Icom IC-7100 Service Manual Addendum page 53

February 2017
[MAIN UNIT]
REF PART
NO. NO.
R3272 7030005010 S.RES ERJ2GEJ 681 X (680)
R3273 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R3274 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R3275 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R3301 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R3302 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R4001 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4003 7030005300 S.RES ERJ2GEJ 150 X (15)
R4007 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
R4008 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4009 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4051 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4052 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R4053 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4054 7030004970 S.RES ERJ2GEJ 470 X (47)
R4055 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R4056 7030004970 S.RES ERJ2GEJ 470 X (47)
R4101 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4102 7030005000 S.RES ERJ2GEJ 471 X (470)
R4103 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4104 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4105 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R4151 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4152 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4153 7030000010 S.RES MCR10EZHJ JPW (000)
R4202 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4203 7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
R4204 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4205 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4206 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R4207 7030004970 S.RES ERJ2GEJ 470 X (47)
R4209 7030007250 S.RES ERJ2GEJ 220 X (22)
R4210 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4211 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4212 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R4213 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R4215 7030005530 S.RES ERJ2GEJ 100 X (10)
R4251 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4252 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4253 7030007280 S.RES ERJ2GEJ 331 X (330)
R4254 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R4255 7030004980 S.RES ERJ2GEJ 101 X (100)
R4256 7030008400 S.RES ERJ2GEJ 182 X (1.8 k)
R4258 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4259 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4260 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R4261 7510001441 S.THE NTCG16 3NH 221JT
R4301 7030004970 S.RES ERJ2GEJ 470 X (47)
R4302 7030007270 S.RES ERJ2GEJ 151 X (150)
R4303 7030009200 S.RES ERJ2GEJ 390 X (39)
R4304 7030007270 S.RES ERJ2GEJ 151 X (150)
R4351 7030004980 S.RES ERJ2GEJ 101 X (100)
R4352 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4353 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4354 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4355 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4356 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4401 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R4402 7030004990 S.RES ERJ2GEJ 221 X (220)
R4403 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R4404 7030005000 S.RES ERJ2GEJ 471 X (470)
R4405 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R4406 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4408 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R4411 7510001441 S.THE NTCG16 3NH 221JT
R4501 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R4502 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
R4503 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4504 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4505 7030004970 S.RES ERJ2GEJ 470 X (47)
R4506 7030007250 S.RES ERJ2GEJ 220 X (22)
R4507 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
R4508 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4509 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4510 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4511 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4512 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4513 7030004980 S.RES ERJ2GEJ 101 X (100)
R4514 7030009160 S.RES ERJ2GEJ 181 X (180)
R4515 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4516 7030004980 S.RES ERJ2GEJ 101 X (100)
R4517 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4518 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4520 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4521 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4522 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4523 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4524 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R4525 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R4526 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R4527 7030004980 S.RES ERJ2GEJ 101 X (100)
R4528 7030004980 S.RES ERJ2GEJ 101 X (100)
R4531 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4532 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4533 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R4534 7030004980 S.RES ERJ2GEJ 101 X (100)
R4601 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R4602 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R4603 7030007250 S.RES ERJ2GEJ 220 X (22)
R4604 7030007280 S.RES ERJ2GEJ 331 X (330)
R4605 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R4606 7030008410 S.RES ERJ2GEJ 392 X (3.9 k)
R4608 7030007280 S.RES ERJ2GEJ 331 X (330)
R4609 7030004980 S.RES ERJ2GEJ 101 X (100)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T 21.9/82.7
T 19.0/83.3
B 17.0/82.9
B 21.2/79.5
T 76.1/44.9
T 77.0/44.5
B 37.0/83.4
B 37.4/85.5
B 36.6/89.4
B 37.0/94.5
B 37.0/95.4
T 33.8/84.8
T 31.3/88.7
T 32.7/92.2
T 34.7/88.7
T 31.3/92.7
T 34.7/92.1
B 33.1/96.7
B 38.2/112.2
B 32.1/98.3
B 34.9/109.7
T 33.0/108.2
T 44.7/96.7
T 44.9/105.5
B 35.4/111.7
T 32.6/114.0
T 41.4/115.1
T 39.3/114.6
T 41.3/118.4
T 41.4/114.2
B 44.1/114.9
T 47.6/113.7
T 48.1/118.7
B 51.5/122.7
T 39.7/116.5
T 46.3/113.4
B 41.5/118.0
T 31.7/119.4
B 42.0/123.8
T 41.1/124.4
B 42.6/126.3
B 46.0/122.5
T 44.8/124.6
T 43.0/124.6
T 47.8/122.5
T 45.7/123.0
B 42.3/127.3
T 44.2/137.1
B 65.8/126.9
B 65.4/125.7
B 64.5/126.6
T 35.1/154.2
B 40.1/154.7
B 37.0/155.3
B 39.2/154.7
B 35.6/154.5
B 36.1/155.8
B 34.1/168.7
B 33.6/161.6
B 35.2/160.7
B 39.2/166.1
B 38.2/168.4
B 38.2/170.1
B 41.7/170.1
B 33.8/169.8
T 38.9/158.1
B 37.7/158.2
B 37.1/161.1
T 39.8/158.1
B 39.9/158.0
T 40.9/160.7
B 39.3/162.0
B 46.4/156.5
B 48.2/157.4
B 47.3/157.4
B 45.2/156.9
B 45.7/158.1
T 45.1/157.6
B 50.6/161.2
T 46.1/169.4
T 50.5/171.5
B 48.5/173.7
B 46.9/172.4
B 50.4/171.5
B 52.9/171.9
B 55.0/159.5
B 58.2/157.6
B 56.6/157.6
B 56.9/159.5
B 58.1/159.0
B 59.8/158.6
T 59.7/154.0
B 59.4/146.6
B 61.0/146.6
B 59.7/150.1
T 59.4/148.1
T 59.3/145.1
T 58.0/144.7
T 53.6/146.6
T 56.7/144.3
B 52.7/151.6
B 51.4/155.3
T 46.7/150.9
B 54.9/147.3
(Amended page)
[MAIN UNIT]
H/V REF PART
NO. NO.
R4610 7030005050 S.RES
R4611 7030005010 S.RES
R4612 7030008290 S.RES
R4614 7030005050 S.RES
R4615 7030004980 S.RES
R4701 7030005220 S.RES
R4702 7030005220 S.RES
R4703 7030005040 S.RES
R5001 7030007250 S.RES
R5002 7030007250 S.RES
R5003 7030007250 S.RES
R5004 7030007250 S.RES
R5006 7030005240 S.RES
R5007 7410001240 S.ARR EXB28V220JX
R5008 7030007250 S.RES
R5009 7030007250 S.RES
R5010 7030005040 S.RES
R5011 7030008290 S.RES
R5012 7030005040 S.RES
R5013 7030005040 S.RES
R5014 7030008290 S.RES
R5015 7030005040 S.RES
R5018 7030005120 S.RES
R5019 7030008290 S.RES
R5021 7030005120 S.RES
R5026 7410001230 S.ARR EXB28V101JX
R5027 7410001230 S.ARR EXB28V101JX
R5028 7030004980 S.RES
R5029 7410001230 S.ARR EXB28V101JX
R5036 7030005120 S.RES
R5037 7030007250 S.RES
R5038 7030007250 S.RES
R5039 7030007250 S.RES
R5040 7030007250 S.RES
R5041 7030007250 S.RES
R5051 7030005050 S.RES
R5052 7030005120 S.RES
R5053 7030005240 S.RES
R5054 7030007340 S.RES
R5055 7030004980 S.RES
R5057 7030000010 S.RES
R5062 7030005050 S.RES
R5071 7030004970 S.RES
R5074 7030004970 S.RES
R5075 7410001170 S.ARR EXB28V470JX
R5076 7410001170 S.ARR EXB28V470JX
R5081 7030004980 S.RES
R5082 7030004980 S.RES
R5083 7030004980 S.RES
R5084 7030005040 S.RES
R5085 7030005040 S.RES
R5091 7030005120 S.RES
R5092 7030005050 S.RES
R5093 7030007350 S.RES
R5094 7030005100 S.RES
R5095 7030005000 S.RES
R5096 7030005000 S.RES
R5097 7030007350 S.RES
R5098 7030005090 S.RES
R5099 7030005090 S.RES
R5100 7030004980 S.RES
R5101 7030005040 S.RES
R5102 7030005040 S.RES
R5103 7030007300 S.RES
R5104 7030007300 S.RES
R5105 7030005710 S.RES
R5106 7030005710 S.RES
R5107 7030007290 S.RES
R5112 7030005240 S.RES
R5113 7030005240 S.RES
R5114 7030005040 S.RES
R5115 7030005040 S.RES
R5121 7030005040 S.RES
R5122 7030005040 S.RES
R5123 7030005210 S.RES
R5124 7030009290 S.RES
R5125 7030005710 S.RES
R5126 7030005710 S.RES
R5127 7030005120 S.RES
R5131 7030005120 S.RES
R5132 7030007340 S.RES
R5133 7030005600 S.RES
R5134 7030007340 S.RES
R5141 7030005120 S.RES
R5142 7030007340 S.RES
R5143 7030005600 S.RES
R5144 7030007340 S.RES
R5151 7030005240 S.RES
R5161 7030004980 S.RES
R5162 7030004980 S.RES
R5163 7030004980 S.RES
R5164 7030005040 S.RES
R5165 7030005040 S.RES
R5171 7030007300 S.RES
R5172 7030007300 S.RES
R5173 7030007300 S.RES
R5174 7030007300 S.RES
R5175 7030007290 S.RES
R5176 7030004980 S.RES
R5177 7030007290 S.RES
R5178 7030004980 S.RES
R5191 7030007300 S.RES
R5192 7030007300 S.RES
R5193 7030007300 S.RES
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
7
DESCRIPTION M.
ERJ2GEJ 103 X (10 k) B
ERJ2GEJ 681 X (680) B
ERJ2GEJ 183 X (18 k) B
ERJ2GEJ 103 X (10 k) B
ERJ2GEJ 101 X (100) B
ERJ2GEJ 223 X (22 k) T
ERJ2GEJ 223 X (22 k) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 473 X (47 k) B
B
ERJ2GEJ 220 X (22) B
ERJ2GEJ 220 X (22) B
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 183 X (18 k) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 183 X (18 k) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 102 X (1 k) T
ERJ2GEJ 183 X (18 k) T
ERJ2GEJ 102 X (1 k) T
T
T
ERJ2GEJ 101 X (100) T
B
ERJ2GEJ 102 X (1 k) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 220 X (22) T
ERJ2GEJ 103 X (10 k) T
ERJ2GEJ 102 X (1 k) T
ERJ2GEJ 473 X (47 k) T
ERJ2GEJ 153 X (15 k) T
ERJ2GEJ 101 X (100) B
MCR10EZHJ JPW (000) B
ERJ2GEJ 103 X (10 k) B
ERJ2GEJ 470 X (47) T
ERJ2GEJ 470 X (47) B
B
T
ERJ2GEJ 101 X (100) T
ERJ2GEJ 101 X (100) T
ERJ2GEJ 101 X (100) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 102 X (1 k) B
ERJ2GEJ 103 X (10 k) B
ERJ2GEJ 393 X (39 k) B
ERJ2GEJ 154 X (150 k) B
ERJ2GEJ 471 X (470) B
ERJ2GEJ 471 X (470) B
ERJ2GEJ 393 X (39 k) B
ERJ2GEJ 104 X (100 k) B
ERJ2GEJ 104 X (100 k) B
ERJ2GEJ 101 X (100) T
ERJ2GEJ 472 X (4.7 k) B
ERJ2GEJ 472 X (4.7 k) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 121 X (120) B
ERJ2GEJ 121 X (120) B
ERJ2GEJ 222 X (2.2 k) B
ERJ2GEJ 473 X (47 k) T
ERJ2GEJ 473 X (47 k) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 472 X (4.7 k) T
ERJ2GEJ 472 X (4.7 k) B
ERJ2GEJ 472 X (4.7 k) B
ERJ2GEJ 822 X (8.2 k) B
ERJ2GEJ 562 X (5.6 k) B
ERJ2GEJ 121 X (120) B
ERJ2GEJ 121 X (120) B
ERJ2GEJ 102 X (1 k) B
ERJ2GEJ 102 X (1 k) B
ERJ2GEJ 153 X (15 k) B
ERJ2GEJ 273 X (27 k) B
ERJ2GEJ 153 X (15 k) B
ERJ2GEJ 102 X (1 k) B
ERJ2GEJ 153 X (15 k) B
ERJ2GEJ 273 X (27 k) B
ERJ2GEJ 153 X (15 k) B
ERJ2GEJ 473 X (47 k) T
ERJ2GEJ 101 X (100) T
ERJ2GEJ 101 X (100) T
ERJ2GEJ 101 X (100) T
ERJ2GEJ 472 X (4.7 k) B
ERJ2GEJ 472 X (4.7 k) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 222 X (2.2 k) B
ERJ2GEJ 101 X (100) B
ERJ2GEJ 222 X (2.2 k) B
ERJ2GEJ 101 X (100) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 332 X (3.3 k) B
ERJ2GEJ 332 X (3.3 k) B
H/V
LOCATION
54.5/153.7
51.0/148.5
56.2/153.5
57.5/154.0
59.1/152.6
24.5/102.5
24.5/100.5
27.3/103.6
144.2/126.7
144.2/129.4
144.2/133.9
144.2/134.8
146.4/136.9
146.3/135.1
143.9/143.5
143.0/143.5
144.2/127.6
144.2/132.1
144.2/128.5
144.2/133.0
144.2/136.6
144.2/135.7
144.2/131.2
144.2/138.4
144.2/137.5
111.6/133.5
111.9/136.9
111.9/139.4
118.3/141.9
123.3/123.4
131.7/123.4
132.6/123.4
133.8/123.4
138.3/123.4
139.2/123.4
126.9/116.3
125.3/118.6
125.7/113.6
127.4/114.3
120.6/115.8
107.4/152.6
126.7/150.8
92.7/155.0
96.2/152.0
96.2/150.3
104.4/151.0
91.2/165.8
77.6/163.8
69.1/165.4
65.3/156.7
65.3/158.4
93.4/158.2
93.4/161.2
92.9/162.5
92.9/163.4
90.8/164.5
95.1/160.8
96.0/159.3
96.9/161.2
97.1/157.1
94.2/164.0
88.8/163.3
88.2/161.3
87.7/160.0
86.3/164.0
86.3/163.1
86.3/162.2
86.3/166.4
82.7/162.7
81.7/162.7
80.7/162.7
80.7/161.1
80.6/161.3
81.0/159.2
79.1/159.2
78.2/161.9
78.2/161.0
78.2/160.1
76.2/163.3
71.4/161.3
69.7/161.3
68.8/162.2
68.8/163.1
64.6/164.7
64.6/163.8
63.0/162.9
63.0/163.8
57.6/164.5
76.7/147.4
82.7/144.2
82.4/152.0
90.9/146.5
92.1/146.3
74.7/153.5
75.2/152.2
78.2/154.8
78.2/153.4
79.8/154.8
81.0/155.3
79.8/153.4
81.1/152.9
73.5/146.5
74.6/144.8
77.6/146.5
