Unlike most gigabit Ethernet media converters, which allow only two media
converters in series, the SFMFF13xx-28x has a retiming/reshaping feature that
makes it possible to connect any number of media converters in series.
Part Number
Port One - Duplex Fiber Optic
1000Base-SX
SFMFF1314-280
SC, 850 nm multimode
220 m (721 ft)**
SFMFF1315-280
SC, 850 nm multimode
220 m (721 ft)**
SFMFF1317-280
SC, 850 nm multimode
220 m (721 ft)**
SFMFF1324-280
SC, 850 nm multimode
220 m (721 ft)**
SFMFF1335-280
SC, 850 nm multimode
220 m (721 ft)**
Unless otherwise indicated, the distances listed are the typical maximum cable
distance. The actual maximum cable distances are dependent upon the physical
characteristics of the network installation.
** Minimum Cable Distance:
Typical Maximum Cable Distance:
NOTE: The CFMFF13xx-28x model is the chassis version of the media converter.
For more information, see the user's guide on-line at: www.transition.com.
SFMFF13xx-28x
User's Guide
Single Mode to Multimode Retiming
Media Converter
• Stand-Alone Media Converter
• Gigabit Ethernet
Transition Networks SFMFF13xx-28x series
media converters extend multimode
interfaces over gigabit Ethernet fiber optic
cable.
Port Two - Duplex Fiber-Optic
1000Base-LX
SC, 1310 nm single mode
10 km (6.2 miles)
SC, 1310 nm single mode
25 km (15.5 miles)
SC, 1550 nm single mode
65 km (40.3 miles)
SC, 1300 nm multimode
(1000Base-SX) 2 km (1.2 miles)
(62.5 / 125 mm fiber only)
SC, 1550 nm single mode
125 km (77.5 mi)
2 meters
220 meters for 160/500MHz•Km
270 meters for 200/500MHz•Km
Installation . . . . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . . . .6
Cable Specifications . . . . . . . . . . . .7
Technical Specifications . . . . . . . .8
Troubleshooting . . . . . . . . . . . . . . .9
Contact Us . . . . . . . . . . . . . . . . . .11
Compliance Information . . . . . . .12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFMFF1314-280 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Transition Networks SFMFF1314-280

Summary of Contents for Transition Networks SFMFF1314-280

  • Page 1 Unlike most gigabit Ethernet media converters, which allow only two media converters in series, the SFMFF13xx-28x has a retiming/reshaping feature that makes it possible to connect any number of media converters in series. Part Number Port One - Duplex Fiber Optic...

  • Page 2: Optional Accessories

    SFMFF13xx-28x Part Number Port One - Duplex Fiber Optic Port Two - Single Mode Fiber-Optic 1000Base-SX Single Fiber, 1000Base-LX SFMFF1329-280 SC, 850 nm multimode SC, 1310 nm (TX)/1550 nm (RX) 220 m (721 ft)** 20 km (12.4 miles) SFMFF1329-281 SC, 850 nm multimode SC, 1550 nm (TX)/1310 nm (RX) 220 m (721 ft)** 20 km (12.4 miles)

  • Page 3: Power The Media Converter

    SFMFF13xx-28x Installation -- Continued Pause (Switches 3 & 4) The pause feature can improve network performance by allowing one end of the link to signal the other to discontinue frame transmission for a set period of time to relieve buffer congestion. To properly set the pause feature in the network, the link partner (i.e., the device to which the SFMFF13xx-28x is linked) must also have comparable pause switches.

  • Page 4: Operation

    1300 nm multimode Fiber-optic Transmitter Power: min: -10.0 dBm Fiber-optic Receiver Sensitivity: min: -17.0 dBm Link Budget: 7.0 dB Port 2: SFMFF1314-280 1310 nm single mode Fiber-optic Transmitter Power: min: -13.0 dBm Fiber-optic Receiver Sensitivity: min: -20.0 dBm Link Budget: 7.0 dB...

  • Page 5: Technical Specifications

    SFMFF13xx-28x Technical Specifications For use with Transition Networks Model SFMFF13xx-28x or equivalent Standards IEEE 802.3™ 2000 (802.3z) Dimensions 3.25" x 1.0" x 4.7" (83 mm x 25 mm x 119 mm) Weight 10 oz. (283 g) (approximate) Data Rate 1000 Mb/s Power Consumption 3.6 watts (typical) Power Supply...
  • Page 6 Transition Networks 6475 City West Parkway, Minneapolis MN 55344 USA Model: SFMFF13xx-28x Series Media Converters Part Number(s): SFMFF1314-280, SFMFF1315-280, SFMFF1317-280, SFMFF1324-280, SFMFF1335-280, SFMFF1329-280, SFMFF1329-281, SFMFF1329-282, SFMFF1329-283 Regulation: EMC Directive 89/336/EEC Purpose: To declare that the SFMFF13xx-28x to which this declaration refers is in conformity with the following standards.

  • Page 7: Compliance Information

    Compliance Information CISPR22/EN55022 Class A CE Mark FCC Regulations This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
