3
MP17 8810009061 FLAT M3 X 6 ZK3
MP18 8810009061 FLAT M3 X 6 ZK3
MP19 8820000530 FLANGE BOLT M4 X 8 NI
MP20 8850000140 FLAT WASHER M 4 NI BS
MP22 8810008661 PHBT M3 X 8 NI-ZC3
MP23 8810010780 PH BT M3 X20 NI-ZK3
MP24 8810003171 SET SCREWA M3 X 8 ZC3
MP25* 8810003171 SET SCREWA M3 X 8 ZC3
MP26 8810003381 SET SCREWC M3 X10 ZC3
MP27* 8810003361 SET SCREWC M3 X 6 ZC3
MP28 8930068370 2427 A-MAGNETIC SHIELD
MP30* 8930078840 SHIELD SPONGE (CM)
MP31* 8930082341 SHIELD SPONGE (CR)-1
MP32* 8930082341 SHIELD SPONGE (CR)-1
MP33* 8930082341 SHIELD SPONGE (CR)-1
MP34* 8930082341 SHIELD SPONGE (CR)-1
MP35 6910008240 59TN4772 (SPCC)
MP36* 8930082341 SHIELD SPONGE (CR)-1
MP37* 8930088280 FERRITE SHEET (AL)
MP38 8930088330 FERRITE SHEET (AM)
MP39* 8930088000 SPONGE (MH)
MP40 8930063000 THERMAL SHEET (AQ) TC-700HS-1.4
MP41 8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
MP42 8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
8930064840 SHIELD SPONGE (AO)
MP43 8930048971 SHIELD TAPE (C)-1
8930048971 SHIELD TAPE (C)-1
8930048971 SHIELD TAPE (C)-1
8930048971 SHIELD TAPE (C)-1
8930048971 SHIELD TAPE (C)-1
8930074740 SHIELD SPONGE (CE)
MP44* 8930068000 SHIELD SPONGE (AT)
8930068000 SHIELD SPONGE (AT)
8930068000 SHIELD SPONGE (AT)
8930068000 SHIELD SPONGE (AT)
8930068000 SHIELD SPONGE (AT)
8930068000 SHIELD SPONGE (AT)
MP45 8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
MP46 8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
8930057790 SHIELD SPONGE (K)
MP47* 8930082341 SHIELD SPONGE (CR)-1
MP48* 8930068000 SHIELD SPONGE (AT)
MP49* 8930057870 2429 EARTH SPRING
MP50** 8930018700 THERMAL SHEET Z
MP51** 8930018700 THERMAL SHEET Z
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

(Replacement page)

MECHANICAL PARTS

DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
4
11
12
4
9
9
1
1
2
4
1
4
2
2
1
1
1
1
1
1
1
1
1
1
1
1
[USA] 1
[EUR] 1
[EUR-01] 1
[ITR] 1
[ESP] 1
[FRA] 1
[USA] 1
[EUR] 1
[EUR-01] 1
[ITR] 1
[ESP] 1
[FRA] 1
[USA] 1
[EUR] 1
[EUR-01] 1
[ITR] 1
[ESP] 1
[FRA] 1
[USA] 1
[EUR] 1
[EUR-01] 1
[ITR] 1
[ESP] 1
[FRA] 1
[EUR] 1
[EUR-01] 1
[ITR] 1
[ESP] 1
[FRA] 1
[EUR] 1
[EUR-01] 1
[ITR] 1
[ESP] 1
[FRA] 1
Only [USA] 1
Only [USA] 1
Only [USA] 1
Only [USA] 1
Only [USA] 1
[MAIN UNIT]
REF ORDER
NO. NO.
J1* 6510023720 LGY6501-0600C
J11* 6510027740 HSJ2462-010010
J31* 6450001641 TCS5044-0141177
J111* 6450001841 TCS7568-4320177
J151* 6510029830 3008S-8824 (50U) <KIN>
J171* 6510023110 3008L-8P8C <KIN>
J191* 6510023720 LGY6501-0600C
J261* 6510028980 SCDABA0500
J301* 6510024880 52689-3087
J401* 6510024880 52689-3087
J501* 6510028200 UB-M5BR-S14-4S (LF) (SN)
J571* 6510023720 LGY6501-0600C
J3001* 6510018450 TMP-S01X-B1
J5002* 6510025840 AXN316C038P
J5501* 6510027111 08FLT-SM2-TB (LF) (SN) (M)
J6501* 6510024522 12FLT-SM2-TB (LF) (SN) (M)
J6502* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
BT6201* 3020000390 ML414HIV01E
EP2004* 6910002161 CASE-BM7H-LF
EP2206* 6910002161 CASE-BM7H-LF
EP2211* 6910002161 CASE-BM7H-LF
EP2404* 6910002161 CASE-BM7H-LF
EP2756* 6910002161 CASE-BM7H-LF
MP221* 8510020800 3393 C-SHIELD PLATE Y1292
MP401* 8930071160 2427 F-EARTH SPRING Y896
MP501* 8930071160 2427 F-EARTH SPRING Y896
8930071160 2427 F-EARTH SPRING Y896
8930071160 2427 F-EARTH SPRING Y896
8930071160 2427 F-EARTH SPRING Y896
8930071160 2427 F-EARTH SPRING Y896
MP1001* 8510020100 3182 DC-DC CASE Y1220
MP2101* 8510020790 3393 B-SHIELD PLATE <KN>
MP2102* 8510020800 3393 C-SHIELD PLATE Y1292
MP2201* 8510020800 3393 C-SHIELD PLATE Y1292
MP2202* 8510020790 3393 B-SHIELD PLATE <KN>
MP2301* 8510020830 3393 D-SHIELD PLATE Y1295
MP2501* 8510020780 3393 A-SHIELD PLATE <KN>
MP3031* 8510020800 3393 C-SHIELD PLATE Y1292
MP3231* 8510020770 3393 A-SHIELD CASE <KN>
MP3232* 8510020840 3393 E-SHIELD PLATE Y1296
MP4001* 8510020800 3393 C-SHIELD PLATE Y1292
MP4002* 8930071160 2427 F-EARTH SPRING Y896
MP4302* 8510012400 2177 D/A CASE Y454
MP5051* 8510020800 3393 C-SHIELD PLATE Y1292
6-1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
[EUR] 1
[EUR-01] 1
[ITR] 1
[ESP] 1
[FRA] 1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
