i7100
NOTE: Use these amended pages as one addendum set.
Do not mix them up with the previous master pages.
CONTENTS
REPLACEMENT PAGES:
ADJUSTMENT PROCEDURE ������������������� 4-3
MECHANICAL PARTS �������������������� 6-1~6-3
AMENDED PAGES:
PARTS LIST ���������������������������� 1
BLOCK DIAGRAM ������������������������� 21
BOARD LAYOUT �������������������������� 24
VOLTAGE DIAGRAM ������������������������ 30
February 2017
SERVICE MANUAL
ADDENDUM
