Icom IC-7100 Service Manual Addendum page 13

November 2018
[MAIN UNIT]
REF PART
NO. NO.
R2111 7030016050 S.RES RMC1/16S-102JTH (1 k)
R2112 7030015930 S.RES RMC1/16S-471JTH (470)
R2151 7030016590 S.RES RMC1/16S-120JTH (12)
R2152 7030015910 S.RES RMC1/16S-101JTH (100)
R2153 7030016590 S.RES RMC1/16S-120JTH (12)
R2154 7030015970 S.RES RMC1/16S-103JTH (10 k)
R2155 7030016150 S.RES RMC1/16S-100JTH (10)
R2156 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R2157 7030016280 S.RES RMC1/16S-331JTH (330)
R2158 7030015910 S.RES RMC1/16S-101JTH (100)
R2159 7030015910 S.RES RMC1/16S-101JTH (100)
R2160 7030016050 S.RES RMC1/16S-102JTH (1 k)
R2161 7030015930 S.RES RMC1/16S-471JTH (470)
R2162 7030015930 S.RES RMC1/16S-471JTH (470)
R2163 7030015900 S.RES RMC1/16S-470JTH (47)
R2164 7030016150 S.RES RMC1/16S-100JTH (10)
R2165 7030015930 S.RES RMC1/16S-471JTH (470)
R2166 7030015930 S.RES RMC1/16S-471JTH (470)
R2201 7030016050 S.RES RMC1/16S-102JTH (1 k)
R2203 7030015900 S.RES RMC1/16S-470JTH (47)
R2205 7030015920 S.RES RMC1/16S-221JTH (220)
R2207 7030016210 S.RES RMC1/16S-121JTH (120)
R2208 7030016210 S.RES RMC1/16S-121JTH (120)
R2212 7030016560 S.RES RMC1/16SJPTH
R2214 7030015920 S.RES RMC1/16S-221JTH (220)
R2215 7030015920 S.RES RMC1/16S-221JTH (220)
R2216 7030015920 S.RES RMC1/16S-221JTH (220)
R2219 7030016430 S.RES RMC1/16S-392JTH (3.9 k)
R2221 7030015920 S.RES RMC1/16S-221JTH (220)
R2223 7030016050 S.RES RMC1/16S-102JTH (1 k)
R2224 7030016130 S.RES RMC1/16S-150JTH (15)
R2225 7030016560 S.RES RMC1/16SJPTH
R2228 7030016050 S.RES RMC1/16S-102JTH (1 k)
R2251 7030016370 S.RES RMC1/16S-271JTH (270)
R2252 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2261 7030015920 S.RES RMC1/16S-221JTH (220)
R2262 7030016270 S.RES RMC1/16S-151JTH (150)
R2263 7030016470 S.RES RMC1/16S-390JTH (39)
R2264 7030016270 S.RES RMC1/16S-151JTH (150)
R2265 7030015920 S.RES RMC1/16S-221JTH (220)
R2266 7030016370 S.RES RMC1/16S-271JTH (270)
R2267 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2301 7030015920 S.RES RMC1/16S-221JTH (220)
R2302 7030016410 S.RES RMC1/16S-561JTH (560)
R2303 7030016410 S.RES RMC1/16S-561JTH (560)
R2304 7030015920 S.RES RMC1/16S-221JTH (220)
R2305 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2321 7030016410 S.RES RMC1/16S-561JTH (560)
R2322 7030016410 S.RES RMC1/16S-561JTH (560)
R2323 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2324 7030016470 S.RES RMC1/16S-390JTH (39)
R2325 7030016270 S.RES RMC1/16S-151JTH (150)
R2326 7030016270 S.RES RMC1/16S-151JTH (150)
R2351 7030016150 S.RES RMC1/16S-100JTH (10)
R2401 7030016480 S.RES RMC1/16S-821JTH (820)
R2402 7030016410 S.RES RMC1/16S-561JTH (560)
R2403 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2404 7030016150 S.RES RMC1/16S-100JTH (10)
R2405 7030016160 S.RES RMC1/16S-820JTH (82)
R2407 7030016560 S.RES RMC1/16SJPTH
R2410 7030015920 S.RES RMC1/16S-221JTH (220)
R2411 7030016410 S.RES RMC1/16S-561JTH (560)
R2413 7030016480 S.RES RMC1/16S-821JTH (820)
R2414 7030016470 S.RES RMC1/16S-390JTH (39)
R2415 7030016270 S.RES RMC1/16S-151JTH (150)
R2416 7030016270 S.RES RMC1/16S-151JTH (150)
R2419 7030015900 S.RES RMC1/16S-470JTH (47)
R2501 7030016410 S.RES RMC1/16S-561JTH (560)
R2502 7030016210 S.RES RMC1/16S-121JTH (120)
R2503 7030016160 S.RES RMC1/16S-820JTH (82)
R2504 7030016160 S.RES RMC1/16S-820JTH (82)
R2505 7030016410 S.RES RMC1/16S-561JTH (560)
R2506 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2551 7030016410 S.RES RMC1/16S-561JTH (560)
R2552 7030016410 S.RES RMC1/16S-561JTH (560)
R2553 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2555 7030016560 S.RES RMC1/16SJPTH
R2601 7030016410 S.RES RMC1/16S-561JTH (560)
R2602 7030016410 S.RES RMC1/16S-561JTH (560)
R2603 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2604 7030016460 S.RES RMC1/16S-181JTH (180)
R2605 7030016260 S.RES RMC1/16S-330JTH (33)
R2606 7030016460 S.RES RMC1/16S-181JTH (180)
R2651 7030016410 S.RES RMC1/16S-561JTH (560)
R2652 7030016260 S.RES RMC1/16S-330JTH (33)
R2653 7030016460 S.RES RMC1/16S-181JTH (180)
R2654 7030016460 S.RES RMC1/16S-181JTH (180)
R2655 7030016410 S.RES RMC1/16S-561JTH (560)
R2656 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2701 7030016410 S.RES RMC1/16S-561JTH (560)
R2702 7030016470 S.RES RMC1/16S-390JTH (39)
R2703 7030016270 S.RES RMC1/16S-151JTH (150)
R2704 7030016270 S.RES RMC1/16S-151JTH (150)
R2705 7030016410 S.RES RMC1/16S-561JTH (560)
R2706 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2751 7030016480 S.RES RMC1/16S-821JTH (820)
R2752 7030016410 S.RES RMC1/16S-561JTH (560)
R2753 7030016410 S.RES RMC1/16S-561JTH (560)
R2754 7030016480 S.RES RMC1/16S-821JTH (820)
R2755 7030016020 S.RES RMC1/16S-104JTH (100 k)
R2771 7030016160 S.RES RMC1/16S-820JTH (82)
R2772 7030016160 S.RES RMC1/16S-820JTH (82)
R2773 7030016160 S.RES RMC1/16S-820JTH (82)
R2774 7030016370 S.RES RMC1/16S-271JTH (270)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B 74.4/130.1
B 72.6/126.9
T 88.1/126.4
T 89.3/126.6
T 89.3/125.7
B 92.1/120.8
B 92.6/122.0
B 92.1/124.1
B 96.2/122.4
B 90.8/122.8
B 84.7/122.6
B 85.2/121.4
B 86.9/122.8
B 85.6/120.2
B 88.8/122.8
B 82.0/120.3
B 82.6/121.7
B 80.8/120.6
B 67.4/117.5
B 71.6/119.7
B 64.4/114.3
B 77.5/110.5
B 76.6/111.0
B 96.1/113.5
B 64.4/110.5
B 64.4/109.6
B 64.4/108.7
B 76.9/108.2
B 66.7/106.6
B 97.1/105.2
B 98.0/109.9
B 94.9/99.2
B 98.8/104.0
B 88.2/107.0
B 88.2/106.1
B 85.5/109.1
B 86.1/114.8
B 86.9/115.7
B 88.2/115.4
B 92.0/111.4
B 89.1/114.5
B 90.0/114.5
B 96.1/97.5
T 94.5/94.3
T 94.5/89.2
B 94.9/85.2
T 94.9/91.4
T 91.1/96.9
T 91.1/88.1
T 91.6/89.3
T 95.1/84.7
T 96.3/85.1
T 96.3/84.2
T 91.7/82.8
B 87.9/77.9
B 88.0/82.1
B 77.4/82.7
T 75.3/84.0
B 85.6/77.1
B 84.3/78.4
B 86.8/76.7
B 79.0/82.7
B 79.3/79.3
T 78.1/81.9
T 78.5/80.6
T 77.6/80.6
B 79.9/89.0
T 65.5/90.2
B 56.0/90.8
B 56.5/89.5
B 55.6/89.5
T 55.8/90.2
T 63.4/89.7
T 67.0/85.3
T 55.9/85.3
T 64.9/84.9
B 55.6/86.3
T 66.9/80.8
T 56.0/80.8
T 64.8/80.3
B 57.5/80.1
B 56.2/81.3
B 55.7/80.1
T 66.5/76.8
B 56.1/76.9
B 56.5/75.5
B 55.6/75.5
T 55.7/76.8
T 64.0/76.3
T 65.7/73.1
B 56.1/71.9
B 56.6/70.7
B 55.7/70.7
T 55.5/73.1
T 64.0/72.7
B 70.0/87.4
B 73.5/78.4
T 55.8/68.2
B 52.4/91.2
T 57.9/67.7
B 75.5/67.2
B 74.3/66.7
B 75.5/66.3
B 66.7/65.9
(Amended page)
[MAIN UNIT]
H/V
REF PART
NO. NO.
R2775 7030016570 S.RES
R2776 7030016370 S.RES
R2801 7030016560 S.RES
R2803 7030016130 S.RES
R3001 7030019460 S.RES
R3011 7030016570 S.RES
R3012 7030016370 S.RES
R3013 7030016370 S.RES
R3014 7030015910 S.RES
R3015 7030015910 S.RES
R3016 7030016090 S.RES
R3017 7030016090 S.RES
R3018 7030016280 S.RES
R3021 7030015910 S.RES
R3022 7030016600 S.RES
R3023 7030016600 S.RES
R3024 7030016210 S.RES
R3025 7030016270 S.RES
R3031 7030016150 S.RES
R3032 7030016280 S.RES
R3033 7030015920 S.RES
R3034 7030016090 S.RES
R3035 7030016570 S.RES
R3036 7030016370 S.RES
R3037 7030016370 S.RES
R3051 7030016150 S.RES
R3052 7030016150 S.RES
R3053 7030016150 S.RES
R3054 7030016210 S.RES
R3055 7030016280 S.RES
R3056 7030016270 S.RES
R3057 7030016090 S.RES
R3071 7030015910 S.RES
R3073 7030016090 S.RES
R3074 7030015920 S.RES
R3075 7030015970 S.RES
R3076 7030015970 S.RES
R3077 7030016050 S.RES
R3081 7030019460 S.RES
R3082 7030016110 S.RES
R3083 7030016470 S.RES
R3084 7030016470 S.RES
R3085 7030016600 S.RES
R3086 7030019460 S.RES
R3087 7030016110 S.RES
R3091 7030015920 S.RES
R3092 7030016090 S.RES
R3093 7030015920 S.RES
R3111 7030016460 S.RES
R3112 7030016460 S.RES
R3113 7030016090 S.RES
R3121 7030016210 S.RES
R3122 7030016460 S.RES
R3123 7030016090 S.RES
R3131 7030016210 S.RES
R3132 7030016460 S.RES
R3133 7030016090 S.RES
R3141 7030016210 S.RES
R3142 7030016460 S.RES
R3143 7030016090 S.RES
R3151 7030016210 S.RES
R3152 7030016460 S.RES
R3153 7030016090 S.RES
R3161 7030016210 S.RES
R3162 7030016460 S.RES
R3163 7030016090 S.RES
R3171 7030016210 S.RES
R3172 7030016460 S.RES
R3173 7030016090 S.RES
R3181 7030016210 S.RES
R3182 7030016460 S.RES
R3183 7030016090 S.RES
R3191 7030016210 S.RES
R3192 7030016460 S.RES
R3193 7030016090 S.RES
R3201 7030019460 S.RES
R3202 7030019460 S.RES
R3203 7030016290 S.RES
R3204 7030016290 S.RES
R3205 7030016150 S.RES
R3206 7030016180 S.RES
R3207 7030015910 S.RES
R3208 7030016410 S.RES
R3209 7030016410 S.RES
R3210 7030016410 S.RES
R3211 7030016410 S.RES
R3212 7030015910 S.RES
R3213 7030016090 S.RES
R3214 7030016090 S.RES
R3215 7030019460 S.RES
R3216 7030019460 S.RES
R3231 7030016460 S.RES
R3232 7030015930 S.RES
R3233 7030015930 S.RES
R3234 7030016280 S.RES
R3235 7030016050 S.RES
R3236 7030015930 S.RES
R3237 7310004300 S.TRI
R3238 7030015970 S.RES
R3241 7030015920 S.RES
R3242 7030015930 S.RES
R3251 7030016460 S.RES
R3252 7030016090 S.RES
R3253 7030015920 S.RES
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
6
DESCRIPTION M.
RMC1/16S-180JTH (18) B
RMC1/16S-271JTH (270) B
RMC1/16SJPTH B
RMC1/16S-150JTH (15) B
RMC1/8-561JTP (560) T
RMC1/16S-180JTH (18) T
RMC1/16S-271JTH (270) T
RMC1/16S-271JTH (270) T
RMC1/16S-101JTH (100) T
RMC1/16S-101JTH (100) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-331JTH (330) T
RMC1/16S-101JTH (100) B
RMC1/16S-8R2JTH (8.2) B
RMC1/16S-8R2JTH (8.2) B
RMC1/16S-121JTH (120) B
RMC1/16S-151JTH (150) B
RMC1/16S-100JTH (10) B
RMC1/16S-331JTH (330) T
RMC1/16S-221JTH (220) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-180JTH (18) B
RMC1/16S-271JTH (270) B
RMC1/16S-271JTH (270) B
RMC1/16S-100JTH (10) T
RMC1/16S-100JTH (10) B
RMC1/16S-100JTH (10) B
RMC1/16S-121JTH (120) B
RMC1/16S-331JTH (330) B
RMC1/16S-151JTH (150) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-101JTH (100) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-221JTH (220) T
RMC1/16S-103JTH (10 k) T
RMC1/16S-103JTH (10 k) T
RMC1/16S-102JTH (1 k) T
RMC1/8-561JTP (560) B
RMC1/16S-473JTH (47 k) T
RMC1/16S-390JTH (39) B
RMC1/16S-390JTH (39) B
RMC1/16S-8R2JTH (8.2) B
RMC1/8-561JTP (560) T
RMC1/16S-473JTH (47 k) T
RMC1/16S-221JTH (220) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-221JTH (220) T
RMC1/16S-181JTH (180) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-121JTH (120) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/8-561JTP (560) T
RMC1/8-561JTP (560) T
RMC1/16S-222JTH (2.2 k) T
RMC1/16S-222JTH (2.2 k) B
RMC1/16S-100JTH (10) B
RMC1/16S-680JTH (68) T
RMC1/16S-101JTH (100) T
RMC1/16S-561JTH (560) T
RMC1/16S-561JTH (560) T
RMC1/16S-561JTH (560) B
RMC1/16S-561JTH (560) B
RMC1/16S-101JTH (100) B
RMC1/16S-223JTH (22 k) T
RMC1/16S-223JTH (22 k) T
RMC1/8-561JTP (560) T
RMC1/8-561JTP (560) T
RMC1/16S-181JTH (180) T
RMC1/16S-471JTH (470) T
RMC1/16S-471JTH (470) T
RMC1/16S-331JTH (330) T
RMC1/16S-102JTH (1 k) T
RMC1/16S-471JTH (470) B
EVM-3SSX50 B13 T
RMC1/16S-103JTH (10 k) T
RMC1/16S-221JTH (220) T
RMC1/16S-471JTH (470) T
RMC1/16S-181JTH (180) T
RMC1/16S-223JTH (22 k) T
RMC1/16S-221JTH (220) B
H/V
LOCATION
66.2/67.2
65.8/65.9
51.6/89.3
47.9/91.7
10.1/54.0
15.8/51.8
14.7/50.8
14.7/52.4
17.2/52.1
32.1/51.7
32.1/49.7
12.2/56.0
23.9/45.8
22.4/40.4
25.1/40.7
27.0/40.7
25.6/39.5
24.4/39.1
28.8/55.6
24.3/54.0
24.5/67.7
26.4/68.4
24.1/68.1
25.0/68.1
24.5/69.3
18.4/66.8
20.9/67.4
20.5/68.7
19.3/67.4
21.8/50.1
15.4/68.8
15.0/70.0
16.4/41.4
6.1/55.0
6.3/49.6
18.1/42.6
19.2/41.7
18.7/40.4
17.6/33.8
18.7/36.2
19.6/30.6
20.8/31.1
19.6/29.7
16.6/31.7
19.6/31.3
12.1/68.9
11.0/63.6
12.5/70.1
30.1/35.2
30.5/39.2
34.4/33.2
36.2/30.5
36.2/39.4
38.0/29.1
40.0/32.0
40.3/38.9
43.3/29.1
46.6/31.5
46.6/39.3
50.2/29.1
52.2/32.4
52.2/38.4
55.7/29.1
57.4/32.4
57.4/38.4
61.4/29.2
62.7/32.5
63.0/38.1
66.7/29.2
68.4/32.0
68.4/37.4
70.7/28.9
73.7/31.8
74.4/37.6
77.3/29.1
48.6/52.6
55.7/53.6
57.2/47.3
60.2/47.0
56.3/51.4
65.4/58.6
70.6/55.6
67.8/49.9
68.7/49.9
68.6/57.0
68.5/55.4
69.8/51.3
71.4/53.3
71.4/54.2
53.2/54.3
49.0/55.3
41.1/55.5
43.4/66.1
43.4/62.3
45.1/60.0
33.3/67.9
33.8/79.7
41.8/60.0
38.7/64.4
40.9/69.3
49.2/70.9
32.2/71.6
29.2/80.1
31.1/78.0
