Icom IC-7100 Service Manual Addendum page 18

November 2018
[MAIN UNIT]
REF PART
NO. NO.
C2326 4030022550 S.CER 0402N4R0B500CT
C2327 4030022860 S.CER 0402N470J500CT
C2328 4030022770 S.CER 0402N270J500CT
C2329 4030022770 S.CER 0402N270J500CT
C2330 4030022920 S.CER 0402N820J500CT
C2331 4030022760 S.CER 0402N240J500CT
C2332 4030022710 S.CER 0402N181J500CT
C2333 4030022840 S.CER 0402N390J500CT
C2334 4030022870 S.CER 0402N471J500CT
C2335 4030023090 S.CER 0402B102K500CT
C2336 4030023030 S.CER 0402B103K250CT
C2351 4030023090 S.CER 0402B102K500CT
C2352 4030023090 S.CER 0402B102K500CT
C2354 4030022840 S.CER 0402N390J500CT
C2355 4030022840 S.CER 0402N390J500CT
C2401 4030023090 S.CER 0402B102K500CT
C2402 4030023030 S.CER 0402B103K250CT
C2404 4030023030 S.CER 0402B103K250CT
C2405 4030022810 S.CER 0402N330J500CT
C2406 4030022570 S.CER 0402N6R0C500CT
C2407 4030022860 S.CER 0402N470J500CT
C2408 4030022830 S.CER 0402N360J500CT
C2409 4030023030 S.CER 0402B103K250CT
C2410 4030022860 S.CER 0402N470J500CT
C2411 4030022750 S.CER 0402N221J500CT
C2414 4030022660 S.CER 0402N120J500CT
C2415 4030022560 S.CER 0402N5R0B500CT
C2416 4030022680 S.CER 0402N150J500CT
C2417 4030022660 S.CER 0402N120J500CT
C2418 4030022690 S.CER 0402N151J500CT
C2419 4030022760 S.CER 0402N240J500CT
C2420 4030023090 S.CER 0402B102K500CT
C2421 4030023090 S.CER 0402B102K500CT
C2422 4030023090 S.CER 0402B102K500CT
C2424 4030023090 S.CER 0402B102K500CT
C2425 4030022660 S.CER 0402N120J500CT
C2426 4030022660 S.CER 0402N120J500CT
C2427 4030019560 S.CER GRM21BB31C106KE15L
C2428 4030019560 S.CER GRM21BB31C106KE15L
C2429 4030022590 S.CER 0402N8R0C500CT
C2430 4030022590 S.CER 0402N8R0C500CT
C2501 4030022810 S.CER 0402N330J500CT
C2502 4030022800 S.CER 0402N300J500CT
C2503 4030022660 S.CER 0402N120J500CT
C2504 4030022700 S.CER 0402N180J500CT
C2505 4030022840 S.CER 0402N390J500CT
C2506 4030022550 S.CER 0402N4R0B500CT
C2507 4030022900 S.CER 0402N680J500CT
C2508 4030022560 S.CER 0402N5R0B500CT
C2509 4030022860 S.CER 0402N470J500CT
C2510 4030022590 S.CER 0402N8R0C500CT
C2511 4030022700 S.CER 0402N180J500CT
C2512 4030023030 S.CER 0402B103K250CT
C2513 4030023030 S.CER 0402B103K250CT
C2551 4030023030 S.CER 0402B103K250CT
C2552 4030022630 S.CER 0402N100C500CT
C2553 4030022540 S.CER 0402N3R0B500CT
C2554 4030022770 S.CER 0402N270J500CT
C2555 4030022580 S.CER 0402N7R0C500CT
C2556 4030022740 S.CER 0402N220J500CT
C2557 4030022700 S.CER 0402N180J500CT
C2558 4030022560 S.CER 0402N5R0B500CT
C2559 4030022630 S.CER 0402N100C500CT
C2560 4030022710 S.CER 0402N181J500CT
C2561 4030022630 S.CER 0402N100C500CT
C2562 4030022640 S.CER 0402N101J500CT
C2563 4030022680 S.CER 0402N150J500CT
C2564 4030022810 S.CER 0402N330J500CT
C2565 4030022700 S.CER 0402N180J500CT
C2566 4030023030 S.CER 0402B103K250CT
C2567 4030023030 S.CER 0402B103K250CT
C2601 4030022680 S.CER 0402N150J500CT
C2602 4030022780 S.CER 0402N271J500CT
C2603 4030022590 S.CER 0402N8R0C500CT
C2604 4030022920 S.CER 0402N820J500CT
C2605 4030022590 S.CER 0402N8R0C500CT
C2606 4030022900 S.CER 0402N680J500CT
C2607 4030022660 S.CER 0402N120J500CT
C2608 4030022590 S.CER 0402N8R0C500CT
C2609 4030022530 S.CER 0402N2R0B500CT
C2610 4030022740 S.CER 0402N220J500CT
C2611 4030022560 S.CER 0402N5R0B500CT
C2612 4030022680 S.CER 0402N150J500CT
C2613 4030022580 S.CER 0402N7R0C500CT
C2614 4030023090 S.CER 0402B102K500CT
C2615 4030022560 S.CER 0402N5R0B500CT
C2616 4030023030 S.CER 0402B103K250CT
C2652 4030022700 S.CER 0402N180J500CT
C2653 4030022530 S.CER 0402N2R0B500CT
C2654 4030022770 S.CER 0402N270J500CT
C2655 4030022540 S.CER 0402N3R0B500CT
C2656 4030022740 S.CER 0402N220J500CT
C2657 4030022560 S.CER 0402N5R0B500CT
C2658 4030022660 S.CER 0402N120J500CT
C2659 4030022580 S.CER 0402N7R0C500CT
C2660 4030022880 S.CER 0402N560J500CT
C2661 4030022560 S.CER 0402N5R0B500CT
C2662 4030022880 S.CER 0402N560J500CT
C2663 4030022560 S.CER 0402N5R0B500CT
C2664 4030022710 S.CER 0402N181J500CT
C2665 4030022600 S.CER 0402N9R0C500CT
C2666 4030023090 S.CER 0402B102K500CT
C2667 4030023030 S.CER 0402B103K250CT
C2701 4030022650 S.CER 0402N110J500CT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B 90.8/93.1
B 89.5/90.9
B 92.0/92.6
B 89.9/89.6
B 90.7/90.5
B 89.9/88.7
B 91.1/89.3
B 90.3/86.9
B 89.9/87.8
T 94.8/85.9
T 91.6/90.2
T 92.3/81.4
T 95.1/83.1
T 92.2/77.8
T 89.8/77.8
B 88.3/79.3
B 77.4/83.6
B 89.3/82.6
B 86.1/80.3
B 86.4/82.7
B 85.9/84.0
B 85.2/80.3
B 85.9/75.8
B 85.5/85.5
B 85.5/86.4
B 83.8/77.1
B 82.6/77.3
B 79.4/85.5
B 81.4/76.9
B 78.2/85.1
B 79.4/83.9
B 80.7/80.8
T 77.1/83.0
T 72.3/80.8
T 75.3/83.1
B 71.5/80.7
B 69.9/80.6
T 98.8/111.2
T 74.8/85.6
T 70.4/82.2
T 69.8/80.2
B 66.2/91.9
B 65.7/90.7
B 64.6/91.9
B 63.0/91.9
B 61.9/89.5
B 61.3/91.9
B 60.4/89.5
B 59.7/91.9
B 58.3/89.5
B 57.8/90.7
B 57.4/89.5
B 55.1/91.7
T 64.3/89.7
B 67.5/85.6
B 66.6/84.8
B 66.2/86.0
B 65.7/84.8
B 64.7/87.2
B 63.6/84.8
B 63.1/87.2
B 62.1/84.8
B 61.5/87.2
B 59.9/86.0
B 59.9/87.2
B 59.0/86.0
B 58.3/87.2
B 58.1/86.0
B 56.7/87.2
T 65.8/84.9
B 54.2/85.4
B 67.6/82.5
B 66.0/81.3
B 66.0/82.5
B 65.1/81.3
B 64.4/82.5
B 64.2/81.3
B 62.8/82.5
B 62.1/80.1
B 61.2/82.5
B 60.6/80.1
B 59.6/82.5
B 58.4/80.1
B 58.0/81.3
B 55.2/82.4
B 56.6/80.1
T 65.7/80.3
B 68.2/75.4
B 67.0/77.8
B 66.7/75.4
B 65.4/77.8
B 64.2/75.4
B 63.8/77.8
B 62.9/75.4
B 62.2/77.8
B 60.4/76.6
B 60.6/77.8
B 59.5/76.6
B 59.0/77.8
B 58.6/76.6
B 57.4/77.8
B 55.7/77.8
T 65.3/76.3
B 67.8/73.1
(Amended page)
[MAIN UNIT]
H/V
REF PART
NO. NO.
C2702 4030022690 S.CER 0402N151J500CT
C2703 4030022560 S.CER 0402N5R0B500CT
C2704 4030022840 S.CER 0402N390J500CT
C2705 4030022560 S.CER 0402N5R0B500CT
C2706 4030022810 S.CER 0402N330J500CT
C2707 4030022600 S.CER 0402N9R0C500CT
C2708 4030022550 S.CER 0402N4R0B500CT
C2709 4030022580 S.CER 0402N7R0C500CT
C2710 4030022680 S.CER 0402N150J500CT
C2711 4030022540 S.CER 0402N3R0B500CT
C2712 4030022700 S.CER 0402N180J500CT
C2713 4030022530 S.CER 0402N2R0B500CT
C2714 4030022650 S.CER 0402N110J500CT
C2715 4030023090 S.CER 0402B102K500CT
C2716 4030023030 S.CER 0402B103K250CT
C2751 4030023030 S.CER 0402B103K250CT
C2752 4030023090 S.CER 0402B102K500CT
C2753 4030022700 S.CER 0402N180J500CT
C2755 4030022700 S.CER 0402N180J500CT
C2756 4030022570 S.CER 0402N6R0C500CT
C2757 4030022540 S.CER 0402N3R0B500CT
C2758 4030022570 S.CER 0402N6R0C500CT
C2759 4030022550 S.CER 0402N4R0B500CT
C2760 4030022630 S.CER 0402N100C500CT
C2761 4030022550 S.CER 0402N4R0B500CT
C2762 4030022810 S.CER 0402N330J500CT
C2763 4030022530 S.CER 0402N2R0B500CT
C2764 4030022570 S.CER 0402N6R0C500CT
C2765 4030022570 S.CER 0402N6R0C500CT
C2766 4030022790 S.CER 0402N2R5B500CT
C2768 4030022550 S.CER 0402N4R0B500CT
C2769 4030023090 S.CER 0402B102K500CT
C2771 4030023090 S.CER 0402B102K500CT
C2772 4030023090 S.CER 0402B102K500CT
C2773 4030023090 S.CER 0402B102K500CT
C2774 4030022640 S.CER 0402N101J500CT
C2801 4030023030 S.CER 0402B103K250CT
C2802 4030023090 S.CER 0402B102K500CT
C2803 4030023090 S.CER 0402B102K500CT
C2804 4030023090 S.CER 0402B102K500CT
C2805 4030022740 S.CER 0402N220J500CT
C2806 4030023090 S.CER 0402B102K500CT
C2908 4030023090 S.CER 0402B102K500CT
C2916 4030019560 S.CER GRM21BB31C106KE15L
C3001 4030023010 S.CER 0402B104K160CT
C3002 4030023010 S.CER 0402B104K160CT
C3003 4030020190 S.CER GRM32EB31C476KE15L
C3011 4030023010 S.CER 0402B104K160CT
C3012 4030022670 S.CER 0402N121J500CT
C3013 4030022740 S.CER 0402N220J500CT
C3014 4030022670 S.CER 0402N121J500CT
C3015 4030022880 S.CER 0402N560J500CT
C3016 4030022700 S.CER 0402N180J500CT
C3017 4030022880 S.CER 0402N560J500CT
C3018 4030023010 S.CER 0402B104K160CT
C3019 4030023010 S.CER 0402B104K160CT
C3021 4030023200 S.CER 0402B471K500CT
C3022 4030023010 S.CER 0402B104K160CT
C3023 4030023010 S.CER 0402B104K160CT
C3024 4030023010 S.CER 0402B104K160CT
C3031 4030023090 S.CER 0402B102K500CT
C3032 4030023090 S.CER 0402B102K500CT
C3033 4030023090 S.CER 0402B102K500CT
C3035 4030022660 S.CER 0402N120J500CT
C3036 4030022880 S.CER 0402N560J500CT
C3037 4030022660 S.CER 0402N120J500CT
C3038 4030022630 S.CER 0402N100C500CT
C3039 4030022700 S.CER 0402N180J500CT
C3040 4030022770 S.CER 0402N270J500CT
C3041 4030022560 S.CER 0402N5R0B500CT
C3042 4030022880 S.CER 0402N560J500CT
C3043 4030022660 S.CER 0402N120J500CT
C3044 4030022810 S.CER 0402N330J500CT
C3045 4030023090 S.CER 0402B102K500CT
C3046 4030022600 S.CER 0402N9R0C500CT
C3051 4030023200 S.CER 0402B471K500CT
C3052 4030023200 S.CER 0402B471K500CT
C3053 4030022560 S.CER 0402N5R0B500CT
C3054 4030022560 S.CER 0402N5R0B500CT
C3055 4030023200 S.CER 0402B471K500CT
C3056 4030023200 S.CER 0402B471K500CT
C3058 4030023200 S.CER 0402B471K500CT
C3059 4030023200 S.CER 0402B471K500CT
C3073 4030023090 S.CER 0402B102K500CT
C3075 4030019120 S.CER GRM188B31E105KA75D
Eqv. 4030025230 S.CER TMK107BJ105KAHT
Eqv. 4030025410 S.CER GRM188B31E105KAADD
C3076 4030019120 S.CER GRM188B31E105KA75D
Eqv. 4030025230 S.CER TMK107BJ105KAHT
Eqv. 4030025410 S.CER GRM188B31E105KAADD
C3078 4030023010 S.CER 0402B104K160CT
C3079 4030023030 S.CER 0402B103K250CT
C3081 4030019120 S.CER GRM188B31E105KA75D
Eqv. 4030025230 S.CER TMK107BJ105KAHT
Eqv. 4030025410 S.CER GRM188B31E105KAADD
C3082 4030023010 S.CER 0402B104K160CT
C3083 4030019120 S.CER GRM188B31E105KA75D
Eqv. 4030025230 S.CER TMK107BJ105KAHT
Eqv. 4030025410 S.CER GRM188B31E105KAADD
C3091 4030023090 S.CER 0402B102K500CT
C3093 4030023090 S.CER 0402B102K500CT
C3102 4030023010 S.CER 0402B104K160CT
C3103 4030018600 S.CER C1608 CH 1H 152J-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
11
DESCRIPTION M.
LOCATION
B 66.0/71.9
B 66.2/73.1
B 65.1/71.9
B 64.6/73.1
B 64.2/71.9
B 63.0/73.1
B 62.0/70.7
B 61.4/73.1
B 60.5/70.7
B 59.8/73.1
B 58.4/70.7
B 57.9/71.9
B 57.5/70.7
B 55.5/72.9
T 65.3/71.8
B 75.8/78.4
B 72.1/78.0
B 74.5/77.5
B 74.5/76.0
B 65.3/68.1
B 63.7/68.1
B 64.8/66.9
B 60.7/68.1
B 63.3/66.9
B 60.3/66.9
B 61.2/66.9
B 58.2/65.9
B 57.9/67.1
B 57.3/65.9
B 56.3/67.1
B 56.4/65.9
T 57.0/67.7
B 73.8/65.5
B 67.1/68.1
B 69.7/66.0
B 68.8/66.0
B 47.4/92.9
B 52.8/89.8
B 51.2/88.1
B 49.2/88.5
B 50.6/84.4
B 51.8/83.5
T 78.5/100.4
T 75.2/64.0
T 12.6/49.7
T 10.8/61.2
T
T 13.8/50.8
T 16.6/44.7
T 19.5/47.3
T 16.6/46.4
T 19.8/53.5
T 19.8/52.6
T 21.1/53.0
B 22.2/46.0
T 29.3/46.3
B 23.3/41.3
B 23.3/42.2
B 24.7/42.0
B 25.6/37.9
T 28.1/54.4
B 23.9/54.2
B 27.4/55.1
B 25.9/57.5
B 25.9/58.4
B 24.7/57.9
B 25.2/59.3
B 24.7/61.4
B 26.0/61.8
B 25.2/62.7
B 26.8/62.7
B 25.9/65.4
B 25.9/67.0
B 25.9/68.6
B 25.2/60.2
B 18.5/50.7
B 21.4/51.3
B 18.5/56.5
B 18.5/57.9
B 18.9/63.1
B 21.3/62.6
B 22.1/66.9
B 18.9/66.2
T
T 15.9/38.2
T 17.3/38.2
B 19.2/35.7
T 20.8/42.2
T 19.9/36.2
B 19.2/31.8
B 15.0/29.7
B 10.9/70.0
T 10.8/64.8
B 25.9/32.9
B 29.4/32.9
H/V
8.5/63.2
3.4/54.0
