Icom IC-7100 Service Manual Addendum page 12

November 2018
[MAIN UNIT]
REF PART
NO. NO.
R175 7030016150 S.RES RMC1/16S-100JTH (10)
R177 7030006070 S.RES ERJ12YJ101U (100)
R181 7030016270 S.RES RMC1/16S-151JTH (150)
R182 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R183 7030015970 S.RES RMC1/16S-103JTH (10 k)
R184 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R185 7030015980 S.RES RMC1/16S-333JTH (33 k)
R186 7030016330 S.RES RMC1/16S-153JTH (15 k)
R201 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R202 7030016300 S.RES RMC1/16S-332JTH (3.3 k)
R203 7030016280 S.RES RMC1/16S-331JTH (330)
R213 7030007160 S.RES ERJ12YJ3R3U (3.3)
R214 7030007160 S.RES ERJ12YJ3R3U (3.3)
R221 7030015970 S.RES RMC1/16S-103JTH (10 k)
R224 7030016050 S.RES RMC1/16S-102JTH (1 k)
R225 7030016380 S.RES RMC1/16S-183JTH (18 k)
R226 7030016110 S.RES RMC1/16S-473JTH (47 k)
R227 7030016330 S.RES RMC1/16S-153JTH (15 k)
R228 7030015970 S.RES RMC1/16S-103JTH (10 k)
R231 7030016150 S.RES RMC1/16S-100JTH (10)
R233 7030016150 S.RES RMC1/16S-100JTH (10)
R234 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R251 7030015970 S.RES RMC1/16S-103JTH (10 k)
R252 7030016040 S.RES RMC1/16S-224JTH (220 k)
R253 7030016040 S.RES RMC1/16S-224JTH (220 k)
R254 7030016050 S.RES RMC1/16S-102JTH (1 k)
R255 7030016330 S.RES RMC1/16S-153JTH (15 k)
R261 7030016110 S.RES RMC1/16S-473JTH (47 k)
R262 7030016110 S.RES RMC1/16S-473JTH (47 k)
R263 7410001140 S.ARR EXB28V104JX
R271 7030016110 S.RES RMC1/16S-473JTH (47 k)
R272 7030016110 S.RES RMC1/16S-473JTH (47 k)
R401 7030015910 S.RES RMC1/16S-101JTH (100)
R402 7030016020 S.RES RMC1/16S-104JTH (100 k)
R403 7030016020 S.RES RMC1/16S-104JTH (100 k)
R404 7030016230 S.RES RMC1/16S-394JTH (390 k)
R405 7030015910 S.RES RMC1/16S-101JTH (100)
R421 7410001230 S.ARR EXB28V101JX
R501 7030016050 S.RES RMC1/16S-102JTH (1 k)
R502 7030016050 S.RES RMC1/16S-102JTH (1 k)
R506 7030016110 S.RES RMC1/16S-473JTH (47 k)
R507 7030016110 S.RES RMC1/16S-473JTH (47 k)
R511 7030016090 S.RES RMC1/16S-223JTH (22 k)
R512 7030015970 S.RES RMC1/16S-103JTH (10 k)
R513 7030015950 S.RES RMC1/16S-152JTH (1.5 k)
R514 7030016060 S.RES RMC1/16S-105JTH (1 M)
R515 7030016020 S.RES RMC1/16S-104JTH (100 k)
R516 7030015950 S.RES RMC1/16S-152JTH (1.5 k)
R517 7030016050 S.RES RMC1/16S-102JTH (1 k)
R521 7030016520 S.RES RMC1/16S-270JTH (27)
R522 7030016520 S.RES RMC1/16S-270JTH (27)
R523 7030016330 S.RES RMC1/16S-153JTH (15 k)
R524 7030016330 S.RES RMC1/16S-153JTH (15 k)
R525 7030016520 S.RES RMC1/16S-270JTH (27)
R526 7030016520 S.RES RMC1/16S-270JTH (27)
R527 7030016520 S.RES RMC1/16S-270JTH (27)
R528 7030016520 S.RES RMC1/16S-270JTH (27)
R529 7030016330 S.RES RMC1/16S-153JTH (15 k)
R530 7030016330 S.RES RMC1/16S-153JTH (15 k)
R531 7030016520 S.RES RMC1/16S-270JTH (27)
R532 7030016330 S.RES RMC1/16S-153JTH (15 k)
R533 7030016520 S.RES RMC1/16S-270JTH (27)
R534 7030016330 S.RES RMC1/16S-153JTH (15 k)
R541 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R542 7030015970 S.RES RMC1/16S-103JTH (10 k)
R543 7030015970 S.RES RMC1/16S-103JTH (10 k)
R544 7030015970 S.RES RMC1/16S-103JTH (10 k)
R545 7030016250 S.RES RMC1/16S-220JTH (22)
R546 7030016250 S.RES RMC1/16S-220JTH (22)
R548 7030015970 S.RES RMC1/16S-103JTH (10 k)
R550 7030016250 S.RES RMC1/16S-220JTH (22)
R551 7030016250 S.RES RMC1/16S-220JTH (22)
R561 7030016020 S.RES RMC1/16S-104JTH (100 k)
R562 7030016020 S.RES RMC1/16S-104JTH (100 k)
R563 7030016380 S.RES RMC1/16S-183JTH (18 k)
R564 7030015970 S.RES RMC1/16S-103JTH (10 k)
R565 7030016110 S.RES RMC1/16S-473JTH (47 k)
R566 7030016360 S.RES RMC1/16S-123JTH (12 k)
R591 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R592 7030015970 S.RES RMC1/16S-103JTH (10 k)
R593 7030015970 S.RES RMC1/16S-103JTH (10 k)
R594 7030015970 S.RES RMC1/16S-103JTH (10 k)
R595 7030016250 S.RES RMC1/16S-220JTH (22)
R596 7030016250 S.RES RMC1/16S-220JTH (22)
R601 7030015950 S.RES RMC1/16S-152JTH (1.5 k)
R602 7030015970 S.RES RMC1/16S-103JTH (10 k)
R603 7030016250 S.RES RMC1/16S-220JTH (22)
R604 7030016250 S.RES RMC1/16S-220JTH (22)
R605 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R606 7030016060 S.RES RMC1/16S-105JTH (1 M)
R607 7030016060 S.RES RMC1/16S-105JTH (1 M)
R608 7030016110 S.RES RMC1/16S-473JTH (47 k)
R609 7030016020 S.RES RMC1/16S-104JTH (100 k)
R610 7030016020 S.RES RMC1/16S-104JTH (100 k)
R611 7030015970 S.RES RMC1/16S-103JTH (10 k)
R612 7030015970 S.RES RMC1/16S-103JTH (10 k)
R621 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R622 7030015950 S.RES RMC1/16S-152JTH (1.5 k)
R1003 7030015970 S.RES RMC1/16S-103JTH (10 k)
R1004 7030016740 S.RES RMC1/16SK474DTH (470 k)
R1005 7030016800 S.RES RMC1/16SK104FTH (100 k)
R1006 7030016550 S.RES RMC1/16SK154FTH (150 k)
R1007 7030016110 S.RES RMC1/16S-473JTH (47 k)
R1008 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B 136.1/180.2
B 139.5/181.4
T 141.6/187.4
T 149.7/193.5
T 140.0/188.3
T 147.7/193.5
T 146.8/192.4
T 147.2/191.2
T 130.6/197.1
T 130.6/198.1
T 120.8/200.4
T 115.1/162.2
T 115.1/166.2
B 115.6/171.1
T 112.7/172.6
B 110.8/178.1
B 117.6/178.2
B 111.2/176.6
B 111.2/175.0
B 116.2/181.4
B 119.4/180.5
B 130.4/183.0
B 130.4/188.7
B 130.4/186.2
B 131.3/188.3
B 125.6/184.0
B 128.9/188.3
T 120.5/31.9
T 130.4/30.6
T 121.9/33.9
T 133.4/36.0
T 136.3/37.8
B 32.6/93.8
B 28.8/84.6
B 29.7/84.6
B 30.6/84.6
B 31.5/84.6
B 12.5/121.9
T 119.1/204.3
T 119.1/202.6
T 96.1/174.7
B 71.0/182.8
B 56.9/176.5
B 58.3/181.3
T 97.2/181.6
T 96.3/182.5
T 88.7/188.3
T 89.6/188.3
B 58.3/176.4
T 93.6/190.0
T 92.4/190.6
T 85.3/186.8
T 82.6/186.8
T 84.4/186.8
T 83.5/186.8
T 83.1/180.6
T 83.1/179.7
T 83.1/181.5
T 83.1/178.8
T 90.3/174.7
T 91.2/174.7
T 89.4/174.7
T 88.5/174.7
B 62.4/186.0
B 62.4/187.0
B 62.4/185.1
B 70.5/188.7
B 70.5/185.8
B 70.5/186.7
B 70.5/184.9
T 73.3/193.7
B 70.5/184.0
T 72.2/188.1
T 72.2/187.2
T 79.0/198.2
T 77.4/198.2
T 76.0/195.0
T 76.0/192.1
B 85.6/177.3
B 87.5/171.6
B 85.6/178.3
B 94.9/178.5
B 96.5/175.3
B 94.9/176.8
T 81.9/177.0
T 85.6/171.2
T 81.3/179.7
T 81.3/180.6
T 74.3/169.0
T 74.3/169.9
T 75.1/180.8
T 62.5/176.0
B 64.9/175.7
B 64.4/174.1
B 63.5/176.2
B 63.2/174.6
T 68.2/172.8
T 67.8/171.6
T 4.7/171.7
T 19.0/171.3
T 18.1/169.7
T 19.0/169.7
T 28.9/174.8
T 30.1/175.2
(Amended page)
[MAIN UNIT]
H/V
REF PART
NO. NO.
R1009 7030016300 S.RES
R1103 7030016740 S.RES
R1104 7030016690 S.RES
R1105 7030016800 S.RES
R1203 7030016740 S.RES
R1204 7030016690 S.RES
R1205 7030016690 S.RES
R1301 7030016050 S.RES
R1302 7030016050 S.RES
R1305 7030015960 S.RES
R1306 7030015910 S.RES
R1307 7030016060 S.RES
R1401 7030015960 S.RES
R1404 7030015960 S.RES
R1406 7030016290 S.RES
R1407 7030016050 S.RES
R1408 7030016290 S.RES
R1409 7030016050 S.RES
R1451 7030015960 S.RES
R1452 7030015960 S.RES
R1491 7030016440 S.RES
R1501 7030016020 S.RES
R1502 7030016020 S.RES
R1503 7030016110 S.RES
R1504 7030016020 S.RES
R1505 7030016110 S.RES
R1506 7030015960 S.RES
R1507 7030015910 S.RES
R1508 7030016020 S.RES
R1509 7030018130 S.RES
R1510 7030016050 S.RES
R1511 7030016900 S.RES
R1512 7030015910 S.RES
R1513 7030016380 S.RES
R1514 7030015970 S.RES
R1515 7030016330 S.RES
R1516 7030016050 S.RES
R1517 7510001511 S.THE
R1518 7030016020 S.RES
R1519 7030016110 S.RES
R1520 7030016400 S.RES
R1521 7030015970 S.RES
R1522 7030016290 S.RES
R1523 7030016020 S.RES
R1524 7030016020 S.RES
R1526 7030016390 S.RES
R1528 7030016100 S.RES
R1529 7030015970 S.RES
R1530 7030016020 S.RES
R1531 7030015990 S.RES
R1532 7030016390 S.RES
R1533 7030016050 S.RES
R1534 7030015970 S.RES
R1535 7030016050 S.RES
R1536 7030016200 S.RES
R1537 7030016320 S.RES
R1538 7030016280 S.RES
R1539 7030015930 S.RES
R1540 7030015910 S.RES
R1541 7030016560 S.RES
R1542 7030016420 S.RES
R1543 7030015960 S.RES
R1544 7030016710 S.RES
R1545 7030015910 S.RES
R1546 7030016060 S.RES
R1547 7030015990 S.RES
R1548 7030016380 S.RES
R1549 7030016310 S.RES
R1550 7030016720 S.RES
R1551 7030016070 S.RES
R1552 7030016790 S.RES
R1553 7030015910 S.RES
R1554 7030015910 S.RES
R1555 7030015950 S.RES
R1557 7030016100 S.RES
R2001 7030015980 S.RES
R2002 7030016220 S.RES
R2003 7030015990 S.RES
R2005 7030016330 S.RES
R2006 7030016380 S.RES
R2007 7030015930 S.RES
R2008 7030015920 S.RES
R2009 7030015900 S.RES
R2010 7030015900 S.RES
R2011 7030015970 S.RES
R2012 7030015900 S.RES
R2013 7030015900 S.RES
R2014 7030016050 S.RES
R2015 7030016050 S.RES
R2016 7030016050 S.RES
R2017 7030015900 S.RES
R2018 7030015930 S.RES
R2019 7030015900 S.RES
R2020 7030015920 S.RES
R2101 7030015960 S.RES
R2102 7030015970 S.RES
R2103 7030016250 S.RES
R2104 7030016280 S.RES
R2105 7030015910 S.RES
R2106 7030015900 S.RES
R2107 7030015910 S.RES
R2108 7030016180 S.RES
R2109 7030016150 S.RES
R2110 7030015950 S.RES
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5
DESCRIPTION M.
RMC1/16S-332JTH (3.3 k) T
RMC1/16SK474DTH (470 k) T
RMC1/16SK393FTH (39 k) T
RMC1/16SK104FTH (100 k) T
RMC1/16SK474DTH (470 k) T
RMC1/16SK393FTH (39 k) T
RMC1/16SK393FTH (39 k) T
RMC1/16S-102JTH (1 k) T
RMC1/16S-102JTH (1 k) T
RMC1/16S-472JTH (4.7 k) T
RMC1/16S-101JTH (100) T
RMC1/16S-105JTH (1 M) T
RMC1/16S-472JTH (4.7 k) B
RMC1/16S-472JTH (4.7 k) T
RMC1/16S-222JTH (2.2 k) B
RMC1/16S-102JTH (1 k) B
RMC1/16S-222JTH (2.2 k) B
RMC1/16S-102JTH (1 k) B
RMC1/16S-472JTH (4.7 k) T
RMC1/16S-472JTH (4.7 k) T
RMC1/16S-272JTH (2.7 k) T
RMC1/16S-104JTH (100 k) B
RMC1/16S-104JTH (100 k) B
RMC1/16S-473JTH (47 k) B
RMC1/16S-104JTH (100 k) B
RMC1/16S-473JTH (47 k) B
RMC1/16S-472JTH (4.7 k) B
RMC1/16S-101JTH (100) B
RMC1/16S-104JTH (100 k) T
RMC1/16SK472FTH (4.7 k) T
RMC1/16S-102JTH (1 k) B
RMC1/16SK102FTH (1 k) T
RMC1/16S-101JTH (100) B
RMC1/16S-183JTH (18 k) B
RMC1/16S-103JTH (10 k) B
RMC1/16S-153JTH (15 k) B
RMC1/16S-102JTH (1 k) T
NTCG16 4LH 223JT B
RMC1/16S-104JTH (100 k) B
RMC1/16S-473JTH (47 k) B
RMC1/16S-564JTH (560 k) B
RMC1/16S-103JTH (10 k) T
RMC1/16S-222JTH (2.2 k) B
RMC1/16S-104JTH (100 k) B
RMC1/16S-104JTH (100 k) B
RMC1/16S-184JTH (180 k) B
RMC1/16S-334JTH (330 k) B
RMC1/16S-103JTH (10 k) B
RMC1/16S-104JTH (100 k) B
RMC1/16S-683JTH (68 k) B
RMC1/16S-184JTH (180 k) B
RMC1/16S-102JTH (1 k) T
RMC1/16S-103JTH (10 k) B
RMC1/16S-102JTH (1 k) T
RMC1/16S-274JTH (270 k) B
RMC1/16S-225JTH (2.2 M) B
RMC1/16S-331JTH (330) B
RMC1/16S-471JTH (470) B
RMC1/16S-101JTH (100) B
RMC1/16SJPTH B
RMC1/16S-182JTH (1.8 k) B
RMC1/16S-472JTH (4.7 k) B
RMC1/16S-106JTH (10 M) B
RMC1/16S-101JTH (100) B
RMC1/16S-105JTH (1 M) B
RMC1/16S-683JTH (68 k) B
RMC1/16S-183JTH (18 k) B
RMC1/16S-155JTH (1.5 M) T
RMC1/16S-185JTH (1.8 M) B
RMC1/16S-474JTH (470 k) B
RMC1/16S-335JTH (3.3 M) T
RMC1/16S-101JTH (100) T
RMC1/16S-101JTH (100) T
RMC1/16S-152JTH (1.5 k) T
RMC1/16S-334JTH (330 k) B
RMC1/16S-333JTH (33 k) T
RMC1/16S-563JTH (56 k) T
RMC1/16S-683JTH (68 k) T
RMC1/16S-153JTH (15 k) B
RMC1/16S-183JTH (18 k) B
RMC1/16S-471JTH (470) T
RMC1/16S-221JTH (220) B
RMC1/16S-470JTH (47) B
RMC1/16S-470JTH (47) B
RMC1/16S-103JTH (10 k) T
RMC1/16S-470JTH (47) T
RMC1/16S-470JTH (47) T
RMC1/16S-102JTH (1 k) T
RMC1/16S-102JTH (1 k) T
RMC1/16S-102JTH (1 k) T
RMC1/16S-470JTH (47) T
RMC1/16S-471JTH (470) T
RMC1/16S-470JTH (47) T
RMC1/16S-221JTH (220) T
RMC1/16S-472JTH (4.7 k) B
RMC1/16S-103JTH (10 k) B
RMC1/16S-220JTH (22) B
RMC1/16S-331JTH (330) B
RMC1/16S-101JTH (100) B
RMC1/16S-470JTH (47) B
RMC1/16S-101JTH (100) B
RMC1/16S-680JTH (68) B
RMC1/16S-100JTH (10) B
RMC1/16S-152JTH (1.5 k) B
H/V
LOCATION
31.0/176.4
19.0/162.2
18.1/160.6
19.0/160.6
19.0/153.0
18.1/151.4
19.0/151.4
6.1/147.7
6.1/148.6
20.1/147.5
8.9/142.9
20.1/145.9
33.9/44.9
80.5/55.4
37.6/45.9
41.9/44.5
43.5/45.9
47.8/44.4
21.9/119.3
21.9/116.4
33.4/132.2
17.6/134.7
20.6/136.9
18.8/132.6
22.2/132.6
19.2/127.7
20.8/125.8
16.3/122.2
30.6/135.5
13.0/129.4
18.9/122.4
13.4/127.4
16.0/125.6
17.0/119.4
15.8/120.1
19.6/126.3
21.6/123.8
30.2/123.8
18.3/125.8
25.7/131.9
28.8/129.8
25.5/139.4
30.2/133.2
30.2/131.6
29.3/132.4
26.2/127.0
27.5/131.9
26.2/130.7
28.0/125.6
30.9/126.0
30.5/129.5
27.8/136.4
29.1/126.5
25.5/138.5
26.2/129.8
29.2/125.2
31.9/129.0
24.7/130.2
28.0/124.7
33.0/129.9
26.5/138.3
25.1/137.9
25.1/136.3
28.1/138.3
32.0/133.2
26.1/120.4
28.2/120.4
24.7/124.6
27.3/120.4
26.1/121.3
26.1/122.1
16.0/126.5
24.7/128.3
24.9/122.5
31.0/128.3
105.0/140.1
104.5/138.9
103.8/140.6
93.6/140.7
94.7/139.8
90.0/139.4
89.8/139.5
86.1/138.6
86.5/137.4
83.4/139.4
81.7/139.4
75.7/137.4
71.7/138.4
70.8/138.4
69.9/138.4
69.8/134.9
68.0/137.3
67.6/139.4
66.4/138.2
91.3/135.8
87.8/136.0
90.1/135.5
90.5/134.3
89.2/131.3
73.1/128.1
86.8/127.6
77.9/129.0
76.5/129.7
72.6/129.4
