Icom IC-7100 Service Manual Addendum page 242

4-11 RECEIVE ADJUSTMENTS (UHF BAND)
1) Set or modify the adjustment value as specifi ed by rotating [MAIN DIAL].
2) Push [SET] to store the value.
ADJUSTMENT ITEM
PREPARATION 1 • Frequency: 400.2015 MHz
TUNED BPF 2 • Display: "Tuned BPF UHF1-L"
3 • Display: "Tuned BPF2 UHF-M"
4 • Display: "Tuned BPF UHF-H"
RX TOTAL GAIN 5 • Display: "Total Gain UHF"
S-METER NOTE: DO NOT change the SSG output level until the beep sounds.
6 • Display: "S9 Level UHF"
7 • Display: "S9+60 Level UHF"
Automatically returns to the receive adjustment menu.
4-12 RECEIVE ADJUSTMENTS (In the WFM mode)
1) Set or modify the adjustment value as specifi ed by rotating [MAIN DIAL].
2) Push [SET] to store the value.
ADJUSTMENT ITEM
PREPARATION 1 • Frequency: 90.200 MHz
S-METER NOTE: DO NOT change the SSG output level until the beep sounds.
2 • Display: "S0 Level WFM"
3 • Display: "S9 Level WFM"
4 • Display: "S9+60 Level WFM"
Automatically returns to the receive adjustment menu.
Push [MIC/RF PWR] to return to the main adjustment menu.
TRANSCEIVER'S CONDITION
• Receive
• Receive
• Receive
• Receive
• Receive
• Receive
• Receive
TRANSCEIVER'S CONDITION
• Receive
• Receive
• Receive
• Receive
OPERATION
1) Connect the SSG to [ANT2], and
then set it as;
Frequency : 400.2015 MHz
Level : +10 dBµ (–97 dBm)
Modulation: None
2) Connect the millivoltmeter and a
speaker to [EXT-SP].
–
• Set the SSG as;
Frequency : 435.0215 MHz
• Set the SSG as;
Frequency : 469.8015 MHz
Level :+20 dBµ (–87 dBm)
Modulation: None
• Set the SSG as;
Frequency : 435.0215 MHz
Level :+10 dBµ (–97 dBm)
Modulation: None
• Set the SSG as;
Level : +10 dBµ (–97 dBm)
• Set the SSG as;
Level : +70 dBµ (–37 dBm)
OPERATION
1) Connect the SSG to [ANT2], and
then set it as;
Frequency : 90.200 MHz
Level : –5 dBµ (–112 dBm)
Modulation: None
2) Connect the millivoltmeter and a
speaker to [EXT-SP].
–
• Set the SSG as;
Level : +10 dBµ (–97 dBm)
• Set the SSG as;
Level : +50 dBµ (–57 dBm)
4-11
ADJUST
VALUE
POINT
Push [NR].
Push [SET].
(A beep sounds, and
then another beeps
–
sound 3 sec. later)
Push [SET].
(A beep sounds, and
then another beeps
sound 10 sec. later)
Push [SET].
(A beep sounds, and
–
then another beeps
sound 1 sec. later)
ADJUST
VALUE
POINT
Push [NOTCH].
–
Push [SET].
(A beep sounds, and
then another beeps
–
sound 1 sec. later)
