Icom IC-7100 Service Manual Addendum page 63

February 2017
[PA UNIT]
REF PART
NO. NO.
C181 4030006900 S.CER C1608 JB 1H 103K-T
C182 4030019120 S.CER GRM188B31E105KA75D
C201 4030011600 S.CER C1608 JB 1E 104K-T
C202 4030006860 S.CER C1608 JB 1H 102K-T
C204 4030011600 S.CER C1608 JB 1E 104K-T
C205 4030006860 S.CER C1608 JB 1H 102K-T
C206 4030006860 S.CER C1608 JB 1H 102K-T
C207 4030006860 S.CER C1608 JB 1H 102K-T
C208 4030011600 S.CER C1608 JB 1E 104K-T
C209 4030007170 S.CER C1608 CH 1H 221J-T
C214 4030021020 S.CER GRM31A5C2J101JW01D
C216 4030018350 S.CER GRM31A5C2J151JW01D
C218 4030020820 S.CER GRM31A5C2J121JW01D
C252 4030018640 S.CER C2012 CH 1H 103J-T
C254 4030020750 S.CER GRM31A5C2J220JW01D
C262 4030021200 S.CER GRM31A5C2J120JW01D
C265 4030020770 S.CER GRM31A5C2J330JW01D
C266 4030020820 S.CER GRM31A5C2J121JW01D
C267 4030020770 S.CER GRM31A5C2J330JW01D
C291 4030011600 S.CER C1608 JB 1E 104K-T
C301 4030001100 S.CER GRM216B11H102KA01D
C302 4030001020 S.CER GRM2162C1H121JA01D
C303 4030011600 S.CER C1608 JB 1E 104K-T
C304 4030017320 S.CER GRM21BB11H104KA01L
C305 4510010300 S.ELE 16 CE 470 AX
C309 4030011600 S.CER C1608 JB 1E 104K-T
C311 4030018750 S.CER C3225 CH 2J 682K-T
C312 4030018750 S.CER C3225 CH 2J 682K-T
C313 4030011600 S.CER C1608 JB 1E 104K-T
C314 4030018750 S.CER C3225 CH 2J 682K-T
C315 4030018750 S.CER C3225 CH 2J 682K-T
C319 4030021020 S.CER GRM31A5C2J101JW01D
C320 4030021020 S.CER GRM31A5C2J101JW01D
C323 4030003790 S.MIC UC342H 2200F-T
C324 4320001050 S.MIC UC342H 3900J-T
C325 4030003810 S.MIC UC342H 1200J-T
C327 4030018790 S.CER C3225 JB 2E 104K-T
C331 4030011600 S.CER C1608 JB 1E 104K-T
C332 4030011600 S.CER C1608 JB 1E 104K-T
C333 4030018340 S.CER GRM31A5C2J331JW01D
C351 4030006850 S.CER C1608 JB 1H 471K-T
C362 4030011600 S.CER C1608 JB 1E 104K-T
C371 4030017320 S.CER GRM21BB11H104KA01L
C372 4030006860 S.CER C1608 JB 1H 102K-T
C373 4510010300 S.ELE 16 CE 470 AX
C374 4510010450 S.ELE EEEFT1C102AP
C375 4030011600 S.CER C1608 JB 1E 104K-T
C376 4030006900 S.CER C1608 JB 1H 103K-T
C377 4030006860 S.CER C1608 JB 1H 102K-T
C378 4510010300 S.ELE 16 CE 470 AX
C379 4510010450 S.ELE EEEFT1C102AP
4510010450 S.ELE EEEFT1C102AP
4510010450 S.ELE EEEFT1C102AP
4510010450 S.ELE EEEFT1C102AP
4510010450 S.ELE EEEFT1C102AP
C381 4030006860 S.CER C1608 JB 1H 102K-T
C382 4030006900 S.CER C1608 JB 1H 103K-T
C383 4030006900 S.CER C1608 JB 1H 103K-T
C391 4030011600 S.CER C1608 JB 1E 104K-T
C392 4030019560 S.CER GRM21BB31C106KE15L
C411 4030021280 S.CER GQM22M5C2H180JB01L
C412 4030021350 S.CER GQM22M5C2H270JB01L
C413 4030021430 S.CER GQM22M5C2H4R0CB01L
C420 4030004810 S.CER C2012 CH 1H 040C-T
C421 4030006860 S.CER C1608 JB 1H 102K-T
C422 4030011090 S.CER GRM31M2C2H7R0DV01L
C423 4030004840 S.CER C2012 CH 1H 070D-T
C424 4030020730 S.CER GRM31A5C2J471JW01D
C425 4030004710 S.CER C2012 JB 1H 471K-T
C428 4030006860 S.CER C1608 JB 1H 102K-T
C429 4030006850 S.CER C1608 JB 1H 471K-T
C430 4030006850 S.CER C1608 JB 1H 471K-T
C431 4030020730 S.CER GRM31A5C2J471JW01D
C432 4030021210 S.CER GRM31A5C2J150JW01D
C433 4030021230 S.CER GRM31B5C2J102JW01L
C434 4030006860 S.CER C1608 JB 1H 102K-T
C435 4030006860 S.CER C1608 JB 1H 102K-T
C436 4030011040 S.CER GRM31M4C2H2R0CY21L
C437 4030021200 S.CER GRM31A5C2J120JW01D
C438 4030006860 S.CER C1608 JB 1H 102K-T
C439 4030006860 S.CER C1608 JB 1H 102K-T
C440 4030020730 S.CER GRM31A5C2J471JW01D
C441 4030020730 S.CER GRM31A5C2J471JW01D
C442 4030011080 S.CER GRM31M2C2H6R0DV01L
C443 4030011100 S.CER GRM31M2C2H8R0DV01L
C444 4030021310 S.CER GQM22M5C2H680JB01L
C448 4030011130 S.CER GRM31M2C2H110JV01L
C449 4030006860 S.CER C1608 JB 1H 102K-T
C452 4030007020 S.CER C1608 CH 1H 120J-T
C453 4030006860 S.CER C1608 JB 1H 102K-T
C454 4030007020 S.CER C1608 CH 1H 120J-T
C456 4030009910 S.CER C1608 CH 1H 040B-T
C457 4030006860 S.CER C1608 JB 1H 102K-T
C458 4030006860 S.CER C1608 JB 1H 102K-T
C459 4030006860 S.CER C1608 JB 1H 102K-T
C461 4030011600 S.CER C1608 JB 1E 104K-T
C462 4030011600 S.CER C1608 JB 1E 104K-T
C463 4030006860 S.CER C1608 JB 1H 102K-T
C464 4030011600 S.CER C1608 JB 1E 104K-T
C465 4030011600 S.CER C1608 JB 1E 104K-T
C466 4030006860 S.CER C1608 JB 1H 102K-T
C467 4030006860 S.CER C1608 JB 1H 102K-T
C468 4030007000 S.CER C1608 CH 1H 090D-T
C469 4030006860 S.CER C1608 JB 1H 102K-T
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B 30.3/33.4
B 30.7/27.9
T 61.6/10.0
T 61.6/11.2
B 59.5/21.5
B 59.5/35.0
B 59.5/26.8
B 59.5/19.8
B 59.5/28.5
B 59.5/18.0
T 89.3/44.4
T 85.2/38.2
T 98.3/50.7
B 65.7/13.7
T 75.4/13.3
T 76.0/32.4
B 81.3/14.1
T 77.7/17.9
B 81.4/25.9
T 47.2/31.9
B 112.1/67.3
B 112.1/65.3
B 113.4/51.6
B 112.1/63.2
T 120.4/53.8
B 99.4/52.9
T 89.6/65.2
T 89.6/76.9
B 99.4/89.1
T 89.1/61.3
T 89.1/80.7
T 52.2/51.7
T 52.2/82.8
T 50.8/66.0
B 47.3/66.0
B 51.5/66.0
T 57.7/94.9
B 99.3/55.9
B 99.3/86.1
B 113.5/71.0
B 88.5/35.1
T 29.1/83.6
B 26.8/77.0
B 26.9/75.0
T 34.1/38.4
T 14.2/24.1
T 34.4/98.2
T 33.1/98.2
T 31.8/98.2
T 43.2/109.6
[EUR] T 51.1/102.2
[EUR-1]
[ITR]
[ESP]
[FRA]
T 23.2/30.8
T 23.2/32.3
T 23.2/33.8
B 18.8/20.9
B 14.7/15.0
T 106.6/12.6
T 110.8/10.5
T 151.2/18.4
T 139.6/95.5
B 137.4/65.8
T 146.9/85.0
T 142.2/86.9
B 137.5/85.2
B 135.6/91.6
T 136.1/99.4
T 138.7/86.2
T 135.3/90.9
T 149.7/72.0
T 143.8/57.7
T 136.4/44.6
T 140.3/69.7
T 140.3/73.3
T 143.8/49.2
T 143.9/108.4
T 143.1/106.0
T 136.9/106.4
T 149.6/95.3
T 144.4/120.3
T 144.4/125.8
T 141.7/130.9
T 151.4/130.3
T 140.7/115.4
B 137.5/108.3
T 123.5/102.7
B 123.0/103.6
T 116.1/106.6
T 118.0/102.7
B 116.9/100.0
T 114.6/103.5
B 119.7/110.3
B 111.7/108.7
T 115.0/109.2
T 113.8/109.2
T 113.0/103.5
T 111.4/109.2
T 111.8/103.5
T 112.6/109.2
T 110.2/106.6
B 104.5/101.4
(Amended page)
[PA UNIT]
H/V REF PART
NO. NO.
C470 4030011600 S.CER C1608 JB 1E 104K-T
C471 4030006860 S.CER C1608 JB 1H 102K-T
C472 4030009500 S.CER C1608 CH 1H 0R5B-T
C473 4030007000 S.CER C1608 CH 1H 090D-T
C474 4030009530 S.CER C1608 CH 1H 030B-T
C477 4030006860 S.CER C1608 JB 1H 102K-T
C480 4030007090 S.CER C1608 CH 1H 470J-T
C482 4030006860 S.CER C1608 JB 1H 102K-T
C484 4030006860 S.CER C1608 JB 1H 102K-T
C491 4030011600 S.CER C1608 JB 1E 104K-T
C501 4030006900 S.CER C1608 JB 1H 103K-T
C503 4030006900 S.CER C1608 JB 1H 103K-T
C504 4030021230 S.CER GRM31B5C2J102JW01L
C509 4030021270 S.CER GQM22M5C2H120JB01L
C510 4030021270 S.CER GQM22M5C2H120JB01L
C511 4030021300 S.CER GQM22M5C2H330JB01L
C512 4030021300 S.CER GQM22M5C2H330JB01L
C513 4030021440 S.CER GQM22M5C2H470JB01L
C514 4030021310 S.CER GQM22M5C2H680JB01L
C516 4030021230 S.CER GRM31B5C2J102JW01L
C521 4030021230 S.CER GRM31B5C2J102JW01L
C522 4030021230 S.CER GRM31B5C2J102JW01L
C523 4030021230 S.CER GRM31B5C2J102JW01L
C524 4030021230 S.CER GRM31B5C2J102JW01L
C525 4030006900 S.CER C1608 JB 1H 103K-T
C531 4030006900 S.CER C1608 JB 1H 103K-T
C532 4030006900 S.CER C1608 JB 1H 103K-T
C533 4030007090 S.CER C1608 CH 1H 470J-T
C534 4030006850 S.CER C1608 JB 1H 471K-T
C535 4030006860 S.CER C1608 JB 1H 102K-T
C536 4030006900 S.CER C1608 JB 1H 103K-T
C541 4030020770 S.CER GRM31A5C2J330JW01D
C542 4030011090 S.CER GRM31M2C2H7R0DV01L
C543 4030020760 S.CER GRM31A5C2J270JW01D
C544 4030011040 S.CER GRM31M4C2H2R0CY21L
C545 4030020760 S.CER GRM31A5C2J270JW01D
C546 4030011080 S.CER GRM31M2C2H6R0DV01L
C547 4030021200 S.CER GRM31A5C2J120JW01D
C551 4030006860 S.CER C1608 JB 1H 102K-T
C552 4030006860 S.CER C1608 JB 1H 102K-T
C553 4030006850 S.CER C1608 JB 1H 471K-T
C554 4030006860 S.CER C1608 JB 1H 102K-T
C555 4030006860 S.CER C1608 JB 1H 102K-T
C556 4030011600 S.CER C1608 JB 1E 104K-T
C557 4030006860 S.CER C1608 JB 1H 102K-T
C558 4030006860 S.CER C1608 JB 1H 102K-T
C559 4030006860 S.CER C1608 JB 1H 102K-T
C560 4030006860 S.CER C1608 JB 1H 102K-T
C561 4030006850 S.CER C1608 JB 1H 471K-T
C562 4030006860 S.CER C1608 JB 1H 102K-T
C563 4030006860 S.CER C1608 JB 1H 102K-T
C565 4030006860 S.CER C1608 JB 1H 102K-T
C567 4030006860 S.CER C1608 JB 1H 102K-T
C591 4030011060 S.CER GRM31M2C2H4R0CY21L
C592 4030011080 S.CER GRM31M2C2H6R0DV01L
C647 4030018480 S.CER GRM31A5C2J221JW01D
C651 4030011600 S.CER C1608 JB 1E 104K-T
C653 4030006860 S.CER C1608 JB 1H 102K-T
C654 4030006860 S.CER C1608 JB 1H 102K-T
C656 4030006860 S.CER C1608 JB 1H 102K-T
C663 4030006860 S.CER C1608 JB 1H 102K-T
C664 4030006860 S.CER C1608 JB 1H 102K-T
C665 4030006860 S.CER C1608 JB 1H 102K-T
C666 4030006860 S.CER C1608 JB 1H 102K-T
C701 4030007130 S.CER C1608 CH 1H 101J-T
C702 4030011600 S.CER C1608 JB 1E 104K-T
C703 4030011600 S.CER C1608 JB 1E 104K-T
C704 4030011600 S.CER C1608 JB 1E 104K-T
C705 4030011600 S.CER C1608 JB 1E 104K-T
C706 4030006900 S.CER C1608 JB 1H 103K-T
C707 4030011600 S.CER C1608 JB 1E 104K-T
C708 4030006900 S.CER C1608 JB 1H 103K-T
C709 4030006900 S.CER C1608 JB 1H 103K-T
C710 4030007130 S.CER C1608 CH 1H 101J-T
C711 4030011600 S.CER C1608 JB 1E 104K-T
C712 4030011600 S.CER C1608 JB 1E 104K-T
C713 4030011600 S.CER C1608 JB 1E 104K-T
C714 4030011600 S.CER C1608 JB 1E 104K-T
C715 4030011600 S.CER C1608 JB 1E 104K-T
C716 4030011600 S.CER C1608 JB 1E 104K-T
C717 4030006860 S.CER C1608 JB 1H 102K-T
C718 4030006860 S.CER C1608 JB 1H 102K-T
C721 4030006900 S.CER C1608 JB 1H 103K-T
C722 4030006900 S.CER C1608 JB 1H 103K-T
C723 4030011600 S.CER C1608 JB 1E 104K-T
C724 4030011600 S.CER C1608 JB 1E 104K-T
C725 4030006860 S.CER C1608 JB 1H 102K-T
C727 4030011600 S.CER C1608 JB 1E 104K-T
C728 4030011600 S.CER C1608 JB 1E 104K-T
C729 4030011600 S.CER C1608 JB 1E 104K-T
C731 4030006860 S.CER C1608 JB 1H 102K-T
C732 4030006860 S.CER C1608 JB 1H 102K-T
C741 4030006860 S.CER C1608 JB 1H 102K-T
C742 4030006860 S.CER C1608 JB 1H 102K-T
C743 4030006860 S.CER C1608 JB 1H 102K-T
C750 4030011600 S.CER C1608 JB 1E 104K-T
C751 4030007090 S.CER C1608 CH 1H 470J-T
C752 4030006860 S.CER C1608 JB 1H 102K-T
C753 4030007090 S.CER C1608 CH 1H 470J-T
C754 4030007090 S.CER C1608 CH 1H 470J-T
C755 4030011600 S.CER C1608 JB 1E 104K-T
C756 4030011600 S.CER C1608 JB 1E 104K-T
C766 4030006860 S.CER C1608 JB 1H 102K-T
C771 4030006900 S.CER C1608 JB 1H 103K-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
17
DESCRIPTION M.
LOCATION
T 107.5/103.5
T 108.9/103.5
T 104.6/107.4
T 103.1/103.9
T 101.8/107.4
B 105.9/108.9
B 87.7/108.2
T 90.8/104.6
T 90.8/107.2
T 57.7/32.3
T
T
T
B 102.1/25.9
B 102.1/14.1
B 98.8/25.9
B 98.8/14.1
T 117.8/35.1
T 117.8/31.8
T 129.3/53.6
T 100.5/37.8
B 98.9/36.1
T 100.5/39.9
B 98.9/33.5
T 111.2/53.7
T 121.1/80.5
B 125.6/73.5
T 121.3/66.7
T 121.3/65.5
T 121.3/64.3
T 121.0/74.2
T 131.4/109.2
T 133.7/113.6
T 126.3/119.1
T 135.1/126.4
T 128.1/128.2
T 128.0/111.3
T 126.3/121.2
T 124.1/88.1
T 120.1/92.0
T 116.1/90.4
T 114.0/93.8
T 116.3/98.0
T 110.3/96.0
T 108.3/90.5
T 107.1/90.5
T 104.5/95.4
B 102.5/98.1
T 103.2/91.0
T 99.3/93.5
B 108.9/90.1
B 99.0/94.8
B 120.5/91.3
T 145.4/146.9
T 143.1/151.2
B 24.1/145.1
T 128.8/148.5
T 145.3/164.0
T 148.3/160.6
B 126.6/151.1
T 134.8/165.8
T 131.7/169.2
B 132.2/153.8
B 128.9/157.4
T
T 13.7/52.0
T
T 15.9/68.6
T 15.9/72.2
B 11.2/69.5
T
T
T
T
T 20.4/80.3
T 20.4/81.5
T 20.5/82.7
T 20.5/83.9
T 20.5/85.1
T 20.5/86.3
T 20.5/87.5
T 20.5/88.7
B
T
T
T
T
T
T
T
B 16.2/89.6
B 17.0/91.2
T 38.6/177.0
T 38.6/174.6
T 38.6/171.6
T
B
B 16.3/92.9
B 10.4/90.9
B 10.4/94.1
T
T 14.5/146.6
T
T 63.8/109.6
H/V
79.5/5.7
73.3/5.7
79.8/9.3
9.7/54.8
7.4/66.8
5.6/68.7
6.0/70.7
5.9/72.7
7.4/68.3
9.3/80.3
6.6/80.3
6.6/81.5
6.6/82.7
6.6/86.3
6.6/88.7
6.6/85.1
6.6/83.9
8.7/111.3
9.6/97.5
7.4/90.7
6.6/87.5
