Page 1 Round baler Comprima F 125 (XC) Comprima F 155 (XC) Comprima V 150 (XC) Comprima V 180 (XC) Comprima V 210 (XC) (from serial no.: 911 095) Order no.: 150 000 126 08 en 25.11.2014...
Page 2 KRONE Round Baler Machine: Type / Types: Comprima F 125 / Comprima F 125 XC Comprima F 155 / Comprima F 155 XC Comprima V 150 / Comprima V 150 XC Comprima V 180 / Comprima V 180 XC...
Page 3: Foreword
Pos: 3.2 /BA/Vorwort/Rundballenpressen/Verehrter Kunde Rundballenpresse @ 27\mod_1246526159413_78.docx @ 267781 @ @ 1 Dear Customer! By purchasing the round baler, you have acquired a quality product from KRONE. We are grateful for the confidence you have invested in us in buying this machine.
Page 4: Table Of Contents
Intended use ............................. 14 Technical data ..........................15 3.5.1 Technical Data Comprima F 125/ Comprima F 125 XC ............15 3.5.2 Technical Data Comprima F 155/ Comprima F 155 XC ............16 ...
Page 5 5.6.1 Net brake ........................... 64 Installation of Lighting System ......................64 KRONE operation terminal Alpha ....................... 65 KRONE Operation Terminal Alpha ....................65 6.1.1 General Description ........................65 ...
Page 6 7.13.2 Physical messages ......................... 129 7.13.3 General Messages ........................130 KRONE ISOBUS-Terminal CCI 100 ....................132 Installing the terminal into cabin ..................... 133 ISOBUS Short Cut Button ......................134 ...
Page 7 Connection Terminal to Tractor ....................190 9.1.2 Connection Tractor to Machine ....................190 Differing functions to KRONE ISOBUS terminal CCI ..............190 ISOBUS „Auxiliary“-function (AUX) ....................192 9.3.1 Example of joystick assignment for Fendt (default setting) ............ 193 ...
Page 8 Table of Contents 12.2 Hydraulics ............................210 12.2.1 Special Safety Instructions ...................... 210 12.2.2 Connecting the hydraulic lines ....................211 12.3 Hydraulic brake (Export) ........................ 213 12.4 Hydraulic brake (auxiliary brake) ....................213 ...
Page 9 Table of Contents 14.17 Net Wrapping ..........................255 14.17.1 Net wrapping parts ........................256 14.17.2 Function of the Net Tying ......................256 14.18 Inserting the Net Roll ........................257 14.18.1 Insert Net ..........................
Page 10 19.3 Malfunctions on the central chain lubrication system ..............348 19.4 Error Messages of KRONE Operation Terminal ................348 Disposal of the machine ........................349 20.1 Disposal of the machine ......................... 349 ...
Page 11 Table of Contents Pos: 7 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 12: Introduction
Pick-up as it passes over them. Pos: 9.5 /Überschriften/Überschriften 3/A-E/A/Ansprechpartner @ 0\mod_1195569394286_78.docx @ 839 @ 2 @ 1 3.1.1 Contact Pos: 9.6 /BA/Adressen/Adresse Maschinenfabrik KRONE Spelle @ 0\mod_1195568531083_78.docx @ 734 @ @ 1 Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Strasse 10 D-48480 Spelle (Germany) Telephone: + 49 (0) 59 77/935-0 (Head Office) Fax.: + 49 (0) 59 77/935-339 (Head Office)
Page 13: Identification Plate
Authentic KRONE spare parts and accessories authorised by the manufacturer help to ensure safety. The use of spare parts, accessories and other devices which are not manufactured, tested or approved by KRONE will result in the revoking of the liability for damages resulting thereof.
Page 14: Intended Use
Introduction Pos: 9.12.1 /Überschriften/Überschriften 2/A-E/Bestimmungsgemäße Verwendung @ 103\mod_1332169199326_78.docx @ 940071 @ 2 @ 1 Intended use Pos: 9.12.2 /BA/Einleitung/Bestimmungsgemäßer Gebrauch/Rundballenpresse/Bestimmungsgemäßer Gebrauch Rundballenpresse @ 32\mod_1253019678915_78.docx @ 308291 @ @ 1 The round baler is built exclusively for customary use in agricultural work (intended use). Pos: 9.12.3 /BA/Einleitung/Bestimmungsgemäßer Gebrauch/Nicht bestimmungsgemäß...
Page 15: Technical Data
We reserve the right to make design changes at any time and without notification of reasons. Pos: 9.15 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Comprima F 125 @ 38\mod_1265188510030_78.docx @ 345240 @ 3 @ 1 3.5.1...
Page 16: Technical Data Comprima F 155/ Comprima F 155 Xc
Introduction Pos: 9.17 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Comprima F 155 @ 38\mod_1265192006264_78.docx @ 345265 @ 3 @ 1 3.5.2 Technical Data Comprima F 155/ Comprima F 155 XC Comprima F155 Comprima F155 XC (without cutting (with cutting system) system) Axle Single axle Single axle Tandem axle Pick-up (width)
Page 17: Technical Data Comprima V 150/ Comprima V 150 Xc
Introduction Pos: 9.19 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Comprima V 150 @ 104\mod_1332319166609_78.docx @ 942644 @ 3 @ 1 3.5.3 Technical Data Comprima V 150/ Comprima V 150 XC Comprima V 150 Comprima V 150 XC (without cutting (with cutting system) system) Axle Single axle Single axle...
Page 18: Technical Data Comprima V 180/ Comprima V 180 Xc
Introduction Pos: 9.21 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Comprima V 180 @ 38\mod_1265194153201_78.docx @ 345490 @ 3 @ 1 3.5.4 Technical Data Comprima V 180/ Comprima V 180 XC Comprima V 180 Comprima V 180XC (without cutting (with cutting system) system) Axle Single axle Single axle Tandem axle...
Page 19: Technical Data Comprima V 210/ Comprima V 210 Xc
Introduction Pos: 9.23 /Überschriften/Überschriften 3/P-T/Technische Daten V210 @ 84\mod_1319023911900_78.docx @ 736748 @ 3 @ 1 3.5.5 Technical Data Comprima V 210/ Comprima V 210 XC Pos: 9.24 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Comprima V 210 MC @ 57\mod_1295439313843_78.docx @ 543548 @ @ 1 Comprima V210 Comprima V210 MC (without cutting system)
Page 20: Safety
Safety Pos: 11 /Überschriften/Überschriften 1/P-T/Sicherheit @ 0\mod_1195566748646_78.docx @ 635 @ 11 @ 1 Safety Pos: 12 /BA/Sicherheit/6. Überarbeitete Warnhinweise/Kennzeichnung von Hinweisen in der Betriebsanleitung Einführungstext (2012-07-27 09:59:06) @ 0\mod_1195637804826_78.docx @ 1098 @ 2 @ 1 Identifying Symbols in the Operating Instructions The safety instructions contained in this manual which could result in personal injury if not followed are identified by the general danger sign: Pos: 13 /BA/Sicherheit/6.
Page 21: Basic Safety Instructions
Safety Pos: 16 /Überschriften/Überschriften 2/F-J/Grundlegende Sicherheitshinweise @ 186\mod_1380009482364_78.docx @ 1606585 @ 22 @ 1 Basic safety instructions Pos: 17.1 /BA/Sicherheit/Personalqualifikation und -schulung @ 0\mod_1195639383185_78.docx @ 1136 @ 3 @ 1 4.3.1 Personnel Qualification and Training The machine may be used, maintained and repaired only by persons who are familiar with it and have been instructed about the dangers connected with it.
Page 22: Safety Instructions And Accident Prevention Regulations
Safety Pos: 17.6 /BA/Sicherheit/Sicherheits- und Unfallverhütungs-VorschriftenRundballenpressen @ 240\mod_1395127554138_78.docx @ 1888942 @ 2 @ 1 Safety Instructions and Accident Prevention Regulations Please follow all generally applicable safety and accident prevention regulations in addition to the safety instructions contained in these operating instructions! The attached warning and safety signs provide important information for safe operation.
Page 23: Hitched Implements
Safety 25 Parts operated by external power (e.g. hydraulically) can cause crushing and shearing injuries! Pos: 17.7 /BA/Sicherheit/Sicherheit-Verlassen des Traktors @ 240\mod_1395128143546_78.docx @ 1889191 @ @ 1 26 Before leaving the tractor, actuate the parking brake, switch off the engine, remove the ignition key and carry it with you.
Page 24: Pto Operation
Safety Pos: 17.10 /BA/Sicherheit/Zapfwellenbetrieb Traktor RB @ 156\mod_1364225944809_78.docx @ 1383869 @ 2 @ 1 PTO operation Use only universal shafts specified by the manufacturer! The guard tube and guard cone of the universal shaft and the PTO guard must be attached and in good working condition –...
Page 25: Hydraulic System
Safety Pos: 17.13 /BA/Sicherheit/Hydraulikanlage @ 2\mod_1203503691986_78.docx @ 66225 @ 2 @ 1 Hydraulic system 1 The hydraulic system is pressurised! 2 When connecting hydraulic cylinders and motors, make sure the hydraulic hoses are connected as specified! 3 When connecting the hydraulic hoses to the tractor hydraulics, make sure that the hydraulics of both the tractor and the implement have been depressurized! 4...
Page 26: Maintenance
Spare parts must at least comply with the technical requirements determined by the manufacturer of the implements! This is ensured by KRONE original spare parts! Pos: 17.21 /BA/Sicherheit/Wartung/Wartung Zusatz Bei Gasspeicherung/Schneidwekzeuge @ 2\mod_1203504102830_78.docx @ 66265 @ @ 1 9...
Page 27: Unauthorised Conversion/Modification And Spare Parts Production
Safety Pos: 17.26 /BA/Sicherheit/Eigenmächtiger Umbau und Ersatzteilherstellung @ 1\mod_1201937705539_78.docx @ 55745 @ 2 @ 1 4.11 Unauthorised Conversion/Modification and Spare Parts Production Conversions or modifications of the machine are permitted only with prior consultation with the manufacturer. Original spare parts and accessories authorised by the manufacturer help to ensure safety.
Page 28: Position Of The Adhesive Safety Stickers On The Machine
Safety Pos: 20.1 /Überschriften/Überschriften 2/K-O/Lage der Sicherheitsaufkleber an der Maschine @ 0\mod_1195634967326_78.docx @ 1020 @ 2 @ 1 4.14 Position of the Adhesive Safety Stickers on the Machine Pos: 20.2 /BA/Sicherheit/Aufkleber/Rundballenpresse/Sicherheitsaufkleber Comprima F XC @ 295\mod_1412238292704_78.docx @ 2320887 @ @ 1 Comprima F125/F155 (XC) RPN00039_3 Fig.
Page 29 Safety Before starting the machine, The PTO speed must not exceed 540 rpm! The read and observe the operating operating pressure of the hydraulic system must instructions and safety not exceed 200 bar! instructions. 939 100-4 540/ MAX. 939 471 1 (1x) MAX.
Page 30 Safety Pos: 20.4 /BA/Sicherheit/Aufkleber/Rundballenpresse/Sicherheitsaufkleber Comprima V XC @ 201\mod_1385563046804_78.docx @ 1688093 @ @ 1 Comprima V 150/V 180/V210 (XC) VPN00002_3 Fig. 4 VPN00003_3 Fig. 5...
Page 31 Safety Before starting the machine, The PTO speed must not exceed 540 rpm! The read and observe the operating operating pressure of the hydraulic system must instructions and safety not exceed 200 bar! instructions. 939 100-4 540/ MAX. 939 471 1 (1x) MAX.
Page 32: Re-Ordering The Adhesive Safety And Information Labels
Safety Pos: 20.6 /BA/Sicherheit/6. Überarbeitete Warnhinweise/Hinweis - Nachbestellung/ Anbringung Aufkleber @ 0\mod_1195637337107_78.docx @ 1079 @ 33 @ 1 4.14.1 Re-Ordering the Adhesive Safety and Information Labels Note Every adhesive safety and information label is assigned an order number and can be ordered directly from the manufacturer or from an authorized dealer (see Section "Contact").
Page 33: Safety Routines
Safety Pos: 22.1 /Überschriften/Überschriften 2/P-T/Sicherheitsroutinen @ 187\mod_1380089318480_78.docx @ 1608182 @ 2 @ 1 4.15 Safety routines Pos: 22.2 /Überschriften/Überschriften 3/K-O/Maschine stillsetzen und sichern @ 190\mod_1381323544614_78.docx @ 1624780 @ 3 @ 1 4.15.1 Stopping and securing the machine Pos: 22.3 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine stillsetzen und sichern -gezogene Maschinen_mit Feststellbremse @ 244\mod_1395817975869_78.docx @ 1909963 @ @ 1 WARNING! Crush hazard due to movement of the machine or machine parts! If the machine has not been shut down, the machine or machine parts may move...
Page 34: Coupling The Machine Safely
Safety Pos: 22.7 /Überschriften/Überschriften 3/K-O/Maschine sicher ankuppeln @ 274\mod_1404282415732_78.docx @ 2062014 @ 3 @ 1 4.15.3 Coupling the machine safely Pos: 22.8 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine an den Traktor ankuppeln (BiG PACK) @ 273\mod_1404105657612_78.docx @ 2057995 @ @ 1 WARNING! Risk of injury when coupling the machine The machine or machine parts may move unintentionally while the machine is coupled to the tractor.
Page 35: Preparing The Machine For Repair, Maintenance And Adjustment Work
Safety Pos: 22.12 /Überschriften/Überschriften 3/K-O/Maschine für Instandhaltungs-, Reparatur-, Wartungs- und Einstellarbeiten vorbereiten @ 274\mod_1404283183227_78.docx @ 2062418 @ 3 @ 1 4.15.5 Preparing the machine for repair, maintenance and adjustment work Pos: 22.13 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine für Instandhaltungs-, Reparatur-, Wartungs- und Einstellarbeiten vorbereiten @ 272\mod_1403522290336_78.docx @ 2051115 @ @ 1 WARNING! Risk of injury during repair, maintenance and adjustment work on the machine.
Page 36: Safety Equipment
Safety Pos: 24.1 /Überschriften/Überschriften 3/P-T/Sicherheitsausstattung @ 65\mod_1301322015268_78.docx @ 588814 @ 3 @ 1 4.15.7 Safety Equipment Pos: 24.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Gefahr - Funktion Sicherheitseinrichtungen Maschine @ 211\mod_1389263571993_78.docx @ 1734475 @ @ 1 WARNING! - Unexpected movement of components due to defective safety equipment! Effect: Danger to life, risk of a serious accident or damage to the machine •...
Page 37: Attaching The Safety Cable
Safety Pos: 24.11 /Überschriften/Überschriften 3/P-T/Sicherungsseil anbringen @ 289\mod_1410256423639_78.docx @ 2286884 @ 3 @ 1 4.15.9 Attaching the safety cable Pos: 24.12 /BA/Inbetriebnahme/Feststellbremse/Handbremse mit Seil Bild Comprima @ 295\mod_1411992662492_78.docx @ 2315767 @ @ 1 KWT20026 COM00367 Fig. 7 Pos: 24.13 /BA/Inbetriebnahme/Feststellbremse/Sicherungsseil betätigen KWT 2000 @ 289\mod_1410252873946_78.docx @ 2286392 @ @ 1 The safety cable (1) applies the parking brake (3) if the machine breaks away from the tractor while it is driving.
Page 38: Parking Support
Safety Pos: 24.15 /Überschriften/Überschriften 3/A-E/A/Abstellstütze @ 109\mod_1335355963452_78.docx @ 976541 @ 3 @ 1 4.15.10 Parking Support Pos: 24.16 /BA/Sicherheit/Rundballenpresse/Allgemeiner Text Abstellstütze Ultima @ 159\mod_1365421830511_78.docx @ 1407965 @ @ 1 When the machine is not connected to the tractor, the parking support (1) ensures the stability of the machine.
Page 39: Wheel Chocks
Safety Pos: 24.25 /Überschriften/Überschriften 3/U-Z/Unterlegkeile @ 33\mod_1254202555660_78.docx @ 318451 @ 3 @ 1 4.15.12 Wheel chocks Pos: 24.26 /BA/Fahren und Transport/Rundballenpresse/Bild Unterlegkeile Comprima neu @ 292\mod_1411049005397_78.docx @ 2302669 @ @ 1 Fig. 10 Pos: 24.27 /BA/Fahren und Transport/Rundballenpresse/Text Pos. Unterlegkeile Comprima F/V x-treme @ 292\mod_1411104706771_78.docx @ 2303581 @ @ 1 The wheel chocks (1) are kept in a holder at the front left beside the drawbar.
Page 40: Stop Points
Safety Pos: 24.31 /Überschriften/Überschriften 3/A-E/A/Anschlagpunkte @ 168\mod_1368430700205_78.docx @ 1453905 @ 3 @ 1 4.15.14 Stop Points Pos: 24.32 /BA/Sicherheit/7. Gefahrenhinweise alt/Warnung - Anheben @ 168\mod_1368433456450_78.docx @ 1454049 @ @ 1 WARNING! Danger from falling loads! • Never step or stay under suspended loads! •...
Page 41: Shut-Off Valve For Tailgate
Safety Pos: 24.35 /Überschriften/Überschriften 3/A-E/A/Absperrhahn Heckklappe @ 34\mod_1255589255891_78.docx @ 324197 @ 3 @ 1 4.15.17 Shut-off valve for tailgate Pos: 24.36 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Absperrhahn Hydraulikzyl geschlossen @ 34\mod_1256114957331_78.docx @ 325995 @ @ 1 DANGER! – Settings on the machine! Danger to life or serious injuries. •...
Page 42: Step For Working On The Linkage
Safety Pos: 24.40 /Überschriften/Überschriften 3/P-T/Trittstufe für Arbeiten am Bindemechanismus @ 292\mod_1411108971813_78.docx @ 2303616 @ 3 @ 1 4.15.18 Step for working on the linkage Pos: 24.41 /BA/Sicherheit/2. Vorangestellte Warnhinweise/Kopie von WARNUNG - Zugang zur Maschine @ 295\mod_1411994870948_78.docx @ 2316787 @ @ 1 WARNING! Risk of injury when climbing up and down.
Page 43: Commissioning
Commissioning Pos: 26.1 /Überschriften/Überschriften 1/A-E/Erstinbetriebnahme @ 0\mod_1196314201498_78.docx @ 5855 @ 1 @ 1 Commissioning Pos: 26.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Inbetriebnahme/Unvorhergesehene Inbetriebnahme Fortima V 1500 MC @ 209\mod_1387357052199_78.docx @ 1724288 @ @ 1 DANGER! - Unintentional starting, moving machine components and / or unexpected machine movement! Effect: Risk of death, injuries or damage to the machine.
Page 44 Commissioning Pos: 26.6 /BA/Erstinbetriebnahme/Rundballenpresse/Teile Erstinbetriebnahme_Comprima F/V @ 225\mod_1392634851941_78.docx @ 1823269 @ @ 1 COM00004_3 Fig. 14 Pos. Designation Storage location Bale ejector under the machine Spacer (Comprima V180 (XC)) Twine box Small parts Twine box Guard cup Bale chamber Eye screws Twine box Springs Twine box...
Page 45 Commissioning KR-1-081 Fig. 15 • Park the machine on firm, level ground. • Place two wheel chocks (1) under the wheels to prevent the machine from rolling away. VP800016 Fig. 16 • Take the bag with the small parts (1) out of the twine box.
Page 46 Commissioning RBV01170 Fig. 17 • Relieve all pressure from the tractor hydraulics. • Connect the hydraulic hoses (1), (2) and (3) to the tractor hydraulics according to colour coding. RBV0116A Fig. 18 • Set the control valve (1) for "Open tailgate (2)" to "Raise". Pos: 26.9 /BA/Sicherheit/Module Achtung/Gefahr - Geöffnete Heckklappe @ 32\mod_1253180791300_78.docx @ 312630 @ @ 1 DANGER! –...
Page 47 Commissioning Pos: 26.11 /BA/Erstinbetriebnahme/Rundballenpresse/Heckklappe sperren Comprima @ 103\mod_1332165161046_78.docx @ 939811 @ @ 1 CPK00230_3 Fig.19 • Swivel the shut-off valve (1) of the left lifting cylinder from position (a) to position (b). Tailgate is locked hydraulically. Pos: 26.12 /BA/Erstinbetriebnahme/Rundballenpresse/Anbauanteile aus Ballenkammer entnehmen @ 72\mod_1306392448657_78.docx @ 645189 @ @ 1 RBV01150 Fig.
Page 48: Removing The Transport Holding Down Tensioning Device
Commissioning Pos: 26.14 /Überschriften/Überschriften 2/A-E/Demontage Transport-Niederhalte-Spannvorrichtung @ 169\mod_1369640231639_78.docx @ 1465252 @ 2 @ 1 Removing the transport holding down tensioning device Pos: 26.15 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F155 (XC) @ 79\mod_1314690325737_78.docx @ 697640 @ @ 1 Comprima F155 (XC) Pos: 26.16 /BA/Erstinbetriebnahme/Rundballenpresse/Hinweis Spannarme herunter ziehen @ 66\mod_1302006118603_78.docx @ 593450 @ @ 1 Note If the clamping arms of the machine were pulled down and attached for transportation with the tensioning system (not all truck types), the tensioning system must be removed before the...
Page 49 Commissioning COM00311 Fig. 23 • Remove the screw connection (5). • Remove the connecting tube (6) and link (7). Note Dispose of all removed parts properly. Reuse is not permitted! COM00312 Fig. 24 • Connect the plug connection (8) for the sensor on the left side of the machine. •...
Page 50: Assembling The Bale Ejector
Commissioning Pos: 26.19 /Überschriften/Überschriften 2/K-O/Montage Ballenauswerfer @ 32\mod_1253182217691_78.docx @ 312680 @ 2 @ 1 Assembling the bale ejector Pos: 26.20 /BA/Erstinbetriebnahme/Rundballenpresse/Optional für Comprima V @ 191\mod_1381762588149_78.docx @ 1630591 @ @ 1 Optional for Comprima V 150 Pos: 26.21.1 /BA/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/1_Schraubverbindungen der Aufnahmebleche lösen_Bild_Comprima @ 191\mod_1381922071542_78.docx @ 1633442 @ @ 1 Single axle Tandem axle COM00315...
Page 51 Commissioning Pos: 26.21.6 /BA/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/3_Leiste am Ballenauswerfer montieren_Bild_Comprima @ 191\mod_1381922407943_78.docx @ 1633646 @ @ 1 COM00316_1 Fig. 27 Pos: 26.21.7 /BA/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/3_Leiste am Ballenauswerfer montieren_Text @ 191\mod_1381922409479_78.docx @ 1633675 @ @ 1 • Fitting the strip (1) on the right and left of the bale ejector: Secure with a screw (2), washer (3) and locknut (4).
Page 52 Commissioning Pos: 26.21.14 /BA/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/6_Gestänge montieren_Bild_Comprima @ 295\mod_1412242167621_78.docx @ 2321309 @ @ 1 FOR00065 Fig. 29 Pos: 26.21.15 /BA/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/6_Gestänge montieren_Text @ 191\mod_1381922668059_78.docx @ 1633852 @ @ 1 • Push the linkage (1) on the right and left onto the stud bolts (2) on the frame and secure with a washer (3) and clamping sleeve (4).
Page 53 Commissioning Pos: 26.21.18 /BA/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/8_Sicherheitsfolie anbringen @ 192\mod_1381932917444_78.docx @ 1634412 @ @ 1 VP700016 Fig.31 • Attach the safety sheet (1) in the middle on the rear cross bar of the bale ejector (2). Pos: 26.22 /BA/Erstinbetriebnahme/Rundballenpresse/Zugstange versetzen @ 81\mod_1316516738368_78.docx @ 718489 @ @ 1 COM00327 Fig.
Page 54 Commissioning Pos: 26.24 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V180XC @ 79\mod_1314685787205_78.docx @ 697438 @ @ 1 Comprima V180 (XC) Pos: 26.25 /BA/Erstinbetriebnahme/Rundballenpresse/Bild Abstandhalter montieren Comprima V180 @ 72\mod_1306389688224_78.docx @ 644991 @ @ 1 VP700017 Fig. 33 Pos: 26.26 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V210 (XC) @ 84\mod_1319031579512_78.docx @ 736803 @ @ 1 Comprima V210 (XC) Pos: 26.27 /BA/Erstinbetriebnahme/Rundballenpresse/Bild Abstandhalter montieren @ 57\mod_1295446352140_78.docx @ 544411 @ @ 1 V2100000...
Page 55 Commissioning Pos: 26.30 /Überschriften/Bei Einzelachse @ 72\mod_1306389977797_78.docx @ 645051 @ @ 1 In Case of a Single Axle Pos: 26.31 /BA/Erstinbetriebnahme/Rundballenpresse/Bild bei Einzelachse Comprima @ 72\mod_1306390041232_78.docx @ 645075 @ @ 1 COM00317 Fig. 35 Pos: 26.32 /BA/Erstinbetriebnahme/Rundballenpresse/U-Blech @ 219\mod_1391008199383_78.docx @ 1772802 @ @ 1 •...
Page 56: Adjusting The Drawbar Height
Commissioning Pos: 26.35 /Überschriften/Überschriften 2/F-J/Höhenanpassung der Deichsel @ 17\mod_1236255816988_78.docx @ 204061 @ 2 @ 1 Adjusting the drawbar height Pos: 26.36 /BA/Sicherheit/7. Gefahrenhinweise alt/Inbetriebnahme/Gefahr - Unvorhergesehene Inbetriebnahme_2 BiG Pack @ 17\mod_1236255571519_78.docx @ 204032 @ @ 1 DANGER! - Unexpected movements of the machine! Effect: Danger to life, injuries or damage to the machine.
Page 57 Commissioning Pos: 26.43 /BA/Erstinbetriebnahme/Rundballenpresse/Deichselhöhe einstellen CF_CV @ 66\mod_1302004633503_78.docx @ 593369 @ @ 1 RPN00063 Fig.38 Note Before starting the adjustment set the machine on the parking support and uncouple the tractor. Adjusting the height of the drawbar: • Loosen the safety nuts (3) until the drawbar (1) can be turned in the lock washer connection.
Page 58: Pto Shaft
Commissioning Pos: 26.46 /Überschriften/Überschriften 2/F-J/Gelenkwelle @ 0\mod_1199781879794_78.docx @ 34542 @ 2 @ 1 PTO shaft Pos: 26.47 /Überschriften/Überschriften 3/K-O/Längenanpassung @ 1\mod_1201687632810_78.docx @ 53589 @ 3 @ 1 5.5.1 Length adjustment Pos: 26.48 /BA/Sicherheit/Gelenkwelle/ACHTUNG - Gekenkwelle vom Hersteller nicht spezifiziert @ 272\mod_1403599419151_78.docx @ 2052394 @ @ 1 ATTENTION! The use of a universal shaft not approved by the manufacturer and operation at a higher PTO speed can cause damage to the machine.
Page 59: Mounting The Pto Shaft On The Machine Side
Commissioning Pos: 26.54 /Überschriften/Überschriften 3/K-O/Maschinenseitige Montage der Gelenkwelle @ 32\mod_1253532604423_78.docx @ 314180 @ 3 @ 1 5.5.2 Mounting the PTO shaft on the machine side Pos: 26.55 /BA/Sicherheit/Gelenkwelle/Gefahr - Sich drehende Gelenkwelle_2 @ 0\mod_1199781692950_78.docx @ 34523 @ @ 1 Danger! - Rotating PTO shaft Effect: Danger to life or serious injuries •...
Page 60 Commissioning Pos: 26.59 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Bild Anbau Gelenkwellenhalter @ 32\mod_1253533150220_78.docx @ 314206 @ @ 1 RP-99-012 Fig. 41 Pos: 26.60 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Anbau Gelenkwellenhalter @ 32\mod_1253533341376_78.docx @ 314231 @ @ 1 • Switch off the engine and remove the ignition key. • Assemble the PTO shaft bracket (1) and secure the PTO shaft support (2). Pos: 26.61 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Bild Anbau Gelenkwelle @ 32\mod_1253534105814_78.docx @ 314281 @ @ 1 KR-1-080 Fig.
Page 61 Commissioning Pos: 26.64 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Zugöse drehen @ 77\mod_1310047904943_78.docx @ 667353 @ @ 1 COM00321 Fig. 43 Note To achieve greater PTO shaft freedom, the towing ring can be mounted in position (1) or (2) on the drawbar (3). • Use a suitable tool to loosen the screw connection (4). •...
Page 62: Attaching The Guard Cup For Universal Shaft
Commissioning Pos: 26.68 /Überschriften/Überschriften 3/A-E/A/Anbau des Schutztopfes für die Gelenkwelle @ 46\mod_1278501178484_78.docx @ 442635 @ 3 @ 1 5.5.3 Attaching the guard cup for universal shaft Pos: 26.69 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Bild Anbau Schutztopf Comprima C/V @ 81\mod_1316520279377_78.docx @ 718640 @ @ 1 RPN00100 Fig.
Page 63: Hose Holder Assembly
Commissioning Pos: 26.73 /Überschriften/Überschriften 2/K-O/Montage Schlauchhalter @ 32\mod_1253538064080_78.docx @ 314638 @ 2 @ 1 Hose holder assembly Pos: 26.74 /BA/Erstinbetriebnahme/Rundballenpresse/Bild Befestigungsmaterial @ 32\mod_1253535577392_78.docx @ 314511 @ @ 1 RBV01080 Fig. 46 Pos: 26.75 /BA/Erstinbetriebnahme/Rundballenpresse/Montage Befestigungsmaterial @ 32\mod_1253535783611_78.docx @ 314534 @ @ 1 •...
Page 64: Net Brake
Commissioning Pos: 26.79 /BA/Erstinbetriebnahme/Rundballenpresse/Netzbremse Fortima V 1500 MC @ 32\mod_1253193714019_78.docx @ 313061 @ 3 @ 1 5.6.1 Net brake Fig. 48 Before starting up for the first time, neatly remove the protective tape from the brake surface (1) of the net brake disc (2). Pos: 26.80 /BA/Erstinbetriebnahme/Rundballenpresse/Anbau Beleuchtungsanlage Comprima F/V @ 81\mod_1316523735423_78.docx @ 718872 @ 2 @ 1 Installation of Lighting System RPN00066...
Page 65: Krone Operation Terminal Alpha
Pos: 28 /Überschriften/Überschriften 1/K-O/KRONE Bedienterminal Alpha @ 51\mod_1288788599828_78.docx @ 497442 @ 3 @ 1 KRONE operation terminal Alpha Pos: 29.1 /Überschriften/Überschriften 2/K-O/KRONE Bedienterminal Alpha (Übersicht) @ 78\mod_1312872399342_78.docx @ 671353 @ 3 @ 1 KRONE Operation Terminal Alpha Pos: 29.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Achtung - Bedieneinheit schützen @ 0\mod_1200308247867_78.docx @ 39598 @ @ 1 Caution! - Protect Control Unit.
Page 66: Mounting The Control Unit
KRONE operation terminal Alpha Pos: 29.6 /Überschriften/Überschriften 3/A-E/B/Bedieneinheit montieren @ 83\mod_1317114999419_78.docx @ 726893 @ 4 @ 1 6.1.2 Mounting the Control Unit Pos: 29.7 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Bedieneinheit montieren @ 78\mod_1312878761653_78.docx @ 671550 @ @ 1 BPM50390_1 Fig. 51 Mount the control unit with its support (1) where the driver can see it.
Page 67: Control Unit
KRONE operation terminal Alpha Pos: 29.10 /Überschriften/Überschriften 3/A-E/B/Bedieneinheit @ 64\mod_1300173967609_78.docx @ 580758 @ 3 @ 1 6.1.3 Control Unit Pos: 29.11 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Bedieneinheit - Alpha @ 78\mod_1312881664219_78.docx @ 672000 @ @ 1 Overview RPM00001 Fig. 53 Key ON/OFF Pilot lamp ON/OFF "-"...
Page 68: Operational Readiness
KRONE operation terminal Alpha Pos: 29.13 /Überschriften/Überschriften 3/A-E/B/Betriebsbereitschaft @ 64\mod_1300174903968_78.docx @ 580838 @ 4 @ 1 6.1.4 Operational Readiness Pos: 29.14 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Betriebsbereitschaft @ 82\mod_1317026811213_78.docx @ 724690 @ @ 1 Switching ON RPM00002 Fig. 54 1. Actuate key. A brief self-test follows provided the electrical power supply has been properly connected.
Page 69: Adjusting The Net Wrappings
KRONE operation terminal Alpha Pos: 29.16 /Überschriften/Überschriften 4/A-E/Einstellen der Netzwicklungen @ 82\mod_1317028244320_78.docx @ 724774 @ 4 @ 1 6.1.4.1 Adjusting the Net Wrappings Pos: 29.17 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Einstellen der Netzwicklungen @ 82\mod_1317028122637_78.docx @ 724717 @ @ 1 RPM00003 Fig. 55 1. Use the key to increase or decrease the number of net winds.
Page 70: Baling Pressure Setting (Comprima F125 / F155 Medium) Or Bale Diameter (Comprima V 150 / V 180)
Bale Diameter (Comprima V 150 / V 180) Pos: 29.20 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Pressdruckanzeige (Comprima F 125/F 155) bzw. Ballendurchmesser (Comprima V 150 / V 180) @ 82\mod_1317028947729_78.docx @ 724811 @ @ 1 The setting is made on the machine (see Chapter Baling Pressure Setting (Comprima F125;...
Page 71: Operation Of Tying (Manual Mode)
The pilot lamp for type of tying “Net” (4) or the pilot lamp for type of tying “Twine” (5) lights up. As soon as the round bale has reached the baling pressure (Comprima F 125/F 155) or bale diameter (Comprima V 150/V 180) preselected on the preselection indicator of the round baler, a horn is sounded and the pilot lamps (12) light up.
Page 72: Operation Of Tying (Automatic Mode)
KRONE operation terminal Alpha Pos: 29.25 /Überschriften/Überschriften 4/A-E/Betätigung der Bindung (Automatikbetrieb) @ 82\mod_1317030628350_78.docx @ 724921 @ 4 @ 1 6.1.5.2 Operation of Tying (Automatic Mode) Pos: 29.26 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Betätigung der Bindung (Automatikbetrieb) @ 82\mod_1317030279892_78.docx @ 724893 @ @ 1 RPM00004 Fig.
Page 73: Settings And Diagnostics
KRONE operation terminal Alpha Pos: 29.28 /Überschriften/Überschriften 3/A-E/E/Einstellungen und Diagnose @ 82\mod_1317031594057_78.docx @ 725066 @ 4 @ 1 6.1.6 Settings and Diagnostics Pos: 29.29 /Überschriften/Überschriften 4/A-E/Einstellen der Automatik-Sperrzeit @ 82\mod_1317031781459_78.docx @ 725093 @ 4 @ 1 6.1.6.1 Adjusting the Automatic Blocking Time Pos: 29.30 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Einstellungen und Diagnose @ 82\mod_1317031393670_78.docx @ 725038 @ @ 1...
Page 74: Adjusting The Feed Position
KRONE operation terminal Alpha Pos: 29.34 /Überschriften/Überschriften 4/A-E/Einstellung der Zuführposition @ 55\mod_1294751304875_78.docx @ 533950 @ 3 @ 1 6.1.6.3 Adjusting the Feed Position Pos: 29.35 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Einstellung der Zuführposition @ 83\mod_1317103833880_78.docx @ 726405 @ @ 1 RPM00014_2 Fig. 60 1. The engine is extended up to the feed position with the key, i.e.:...
Page 75 KRONE operation terminal Alpha The motor should not be moved to the tying position again until after the values for the feed and cut-off position have been set. RPM00008 Fig. 62 1. Use the key to move the engine to the tying position.
Page 76: Sensor Test Digital
KRONE operation terminal Alpha Pos: 29.41 /Überschriften/Überschriften 3/P-T/Sensortest digital @ 55\mod_1294752559156_78.docx @ 534106 @ 3 @ 1 6.1.7 Sensor Test Digital Pos: 29.42 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Sensortest digital @ 83\mod_1317108532724_78.docx @ 726779 @ @ 1 In the sensor test the sensors fitted on the machine are tested for their digital condition.
Page 77: Sensor Test Analogue
KRONE operation terminal Alpha Pos: 29.44 /Überschriften/Überschriften 3/P-T/Sensortest analog @ 55\mod_1294752688031_78.docx @ 534158 @ 1 @ 1 6.1.8 Sensor Test Analogue Pos: 29.45 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Sensortest analog @ 83\mod_1317108790120_78.docx @ 726807 @ @ 1 The function of the rotary potentiometer is checked in the analogue sensor test.
Page 78: Displays "Version Number
KRONE operation terminal Alpha Pos: 29.47 /Überschriften/Überschriften 3/A-E/A/Anzeigen der "Versionsnummer" @ 55\mod_1294753104812_78.docx @ 534210 @ 3 @ 1 6.1.9 Displays “Version Number” Pos: 29.48 /WHB/Elektrik/Rundballenpresse/Alpha (Medium)/Anzeigen der Versionsnummer @ 83\mod_1317109948175_78.docx @ 726835 @ @ 1 RPM00050 Fig. 65 • When switching operation on, keep the key pressed.
Page 79 KRONE operation terminal Alpha Pos: 31 /Layout Module /Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ @ 1 This page has been left blank deliberately!! Pos: 32 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 80: Krone Operation Terminal Beta
KRONE operation terminal Beta Pos: 33.1 /Überschriften/Überschriften 1/K-O/KRONE Bedienterminal Beta @ 54\mod_1291734038125_78.docx @ 514470 @ 1 @ 1 KRONE operation terminal Beta Pos: 33.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Achtung - Bedieneinheit schützen @ 0\mod_1200308247867_78.docx @ 39598 @ @ 1 Caution! - Protect Control Unit.
Page 81: Attachment Of Control Unit
KRONE operation terminal Beta Pos: 33.3.3 /BA/Info-Center/Ladewagen/Anbau/Anbau Bedieneinheit @ 33\mod_1254829965082_78.docx @ 320172 @ 2 @ 1 Attachment of control unit BPM50390_1 Fig. 67 Mount the control unit with its support (1) where it can be seen by the driver. Direct fastening •...
Page 82: Description Of The Keys
KRONE operation terminal Beta Pos: 33.5 /Überschriften/Überschriften 2/A-E/Beschreibung der Tasten @ 6\mod_1215069821134_78.docx @ 98445 @ 2 @ 1 Description of the keys Pos: 33.6 /BA/Info-Center/Rundballenpresse/Übersicht/Beschreibung der Tasten 1-8_Fortima_Bild @ 252\mod_1397057135677_78.docx @ 1942838 @ @ 1 Fig. 69 Pos: 33.7 /BA/Info-Center/Rundballenpresse/Übersicht/Beschreibung der Tasten 1-8_Fortima_Text @ 252\mod_1397057177662_78.docx @ 1942867 @ @ 1...
Page 83: Operational Readiness
KRONE operation terminal Beta Pos: 33.9 /Überschriften/Überschriften 2/A-E/Betriebsbereitschaft @ 78\mod_1313048474927_78.docx @ 672856 @ 2 @ 1 Operational Readiness Pos: 33.10 /BA/Info-Center/Rundballenpresse/Übersicht/Betriebsbereitschaft_Einschalten Bedieneinheit @ 185\mod_1379424357442_78.docx @ 1595297 @ @ 1 Switching on • Press the key Pos: 33.11 /BA/Info-Center/Rundballenpresse/Übersicht/Betriebsbereitschaft_Verbindung hergestellt_Bild_Comprima V und F @ 256\mod_1397713806608_78.docx @ 1962554 @ @ 1...
Page 84: Basic Screen
KRONE operation terminal Beta Pos: 33.16.1 /Überschriften/Überschriften 2/F-J/Grundbild @ 50\mod_1287483189546_78.docx @ 471279 @ 2 @ 1 Basic Screen Pos: 33.16.2 /BA/Info-Center/Rundballenpresse/Grundbild/Hinweis - Grafiken und Symbole richten sich nach der Ausstattung der Maschine @ 186\mod_1379942599304_78.docx @ 1604995 @ @ 1 Note Graphics and symbols that are available depend on the equipment of the machine.
Page 85: Selecting Manual Or Automatic Mode
KRONE operation terminal Beta Pos: 33.16.7 /Überschriften/Überschriften 3/F-J/Hand- oder Automatikbetrieb einstellen @ 186\mod_1380002466289_78.docx @ 1606045 @ 3 @ 1 Selecting manual or automatic mode Pos: 33.16.8 /BA/Info-Center/Rundballenpresse/Grundbild/Hand- oder Automatikbetrieb einstellen @ 250\mod_1396882958015_78.docx @ 1935805 @ @ 1 After switching on control terminal, operating mode “Manual mode” is set by default.
Page 86: Displays In The Main Window
KRONE operation terminal Beta Pos: 33.16.12 /Überschriften/Überschriften 3/A-E/A/Anzeigen im Hauptfenster @ 69\mod_1305104621940_78.docx @ 633845 @ 3 @ 1 7.5.2 Displays in the Main Window Pos: 33.16.13 /BA/Info-Center/Rundballenpresse/Grundbild/Anzeigen im Hauptfenster_Bild variable und feste Ballenkammer_Comprima @ 256\mod_1397748465988_78.docx @ 1966864 @ @ 1...
Page 87: Messages
KRONE operation terminal Beta Pos: 33.16.20 /Überschriften/Überschriften 3/K-O/Meldungen @ 64\mod_1300188087828_78.docx @ 582130 @ 3 @ 1 7.5.3 Messages Pos: 33.16.21 /BA/Info-Center/Rundballenpresse/Meldungen/Infomeldung @ 33\mod_1255007589312_78.docx @ 321443 @ @ 1 Information message The information message will appear only, if the main operation display has been set. The message will disappear automatically, when the cause for the information message has been removed.
Page 88: Setting Bale Firmness
KRONE operation terminal Beta Pos: 33.16.24.1 /Überschriften/Überschriften 3/A-E/B/Ballenfestigkeit einstellen @ 185\mod_1379568677694_78.docx @ 1597412 @ 3 @ 1 7.5.4 Setting Bale Firmness Pos: 33.16.24.2 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F125 (XC) @ 262\mod_1399898256615_0.docx @ 2000262 @ @ 1 Comprima F125 (XC) Pos: 33.16.24.3 /BA/Info-Center/Rundballenpresse/Ballendurchmesser/-festigkeit einstellen/Ballenfestigkeit im Grundbild_Bild @ 185\mod_1379572786493_78.docx @ 1597673 @ @ 1 28/50 % Fig.
Page 89: Setting Bale Diameter
KRONE operation terminal Beta Pos: 33.16.24.10 /Überschriften/Überschriften 3/A-E/B/Ballendurchmesser einstellen @ 185\mod_1379568590086_78.docx @ 1597384 @ 3 @ 1 7.5.6 Setting Bale Diameter Pos: 33.16.24.11 /BA/Info-Center/Rundballenpresse/Ballendurchmesser/-festigkeit einstellen/Bildtitel_Comprima V150 (XC) Comprima V180 (XC) @ 256\mod_1397734170932_0.docx @ 1964681 @ @ 1 Comprima V150 (XC) Comprima V180 (XC) Pos: 33.16.24.12 /BA/Info-Center/Rundballenpresse/Ballendurchmesser/-festigkeit einstellen/Ballendurchmesser im Grundbild_Bild_Comprima V150 (XC), V180 (XC) @ 256\mod_1397727227344_78.docx @ 1964534 @ @ 1...
Page 90: Menu Level
KRONE operation terminal Beta Pos: 33.18 /Überschriften/Überschriften 2/K-O/Menüebene Kurzüberblick @ 33\mod_1255074316915_78.docx @ 321525 @ 33 @ 1 Menu Level 7.6.1 Short overview Pos: 33.19 /BA/Info-Center/Rundballenpresse/Menuführung/Menüebene Kurzüberblick Comprima F/V @ 269\mod_1401689776132_78.docx @ 2032033 @ @ 1 Main menu Sub-menu Sub-menu Designation...
Page 91 KRONE operation terminal Beta Main menu Sub-menu Sub-menu Designation Manual operation Service Manual sensor test Manual actuator test Engine position (net wrapping only: passive wrapping) Info Technician Pos: 33.20 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 92: Bringing Up A Menu Level
KRONE operation terminal Beta Pos: 33.21 /Überschriften/Überschriften 3/K-O/Menüebene aufrufen @ 33\mod_1255076738228_78.docx @ 321575 @ 2 @ 1 7.6.2 Bringing up a Menu Level Pos: 33.22 /BA/Info-Center/Rundballenpresse/Menuführung/Menüebene aufrufen Fortima V 1500 MC @ 54\mod_1291798471187_78.docx @ 515666 @ @ 1 122/122 cm RPK50013_2 Fig.
Page 93 KRONE operation terminal Beta Pos: 33.24 /BA/Info-Center/Rundballenpresse/Menuführung/Menüebene Überblick Hauptmenüs Fortima V 1500 MC @ 54\mod_1291798756015_78.docx @ 515713 @ @ 1 The menu level is divided into six main menus: Fig. 80 = main menu 1 "Settings" = main menu 2 "Counters"...
Page 94: Main Menu 1 "Settings
KRONE operation terminal Beta Pos: 33.26.1 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Hauptmenü „Einstellungen“ Beta F/V @ 266\mod_1400591811021_78.docx @ 2018265 @ 3 @ 1 Main Menu 1 "Settings" Fig. 81 • Call the menu level with the key. • You can select main menu 1 with the keys .
Page 95: Menu 1-1 "Contrast
KRONE operation terminal Beta Pos: 33.26.3 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 EinstellungenMenü 1-1 Kontrast (2014-10-15 14:34:36) @ 186\mod_1380005272970_78.docx @ 1606323 @ 3 @ 1 7.7.1 Menu 1-1 "Contrast" Fig. 82 The display contrast can be set in the menu. Displaying the menu Main menu 1 "Settings" appears: •...
Page 96: Menu 1-2 "Bale Diameter" (Comprima F155 (Xc))
KRONE operation terminal Beta Pos: 33.26.6 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-2 „Ballendurchmesser“ Comprima F155 XC @ 269\mod_1401691617182_78.docx @ 2032088 @ 3 @ 1 7.7.2 Menu 1-2 “Bale Diameter” (Comprima F155 (XC)) 135 cm Fig. 83 Calling the Menu Main menu 1 “Settings” is displayed.
Page 97: Menu 1-3 "Number Of Net Winds
KRONE operation terminal Beta Pos: 33.26.9 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-3 „Anzahl Netzwicklungen“ @ 213\mod_1389864057019_78.docx @ 1745118 @ 3 @ 1 7.7.3 Menu 1-3 "Number of net winds" Fig. 84 Opening the menu Main menu 1 "Settings" appears. • Use the buttons to select the menu 1-3 ;...
Page 98: Menu 1-4 "Sensitivity Of Direction Display" (Comprima F125/F155 (Xc))
KRONE operation terminal Beta Pos: 33.26.12 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-4 „Empfindlichkeit Richtungsanzeige“ Comprima F XC @ 269\mod_1401698078847_78.docx @ 2032296 @ 3 @ 1 7.7.4 Menu 1-4 "Sensitivity of direction display" (Comprima F125/F155 (XC)) Fig. 85 Opening the menu Main menu 1 "Settings" appears.
Page 99 KRONE operation terminal Beta Pos: 33.26.16 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-4 „Empfindlichkeit Richtungsanzeige“_Hinweis - Rollboden wird geschont @ 186\mod_1380011213937_78.docx @ 1606640 @ @ 1 Note An even filling of the bale chamber ensures optimally shaped bales and additionally protects the floor conveyor chains of the machine. Therefore it is recommended to set the sensitivity of direction display.
Page 100: Menu 1-5 „Pre-Signalling
KRONE operation terminal Beta Pos: 33.26.20 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-5 „Vorsignalisierung“ Comprima F/V @ 256\mod_1397741673492_78.docx @ 1966310 @ 2 @ 1 7.7.5 Menu 1-5 „Pre-Signalling" Fig. 87 Note Pre-signalling indicates how far in advance it is signaled that the setpoint value –...
Page 101 KRONE operation terminal Beta Setting pre-signalling: Comprima V Comprima F The value is displayed in cm. The value is displayed as percentage. Fig. 88 • Set the desired delay by using key, the symbol in the upper line goes out.
Page 102: Menu 1-6 „Correction Filling
KRONE operation terminal Beta Pos: 33.26.24 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-6 „Korrektur Befüllung“ Beta F/V @ 256\mod_1397742548055_78.docx @ 1966399 @ 3 @ 1 7.7.6 Menu 1-6 „Correction Filling“ Fig. 89 If bale diameter or bale firmness is not reached or if it is too high, bale diameter or bale firmness can be corrected in a predefined range via menu 1-6 “Correction Filling”.
Page 103 KRONE operation terminal Beta Correcting the filling Comprima F Comprima V Bale firmness: -10 % to +10 % Bale diameter: -10 cm to +10 cm +10cm +10% -10cm -10% Fig. 90 • Increase or reduce the desired value by using...
Page 104: Menu 1-9 „Tying Start Delay
KRONE operation terminal Beta Pos: 33.26.27 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-9 „Bindestartverzögerung“_Comprima F/V @ 256\mod_1397742703739_78.docx @ 1966428 @ 3 @ 1 7.7.7 Menu 1-9 „Tying Start Delay" 2,5 s Fig. 91 Calling the menu Main menu 1 “Settings” is displayed. •...
Page 105: Main Menu 2 „Counter
KRONE operation terminal Beta Pos: 33.28.1 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Hauptmenü 2 Zähler Beta Bild @ 83\mod_1317039772762_78.docx @ 725583 @ 2 @ 1 Main Menu 2 „Counter“ Fig. 92 Pos: 33.28.2 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Hauptmenü 2 Zähler @ 33\mod_1255332388835_78.docx @ 321906 @ @ 1 Calling the main menu •...
Page 106: Menu 2-1 "Customer Counters
KRONE operation terminal Beta Pos: 33.28.4 /Überschriften/Überschriften 3/K-O/Menü 2-1 Kundenzähler @ 34\mod_1255338699351_78.docx @ 322235 @ 2 @ 1 7.8.1 Menu 2-1 "Customer counters" Pos: 33.28.5 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Menü 2-1 Kundenzähler Bild @ 33\mod_1255333033288_78.docx @ 322006 @ @ 1 Fig. 93 Pos: 33.28.6 /BA/Info-Center/Rundballenpresse/Hauptmenü...
Page 107 KRONE operation terminal Beta Pos: 33.28.8 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Menü 2-1 Kundenzähler aktivieren @ 33\mod_1255334579523_78.docx @ 322031 @ @ 1 Fig. 94 Activating customer counter • You can use the keys to bring up the desired customer counter. It appears in the top line.
Page 108: Menu 2-2 "Total Bale Counter
KRONE operation terminal Beta Pos: 33.28.11 /Überschriften/Überschriften 3/K-O/Menü 2-2 Gesamtballenzähler @ 33\mod_1255337780148_78.docx @ 322135 @ 3 @ 1 7.8.2 Menu 2-2 "Total bale counter" Pos: 33.28.12 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Bild Menü 2-2 Gesamtballenzähler @ 33\mod_1255337554304_78.docx @ 322110 @ @ 1 Fig. 95 Pos: 33.28.13 /BA/Info-Center/Rundballenpresse/Hauptmenü...
Page 109 KRONE operation terminal Beta Pos: 33.28.15 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Bild Saisonzähler löschen @ 34\mod_1255338614304_78.docx @ 322210 @ @ 1 Fig. 96 Pos: 33.28.16 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Saisonzähler 1 löschen @ 187\mod_1380113706477_78.docx @ 1609802 @ @ 1 Delete season counter 1 • Press the key for softkey Season counter 1 is set to zero.
Page 110: Main Menu 3 „Manual Operation
KRONE operation terminal Beta Pos: 33.30.1 /Überschriften/Überschriften 2/F-J/Hauptmenü 3 Handbedienung @ 55\mod_1292224852765_78.docx @ 517684 @ 2 @ 1 Main menu 3 „Manual operation“ Pos: 33.30.2 /BA/Info-Center/Rundballenpresse/Hauptmenü 3 Handbedienung/Hinweis - Motor kann manuell ein- und ausgefahren werden @ 187\mod_1380108756889_78.docx @ 1609117 @ @ 1 Note The "Manual operation"...
Page 111 KRONE operation terminal Beta WARNING! – Crush hazard due to moving motor! Personal injury. • To prevent injury, do not stand in the area of the extending or retracting motor. Pos: 33.30.9 /BA/Info-Center/Rundballenpresse/Hauptmenü 3 Handbedienung/Einführposition @ 187\mod_1380103521994_78.docx @ 1609059 @ @ 1...
Page 112: Main Menu 4 "Service
KRONE operation terminal Beta Pos: 33.32.1 /Überschriften/Überschriften 2/F-J/Hauptmenü 4 Service @ 34\mod_1255339497523_78.docx @ 322336 @ 3 @ 1 7.10 Main menu 4 "Service" Pos: 33.32.2 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Hauptmenü 4 Service Bild @ 34\mod_1255339598616_78.docx @ 322361 @ @ 1 Fig. 99 Pos: 33.32.3 /BA/Info-Center/Rundballenpresse/Hauptmenü...
Page 113: Menu 4-2 "Manual Sensor Test
KRONE operation terminal Beta Pos: 33.32.5 /Überschriften/Überschriften 3/K-O/Menü 4-2 Sensortest Hand @ 34\mod_1255414500878_78.docx @ 322861 @ 3 @ 1 7.10.1 Menu 4-2 "Manual Sensor Test" Pos: 33.32.6 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Menü 4-2 Sensortest Hand @ 187\mod_1380114678068_78.docx @ 1610095 @ @ 1 RPK50508 Fig.
Page 114 KRONE operation terminal Beta Pos: 33.32.10 /BA/Info-Center/Sensoren/Diagnose Namursensoren @ 19\mod_1238072125300_78.docx @ 214095 @ @ 1 Diagnostics – Namur sensors Pos: 33.32.11 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Diagnose Namursensoren @ 84\mod_1318339931717_78.docx @ 734097 @ @ 1 Fig. 101 Pos: 33.32.12 /BA/Info-Center/Sensoren/Statusanzeigen/Statusanzeigen Sensor (1,2,3,4) farbig @ 189\mod_1380721227163_78.docx @ 1618866 @ @ 1...
Page 115 KRONE operation terminal Beta Pos: 33.32.16 /BA/Info-Center/Sensoren/Diagnose analoge Sensoren @ 19\mod_1238132263369_78.docx @ 214965 @ @ 1 Diagnostics – analogue sensors Pos: 33.32.17 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Diagnose analoge Sensoren @ 84\mod_1318340603895_78.docx @ 734125 @ @ 1 RPK50510 Fig. 102 Pos: 33.32.18 /BA/Info-Center/Sensoren/Einstellwerte analoge Sensoren Hand @ 19\mod_1238132357119_78.docx @ 214994 @ @ 1 Setting values: The bar must be inside the marked area of the bar display.
Page 116 KRONE operation terminal Beta Comprima F125 (XC) Comprima F155 (XC) Fig. 104 Caution! The bale chamber must be closed and empty. If the bar (1) is not inside the rectangle (2) when the bale chamber is closed and emptied, the corresponding sensor (7) must be adjusted mechanically.
Page 117 KRONE operation terminal Beta Pos: 33.32.24 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Sensor B9/B10 Ballendurchmesser_Comprima V150/V180 @ 84\mod_1318409031892_78.docx @ 734557 @ @ 1 Adjust sensor B9/B10 bale diameter (Comprima V150/V180/V210 (XC)) VPN00012_4 COM00011_1 Fig. 105 Before you adjust or correct the setting of the sensor (7) “B9/B10 Bale Diameter,” make certain the stop (6) for the soft core setting is in Pos.
Page 118 KRONE operation terminal Beta Fig. 106 • Loosen the sensor (7) and turn it in the oblong hole until the bar (1) is positioned inside the rectangle (2) of the bar display. Note An audio signal sounds if the bar (1) is inside the rectangle (2).
Page 119 KRONE operation terminal Beta Pos: 33.32.27 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Diagnose Versorgungsspannungen @ 34\mod_1255419287566_78.docx @ 323036 @ @ 1 Diagnostics – power supply voltages Fig. 107 Pos: 33.32.28 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Diagnose Versorgungsspannungen @ 34\mod_1255419249097_78.docx @ 323011 @ @ 1 Sensor icon...
Page 120: Menu 4-4 „Manual Actuator Test
KRONE operation terminal Beta Pos: 33.32.30 /BA/Sicherheit/7. Gefahrenhinweise altGefahr - Aktortest (2014-10-16 08:40:53) @ 47\mod_1285134152781_78.docx @ 455729 @ @ 1 Danger! - Unexpected actions on the machine. Effect: Danger to life or serious injuries. • Only persons familiar with the machine are permitted to perform the actuator test •...
Page 121 KRONE operation terminal Beta Pos: 33.32.34 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Diagnose digitale Aktoren @ 34\mod_1255420082081_78.docx @ 323111 @ @ 1 Diagnostics – digital actuators Fig. 109 Pos: 33.32.35 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Diagnose digitale Aktoren @ 34\mod_1255420229050_78.docx @ 323136 @ @ 1 Errors are only displayed if the actuator is turned on and a test is possible for the actuator (see the table called "Possible digital actuators").
Page 122 KRONE operation terminal Beta Pos: 33.32.40 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Mögliche Motoren (je nach Ausstattung der Maschine) @ 34\mod_1255422731331_78.docx @ 323186 @ @ 1 Possible motors (depending on how the machine is equipped) Pos: 33.32.41 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Mögliche Motoren Fortima, Comprima @ 250\mod_1396970768938_78.docx @ 1938542 @ @ 1 Fig.
Page 123: Menu 4-7 "Position Motor
KRONE operation terminal Beta Pos: 33.32.45 /Überschriften/Überschriften 3/K-O/Menü 4-7 "Position Motor" @ 55\mod_1294820430171_78.docx @ 535577 @ 3 @ 1 7.10.3 Menu 4-7 "Position Motor" Pos: 33.32.46 /BA/Info-Center/Rundballenpresse/Hauptmenü 3 Handbedienung/WARNUNG! – Quetschgefahr durch sich bewegenden Motor @ 187\mod_1380102243196_78.docx @ 1609031 @ @ 1 WARNING! –...
Page 124 KRONE operation terminal Beta Retracting the motor and saving (cutting position) • Press the button for the softkey. The symbol is shown inverted and the motor retracts. When the motor has moved to the cutting position: • Press the button.
Page 125: Main Menu 5 "Info
KRONE operation terminal Beta Pos: 33.34 /BA/Info-Center/Rundballenpresse/Hauptmenü 5 Info/Hauptmenü 5 Info Bild @ 79\mod_1315230754330_78.docx @ 701799 @ 3 @ 1 7.11 Main menu 5 "Info" SW: 200 812 113 1:150200369-03 ISO: 150 200 463-00 FOR00061 Fig. 112 Pos: 33.35 /BA/Info-Center/Rundballenpresse/Hauptmenü 5 Info/Hauptmenü 5 Info @ 79\mod_1315230506158_78.docx @ 701771 @ @ 1 Calling the main menu •...
Page 126: Main Menu 6 „Technician
KRONE operation terminal Beta Pos: 33.37 /Überschriften/Überschriften 2/F-J/Hauptmenü 6 Monteur @ 78\mod_1313050883963_78.docx @ 675374 @ 3 @ 1 7.12 Main Menu 6 „Technician“ Pos: 33.38 /BA/Info-Center/Rundballenpresse/Hauptmenü 6 Monteur/Hauptmenü 6 Monteur Bild @ 34\mod_1255438996941_78.docx @ 323514 @ @ 1 0000 12345...
Page 127: Note And Messages
KRONE operation terminal Beta Pos: 33.40.4 /Überschriften/Überschriften 3/F-J/Hinweise und Meldungen @ 34\mod_1255441383706_78.docx @ 323591 @ 3 @ 1 7.13.1 Note and messages Pos: 33.40.5 /BA/Info-Center/Rundballenpresse/Alarmmeldungen/1) Hinweise und Meldungen Beta @ 213\mod_1389885440800_78.docx @ 1746905 @ @ 1 Figure Possible cause Remedy –...
Page 128 KRONE operation terminal Beta Figure Possible cause Remedy – Check the bale chamber lock – The bale chamber has sprung open. hook. – The bale chamber has been opened without tying. – Check the setting of the "Bale chamber closed left" and "Bale chamber closed right"...
Page 129: Physical Messages
KRONE operation terminal Beta Pos: 33.40.7 /Überschriften/Überschriften 3/P-T/Physikalische Meldungen @ 34\mod_1255442189285_78.docx @ 323664 @ 3 @ 1 7.13.2 Physical messages Pos: 33.40.8 /BA/Info-Center/Rundballenpresse/Alarmmeldungen/2) Physikalische Meldungen Beta C/V @ 213\mod_1389885927264_78.docx @ 1746934 @ @ 1 Symbol Sensor Possible cause Remedy Net length sensor...
Page 130: General Messages
KRONE operation terminal Beta Pos: 33.40.10 /Überschriften/Überschriften 3/A-E/A/Allgemeine Meldungen @ 34\mod_1255443656238_78.docx @ 323714 @ 3 @ 1 7.13.3 General Messages Pos: 33.40.11 /BA/Info-Center/Rundballenpresse/Alarmmeldungen/3) Allgemeine Meldungen @ 34\mod_1255443585941_78.docx @ 323685 @ @ 1 Figure Acoustic signal Description – Fuse in job computer is defective.
Page 131 KRONE operation terminal Beta Pos: 35 /Layout Module /Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ @ 1 This page has been left blank deliberately!! Pos: 36 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 132: Krone Isobus-Terminal Cci 100
KRONE ISOBUS-Terminal CCI 100 Pos: 37.1 /Überschriften/Überschriften 1/K-O/KRONE ISOBUS-Terminal CCI 100 @ 43\mod_1274786526625_78.docx @ 387485 @ 1 @ 1 KRONE ISOBUS-Terminal CCI 100 Pos: 37.2 /BA/Info-Center/CCI-ISOBUS-Terminal/Hinweis Im weiteren Verlauf Terminal auch als Bedieneinheit bezeichnet @ 46\mod_1281680416671_78.docx @ 445465 @ @ 1 Note In the operating instructions which follow, the terminal will also be referred to as the "control...
Page 133: Installing The Terminal Into Cabin
KRONE ISOBUS-Terminal CCI 100 Pos: 37.6 /Überschriften/Überschriften 2/P-T/Terminal in Kabine einbauen @ 47\mod_1285163419265_78.docx @ 455855 @ 3 @ 1 Installing the terminal into cabin Pos: 37.7 /BA/Info-Center/CCI-ISOBUS-Terminal/Hinweis für den Anbau des Terminals, in die Traktorkabine... @ 47\mod_1285163596984_78.docx @ 455881 @ @ 1...
Page 134: Isobus Short Cut Button
KRONE ISOBUS-Terminal CCI 100 Pos: 37.9.1 /Überschriften/Überschriften 2/F-J/ISOBUS Short Cut Button @ 47\mod_1285564773000_78.docx @ 456410 @ 2 @ 1 ISOBUS Short Cut Button Pos: 37.9.2 /BA/Info-Center/CCI-ISOBUS-Terminal/Module für Beipack/ISOBUS Short Cut Button/ISOBUS Short Cut Button_2 Gefahr @ 46\mod_1282643782875_78.docx @ 447376 @ @ 1 DANGER! –...
Page 135: Display / Touchscreen
KRONE ISOBUS-Terminal CCI 100 Pos: 37.9.6 /BA/Info-Center/CCI-ISOBUS-Terminal/Module für Beipack/ISOBUS Short Cut Button/ISOBUS Short Cut Button_wird gelöst @ 120\mod_1342516466580_78.docx @ 1088224 @ @ 1 If the ISOBUS short cut button is deactivated again, the following message will appear in the display: CC000071 Fig.
Page 136: Connecting The Terminal (On Tractors With Integrated Isobus System)
Note The terminal is connected to the tractor via a special cable set (5) which can be ordered by stating the KRONE article no. 20 081 223 0. • Connect plug (2) of cable set (5) with socket (1) (CAN1-IN) of the terminal.
Page 137: Connecting The Terminal (On Tractors Without Isobus System)
KRONE ISOBUS-Terminal CCI 100 Pos: 37.16 /BA/Info-Center/CCI-ISOBUS-Terminal/Terminal anschließen (ohne ISO Schlepper) @ 43\mod_1274882231640_78.docx @ 387925 @ 3 @ 1 8.2.3 Connecting the terminal (on tractors without ISOBUS system) Fig. 120 Connection terminal to machine Note The connection of terminal to machine takes place via a provided cable set (5) (article no.
Page 138: Switching The Terminal On / Off When The Machine Is Not Connected
KRONE ISOBUS-Terminal CCI 100 Pos: 37.18 /Überschriften/Überschriften 3/A-E/E/Ein- Ausschalten des Terminals bei nicht angeschlossener Maschine @ 43\mod_1275290766562_78.docx @ 389835 @ 3 @ 1 8.2.4 Switching the terminal on / off when the machine is not connected Pos: 37.19 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Ein- Ausschalten Bild mit nicht angeschlossener Maschine @ 43\mod_1275291241781_78.docx @ 389860 @ @ 1 Fig.
Page 139: Switching The Terminal On / Off When The Machine Is Connected
KRONE ISOBUS-Terminal CCI 100 Pos: 37.23 /Überschriften/Überschriften 3/A-E/E/Ein- Ausschalten des Terminals bei angeschlossener Maschine @ 43\mod_1274866210140_78.docx @ 387724 @ 3 @ 1 8.2.5 Switching the terminal on / off when the machine is connected Pos: 37.24 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Ein- Ausschalten Bild bei angeschlossener Maschine @ 50\mod_1287481325359_78.docx @ 471123 @ @ 1 CC000200 Fig.
Page 140: Basic Screen
KRONE ISOBUS-Terminal CCI 100 Pos: 37.31 /Überschriften/Überschriften 2/F-J/Grundbild @ 50\mod_1287483189546_78.docx @ 471279 @ 3 @ 1 Basic Screen Pos: 37.32 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Grundbild @ 50\mod_1287482211765_78.docx @ 471174 @ @ 1 CC000201 Fig.125 Pos: 37.33 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Statuszeile (I) oberste Zeile @ 50\mod_1287482314484_78.docx @ 471199 @ @ 1...
Page 141 KRONE ISOBUS-Terminal CCI 100 Pos: 37.35 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Beschreibung der Grafiken (II) für Funktionstasten(F1 bis F6) @ 50\mod_1287482628656_78.docx @ 471224 @ @ 1 Description of the symbols (II) for the function keys (F1 to F6) Net feeding manual mode Net is fed when actuating the function key...
Page 142 KRONE ISOBUS-Terminal CCI 100 Pos: 37.37 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Grundbild @ 50\mod_1287482211765_78.docx @ 471174 @ @ 1 CC000201 Fig.126 Pos: 37.38 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Anzeigen im Hauptfenster (III) je nach Ausstattung @ 50\mod_1287483331343_78.docx @ 471304 @ @ 1 Displays in the main window (III) (depending on how the machine is equipped)
Page 143 KRONE ISOBUS-Terminal CCI 100 Pos: 37.40 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Hinweis Fahrhinweise zu stark oder schwach @ 50\mod_1287483756671_78.docx @ 471329 @ @ 1 Note If the indications for the direction of motion are too strong or too weak, they can still be adjusted (see menu “Sensitivity of direction display”).
Page 144: Setting The Setpoint Bale Firmness
KRONE ISOBUS-Terminal CCI 100 Pos: 37.44 /Überschriften/Überschriften 3/A-E/E/Einstellen der Soll-Ballenfestigkeit @ 117\mod_1341219335997_78.docx @ 1021287 @ 2 @ 1 8.3.1 Setting the Setpoint Bale Firmness Pos: 37.45 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F @ 256\mod_1397714206905_0.docx @ 1962642 @ @ 1 Comprima F Pos: 37.46 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Einstellen der Soll-Ballenfestigkeit Text @ 117\mod_1341217455785_78.docx @ 1021218 @ @ 1...
Page 145: Setting The Target Bale Diameter
KRONE ISOBUS-Terminal CCI 100 Pos: 37.49 /Überschriften/Überschriften 3/A-E/E/Einstellen des Soll_Ballendurchmessers @ 117\mod_1341219444164_78.docx @ 1021315 @ 3 @ 1 8.3.1 Setting the Target Bale Diameter Pos: 37.50 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V @ 256\mod_1397714229979_0.docx @ 1962670 @ @ 1 Comprima V Pos: 37.51 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Einstellen des Soll-Ballendurchmessers Text @ 117\mod_1341219582258_78.docx @ 1021343 @ @ 1 Fig.
Page 146: Messages
KRONE ISOBUS-Terminal CCI 100 Pos: 37.54 /Überschriften/Überschriften 2/K-O/Meldungen @ 33\mod_1255007717750_78.docx @ 321468 @ 2 @ 1 Messages Pos: 37.55 /BA/Info-Center/Rundballenpresse/Meldungen/Infomeldung @ 33\mod_1255007589312_78.docx @ 321443 @ @ 1 Information message The information message will appear only, if the main operation display has been set. The message will disappear automatically, when the cause for the information message has been removed.
Page 147: Menu Level
KRONE ISOBUS-Terminal CCI 100 Pos: 37.58 /Überschriften/Überschriften 2/K-O/Menüebene Kurzüberblick @ 33\mod_1255074316915_78.docx @ 321525 @ 23 @ 1 Menu Level 8.5.1 Short overview Pos: 37.59 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Menüebene Kurzüberblick Maschine_Comprima F/V XC neu @ 269\mod_1401715329598_78.docx @ 2033142 @ @ 1 Main menu Sub-menu...
Page 148 KRONE ISOBUS-Terminal CCI 100 Main menu Sub-menu Sub-menu Designation Service Manual sensor test Manual actuator test Info Technician ISOBUS Virtual terminal (VT) 7-1-1 Select day/night display lighting 7-1-4 Switch to different terminal ISOBUS diagnosis 7-4-2 "Auxiliary" function (AUX) diagnosis Pos: 37.60 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 149: Calling Up The Menu Level
KRONE ISOBUS-Terminal CCI 100 Pos: 37.61 /Überschriften/Überschriften 2/K-O/Menüebene aufrufen @ 44\mod_1275977054046_78.docx @ 394176 @ 3 @ 1 8.5.2 Calling up the menu level Pos: 37.62 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Menüebene aufrufen Bild @ 50\mod_1287554961625_78.docx @ 472210 @ @ 1 CC000207 Fig.130 Pos: 37.63 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Menüebene aufrufen CCI @ 43\mod_1275299708140_78.docx @ 390706 @ @ 1...
Page 150: Main Menu 1 "Settings
KRONE ISOBUS-Terminal CCI 100 Pos: 37.66 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Hauptmenü 1 "Einstellungen" Comprima XC @ 50\mod_1287557062859_78.docx @ 472452 @ 2 @ 1 Main menu 1 "Settings" CC000207 Fig.131 • By pressing the function key in the basic screen you get into the menu level of the machine •...
Page 151: Menu 1-2 „Bale Diameter" (Comprima F155 (Xc))
KRONE ISOBUS-Terminal CCI 100 Pos: 37.68 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-2 Ballendurchmesser Comprima XC @ 265\mod_1400218441465_78.docx @ 2010785 @ 3 @ 1 8.6.1 Menu 1-2 „Bale diameter“ (Comprima F155 (XC)) CC000236 CC000237 Fig. 132 Displaying the menu Main menu 1 “Settings” is displayed.
Page 152: Menu 1-3 „Number Of Net Winds
KRONE ISOBUS-Terminal CCI 100 Pos: 37.70 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-3 Anzahl Netzwicklungen @ 50\mod_1287559160734_78.docx @ 472633 @ 3 @ 1 8.6.2 Menu 1-3 „Number of net winds“ CC000208 CC000753 Fig.133 Displaying the menu Main menu 1 “Settings” is displayed. •...
Page 153: Menu 1-4 "Sensitivity Of The Direction Display" (Comprima F125/F155 (Xc))
KRONE ISOBUS-Terminal CCI 100 Pos: 37.72 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-4 Empfindlichkeit-Richtungsanzeige Comprima XC @ 265\mod_1400225725547_78.docx @ 2010965 @ 3 @ 1 8.6.3 Menu 1-4 “Sensitivity of the direction display” (Comprima F125/F155 (XC)) CC000211 Fig.134 Displaying the menu Main menu 1 “Settings” is displayed.
Page 154: Menu 1-5 „Pre-Signalling
KRONE ISOBUS-Terminal CCI 100 Pos: 37.75 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-5 Vorsignalisierung Comprima XC @ 265\mod_1400229795792_78.docx @ 2011454 @ 3 @ 1 8.6.4 Menu 1-5 „Pre-Signalling" CC000212 Fig. 135 Note Pre-signalling indicates how far in advance it is signaled that the setpoint value –...
Page 155 KRONE ISOBUS-Terminal CCI 100 Setting pre-signalling: Comprima F Comprima V The value is displayed as percentage. The value is displayed in cm. CC000234 CC000213 Fig. 136 • Set the desired time delay by using function keys , symbol in the upper line goes out •...
Page 156: Menu 1-6 „Correction Filling
KRONE ISOBUS-Terminal CCI 100 Pos: 37.77 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-6 Korrektur Befüllung Comprima XC @ 265\mod_1400478891605_78.docx @ 2012135 @ 2 @ 1 8.6.5 Menu 1-6 „Correction Filling“ CC000214 Fig. 137 Note If bale diameter or bale firmness is not reached or if it is too high, bale diameter or bale firmness can be corrected in a predefined range via menu 1-6 “Correction Filling”.
Page 157 KRONE ISOBUS-Terminal CCI 100 Correcting the filling Comprima F Comprima V Bale firmness: -10 % to +10 % Bale size: -10 cm to +10 cm CC000215 Fig. 138 • Increase or reduce the desired value by using function key , the symbol in the upper line goes out.
Page 158: Menu 1-9 „Tying Start Delay
KRONE ISOBUS-Terminal CCI 100 Pos: 37.79 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-9 Bindestartverzögerung Comprima XC @ 265\mod_1400480824220_78.docx @ 2012244 @ 2 @ 1 8.6.6 Menu 1-9 „Tying Start Delay" CC000216 CC000898 Fig. 139 Calling the menu Main menu 1 “Settings” is called.
Page 159: Main Menu 2 „Counter
KRONE ISOBUS-Terminal CCI 100 Pos: 37.81 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 2 Zähler/Hauptmenü 2 Zähler @ 50\mod_1287561670062_78.docx @ 472974 @ 2 @ 1 Main menu 2 „Counter“ CC000218 CC000219 Fig.140 Calling the main menu • By pressing the function key in the basic screen you get into the menu level of the machine •...
Page 160: Menu 2-1 "Customer Counter
KRONE ISOBUS-Terminal CCI 100 Pos: 37.83 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 2 Zähler/Menü 2-1 Kundenzähler @ 50\mod_1287562135281_78.docx @ 473029 @ 3 @ 1 8.7.1 Menu 2-1 "Customer counter" CC000219 Fig.141 Displaying the menu Main menu 2 "Counters" is displayed • You can select menu 2-1 by pressing function key .
Page 161 KRONE ISOBUS-Terminal CCI 100 Pos: 37.85 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 2 Zähler/Kundenzähler aktivieren @ 50\mod_1287562757875_78.docx @ 473074 @ @ 1 Activating customer counters Fig.142 • Press function key to select the desired customer counter and activate by pressing the function key . The desired customer counter (in this case customer counter 1) is highlighted in grey.
Page 162: Menu 2-2 „Total Bale Counter
KRONE ISOBUS-Terminal CCI 100 Pos: 37.87 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 2 Zähler/Menü 2-2 Gesamtballenzähler Fortima, Comprima Solo @ 251\mod_1396978147508_78.docx @ 1938862 @ 3 @ 1 8.7.2 Menu 2-2 „Total Bale Counter“ CC000871 Fig. 143 Calling the menu Main menu 2 “Counters” is called •...
Page 163: Main Menu 3 „Manual Operation
KRONE ISOBUS-Terminal CCI 100 Pos: 37.89 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 3 Handbedienung/Hauptmenü 3 Handbedienung @ 50\mod_1287563629171_78.docx @ 473218 @ 3 @ 1 Main menu 3 „Manual operation“ CC000223 Fig.144 Displaying the menu • By pressing the function key in the basic screen you get into the menu level of the machine •...
Page 164: Menu 3-2 "Net Motor Position
KRONE ISOBUS-Terminal CCI 100 Pos: 37.91 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 3 Handbedienung/Menü 3-2 Position Netzmotor @ 214\mod_1390380480956_78.docx @ 1754925 @ 3 @ 1 8.8.1 Menu 3-2 "Net motor position" CC000755 Fig. 145 Opening the menu Main menu 3 "Manual operation" is opened •...
Page 165: Main Menu 4 „Service
KRONE ISOBUS-Terminal CCI 100 Pos: 37.93 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Hauptmenü 4 Service @ 50\mod_1287564420703_78.docx @ 473318 @ 2 @ 1 Main menu 4 „Service“ CC000225 CC000226 Fig.146 Calling the main menu • By pressing the function key in the basic screen you get into the menu level of the machine •...
Page 166: Menu 4-2 „Manual Sensor Test
KRONE ISOBUS-Terminal CCI 100 Pos: 37.95 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Menü 4-2 Sensortest Hand @ 50\mod_1287564763015_78.docx @ 473363 @ 3 @ 1 8.9.1 Menu 4-2 „Manual sensor test“ CC000226 CC000227 Fig.147 In the manual sensor test, the sensors that are installed on the machine are checked for errors.
Page 167 KRONE ISOBUS-Terminal CCI 100 Pos: 37.97 /BA/Info-Center/Sensoren/Diagnose Namursensoren @ 19\mod_1238072125300_78.docx @ 214095 @ @ 1 Diagnostics – Namur sensors Pos: 37.98 /BA/Info-Center/Sensoren/Mögliche Sensoren (je nach Ausstattung der Maschine) @ 19\mod_1238071336628_78.docx @ 214010 @ @ 1 Possible sensors (depending on how the machine is equipped) Pos: 37.99 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü...
Page 168 KRONE ISOBUS-Terminal CCI 100 Pos: 37.103 /BA/Info-Center/Sensoren/Diagnose analoge Sensoren @ 19\mod_1238132263369_78.docx @ 214965 @ @ 1 Diagnostics – analogue sensors Pos: 37.104 /BA/Info-Center/Sensoren/Einstellwerte analoge Sensoren Hand @ 19\mod_1238132357119_78.docx @ 214994 @ @ 1 Setting values: The bar must be inside the marked area of the bar display.
Page 169 KRONE ISOBUS-Terminal CCI 100 Pos: 37.110 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Sensor B9/B10 Ballenfestigkeit einstellen _ Comprima F125/F155 @ 50\mod_1287566391234_78.docx @ 473549 @ @ 1 Adjust sensor B9/B10 bale firmness (Comprima F125/F155 (XC)): F155 (XC) F125 (XC) RPN00077_1 CC000235_1 Abb. 148 Caution! The bale chamber must be closed and empty.
Page 170 KRONE ISOBUS-Terminal CCI 100 Pos: 37.112 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Sensor B9/B10 Ballendurchmesser einstellen_Comprima V150/V180/V210 @ 50\mod_1287567191468_78.docx @ 473574 @ @ 1 Adjust sensor B9/B10 bale diameter (Comprima V150/V180/V210 (XC)): VPN00012_4 COM00011_1 Fig. 149 Before you readjust or correct the setting of the sensor (7) “B9/B10 bale diameter,” make certain the stop (6) for the soft core setting is in Pos.
Page 171 KRONE ISOBUS-Terminal CCI 100 CC000235_1 Fig.150 • Loosen the sensor (7) and turn it in the oblong hole until the bar (1) is positioned inside the rectangle (2) in the bar display Note An audio signal sounds if the bar (1) is inside the rectangle (2).
Page 172 KRONE ISOBUS-Terminal CCI 100 Pos: 37.115 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Diagnose Versorgungsspannung @ 50\mod_1287568818750_78.docx @ 473600 @ @ 1 Diagnostics – power supply voltage Fig. 151 Sensor icon Description power supply voltage Nominal voltages: 12V Ges: 12 - 14,5 V 12V Ter:...
Page 173: Menu 4-4 Manual Actuator Test
KRONE ISOBUS-Terminal CCI 100 Pos: 37.118 /Überschriften/Überschriften 3/K-O/Menü 4-4 Aktortest Hand @ 44\mod_1275637010843_78.docx @ 393380 @ 4 @ 1 8.9.2 Menu 4-4 Manual actuator test Pos: 37.119 /BA/Sicherheit/7. Gefahrenhinweise altGefahr - Aktortest (2014-10-16 08:40:53) @ 47\mod_1285134152781_78.docx @ 455729 @ @ 1 Danger! - Unexpected actions on the machine.
Page 174 KRONE ISOBUS-Terminal CCI 100 Pos: 37.125 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose digitale Aktoren @ 44\mod_1275889088109_78.docx @ 393610 @ @ 1 Diagnostics – digital actuators Errors are only displayed if the actuator is turned on and a test is possible for the actuator (see the table called "Possible digital actuators").
Page 175 KRONE ISOBUS-Terminal CCI 100 Pos: 37.131 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Mögliche Motoren @ 267\mod_1400740789179_78.docx @ 2021994 @ @ 1 Possible motors (depending on machine configuration) CC000765 Fig. 153 • Press the function button to extend the motor, inching operation only. • Press the function button to retract the motor, inching operation only.
Page 176: Main Menu 5 "Info
KRONE ISOBUS-Terminal CCI 100 Pos: 37.134 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 5 Info/Hauptmenü 5 Info @ 50\mod_1287571352984_78.docx @ 473810 @ 1 @ 1 8.10 Main menu 5 "Info" CC000231 Fig. 154 Calling the main menu • By pressing the function key in the basic screen you get into the menu level of the machine •...
Page 177: Main Menu 6 Technician
KRONE ISOBUS-Terminal CCI 100 Pos: 37.137 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 6 Monteur/Hauptmenü 6 Monteur @ 135\mod_1351678746690_78.docx @ 1203319 @ 2 @ 1 8.11 Main Menu 6 Technician Calling the Main Menu 15-6 0000 054536 CC000051 CC000052_1 Fig. 155 • By pressing function key in the basic screen you get into the menu level •...
Page 178: Main Menu 7 Isobus
KRONE ISOBUS-Terminal CCI 100 Pos: 37.139 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Hauptmenü 7 ISOBUS @ 117\mod_1341411944044_78.docx @ 1023651 @ 2 @ 1 8.12 Main Menu 7 ISOBUS Fig. 156 Calling the Main Menu • By pressing the function key from the basic screen you get into the menu level of the machine •...
Page 179: Menu 7-1 Virtual Terminal (Vt)
KRONE ISOBUS-Terminal CCI 100 Pos: 37.141 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 7-1 Virtual Terminal (Fortima)/Menü 7-1 VT @ 118\mod_1341912242598_78.docx @ 1028326 @ 2 @ 1 8.12.1 Menu 7-1 Virtual Terminal (VT) Fig. 157 Calling the Main Menu Main menu 7 “ISOBUS” is called. •...
Page 180: Menu 7-1-1 Select Day/Night Display Lighting
KRONE ISOBUS-Terminal CCI 100 Pos: 37.144 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-1-1 „Tag-Nacht Umschaltung“ ohne Helligkeit @ 212\mod_1389776201032_78.docx @ 1741804 @ 3 @ 1 8.12.2 Menu 7-1-1 Select day/night display lighting Fig. 158 The "Select day/night display lighting" menu can be used to adjust the brightness of the display.
Page 181: Menu 7-1-4 Switch To Different Terminal
KRONE ISOBUS-Terminal CCI 100 Pos: 37.146 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-1-4 Umschaltung VT @ 213\mod_1390225768211_78.docx @ 1750372 @ 3 @ 1 8.12.3 Menu 7-1-4 Switch to different terminal Note • Menu 7-1-4 only appears if several ISOBUS terminals are connected. • Menu 7-1-4 can be used to switch to the next connected terminal (depending on how many terminals are connected).
Page 182: Menu 7-4 Isobus Diagnostics
KRONE ISOBUS-Terminal CCI 100 Pos: 37.148 /Überschriften/Überschriften 2/K-O/Menü 7-4 ISOBUS Diagnose @ 118\mod_1342010523712_78.docx @ 1066831 @ 2 @ 1 8.13 Menu 7-4 ISOBUS Diagnostics Pos: 37.149 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-4 Isobus Diagnose Bild @ 118\mod_1341989823426_78.docx @ 1029983 @ @ 1 CC000324 Fig.
Page 183: Menu 7-4-2 Diagnostics Auxiliary Functions (Aux)
KRONE ISOBUS-Terminal CCI 100 Pos: 37.152 /Überschriften/Überschriften 3/K-O/Menü 7-4-2 Diagnose "Auxiliary"-Funktion (AUX) @ 117\mod_1341410143303_78.docx @ 1023355 @ 3 @ 1 8.13.1 Menu 7-4-2 Diagnostics Auxiliary Functions (AUX) Pos: 37.153 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-4-2 Diagnose Aux-Funktion_Bild @ 117\mod_1341410286990_78.docx @ 1023385 @ @ 1 Fig.
Page 184: Alarm Messages
KRONE ISOBUS-Terminal CCI 100 Pos: 37.157 /Überschriften/Überschriften 3/A-E/A/Alarmmeldungen @ 34\mod_1255441373066_78.docx @ 323566 @ 2 @ 1 8.13.2 Alarm messages Pos: 37.158 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Alarmmeldungen allgemein @ 213\mod_1390226364462_78.docx @ 1750401 @ @ 1 CC000240_1 Fig. 162 Alarm message If a fault occurs on the machine, an alarm message appears in the display and an acoustic signal sounds at the same time (continuous horn).
Page 185: Acoustic Warnings
KRONE ISOBUS-Terminal CCI 100 Pos: 37.160 /Überschriften/Überschriften 3/A-E/A/Akustische Hinweise @ 50\mod_1287572164250_78.docx @ 473885 @ 3 @ 1 8.13.3 Acoustic warnings Pos: 37.161 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Akustische Hinweise @ 50\mod_1287572618250_78.docx @ 473966 @ @ 1 Wrapping is triggered Filling reached, pre-signal reached, wrapping complete, bale chamber closed...
Page 186: Note And Messages
KRONE ISOBUS-Terminal CCI 100 Pos: 37.163 /Überschriften/Überschriften 3/F-J/Hinweise und Meldungen @ 34\mod_1255441383706_78.docx @ 323591 @ 3 @ 1 8.13.4 Note and messages Pos: 37.164 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Hinweise und Meldungen Comprima F/V @ 115\mod_1339392148445_78.docx @ 1009605 @ @ 1 Symbol Acoustic signal Description...
Page 187: Physical Messages
KRONE ISOBUS-Terminal CCI 100 Pos: 37.166 /Überschriften/Überschriften 3/P-T/Physikalische Meldungen @ 34\mod_1255442189285_78.docx @ 323664 @ 3 @ 1 8.13.5 Physical messages Pos: 37.167 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Physikalische Meldungen Comprima F/V XC @ 267\mod_1400745894558_78.docx @ 2022213 @ @ 1 Symbol Sensor Possible cause Remedy “Net length” sensor “Net running”...
Page 188: General Messages
KRONE ISOBUS-Terminal CCI 100 Pos: 37.169 /Überschriften/Überschriften 3/A-E/A/Allgemeine Meldungen @ 34\mod_1255443656238_78.docx @ 323714 @ 2 @ 1 8.13.6 General Messages Pos: 37.170 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Allgemeine Meldungen @ 50\mod_1287572766734_78.docx @ 474221 @ @ 1 Icon Acoustic signal Description Fuse 2 defective (job computer)
Page 189: Isobus Operation
The operation of this machine requires at least implementation level 3 of the ISOBUS system. Pos: 39.3 /BA/Info-Center/Iso-Bedienung/Gefahr durch nicht von KRONE gelieferte Terminals / Bedieneinheiten @ 48\mod_1286197403750_78.docx @ 459766 @ @ 1 DANGER! When using terminals and other control units which have not been delivered by KRONE mind that the user: •...
Page 190: Mounting Isobus Terminal
• Connect plug (6) (2-pole) of cable set (1) with socket (7) (2-pole) of the machine Pos: 39.6 /BA/Info-Center/Iso-Bedienung/BigPack/Abweichende Funktionen zum KRONE ISOBUS-Termina CCI @ 47\mod_1285223499328_78.docx @ 455993 @ 2 @ 1 Differing functions to KRONE ISOBUS terminal CCI Via the accessory unit, the ISOBUS control unit will provide information and control functions to the display of the ISOBUS terminal.
Page 191 The values for “Bale size (Comprima V150/180)” and “Bale density (Comprima F125/155)” which are set by the scroll wheel in the basic screen on the KRONE ISOBUS terminal CCI, are set on the ISOBUS terminal with the selection key predetermined by the ISOBUS terminal (refer to the operating instructions of the ISOBUS terminal manufacturer).
Page 192: Isobus „Auxiliary"-Function (Aux)
ISOBUS operation Pos: 39.11 /Überschriften/Überschriften 1/A-E/ISOBUS „Auxiliary“-Funktion (AUX) @ 48\mod_1286278825265_78.docx @ 460508 @ 2 @ 1 ISOBUS „Auxiliary“-function (AUX) Pos: 39.12 /BA/Info-Center/Iso-Bedienung/Hinweis Terminal die Auxilliary unterstützen @ 48\mod_1286278420671_78.docx @ 460483 @ @ 1 Note There are terminals which support the additional function “auxiliary” (AUX). With this function, programmable keys of the peripheral equipment (e.g.
Page 193: Example Of Joystick Assignment For Fendt (Default Setting)
ISOBUS operation Pos: 39.15 /BA/Info-Center/Iso-Bedienung/Rundballenpressen/Joystick-Belegung Fendt Comprima F/V @ 221\mod_1391682547329_78.docx @ 1797103 @ 3 @ 1 9.3.1 Example of joystick assignment for Fendt (default setting) Note For further guidelines, please refer to the operating instructions of the terminal being used. Fig.
Page 194: Recommended Settings For A Wtk Multi-Function Lever (Default Setting)
ISOBUS operation Pos: 39.17 /BA/Info-Center/Iso-Bedienung/Rundballenpressen/Joystick-Belegung WTK Comprima F/V @ 221\mod_1391682775576_78.docx @ 1797242 @ 3 @ 1 9.3.2 Recommended settings for a WTK multi-function lever (default setting) Note For further guidelines, please refer to the operating instructions of the terminal being used. Switch (1) on the rear in upper position (LED (2) lights up red).
Page 195: Operation Of The Hydraulic Zero Setting Of Blades (Optional)
Before carrying out any maintenance work on the comfort blade control system or on the cutter base, the hydraulic system must be depressurised on tractor side as well as on machine side. Pos: 41.4 /Überschriften/Überschriften 2/K-O/KRONE Bedienterminal Beta @ 82\mod_1316608830339_78.docx @ 720303 @ 3 @ 1 10.1 KRONE operation terminal Beta Pos: 41.5 /Überschriften/Überschriften 3/F-J/Grundbild bei hydr.
Page 196 Operation of the Hydraulic Zero Setting of Blades (Optional) Selection options blade group control system Swivelling in blade group A (activating) Swivelling in blade group A and B (activating) Swivelling in blade group B (activating) Swivelling out blade group A and B (deactivating) •...
Page 197 Operation of the Hydraulic Zero Setting of Blades (Optional) Status displays of the blade group control system Blade group A swivelled in (activated) Blade group A and B swivelled in (activated) Blade group B swivelled in (activated) Blade group A and B swivelled out (deactivated) Blade group A and B swivelled out and blade base down (removal of blades) (deactivated) Note...
Page 198: Krone Isobus Terminal
Operation of the Hydraulic Zero Setting of Blades (Optional) Pos: 41.8 /Überschriften/Überschriften 2/K-O/KRONE ISOBUS-Terminal @ 212\mod_1389780572708_78.docx @ 1742242 @ 2 @ 1 10.2 KRONE ISOBUS Terminal Pos: 41.9 /Überschriften/Überschriften 3/F-J/Grundbild bei hydr. Messernullschaltung (Option) @ 82\mod_1316609023251_78.docx @ 720331 @ 2 @ 1 10.2.1...
Page 199 Operation of the Hydraulic Zero Setting of Blades (Optional) After having selected the desired blade group control system, the prompt to swivel in or swivel out the blades via the hydraulics on the tractor appears with a delay of approx. 2 seconds: •...
Page 200: Sensor Test / Actuator Test
Operation of the Hydraulic Zero Setting of Blades (Optional) Pos: 41.12 /BA/Info-Center/Rundballenpresse/Hand-/Automatikbetrieb/Sensor_Aktortest bei Messernullschaltung CCI @ 82\mod_1316613987060_78.docx @ 720561 @ 2 @ 1 10.2.1.1 Sensor test / actuator test Additional sensors in the sensor test in comfort blade control system Sensor Description symbol...
Page 201: Alarm Messages For Blade Comfort Selection
Operation of the Hydraulic Zero Setting of Blades (Optional) Pos: 41.14 /BA/Info-Center/Rundballenpresse/Hand-/Automatikbetrieb/Alarmmeldungen bei Messernullschaltung CCI @ 214\mod_1390474160730_78.docx @ 1756784 @ 4 @ 1 10.2.1.2 Alarm messages for blade comfort selection Notes and messages Figure Possible cause Remedy – Blade base is not closed. –...
Page 202: Hydraulic Circuit Diagram With Hydraulic Zero Setting Of Blades
Operation of the Hydraulic Zero Setting of Blades (Optional) Pos: 41.16 /Überschriften/Überschriften 2/F-J/Hydraulikschaltplan mit hydraulischer Messernullschaltung @ 85\mod_1319525718261_78.docx @ 739015 @ 2 @ 1 10.3 Hydraulic Circuit Diagram with Hydraulic Zero Setting of Blades Pos: 41.17 /Beipacks/Rundballenpressen/Hydraulische Messernullschaltung/Bild Hydraulikplan @ 83\mod_1317286494937_78.docx @ 728262 @ @ 1 Fig.
Page 203: Operation Of The Electronic Baling Pressure Adjustment (Optional)
Operation of the Electronic baling pressure adjustment (Optional) Pos: 43.1 /Überschriften/Überschriften 1/A-E/Bedienung der Elektronischen Pressdruckverstellung (Option) @ 102\mod_1330962101298_78.docx @ 900976 @ 1 @ 1 Operation of the Electronic baling pressure adjustment (Optional) Pos: 43.2 /Beipacks/Rundballenpressen/Elektronische Pressdruckverstellung/Richtwerte Druck BA elktr. Pressdruckverstellung @ 102\mod_1330962335054_78.docx @ 901065 @ @ 1 These values serve as rough guides for the following settings of the baling pressure in the operator terminals: 100%...
Page 204: Krone Beta Operator Terminal
Operation of the Electronic baling pressure adjustment (Optional) Pos: 43.4 /BA/Info-Center/Rundballenpresse/Hand-/Automatikbetrieb/Grundbild _elektr. Druckverstellung_Beta @ 86\mod_1319786722418_78.docx @ 739975 @ 33 @ 1 11.1 KRONE Beta operator terminal Pos: 62 /Überschriften/Überschriften 3/F-J/Grundbild bei hydr. Messernullschaltung (Option) @ 82\mod_1316609023251_6.doc @ 720325 11.1.1 Basic screen for the electronic baling pressure setting...
Page 205: Krone Isobus Cci 100 Terminal
Operation of the Electronic baling pressure adjustment (Optional) Pos: 43.7 /BA/Info-Center/Rundballenpresse/Hand-/Automatikbetrieb/Grundbild _elektr. Druckverstellung_ CCI F/V @ 102\mod_1331133339540_78.docx @ 903403 @ 23 @ 1 11.2 KRONE ISOBUS CCI 100 Terminal 11.2.1 Basic screen for the electronic baling pressure setting Pos: 62 /Überschriften/Überschriften 3/F-J/Grundbild bei hydr. Messernullschaltung (Option) @ 82\mod_1316609023251_6.doc @ 720325...
Page 206 Operation of the Electronic baling pressure adjustment (Optional) Adjusting the baling pressure Comprima V 150/180/210 (XC) ZBBP0245 Fig. 172 • function key to increase/decrease the baling pressure. The icon in the upper line disappears • Press key. The set baling pressure is saved and the icon appears in the upper line.
Page 207: Actuator Test
Operation of the Electronic baling pressure adjustment (Optional) Pos: 43.10 /BA/Info-Center/Rundballenpresse/Hand-/Automatikbetrieb/Sensor_Aktortest bei Elektr. Pressdruckventil @ 86\mod_1319799218763_78.docx @ 740718 @ 4 @ 1 11.2.1.1 Actuator test Note The process of performing the actuator test is described in the machine operating instructions. Additional actuators in the actuator test for the electronic pressure limiting valve Actuator Description...
Page 208: Start-Up
Start-up Pos: 45.1 /Überschriften/Überschriften 1/F-J/Inbetriebnahme @ 0\mod_1196327075811_78.docx @ 6375 @ 1 @ 1 Start-up Pos: 45.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Inbetriebnahme/Unvorhergesehene Inbetriebnahme Fortima V 1500 MC @ 209\mod_1387357052199_78.docx @ 1724288 @ @ 1 DANGER! - Unintentional starting, moving machine components and / or unexpected machine movement! Effect: Risk of death, injuries or damage to the machine.
Page 209: Mounting Onto The Tractor
Start-up Pos: 45.4 /Überschriften/Überschriften 2/A-E/Anbau an den Traktor @ 0\mod_1199717845194_78.docx @ 34039 @ 2 @ 1 12.1 Mounting onto the Tractor Pos: 45.5 /BA/Sicherheit/6. Überarbeitete Warnhinweise/An-/ Abbau/Gefahr - An-/ Abbau der Maschine Rundballenpressen @ 295\mod_1412155785169_78.docx @ 2319995 @ @ 1 Warning! There is a risk of injury when you hitch the machine to the tractor.
Page 210: Hydraulics
Start-up Pos: 45.10.1 /Überschriften/Überschriften 2/F-J/Hydraulik @ 0\mod_1199776034950_78.docx @ 34205 @ 2 @ 1 12.2 Hydraulics Pos: 45.10.2 /Überschriften/Überschriften 3/P-T/Spezielle Sicherheitshinweise @ 0\mod_1197301069931_78.docx @ 17662 @ 3 @ 1 12.2.1 Special Safety Instructions Pos: 45.10.3 /BA/Sicherheit/Hydraulik/Warnung - Anschluss der Hydraulikleitungen @ 0\mod_1199776548685_78.docx @ 34225 @ @ 1 Warning ! - Connection of the hydraulic line Effect: severe injuries due to penetration of hydraulic oil under the skin.
Page 211: Connecting The Hydraulic Lines
Start-up Pos: 45.10.7 /Überschriften/Überschriften 3/F-J/Hydraulikleitungen anschließen @ 0\mod_1199777037794_78.docx @ 34244 @ 3 @ 1 12.2.2 Connecting the hydraulic lines Pos: 45.10.8 /BA/Inbetriebnahme/Rundballenpresse/Hydraulik/Am Traktor werden für den Betrieb der Maschine benötigt: @ 220\mod_1391432975471_78.docx @ 1782378 @ @ 1 To perform the following hydraulic functions, the tractor requires: Pos: 45.10.9 /BA/Inbetriebnahme/Rundballenpresse/Hydraulik/2 einfachwirkende Steuergeräte und 1 doppelwirkendes Steuergerät @ 220\mod_1391433071944_78.docx @ 1782441 @ @ 1 –...
Page 212 Start-up Pos: 45.10.16 /BA/Inbetriebnahme/Hydraulikkupplungen anschließen alle Maschinen/Hinweis Hydraulikaufkleber an der Maschine beachten @ 204\mod_1386153225929_78.docx @ 1701911 @ @ 1 Note Connect hydraulic hoses correctly. • The hydraulic hoses are marked with numbers and coloured dust caps. Pos: 45.10.17 /BA/Inbetriebnahme/Hydraulikkupplungen anschließen alle Maschinen/Hydraulikkupplungen anschließen Teil1 @ 213\mod_1390207328923_78.docx @ 1749237 @ @ 1 •...
Page 213: Hydraulic Brake (Export)
Start-up Pos: 45.12 /Überschriften/Überschriften 2/F-J/Hydraulische Bremse (Export) @ 17\mod_1236332990291_78.docx @ 204927 @ 2 @ 1 12.3 Hydraulic brake (Export) Pos: 45.13 /BA/Inbetriebnahme/Hydraulische Bremse/Bild Hydraulische Bremse Fortima V 1500 MC @ 32\mod_1253192337285_78.docx @ 313011 @ @ 1 KR200032 Fig. 175 Pos: 45.14 /BA/Inbetriebnahme/Hydraulische Bremse/Hydraulische Bremse (Export) @ 17\mod_1236333662166_78.docx @ 204952 @ @ 1 A hydraulic brake is provided for certain export versions.
Page 214: Install The Pto Shaft
Start-up Pos: 45.17 /Überschriften/Überschriften 2/F-J/Gelenkwelle montieren @ 2\mod_1202398342788_78.docx @ 59253 @ 2 @ 1 12.5 Install the PTO shaft Pos: 45.18 /BA/Sicherheit/Gelenkwelle/Gefahr - Sich drehende Gelenkwelle_4 @ 17\mod_1236258545347_78.docx @ 204209 @ @ 1 DANGER! - Rotating universal shaft! Effect: Danger to life or serious injuries •...
Page 215 Start-up KR-1-080 Fig. 177 CAUTION! Contact with parts of the tractor or the machine may result in damages to the machine or to the universal shaft • Make certain there is sufficient free space in the swivel range of the PTO shaft in all operating states.
Page 216: Compressed Air Connections For The Compressed Air Brake
Start-up Pos: 45.24 /Überschriften/Überschriften 2/A-E/Druckluftanschlüsse bei Druckluftbremse @ 0\mod_1201161304258_78.docx @ 51103 @ 2 @ 1 12.6 Compressed Air Connections for the Compressed Air Brake Pos: 45.25 /BA/Sicherheit/2. Vorangestellte Warnhinweise/Warnung - Versagen der Druckluftbremsanlage @ 273\mod_1403777396384_78.docx @ 2056965 @ @ 1 WARNING! Danger to life due to failure of the brake system or unexpected movement of the machine.
Page 217: Electrical Connections
Start-up Pos: 45.30 /Überschriften/Überschriften 2/A-E/Elektrische Anschlüsse @ 17\mod_1236579932558_78.docx @ 205175 @ 2 @ 1 12.7 Electrical connections Pos: 45.31 /BA/Inbetriebnahme/Rundballenpresse/Elektrische Anschlüsse Fortima V 1500 MC @ 131\mod_1347959904107_78.docx @ 1164120 @ @ 1 KR-1-044 Fig. 179 • Connect the connection cable (2) for the lighting to the 7-pin plug-in connector of the tractor electrical system •...
Page 218: Using The Safety Chain
Start-up Pos: 45.34.1 /Überschriften/Überschriften 2/P-T/Sicherungskette verwenden @ 6\mod_1214542336632_78.docx @ 94799 @ 2 @ 1 12.8 Using the safety chain Pos: 45.34.2 /BA/Inbetriebnahme/Sicherungskette USA/WARNUNG - Falsch dimensionierte Sicherungskette verwendet mit Variante @ 180\mod_1376576652355_78.docx @ 1547873 @ @ 1 WARNING! When using a wrongly dimensioned safety chain, the safety chain may tear if the machine loosens unintentionally.
Page 219 Start-up Pos: 45.34.7 /Beipacks/Sonstige/Sicherungskette 89kN/Sicherungskette am Traktor montieren Mäher,Schwader,Wender Bild @ 150\mod_1362048508388_78.docx @ 1343347 @ @ 1 ZBBP0899_1 Fig. 180 Pos: 45.34.8 /Beipacks/Sonstige/Sicherungskette 89kN/Sicherungskette am Traktor montieren Text @ 150\mod_1362048347829_78.docx @ 1343318 @ @ 1 • Install safety chain (1) on an eligible position (for example: a or b) on the tractor. Pos: 45.34.9 /BA/Inbetriebnahme/Sicherungskette USA/Sicherheitskette Bild Rundballenpressen @ 181\mod_1376899543214_78.docx @ 1549227 @ @ 1 RPN00075 Fig.
Page 220: Driving And Transport
Driving and Transport Pos: 47.1 /Überschriften/Überschriften 1/F-J/Fahren und Transport @ 0\mod_1196330049217_78.docx @ 6553 @ 2 @ 1 Driving and Transport Pos: 47.2 /Überschriften/Überschriften 2/U-Z/Vorbereitungen zur Straßenfahrt @ 25\mod_1244092605963_78.docx @ 254666 @ 2 @ 1 13.1 Preparations for road travel Pos: 47.3 /BA/Sicherheit/Fahren und Transport/Fortima V 1500 MC Gefahr Straßenfahrt,Mitfahren,Fahrverhalten @ 209\mod_1387367868107_78.docx @ 1724901 @ @ 1 DANGER! - Road driving, riding, driving behaviour Effect: Risk of death, injuries or damage to the machine.
Page 221: Lifting The Pick-Up
Driving and Transport Pos: 47.5 /BA/Fahren und Transport/Großpackenpresse/Arbeiten vor der Straßenfahrt an Maschine und Traktor @ 17\mod_1236587828339_78.docx @ 205393 @ @ 1 The following tasks must be performed on the machine and tractor before road travel: Pos: 47.6 /BA/Einstellungen/Pick-up / Rollenniederhalter/Pick-up ausheben Comprima XC @ 95\mod_1328699529228_78.docx @ 801209 @ 2 @ 1 13.1.1 Lifting the Pick-up COM00338...
Page 222: Checking The Parking Support
Driving and Transport Pos: 47.8 /BA/Fahren und Transport/Rundballenpresse/Abstellstütze prüfen @ 32\mod_1253612569968_78.docx @ 315337 @ 3 @ 1 13.1.2 Checking the parking support CPB00100 Fig. 183 • Disconnect the electrical power supply to the control unit • Check that the parking support (1) is in transport position Pos: 47.9 /Überschriften/Überschriften 3/A-E/B/Beleuchtungsanlage prüfen @ 25\mod_1244090937463_78.docx @ 254566 @ 3 @ 1 13.1.3 Checking the lighting system...
Page 223: Parking
Driving and Transport Pos: 47.14 /Überschriften/Überschriften 2/A-E/Abstellen @ 0\mod_1199801980622_78.docx @ 35320 @ 2 @ 1 13.2 Parking Pos: 47.15 /BA/Sicherheit/7. Gefahrenhinweise alt/Gefahr - Maschine abstellen Fortima V 1500 MC @ 211\mod_1389189770743_78.docx @ 1732857 @ @ 1 DANGER! – Unexpected movement of machine Effect: Risk of death, serious injuries •...
Page 224: Lowering The Parking Support
Driving and Transport Pos: 47.19 /BA/Fahren und Transport/Rundballenpresse/Bild Abstellstütze runter @ 32\mod_1253617125109_78.docx @ 315487 @ 3 @ 1 13.2.2 Lowering the parking support CPB00090 Fig. 186 Pos: 47.20 /BA/Fahren und Transport/Rundballenpresse/Abstellstütze positionieren @ 32\mod_1253617584078_78.docx @ 315512 @ @ 1 • Remove stake bolt (2), bring the support pipe out of the parking support (1) and then secure again with the stake bolt (2).
Page 225: Disconnecting The Supply Lines
Driving and Transport Pos: 47.26 /BA/Fahren und Transport/Rundballenpresse/Bild Fortima V 1500 MC Hydraulikschläuche abziehen @ 32\mod_1253618970406_78.docx @ 315587 @ 3 @ 1 13.2.4 Disconnecting the supply lines KR-1-147 Fig. 188 Pos: 47.27 /BA/Fahren und Transport/Rundballenpresse/Hydraulikschläuche abziehen @ 32\mod_1253618767671_78.docx @ 315566 @ @ 1 •...
Page 226: Operation
Operation Pos: 49.1 /Überschriften/Überschriften 1/A-E/Bedienung @ 0\mod_1199789505403_78.docx @ 34825 @ 1 @ 1 Operation Pos: 49.2 /BA/Sicherheit/Rundballenpresse/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarbeiten VP @ 209\mod_1387358602334_78.docx @ 1724405 @ @ 1 Danger! - Maintenance, installation, repair and adjustment work, troubleshooting and fault resolution Effect: Risk of death, injuries or damage to the machine.
Page 227: Travelling Speed
Operation Pos: 49.7 /BA/Bedienung /Rundballenpresse/hohe Ballendichte @ 35\mod_1256125227222_78.docx @ 326331 @ @ 1 If the cutting system is switched on during baling, the bale density will increase substantially, which makes it necessary to reduce the baling pressure. Pos: 49.8 /BA/Bedienung /Rundballenpresse/Kurzes Stroh @ 66\mod_1302508002442_78.docx @ 616455 @ @ 1 To do this: Short, crumbly straw: •...
Page 228: Filling The Bale Chamber
Operation Pos: 49.14 /BA/Bedienung /Rundballenpresse/Ballenkammer befüllen @ 55\mod_1294145026250_78.docx @ 526912 @ 2 @ 1 14.3 Filling the bale chamber Fig. 189 To attain a consistent bale density inside a round bale, the bale chamber should be filled evenly. The swath width is an important factor here. The swath width is optimal if the swath has exactly the same width as the bale chamber.
Page 229: Reducing The Pressure On The Side Walls Of The Bale Chamber
Operation Pos: 49.19 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F125/F155 (XC) @ 80\mod_1315900077159_78.docx @ 708231 @ @ 1 Comprima F125/F155 (XC) Pos: 49.20 /BA/Bedienung /Rundballenpresse/Hinweise Ballenkammer befüllen CF @ 66\mod_1302514167499_78.docx @ 616925 @ @ 1 Note The binding process should be started at the latest when the baling pressure indicators reach the red range (the buzzer sounds if the comfort electronic system is fitted).
Page 230: Assembly Of Additional Tappet Strips On The Starter Roller
Operation Pos: 49.24 /Überschriften/Überschriften 4/K-O/Montage zusätzlicher Mitnehmerleisten auf der Starterwalze @ 66\mod_1302512470547_78.docx @ 616733 @ 4 @ 1 14.3.1.1 Assembly of Additional Tappet Strips on the Starter Roller Pos: 49.25 /BA/Sicherheit/Module Achtung/Gefahr - Geöffnete Heckklappe @ 32\mod_1253180791300_78.docx @ 312630 @ @ 1 DANGER! –...
Page 231: Assembly Of Additional Ejector Plates In The Tailgate
If the completed bales do even not fall out of the front bale chamber after having installed the ejector plates (1), remove the sliding plates (3) from the machine housing right and left. The ejector plates (1) can be ordered with suitable screws from KRONE spare part storage by stating the following spare parts no.: Pos: 49.33 /BA/Bedienung /Rundballenpresse/Tabelle Ersatzteile Anlagebleche F125/155 @ 137\mod_1353593714768_78.docx @ 1221214 @ @ 1...
Page 232 If the completed bales do even not fall out of the front bale chamber after having installed the ejector plates (1), remove the sliding plates (3) from the machine housing right and left. The ejector plates (1) can be ordered with suitable screws from KRONE spare part storage by stating the following spare parts no.: Pos: 49.38 /BA/Bedienung /Rundballenpresse/Tabelle Ersatzteile Anlagebleche F125/155 @ 137\mod_1353593714768_78.docx @ 1221214 @ @ 1...
Page 233: Wrapping And Depositing Bales
If the completed bales do even not fall out of the front bale chamber after having installed the ejector plates (1), remove the sliding plates (3) from the machine housing right and left. The ejector plates (1) can be ordered with suitable screws from KRONE spare part storage by stating the following spare parts no.: Pos: 49.43 /BA/Bedienung /Rundballenpresse/Tabelle Ersatzteile Anlagebleche CV210 @ 137\mod_1353510973257_78.docx @ 1219422 @ @ 1...
Page 234: Driving With Bale Ejector
Operation Pos: 49.46 /Überschriften/Überschriften 2/F-J/Fahren mit Ballenauswerfer @ 80\mod_1315901275288_78.docx @ 708396 @ 2 @ 1 14.5 Driving with Bale Ejector Pos: 49.47 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 49.48 /BA/Bedienung /Rundballenpresse/Bild Fahren mit Ballenauswerfer @ 81\mod_1315901701515_78.docx @ 708419 @ @ 1 VPN00613 Fig.
Page 235: Before Baling
Operation Pos: 49.51 /Überschriften/Überschriften 2/U-Z/Vor dem Pressen @ 59\mod_1297349886078_78.docx @ 556726 @ 2 @ 1 14.6 Before Baling Pos: 49.52 /Überschriften/Überschriften 3/P-T/Rollboden spannen @ 192\mod_1382085134347_78.docx @ 1637727 @ 3 @ 1 14.6.1 Tensioning the floor conveyor Pos: 49.53 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 49.54 /BA/Bedienung /Rundballenpresse/Hinweise Rollboden spannen @ 59\mod_1297350006477_78.docx @ 556749 @ @ 1 Note...
Page 236: After Baling
The drive is fitted with a cam-type clutch (1) as a protection against overload. This coupling has been set in the works of the manufacturer and may not be adjusted without prior harmonisation with the KRONE after-sales staff. Pos: 49.65 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 237: Pick-Up
Operation Pos: 49.66 /Überschriften/Überschriften 2/P-T/Pick up @ 1\mod_1201791975201_0.docx @ 54586 @ 2 @ 1 14.9 Pick-up Pos: 49.67 /Überschriften/Überschriften 2/F-J/Grundeinstellung (einstellen der Arbeitshöhe) @ 19\mod_1238576636385_78.docx @ 221585 @ 2 @ 1 14.10 Default Setting (Working Height Setting) Pos: 49.68 /BA/Einstellungen/Pick-up / Rollenniederhalter/Hinweis Fahren im Vorgewende @ 20\mod_1238578490213_78.docx @ 221874 @ @ 1 Note Lift the Pick-up for driving in the headland or when driving backward! Pos: 49.69 /BA/Sicherheit/Pick-up / Rollenniederhalter/Warnung - Arbeiten an bzw.
Page 238: Roller Crop Guide
Operation Pos: 49.73.1 /Überschriften/Überschriften 2/P-T/Rollenniederhalter @ 0\mod_1201163046930_78.docx @ 51122 @ 2 @ 1 14.11 Roller crop guide Pos: 49.73.2 /BA/Sicherheit/Pick-up / Rollenniederhalter/Warnung! - Abbau des Rollenniederhalters @ 274\mod_1404216918043_78.docx @ 2060895 @ @ 1 WARNING! Risk of injury if the machine is used without a roller crop guide! If the machine is operated without a roller crop guide, people can be seriously injured or killed.
Page 239: Bearing Pressure Relief Of The Pick-Up
Operation Pos: 49.75 /Überschriften/Überschriften 3/A-E/A/Auflagedruckentlastung der Pick-up @ 67\mod_1302524398424_78.docx @ 617349 @ 3 @ 1 14.11.1 Bearing Pressure Relief of the Pick-up Pos: 49.76 /BA/Einstellungen/Pick-up / Rollenniederhalter/Pick-up Auflagedruckentlastung Bild @ 67\mod_1302524532234_78.docx @ 617373 @ @ 1 RPN00023_3 Abb. 200 Pos: 49.77 /BA/Einstellungen/Pick-up / Rollenniederhalter/Arbeitsschritte Druck Pick-up entlasten Comprima CV/CF/F/V @ 67\mod_1302524952195_78.docx @ 617401 @ @ 1 In order to be able to pass over unevenness better, the pick-up is supported by means of two springs.
Page 240: Cutting System
Operation Pos: 49.80.1 /Überschriften/Überschriften 2/P-T/Schneidwerk @ 20\mod_1238593156760_78.docx @ 223560 @ 2 @ 1 14.12 Cutting system Pos: 49.80.2 /BA/Sicherheit/Schneidwerk/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarb Schneidwerk VP @ 244\mod_1395818598014_78.docx @ 1910171 @ @ 1 WARNING! – Maintenance, assembly, repair and adjustment work as well as troubleshooting and fault clearance Effect: Danger to life, injuries or damage to the machine.
Page 241: Cutting Length
Operation Pos: 49.80.5 /BA/Einstellungen/Schneidwerk/Schnittlänge einstellen/Schnittlänge CF/CV @ 221\mod_1391601707157_78.docx @ 1791248 @ 3 @ 1 14.12.2 Cutting length Fig. 201 The cutting length is determined by the number of blades. Use the key supplied to make adjustments. HDC00012 Fig. 202 The multi-purpose key (1) can be found on the pick-up on the left-hand side of the machine. CAUTION! - Unexpected movement of multi-purpose key! The multi-purpose key can move suddenly due to the spring force of the pretensioned blades.
Page 242 Operation Pos: 49.80.7 /BA/Einstellungen/Schneidwerk/Schnittlänge einstellen/Schnittlänge Messer Bild @ 67\mod_1302528326300_78.docx @ 617569 @ @ 1 RPN00020_2 Abb. 203 Pos: 49.80.8 /BA/Einstellungen/Schneidwerk/Schnittlänge einstellen/Schnittlänge Tabelle durch Messerbestückung CF/CV @ 67\mod_1302528059446_78.docx @ 617541 @ @ 1 Table Cutting Length depending on Blade Equipping In case of 17 blades: Cutting length Number of Blades Setting A/B...
Page 243 Operation Pos: 49.80.10 /BA/Einstellungen/Schneidwerk/Schnittlänge einstellen/Schnittlänge Messer Bild @ 67\mod_1302528326300_78.docx @ 617569 @ @ 1 RPN00020_2 Abb. 204 Pos: 49.80.11 /WHB/Warnhinweise - Allgemeingültig/VORSICHT - Zurückschlagende Messer - nicht von Hand in Arbeitsposition, Hammer verwenden, @ 55\mod_1292578390301_78.docx @ 521706 @ @ 1 CAUTION! - Blades fold back! The blades are pre-tensioned via spring force.
Page 244: Zero Position Of The Cutter
Operation Pos: 49.80.15 /Überschriften/Überschriften 3/K-O/Messer wechseln @ 40\mod_1268820477038_78.docx @ 362202 @ 3 @ 1 14.12.3 Zero position of the cutter Pos: 49.80.16 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Gefahr Messermontage Vorgespannte Messer @ 74\mod_1308724042343_78.docx @ 657335 @ @ 1 DANGER! -Blades are Pre-tensioned With Spring Force! Risk of injury when attaching or removing the blades.
Page 245 Operation Pos: 49.80.22 /BA/Erstinbetriebnahme/Rundballenpresse/Messerboden absenken CF/CV @ 74\mod_1308657880947_78.docx @ 656737 @ @ 1 RPN00013_2 Abb. 206 • Lower the cutter base (1) mechanically or hydraulically Pos: 49.80.23 /BA/Einstellungen/Schneidwerk/Messerschaltwelle 0-Stellung @ 74\mod_1308658167155_78.docx @ 656795 @ @ 1 Move the Blade Control Shafts (A/B) Mechanically Into the Blade-0-Position (Position (-)): RPN00020_2 Abb.
Page 246 Operation Pos: 49.80.25 /BA/Einstellungen/Schneidwerk/Messerwelle entsichern CF/CV @ 74\mod_1308661085085_78.docx @ 656823 @ @ 1 Unlocking the Blade Shaft RPN00015_1 Abb. 208 • Unlock blade shaft: Pull the locking bolt (1) out of position (a) and allow it to engage in position (b) Note The supplied key can also be used for locking/ unlocking the blade shaft.
Page 247 If the cutting system is not connected for long periods, the cutting blades can be replaced with blind blades to prevent soiling of the slots on the blade base and wear to the blades. The blind blades can be ordered from the KRONE spare parts department under part number 200654050.
Page 248: Setting The Bale Diameter
Operation Pos: 49.82 /Überschriften/Überschriften 2/A-E/Einstellen der Ballendurchmessers @ 74\mod_1308726004540_78.docx @ 657421 @ 2 @ 1 14.13 Setting the Bale Diameter Pos: 49.83 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F155 (XC) @ 79\mod_1314690325737_78.docx @ 697640 @ @ 1 Comprima F155 (XC) Pos: 49.84 /WHB/Grundeinstellungen/Rundballenpresse/Einstellen des Ballendurchmessers (COMPRIMA F155) @ 212\mod_1389782655887_78.docx @ 1742440 @ @ 1 The tailgate must be closed and the bale chamber must be empty.
Page 249: Pre-Select The Bale Diameter (Comprima V150/V180/V210 (Xc) )) (Medium Electronic System)
10=1.0 m, 12=1.2 m). 3. Loosen the wing nut (2) in the twine box and move the screw with wing nut in the oblong hole until the pilot lamps on the KRONE operation terminal Alpha light up and the horn sounds.
Page 250: Setting Of The Bale Diameter Display (Comprima V150/V180/V210 Xc)) (Medium Electronic System)
Operation Pos: 49.89 /Überschriften/Überschriften 3/A-E/E/Einstellung der Ballendurchmesseranzeige (COMPRIMA V150 / V180) (Medium) @ 55\mod_1292491678239_78.docx @ 519717 @ 3 @ 1 14.13.2 Setting of the Bale Diameter Display (Comprima V150/V180/V210 XC)) (Medium Electronic System) Pos: 49.90 /WHB/Grundeinstellungen/Rundballenpresse/Einstellung der Ballendurchmesseranzeige (COMPRIMA V150 / V180) (Medium) @ 55\mod_1292491753817_78.docx @ 519743 @ @ 1 WHBCP075 Fig.
Page 251: Setting Baling Pressure
Operation Pos: 49.92 /Überschriften/Überschriften 2/P-T/Pressdruck einstellen @ 59\mod_1297666400713_78.docx @ 558581 @ 2 @ 1 14.14 Setting Baling Pressure Pos: 49.93 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 49.94 /BA/Bedienung /Rundballenpresse/Bild Pressdruck Handrad @ 59\mod_1297666635329_78.docx @ 558608 @ @ 1 VPN00001_2 Fig.
Page 252 2. Manually raise both baling pressure indicators (1) to the desired position (baling pressure). 3. Loosen the wing nut (2) in the twine box and move the screw with wing nut in the oblong hole until the pilot lamps on the KRONE operation terminal Alpha light up and the horn sounds.
Page 253: Setting Tailgate Catch (Medium Electronic System)
Operation Pos: 49.106 /Überschriften/Überschriften 2/A-E/Einstellung Heckklappenverschluss (Mediumelektronik) @ 81\mod_1315916822746_78.docx @ 709962 @ 2 @ 1 14.15 Setting Tailgate Catch (Medium Electronic System) Pos: 49.107 /BA/Bedienung /Rundballenpresse/Einstellen Heckklappenverschluss @ 81\mod_1315916961701_78.docx @ 709986 @ @ 1 RPN00024_2 RPN00025 Fig. 216 The cable (1) (right/left) is used to indicate on both displays (2) on the right-hand side of the machine whether the tailgate is closed correctly.
Page 254: Setting Of The Baling Pressure Display (Medium Electronic System)
Operation “Tighten the floor conveyor and set the spring pretensioning”). If the bales are still formed conically after the adjustment, proceed as follows: Raise the tension levers on the left/right (1) 20 mm (Comprima F 125 (XC)) and 30 mm (Comprima F 155 (XC) each from the stop (2).
Page 255: Net Wrapping
Operation Pos: 49.112 /Überschriften/Überschriften 2/K-O/Netzbindung @ 33\mod_1254400902338_78.docx @ 319495 @ 2 @ 1 14.17 Net Wrapping Pos: 49.113 /BA/Sicherheit/Rundballenpresse/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarbeiten VP @ 209\mod_1387358602334_78.docx @ 1724405 @ @ 1 Danger! - Maintenance, installation, repair and adjustment work, troubleshooting and fault resolution Effect: Risk of death, injuries or damage to the machine.
Page 256: Net Wrapping Parts
Operation Pos: 49.115 /Überschriften/Überschriften 3/A-E/B/Bauteile Netzbindung @ 33\mod_1254401988166_78.docx @ 319545 @ 3 @ 1 14.17.1 Net wrapping parts Pos: 49.116 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Bild Bauteile Netzbindung CF/CV @ 74\mod_1308745050584_78.docx @ 657651 @ @ 1 RPN00007_6 Fig. 218 Blade bar Retaining clip Feed roller 10 Synthetic cloth Net compensation 11 Net...
Page 257: Inserting The Net Roll
Operation Pos: 49.119 /Überschriften/Überschriften 2/K-O/Netzrolle einlegen @ 33\mod_1254403373541_78.docx @ 319645 @ 2 @ 1 14.18 Inserting the Net Roll Pos: 49.120 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Achtung Öl auf Bindegarn @ 37\mod_1264496122520_78.docx @ 341340 @ @ 1 CAUTION! – Contamination of the twine and tying mechanism by oil and grease Effect: Machine damage and problems when unrolling twine •...
Page 258: Insert Net
Operation Pos: 49.125 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netz über Bremse @ 33\mod_1254818678270_78.docx @ 319891 @ @ 1 RBV00111 Fig. 220 • Once installed, the net roll can be aligned to the right and left in the centre to the machine using the mounting lever (2). •...
Page 259 Operation Pos: 49.130 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netz einlegen CF/CV @ 74\mod_1308812341024_78.docx @ 657997 @ @ 1 COM00200_1 Fig. 221 • Before threading in the net, press the blade bar (1) back with your hand until the ratched mechanism (2) engages RPN00008_7 Fig. 222 •...
Page 260: Setting Cut-Off Position
Operation Pos: 49.132 /Überschriften/Überschriften 3/A-E/E/Einstellung Abschneideposition @ 74\mod_1308830581899_78.docx @ 658367 @ 3 @ 1 14.18.2 Setting Cut-off Position Pos: 49.133 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Abschneideposition einstellen CF/CV @ 74\mod_1308828767840_78.docx @ 658310 @ @ 1 RPN00044 Fig. 223 The cut-off position has been reached, when the ratchet mechanism (1) is raised and dimension A between the ratchet mechanism (1) and the adjusting lever (2) is A= 410 mm.
Page 261: Setting Of The Feed Position
Operation Pos: 49.135 /Überschriften/Überschriften 3/A-E/E/Einstellung der Zuführposition @ 55\mod_1292496600692_78.docx @ 520341 @ 3 @ 1 14.18.3 Setting of the Feed Position Pos: 49.136 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Zuführposition einstellen CF/CV @ 74\mod_1308830963595_78.docx @ 658429 @ @ 1 RPM00014_1 Fig. 224 An optimum adjustment of the feed position has been reached when the feeder plate (3) of the net has moved out just far enough that there is still a small gap between the feeder plate (3) and the conveyor roller (4).
Page 262: Setting Of The Tying Position
Selecting the Number of Net Winds Pos: 49.141 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netzumwicklungen wählen F/V @ 81\mod_1315918916295_78.docx @ 710214 @ @ 1 The number of net winds is set at the operation control. KRONE Operation Terminal Alpha (Medium Electronic System) COM00325 Fig. 226 Switching on •...
Page 263 1700 1800 KRONE operation terminal Beta/ Krone ISOBUS-Terminal CCI 100 (comfort electronic) In Comfort electronics, the default bale size and the number of net winds are used to automatically determine the net length. Pos: 49.142 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 264: Bale Counter
14.19 Bale counter Pos: 49.144 /BA/Bedienung /Rundballenpresse/Ballenzähler @ 81\mod_1315921816720_78.docx @ 710584 @ @ 1 On equipment with KRONE operator terminal Alpha (Medium electronic system) RPN00019 Fig. 227 The bale counter (1) is attached to the left-hand side of the machine behind the front side plates.
Page 265: Tighten The Floor Conveyor And Set The Spring Pretensioning
Operation Pos: 49.146 /Überschriften/Überschriften 2/P-T/Rollboden spannen und Federvorspannung einstellen @ 79\mod_1314690152708_78.docx @ 697584 @ 2 @ 1 14.20 Tighten the floor conveyor and set the spring pretensioning Pos: 49.147 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F125 (XC) @ 262\mod_1399898256615_0.docx @ 2000262 @ @ 1 Comprima F125 (XC) Pos: 49.148 /BA/Bedienung /Rundballenpresse/Spannen des Rollbodens (COMPRIMA F125) @ 79\mod_1314628031949_78.docx @ 697293 @ @ 1 COM00323...
Page 266 Operation Pos: 49.150 /BA/Bedienung /Rundballenpresse/Spannrolle versetzen @ 79\mod_1314691243884_78.docx @ 697813 @ @ 1 COM00322 Fig. 229 If the floor conveyor can’t be tightened enough as described in the manner above or the floor conveyer tension diminishes, additional tension path can be created by moving the deflection pulley.
Page 267 Operation Pos: 49.152 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F155 (XC) @ 79\mod_1314690325737_78.docx @ 697640 @ @ 1 Comprima F155 (XC) Pos: 49.153 /BA/Bedienung /Rundballenpresse/Spannen des Rollbodens (COMPRIMA F155) @ 79\mod_1314690382940_78.docx @ 697698 @ @ 1 COM00324 Fig. 230 Note Dimension "d" from the inside of one eyelet to the next is 440 mm and must not be changed. Pos: 49.154 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 268: Adjusting Soft Core
Operation Pos: 49.155 /Überschriften/Überschriften 2/U-Z/Weichkern anpassen @ 58\mod_1297169012752_78.docx @ 555503 @ 2 @ 1 14.21 Adjusting Soft Core Pos: 49.156 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 49.157 /BA/Bedienung /Rundballenpresse/Bild Seil mit Karabiner @ 81\mod_1315982624201_78.docx @ 712061 @ @ 1 VPN00011 Fig.
Page 269 Operation Pos: 49.163 /BA/Bedienung /Rundballenpresse/Bild Positionen Weichkern @ 290\mod_1410271478654_78.docx @ 2288411 @ @ 1 The following positions can be set to alter the strength of the bale inner core: VPN00012_2 VPN00012_3 VPN00012_1 Fig. 233 Pos: 49.164 /BA/Bedienung /Rundballenpresse/Hinweis Position II Weichkern @ 290\mod_1410272109628_78.docx @ 2288442 @ @ 1 Position II is recommended for baling as the machine runs at its quietest in this position and the bale start procedure is simpler.
Page 270: Removing The Crop Blockages In The Crop Collection Area
Operation Pos: 49.170.1 /Überschriften/Überschriften 2/A-E/Erntegutblockaden im Bereich der Gutaufnahme entfernen @ 181\mod_1377084620194_78.docx @ 1554595 @ 2 @ 1 14.22 Removing the Crop Blockages in the Crop Collection Area Pos: 49.170.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Warnung - Unkontrollierte Bewegung der Maschine @ 196\mod_1384152827408_78.docx @ 1658910 @ @ 1 WARNING! –...
Page 271 Operation Pos: 49.170.11.1 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Förderrotor @ 194\mod_1383288777404_78.docx @ 1647840 @ @ 1 Feed rotor Pos: 49.170.11.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Erntegutblockade_Schneid-/Förderrotor_1 Zapfwelle aus, Rückwärts, Pick-up hoch @ 194\mod_1383569094775_78.docx @ 1650483 @ @ 1 • Turn off the PTO shaft. • Drive backwards. •...
Page 272 Operation Pos: 49.170.13.1 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Schneidrotor @ 194\mod_1383288753128_78.docx @ 1647812 @ @ 1 Cutting rotor Pos: 49.170.13.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Erntegutblockade_Schneid-/Förderrotor_1 Zapfwelle aus, Rückwärts, Pick-up hoch @ 194\mod_1383569094775_78.docx @ 1650483 @ @ 1 • Turn off the PTO shaft. • Drive backwards. •...
Page 273 Operation Pos: 49.170.13.18 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Wenn die Blockade dadurch nicht beseitigt ist: @ 194\mod_1383555273315_78.docx @ 1649635 @ @ 1 If the blockage is not removed due to this: Pos: 49.170.13.19 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Motor starten @ 198\mod_1384755866793_78.docx @ 1669545 @ @ 1 •...
Page 274: Crop Blockage At Pick-Up
Operation Pos: 49.170.15 /Überschriften/Überschriften 3/A-E/E/Erntegutblockade an der Pick-up @ 193\mod_1383214911049_78.docx @ 1646507 @ 3 @ 1 14.22.2 Crop blockage at pick-up Pos: 49.170.16.1 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Um das angestaute Erntegut zu beseitigen, wie folgt vorgehen: @ 193\mod_1383231662173_78.docx @ 1647045 @ @ 1 Proceed as follows to remove the accumulated crop: Pos: 49.170.16.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/a) Bei Erntegutansammlung an der rechten/linken Ecke der Pick-up @ 194\mod_1383287252016_78.docx @ 1647635 @ @ 1 a) If crop accumulates on the right/left edge of the pick-up...
Page 275: Reversing
Operation Pos: 49.172.1 /Überschriften/Überschriften 2/P-T/Reversieren (Ausführung mit Förderrotor) @ 194\mod_1383557494325_78.docx @ 1649783 @ 2 @ 1 14.23 Reversing Pos: 49.172.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Förderrotor ab Baujahr 2013 @ 212\mod_1389717240730_78.docx @ 1740986 @ @ 1 (feed rotor produced from 2013 onwards) Pos: 49.172.3 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Warnung - Unkontrollierte Bewegung der Maschine @ 196\mod_1384152827408_78.docx @ 1658910 @ @ 1 WARNING! –...
Page 276 Operation Pos: 49.172.9 /BA/Bedienung /Rundballenpresse/Reversieren/b) Bei Ausführung mit hydraulischer Reversiereinrichtung @ 194\mod_1383558077702_78.docx @ 1649839 @ @ 1 b) For version with hydraulic reversing device Pos: 49.172.10 /BA/Bedienung /Rundballenpresse/Reversieren/Hydraulisch reversieren - Vorgehensweise @ 181\mod_1377095013720_78.docx @ 1555305 @ @ 1 • Turn off the PTO shaft. •...
Page 277: Settings
Settings Pos: 51.1 /Überschriften/Überschriften 1/A-E/Einstellungen @ 0\mod_1199868783862_78.docx @ 36141 @ 2 @ 1 Settings Pos: 51.2 /BA/Sicherheit/Großpackenpressen/Gefahr - Wartungs-, Montage-, Reparatur- und Einstellarbeiten an der Bindung @ 20\mod_1239002475628_78.docx @ 225581 @ @ 1 DANGER! - Maintenance, assembly, repair and adjustment work Effect: Danger to life, injuries or damage to the machine.
Page 278: Setting The Net Brake
Settings Pos: 51.4 /Überschriften/Überschriften 2/K-O/Netzbremse einstellen @ 138\mod_1354097997707_78.docx @ 1227354 @ 2 @ 1 15.1 Setting the Net Brake Pos: 51.5 /WHB/Grundeinstellungen/Rundballenpresse/Einstellung der Netzbremse @ 214\mod_1390461816289_78.docx @ 1756205 @ @ 1 HDC00072 Fig. 240 • Set dimension "a" to 35 mm on the eyebolt (1) and tighten the self-locking nut. Pos: 51.6 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 279: Releasing The Net Brake
Settings Pos: 51.7 /Überschriften/Überschriften 2/K-O/Netzbremse lösen @ 138\mod_1354179479459_78.docx @ 1230660 @ 3 @ 1 15.1.1 Releasing the Net Brake Pos: 51.8 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netzbremse lösen CF/CV @ 137\mod_1353503167368_78.docx @ 1218681 @ @ 1 Note When the brake moves down into the feed position, it should be easy to release the brake to remove the net.
Page 280: Central Chain Lubrication System
Settings Pos: 51.10 /Überschriften/Überschriften 2/U-Z/Zentrale Kettenschmierung @ 33\mod_1254819776816_78.docx @ 319945 @ 3 @ 1 15.2 Central chain lubrication system Pos: 51.11 /BA/Einstellungen/Rundballenpresse/Zentrale Kettenschmierung @ 33\mod_1254819918129_78.docx @ 319966 @ @ 1 RBV05150 Fig. 242 The central chain lubrication system is attached to the left-hand side of the machine behind the front guard.
Page 281 Settings Pos: 51.13 /BA/Einstellungen/Rundballenpresse/Zentrale Kettenschmierung Öl prüfen @ 234\mod_1394008657190_78.docx @ 1860613 @ @ 1 RP100007_2 Fig. 244 Depending on consumption, check the oil supply in the container and top off if necessary. If the lubricant container is empty, the central chain lubrication system needs to be bled: •...
Page 282 Settings Pos: 51.15 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F125/F155 (XC) @ 80\mod_1315900077159_78.docx @ 708231 @ @ 1 Comprima F125/F155 (XC) Pos: 51.16 /BA/Einstellungen/Rundballenpresse/Schaubild zentrale Kettenschmierung CF155XC @ 74\mod_1309173160561_78.docx @ 659443 @ @ 1 RPN00047_2 Fig. 245 Starter roller Spur wheel Cutting system drive Pick-up drive Pick-up Net roller...
Page 283 Settings Pos: 51.18 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 51.19 /BA/Einstellungen/Rundballenpresse/Schaubild zentrale Kettenschmierung CV 150/210 @ 59\mod_1297676781655_78.docx @ 559321 @ @ 1 RPN00048_2 Fig. 246 Rear floor conveyor drive Starter roller Spur wheel Cutting system drive Pick-up drive...
Page 284: Maintenance
Effect: Danger to life, serious injuries or loss of warranty claims as well as exclusion of liability • Use only authentic KRONE spare parts and accessories authorised by the manufacturer. The use of spare parts, accessories or additional equipment not manufactured, tested or approved by KRONE will exclude any liability for consequential damage.
Page 285: Overview
Maintenance Pos: 53.7 /Überschriften/Überschriften 2/U-Z/Übersicht @ 53\mod_1289900374656_78.docx @ 506510 @ 2 @ 1 16.3 Overview Pos: 53.8 /BA/Wartung/Rundballenpresse/Tabelle Wartungsarbeiten CF/CV @ 75\mod_1309354037097_78.docx @ 662609 @ @ 1 Maintenance interval Machine part Wheels, wheel nuts after the first 8 operating hours and every time after a wheel is changed PTO shaft friction clutch after longer downtimes...
Page 286: Setting Of The Scraper Rail To The Upper Spiral Roller
Maintenance Pos: 53.11 /Überschriften/Überschriften 2/A-E/Einstellung der Abstreifschiene zur oberen Spiralwalze @ 75\mod_1309422205904_78.docx @ 662923 @ 2 @ 1 16.4 Setting of the Scraper Rail to the Upper Spiral Roller Pos: 53.12 /BA/Bedienung /Rundballenpresse/Heckklappe öffnen @ 59\mod_1297675801136_78.docx @ 559288 @ @ 1 •...
Page 287 Maintenance Pos: 53.16 /BA/Wartung/Rundballenpresse/Einstellung Abstreifschiene CF/CV @ 75\mod_1309345335707_78.docx @ 662191 @ @ 1 Fig. 248 • Install the scraper bar (4) so it is centred in the oblong hole of the side part and slightly tighten the screws. • Drive the clamping wedge (5) tightly into place and tighten the screws securely. •...
Page 288: Setting Tailgate Lock
Maintenance Pos: 53.18 /BA/Wartung/Rundballenpresse/Einstellung Heckklappenverschluss Comprima @ 101\mod_1330595313576_78.docx @ 896387 @ 2 @ 1 16.5 Setting Tailgate Lock Comprima V Comprima F HDC00030 Fig.249 The spring pretensioning on the tailgate lock must be a = 340 mm (Measure: eye inside-inside). Retighten spring (1) if necessary: •...
Page 289: Sensors
Maintenance Pos: 53.20 /Überschriften/Überschriften 2/P-T/Sensoren @ 9\mod_1219743478068_78.docx @ 121498 @ 2 @ 1 16.6 Sensors Pos: 53.21 /Überschriften/Überschriften 3/K-O/Lage der Sensoren @ 236\mod_1394523625971_78.docx @ 1873537 @ 3 @ 1 16.6.1 Position of the Sensors Pos: 53.22 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F125/F155 (XC) @ 80\mod_1315900077159_78.docx @ 708231 @ @ 1 Comprima F125/F155 (XC) Pos: 53.23 /Überschriften/rechte Maschinenseite @ 60\mod_1297935179130_78.docx @ 562741 @ @ 1 Right-hand Side of the Machine...
Page 290 Maintenance Comprima F125/F155 (XC) Pos: 53.28 /Überschriften/linke Maschinenseite @ 60\mod_1297934981687_78.docx @ 562715 @ @ 1 Left-hand Side of the Machine Pos: 53.29 /BA/Wartung/Rundballenpresse/Bild Lage Sensoren links Comprima F @ 208\mod_1386850861675_78.docx @ 1718528 @ @ 1 RPN00052_2 Fig. 251 Pos: 53.30 /BA/Wartung/Rundballenpresse/Lage Sensoren links Comprima F @ 176\mod_1372937546024_78.docx @ 1507881 @ @ 1 Pos.
Page 291 Maintenance Pos: 53.32 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 53.33 /Überschriften/rechte Maschinenseite @ 60\mod_1297935179130_78.docx @ 562741 @ @ 1 Right-hand Side of the Machine Pos: 53.34 /BA/Wartung/Rundballenpresse/Bild Lage Sensoren rechts Comprima V @ 84\mod_1318488832926_78.docx @ 735293 @ @ 1 RPN00069 Fig.
Page 292 Maintenance Pos: 53.37 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 53.38 /Überschriften/linke Maschinenseite @ 60\mod_1297934981687_78.docx @ 562715 @ @ 1 Left-hand Side of the Machine Pos: 53.39 /BA/Wartung/Rundballenpresse/Bild Lage Sensoren links Comprima V @ 84\mod_1318490696091_78.docx @ 735377 @ @ 1 RPN00070 Fig.
Page 293: Adjusting The Sensors
Maintenance Pos: 53.42 /Überschriften/Überschriften 3/A-E/E/Einstellung der Sensoren @ 0\mod_1199962173428_78.docx @ 37635 @ 3 @ 1 16.6.2 Adjusting the Sensors Pos: 53.43 /BA/Wartung/Sensoren/Namursensor d = 12 mm @ 0\mod_1199962247038_78.docx @ 37654 @ 4 @ 1 16.6.2.1 Namur sensor d = 12 mm BP-VFS-088-1 Figure 254 The dimension between the encoder (2) and the sensor (1) must be "a"...
Page 294: Sensor Position Cutter Base (B8)
Maintenance 16.6.2.3 Sensor Position Cutter base (B8) COM00022 Fig. 256 CAUTION! Damages to the machine. • When setting the sensor (1) for the position of the cutter base, the cutter drawer (2) must rest closely against the cutting system housing (3). Therefore, existent soiling in this area needs to be removed before the setting.
Page 295: Checking And Setting Axial Play Of The Net Brake
Maintenance Pos: 53.47 /BA/Wartung/Sensoren/Axiales Spiel Netzbremse einstellen @ 137\mod_1353596062832_78.docx @ 1221378 @ 3 @ 1 16.6.3 Checking and Setting Axial Play of the Net Brake CAUTION! Damage to sensor B2 • Before setting the sensor B2 (net runs), the axial play of the net brake must be checked and set, if necessary.
Page 296: Tightening Torques
Maintenance Pos: 53.49 /Überschriften/Überschriften 2/A-E/Anzugsdrehmomente @ 45\mod_1277103093968_78.docx @ 410970 @ 2 @ 1 16.7 Tightening Torques Pos: 53.50 /BA/Wartung/Drehmomente / Anzugsmomente/Drehmomente @ 45\mod_1277102920578_78.docx @ 410945 @ @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the (unless otherwise indicated).
Page 297: Tightening Torques (Countersunk Screws)
Maintenance Pos: 53.53 /Überschriften/Überschriften 2/A-E/Anzugsdrehmomente über Innensechskant @ 45\mod_1277106415765_78.docx @ 411230 @ 2 @ 1 16.8 Tightening Torques (Countersunk Screws) Pos: 53.54 /BA/Wartung/Drehmomente / Anzugsmomente/Drehmomente über Innensechskant @ 45\mod_1277106232328_78.docx @ 411205 @ @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the (unless otherwise indicated).
Page 298: Brakes
Maintenance Pos: 53.57 /Überschriften/Überschriften 2/A-E/Bremsen @ 0\mod_1197278385463_78.docx @ 16886 @ 2 @ 1 16.9 Brakes Pos: 53.58 /BA/Wartung/Rundballenpresse/Bremseneinstellung prüfen @ 34\mod_1255605786361_78.docx @ 324931 @ 3 @ 1 16.9.1 Checking the brake setting Natural wear of the brake drum and brake pad makes it necessary to readjust the wheel brakes frequently to maintain the full stroke of the brake cylinder.
Page 299: Settings Of The Brakes With Manual Linkage Setter
Maintenance Pos: 53.61 /BA/Wartung/Rundballenpresse/Einstellung der Bremse mit manuellem Gestängesteller @ 84\mod_1319005962395_78.docx @ 736309 @ 3 @ 1 16.9.3 Settings of the Brakes with Manual Linkage Setter COM00336 Fig. 261 Natural wear of brake drum and brake pad sometimes makes a readjustment of the wheel brakes necessary to preserve the stroke of the brake cylinder as completely as possible.
Page 300: Tandem Axle
Maintenance The setting is made on the readjustment hexagon (2) (hexagonal head screw W/F 19 mm) of the linkage setter (1): Turn adjusting screw to the right until the brake shoes fit tightly against the brake drum. Turn adjusting screw to the left until the idle stroke is approx.
Page 301 Maintenance Pos: 53.65 /BA/Wartung/Rundballenpresse/Bild Tandemachse CF/CV @ 75\mod_1309355596355_78.docx @ 662637 @ @ 1 Fig. 262 Pos: 53.66 /BA/Wartung/Rundballenpresse/Einstellung Tandemachse CF/CV @ 75\mod_1309355773506_78.docx @ 662669 @ @ 1 Note The brake activation has been adjusted in the factory. The brake must be readjusted: •...
Page 302 Maintenance Readjusting Brake Linkage Note Each time before the brake linkage (2a, 2b) is readjusted, the thickness of the lining on the brake shoes must be checked. The thickness of the lining must still be at least 2 mm. 1. Disconnect the brake linkage (2b) from the brake lever (4) 2.
Page 303: Tyres
If tyres are not correctly fitted, it could explode when pumped up. This can cause serious injury. If you do not have sufficient experience of fitting tyres, have tyres fitted by the KRONE dealer or a qualified tyre specialist. •...
Page 304: Checking And Maintaining Tyres
Maintenance Pos: 53.68.4 /Überschriften/Überschriften 3/P-T/Reifen prüfen und pflegen @ 0\mod_1197358037214_78.docx @ 18094 @ 3 @ 1 16.11.1 Checking and maintaining tyres Pos: 53.68.5 /BA/Wartung/Reifen/Reihenfolge Bild 6-Loch @ 4\mod_1213086131413_78.docx @ 86197 @ @ 1 KS-0-034 Fig. 263 Pos: 53.68.6 /BA/Wartung/Reifen/Reihenfolge Reifenmontage Text @ 4\mod_1213085759054_78.docx @ 86177 @ @ 1 When loosening and tightening the wheel nuts, observe the order indicated in the illustration.
Page 305: Tyre Air Pressure
Maintenance Pos: 53.68.9 /BA/Wartung/Reifen/Reifen-Luftdruck allgemein @ 0\mod_1199956852616_78.docx @ 37365 @ 3 @ 1 16.11.2 Tyre air pressure Check the tyre pressure at regular intervals and refill if necessary. The tyre pressure depends on the size of the tyres. The values are listed in the table. Pos: 53.68.10 /BA/Wartung/Reifen/Rundballenpresse/Reifen-Luftdruck Tabelle Comprima F/V @ 84\mod_1318492286342_78.docx @ 735493 @ @ 1 Tyre Designation Minimum...
Page 306: Hitches On The Drawbar
Maintenance Pos: 53.70 /BA/Wartung/Rundballenpresse/Deichsel CF/CV @ 245\mod_1395843200211_78.docx @ 1912690 @ @ 1 RPN00049 Fig. 264 • Tighten screws after 10 operating hours • Check screws every 50 operating hours Pos: 53.71 /Überschriften/Überschriften 3/U-Z/Zugösen an der Deichsel @ 236\mod_1394528187810_78.docx @ 1873833 @ 3 @ 1 16.11.3 Hitches on the Drawbar Pos: 53.72 /BA/Wartung/Zugösen/Zugösen a=43 an der Deichsel @ 236\mod_1394528163742_78.docx @ 1873804 @ @ 1...
Page 307: Oil Level Check And Oil Change On The Gearboxes
Maintenance Pos: 53.74 /Überschriften/Überschriften 2/K-O/Ölstandskontrolle und Ölwechsel an den Getrieben @ 75\mod_1309423338331_78.docx @ 663068 @ 2 @ 1 16.12 Oil Level Check and Oil Change on the Gearboxes Pos: 53.75 /BA/Wartung/Hinweis Ölsorte nicht mischen. @ 10\mod_1222334992520_78.docx @ 140501 @ @ 1 Note! - Do not mix different types of oil.
Page 308: Main Drive
Maintenance Pos: 53.79 /Überschriften/Überschriften 3/F-J/Hauptantrieb @ 20\mod_1238751529465_78.docx @ 225070 @ 3 @ 1 16.12.2 Main drive Pos: 53.80 /BA/Wartung/Rundballenpresse/Bild Hauptantriebe F/V @ 84\mod_1318493589685_78.docx @ 735517 @ @ 1 RPN00050 Fig. 266 Pos: 53.81 /BA/Wartung/Hinweis - Ölstandskontrolle und Ölwechsel bei waagerechter Stellung der Maschine vornehmen @ 12\mod_1224746945841_78.docx @ 153501 @ @ 1 Note Perform oil level check and change the oil while the machine is in a horizontal position! Pos: 53.82 /BA/Wartung/Ölkontrolle_Wechsel/Ölkontrolle_ALT/Ölkontrolle Kontrollschraube (3) @ 84\mod_1318494665586_78.docx @ 735606 @ @ 1...
Page 309: Screw Connections At The Front And Rear Of The Floor Conveyors
Maintenance Pos: 53.88 /BA/Wartung/Rundballenpresse/Schraubverbindung an den Rollböden vorn/hinten @ 295\mod_1412244192171_78.docx @ 2321509 @ 2 @ 1 16.13 Screw connections at the front and rear of the floor conveyors COM00363 Fig. 267 • Set the torque wrench to 40 Nm. • Tighten the nuts on the screw connection (1).
Page 310 Maintenance Pos: 53.90 /BA/Wartung/Rundballenpresse/Stückzahl Schraubverbindung an den Rollböden F/V @ 295\mod_1412231611089_78.docx @ 2320791 @ @ 1 To change all screws on the floor conveyor of the machine, the following unit numbers are required: Designation Material number Comprima Comprima V150XC F125XC Front floor Rear floor Total...
Page 311: Novo Grip Belt On The Floor Conveyor
Maintenance Pos: 53.94 /BA/Wartung/Rundballenpresse/Novo Grip @ 216\mod_1390828279663_78.docx @ 1762682 @ 2 @ 1 16.14 Novo Grip belt on the floor conveyor The Novo Grip belts consist of a composite material (rubber and tissue). Under load, franges come into being on the cutting edges. They must be removed regularly. •...
Page 312: Checks And Maintenance On Rear Floor Conveyor
Maintenance Pos: 53.98.1 /Überschriften/Überschriften 2/P-T/Prüfung und Wartung am hinteren Rollboden @ 215\mod_1390811883572_78.docx @ 1761006 @ 2 @ 1 16.16 Checks and maintenance on rear floor conveyor Pos: 53.98.2 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150(XC)/V180(XC)/V210(XC) @ 140\mod_1355302602832_0.docx @ 1248319 @ @ 1 Comprima V 150 (XC) / V180 (XC) / V 210 (XC) Pos: 53.98.3 /BA/Wartung/Rundballenpresse/Umlenkrolle versetzen/Hinweis: Prüfung nach ca.
Page 313: Adjusting The Deflection Roller
Maintenance Pos: 53.98.7 /Überschriften/Überschriften 3/U-Z/Umlenkrolle versetzen @ 218\mod_1390928585702_78.docx @ 1769495 @ 3 @ 1 16.16.1 Adjusting the deflection roller Pos: 53.98.8 /BA/Wartung/Rundballenpresse/Umlenkrolle versetzen/Umlenkrolle versetzen_Voraussetzungen @ 215\mod_1390811158175_78.docx @ 1760609 @ @ 1 Prerequisites – The left side protector is raised. – The left plastic protector is detached.
Page 314: Drive Chains
Maintenance Pos: 53.100 /Überschriften/Überschriften 2/A-E/Antriebsketten @ 27\mod_1246355234599_78.docx @ 267399 @ 2 @ 1 16.17 Drive chains Pos: 53.101 /BA/Sicherheit/7. Gefahrenhinweise alt/Warnung - Einzugsgefahr der Antriebsketten @ 34\mod_1256045314627_78.docx @ 325616 @ @ 1 WARNING! – Danger of entanglement in the drive chains! Effect: Risk of injury caused by entanglement of loose long hair or loose clothing.
Page 315: Rear Floor Conveyor Drive
Maintenance Pos: 53.108 /Überschriften/Überschriften 4/F-J/Hinterer Rollbodenantrieb @ 60\mod_1297685432944_78.docx @ 559692 @ 4 @ 1 16.17.1.2 Rear Floor Conveyor Drive Pos: 53.109 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 53.110 /BA/Wartung/Rundballenpresse/Spannen Ketten hinterer Rollbodenantrieb V150-210 @ 84\mod_1318942081811_78.docx @ 736221 @ @ 1 RPN00071_1 Fig.
Page 316: Pick-Up
Maintenance Pos: 53.112 /Überschriften/Überschriften 4/P-T/Pick-up @ 75\mod_1309440962543_78.docx @ 663572 @ 4 @ 1 16.17.1.3 Pick-up Pos: 53.113 /BA/Sicherheit/7. Gefahrenhinweise alt/Warnung - Quetschgefahr Pick-up @ 34\mod_1256048391518_78.docx @ 325820 @ @ 1 WARNING! – Crush hazard! Effect: Foot injuries. • Lower pick-up to the ground. Pos: 53.114 /BA/Wartung/Rundballenpresse/Spannen Ketten Pick-up CF/CV @ 75\mod_1309440866033_78.docx @ 663540 @ @ 1 RPN00056_1 Fig.
Page 317 Maintenance VPN00617 VPN00618 Fig. 275 Note After repairing the main drive (1), ensure during installation that the disc springs (2) are arranged as shown in Fig. VPN00618. Pos: 53.117 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 318: Conveyor Auger Drive
Maintenance Pos: 53.118 /Überschriften/Überschriften 4/F-J/Förderschneckenantrieb @ 75\mod_1309442602928_78.docx @ 663600 @ 4 @ 1 16.17.1.4 Conveyor Auger Drive Pos: 53.119 /BA/Wartung/Rundballenpresse/Spannen Ketten Förderschnecke CF/CV @ 75\mod_1309442690939_78.docx @ 663624 @ @ 1 RPN00057_1 Fig. 276 The auger conveyor drive (1) is located on the pick-up on the left-hand side of the machine. The drive chain is tensioned by the clamping element (2).
Page 319: Hydraulics
Risk of injury as a result of incorrect handling of liquids under high pressure. Effect: Escaping high-pressure liquids can penetrate the skin and cause serious injury. Repair work on the hydraulic system may only be performed by authorised KRONE professional workshops.
Page 320: Shut-Off Valve For Tailgate
Maintenance Pos: 53.128 /BA/Wartung/Großpackenpressen/Hydraulikanlage / Bordhydraulik/Hinweis zu Hydraulikarbeiten @ 24\mod_1241518053726_78.docx @ 245734 @ @ 1 Note • When working on the hydraulic system, absolute cleanliness is essential • Check the hydraulic oil level each time before placing the machine in operation •...
Page 321: Electromagnetic Valves
Maintenance Pos: 53.133 /Überschriften/Überschriften 3/A-E/E/Elektromagnetventile @ 76\mod_1309953878084_78.docx @ 665615 @ 3 @ 1 16.18.2 Electromagnetic Valves Pos: 53.134 /BA/Wartung/Rundballenpresse/Bild Elektromagnetventil CF/CV @ 76\mod_1309946039177_78.docx @ 665307 @ @ 1 RPN00101 Fig. 279 Pos: 53.135 /BA/Wartung/Rundballenpresse/Elektromagnetventil CF/CV @ 76\mod_1309946503643_78.docx @ 665335 @ @ 1 The electromagnetic valves (2) are located on the left-hand side of the machine behind the guard.
Page 322: Replacing The Hydraulic Oil Filter
Maintenance Pos: 53.137 /Überschriften/Überschriften 3/F-J/Hydraulikölfilter wechseln @ 34\mod_1255587384500_78.docx @ 324072 @ 3 @ 1 16.18.3 Replacing the Hydraulic Oil Filter Pos: 53.138 /BA/Wartung/Umwelt/Hinweis Entsorgen / Lagern von Öle und Ölfilter Umwelt @ 32\mod_1253101375171_78.docx @ 311770 @ @ 1 ENVIRONMENT! - Disposal and storage of used lubricants and oil filters Effect: Environmental damage Store or dispose used oil and oil filters according to statutory provisions.
Page 323 Maintenance Replacing the filter element Note Store or dispose used oil and oil filters according to statutory provisions. • Relieve all pressure from the hydraulic system. • Screw the bottom of the filter (4) off the filter head piece (1) and clean it. •...
Page 324: Hydraulic Circuit Diagram
Maintenance Pos: 53.142 /Überschriften/Überschriften 3/F-J/Hydraulikschaltplan @ 21\mod_1239190146695_78.docx @ 231350 @ 3 @ 1 16.18.4 Hydraulic circuit diagram Pos: 53.143 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F125/F155 (XC) @ 80\mod_1315900077159_78.docx @ 708231 @ @ 1 Comprima F125/F155 (XC) Pos: 53.144 /BA/Wartung/Rundballenpresse/Hydraulikschaltplan F @ 84\mod_1319009588819_78.docx @ 736337 @ @ 1 Fig.
Page 325 Maintenance Pos: 53.146 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 53.147 /BA/Wartung/Rundballenpresse/Hydraulikschaltplan V150/180 @ 146\mod_1360154425413_78.docx @ 1308279 @ @ 1 – Fig. 282 tractor tailgate pick-up hydr. lower cutter tray clamping arm front clamping arm rear Pos: 53.148 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 326: Grinding Blades
(1). Grind only the ungrooved side. When grinding, make certain no notches are made in area (3). Note If at all possible, use the KRONE grinding mechanism for grinding. The Part No. for the blade holder for the KRONE blade grinding tool is 940 003-0.
Page 327: Maintenance - Brake System (Special Equipment)
Only a machine with an intact brake system may be used for work in the field or for travelling on roads. • No changes may be made to the brake system without the approval of KRONE. • KRONE is not responsible for natural wear, defects caused by overload or changes made to the brake system.
Page 328: Coupling Heads (Non-Interchangeable)
Maintenance Pos: 53.151.6 /Überschriften/Überschriften 3/K-O/Kupplungsköpfe @ 34\mod_1255596655016_78.docx @ 324497 @ 3 @ 1 16.20.1 Coupling heads (non-interchangeable) Pos: 53.151.7 /BA/Wartung/Bremsanlage/Kupplungsköpfe Bild VP @ 34\mod_1255596792281_78.docx @ 324548 @ @ 1 RP-A-031 RP-A-032 "RESERVOIR" coupling head (colour red) "BRAKE" coupling head (colour yellow) Fig.
Page 329: Air Filter For Pipelines
Maintenance Pos: 53.151.10 /Überschriften/Überschriften 3/K-O/Luftfilter für Rohrleitungen @ 34\mod_1255595485391_78.docx @ 324472 @ 3 @ 1 16.20.2 Air filter for pipelines Pos: 53.151.11 /BA/Wartung/Bremsanlage/Luftfilter/Luftfilter für Rohrleitung Bild CF/CV @ 76\mod_1310027669344_78.docx @ 666250 @ @ 1 CP102200 Fig. 285 Pos: 53.151.12 /BA/Wartung/Bremsanlage/Luftfilter/Luftfilter für Rohrleitung Aufzählung @ 6\mod_1214888028238_78.docx @ 96691 @ @ 1 (1) Spring (4) Spring (7) Clasp locking ring...
Page 330: Compressed-Air Reservoir
Maintenance Pos: 53.151.18 /Überschriften/Überschriften 3/A-E/D/Druckluftbehälter @ 34\mod_1255593348281_78.docx @ 324372 @ 3 @ 1 16.20.3 Compressed-air reservoir Pos: 53.151.19 /BA/Wartung/Druckluftbehälter/Druckluftbehälter Bild CF/CV @ 76\mod_1310031671148_78.docx @ 666415 @ @ 1 CP102170 Fig. 286 Pos: 53.151.20 /BA/Wartung/Druckluftbehälter/Druckluftbehälter_Text_mit Pos @ 76\mod_1310032535881_78.docx @ 666447 @ @ 1 The compressed air reservoir (1) stores the compressed air that is pumped by the compressor.
Page 331: Maintenance - Lubrication
Maintenance – lubrication Pos: 53.153.1 /Überschriften/Überschriften 1/U-Z/Wartung - Schmierung @ 24\mod_1241675457008_78.docx @ 247325 @ 1 @ 1 Maintenance – lubrication Pos: 53.153.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 2 @ 1 17.1 Special Safety Instructions Pos: 53.153.3 /BA/Sicherheit/Rundballenpresse/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarbeiten Schmierung @ 240\mod_1395126884169_78.docx @ 1888819 @ @ 1 Danger! - Maintenance, installation, repair and adjustment work, troubleshooting and fault resolution Effect: Risk of death, injuries or damage to the machine.
Page 332: Lubricants
Maintenance – lubrication Pos: 53.153.7 /Überschriften/Überschriften 2/P-T/Schmierfette / Schmieröle @ 24\mod_1241676102945_78.docx @ 247353 @ 2 @ 1 17.2 Lubricants Pos: 53.153.8 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Allgemeines unterschiedliche Schmiersysteme @ 24\mod_1241676457180_78.docx @ 247436 @ 2 @ 1 17.3 General aspects Depending on the design, the machine may be equipped with different lubrication systems. Soft, supple NLGI Class 2 lithium soap greases in accordance with DIN 51825 should be used as lubricating greases.
Page 333: Lubricating The Pto Shaft
Maintenance – lubrication Pos: 53.153.12 /Überschriften/Überschriften 2/A-E/Abschmieren der Gelenkwelle @ 0\mod_1197359496183_78.docx @ 18251 @ 2 @ 1 17.4 Lubricating the PTO shaft Pos: 53.153.13 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Bild Gelenkwelle VP @ 35\mod_1256132667597_78.docx @ 326692 @ @ 1 Fig. 287 Pos: 53.153.14 /BA/Wartung/Gelenkwelle schmieren/Abschmieren Gelenkwelle Text @ 16\mod_1235638171674_78.docx @ 199556 @ @ 1 Lubricate the PTO shafts at the intervals indicated in the drawing with a multi-purpose grease.
Page 334: Walterscheid Cam-Type Clutch K64/12 To K64/24, Ek 64/22 To Ek64/24
Maintenance – lubrication Pos: 53.153.17.1 /Überschriften/Überschriften 2/U-Z/Walterscheid Nockenschaltkupplung K64/12 bis K64/24 und EK 64/22 bis 24 @ 294\mod_1411551224633_78.docx @ 2311498 @ 2 @ 1 17.5 WALTERSCHEID cam-type clutch K64/12 to K64/24, EK 64/22 to EK64/24 Pos: 53.153.17.2 /BA/Sicherheit/7. Gefahrenhinweise alt/_Zur Prüfung/ACHTUNG! – Arbeiten durch Fachwerkstatt ausführen @ 212\mod_1389781577868_78.docx @ 1741636 @ @ 1 CAUTION! If work has been performed by a specialist workshop that is not qualified, the machine may be damaged!
Page 335 Maintenance – lubrication Pos: 53.153.17.5 /BA/Wartung/Nockenschaltkupplung/Wartungsintervall: siehe Kapitel Wartung „Wartungstabelle“ @ 292\mod_1410960610206_78.docx @ 2299807 @ @ 1 Maintenance interval: refer to chapter Maintenance “Maintenance Table” Pos: 53.153.17.6 /BA/Wartung/Nockenschaltkupplung/Wartung - Nockenschaltkupplung Voraussetzung @ 291\mod_1410844087653_78.docx @ 2298027 @ @ 1 Prerequisite: – The machine is stopped and secured. –...
Page 336: Lubrication Points
Maintenance – lubrication Pos: 53.153.19 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Schmierstellen @ 24\mod_1241705838930_78.docx @ 248021 @ 2 @ 1 17.6 Lubrication points The following tables contain a list of lubrication points on the machine and the number of lubrication nipples. Pos: 53.153.20 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima F125/F155 (XC) @ 80\mod_1315900077159_78.docx @ 708231 @ @ 1 Comprima F125/F155 (XC) Pos: 53.153.21 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Bild und Tabelle Schmierplan Comprima F @ 84\mod_1319010941745_78.docx @ 736478 @ @ 1 F155 (XC)
Page 337 Maintenance – lubrication Pos: 53.153.23 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Comprima V150/V180/V210 (XC) @ 84\mod_1318488721897_78.docx @ 735265 @ @ 1 Comprima V150/V180/V210 (XC) Pos: 53.153.24 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Bild und Tabelle Schmierplan Comprima V @ 84\mod_1319016737739_78.docx @ 736534 @ @ 1 COM00008 Fig. 291 Lubrication Points Number of the Grease Nipples Parking jack...
Page 338: Lifting
Maintenance – lubrication Pos: 53.155 /Überschriften/Überschriften 2/A-E/Anheben @ 33\mod_1254380091415_78.docx @ 319041 @ 2 @ 1 17.7 Lifting Pos: 53.156 /BA/Wartung/Rundballenpresse/Anheben der Maschine CF/CV @ 75\mod_1309341187614_78.docx @ 662073 @ 33 @ 1 17.7.1 Lifting Eyes The machine is equipped with four suspension points: •...
Page 339: Placing In Storage
Placing in Storage Pos: 55.1 /Überschriften/Überschriften 1/A-E/Einlagerung @ 0\mod_1197385459120_78.docx @ 19966 @ 2 @ 1 Placing in Storage Pos: 55.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 2 @ 1 18.1 Special Safety Instructions Pos: 55.3 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine für Instandhaltungs-, Reparatur-, Wartungs- und Einstellarbeiten vorbereiten @ 272\mod_1403522290336_78.docx @ 2051115 @ @ 1 WARNING! Risk of injury during repair, maintenance and adjustment work on the machine.
Page 340: At The End Of The Harvest Season
Perform the necessary repair tasks during the time immediately after the harvest season. Draw up a list of all spare parts you will need. This will make it easier for your KRONE dealer to process your orders and you will be certain that your machine will be ready for use at the beginning of the next season.
Page 341: Before The Start Of The New Season
Placing in Storage Pos: 55.8 /Überschriften/Überschriften 2/U-Z/Vor Beginn der neuen Saison @ 0\mod_1197386024448_78.docx @ 20081 @ 3 @ 1 18.3 Before the Start of the New Season Pos: 55.9 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine für Instandhaltungs-, Reparatur-, Wartungs- und Einstellarbeiten vorbereiten @ 272\mod_1403522290336_78.docx @ 2051115 @ @ 1 WARNING! Risk of injury during repair, maintenance and adjustment work on the machine.
Page 342: Maintenance Work Before The Beginning Of The New Season
Placing in Storage Pos: 55.12 /Überschriften/Überschriften 3/U-Z/Wartungsarbeiten vor Beginn der neuen Saison @ 115\mod_1339075746437_78.docx @ 1009040 @ 3 @ 1 18.3.1 Maintenance work before the beginning of the new season Pos: 55.13 /BA/Einlagerung/Rundballenpressen/Bremsscheibe @ 35\mod_1256135763691_78.docx @ 326892 @ @ 1 Fig.
Page 343: Venting The Overload Coupling On The Pto Shaft
Placing in Storage Pos: 55.16 /BA/Einlagerung/Rundballenpressen/Überlastkupplung an Gelenkwelle Comprima @ 96\mod_1328790282568_78.docx @ 822224 @ 3 @ 1 18.3.2 Venting the overload coupling on the PTO shaft Friction clutch only COM00337 Fig. 294 Following extended downtimes, overload coupling surfaces (2) may stick to the contact surfaces.
Page 344: Malfunctions - Causes And Remedies
Malfunctions - Causes and Remedies Pos: 57.1 /Überschriften/Überschriften 1/P-T/Störungen - Ursachen und Behebung @ 0\mod_1200296925180_78.docx @ 39459 @ 1 @ 1 Malfunctions - Causes and Remedies Pos: 57.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 2 @ 1 19.1 Special Safety Instructions Pos: 57.3 /BA/Sicherheit/7.
Page 345: General Malfunctions
Malfunctions - Causes and Remedies Pos: 57.5 /Überschriften/Überschriften 2/A-E/Allgemeine Störungen @ 24\mod_1241775122213_78.docx @ 248807 @ 2 @ 1 19.2 General malfunctions Pos: 57.6 /BA/Störungen - Ursachen und Behebung/Rundballenpressen/Tabellarische Auflistung Allgemein F/V @ 290\mod_1410329551230_78.docx @ 2288925 @ @ 1 Fault Possible cause Remedy The pick-up cannot be Hydraulic hose not connected.
Page 346 Malfunctions - Causes and Remedies Fault Possible cause Remedy Net immediately tears off Blade bar is lowered immediately Remove impurities. again after starting or after starting. during wrapping. Roller brake is set with too much Check the brake device setting. force.
Page 347 Malfunctions - Causes and Remedies Fault Possible cause Remedy Net tears when reducing Spring for brake is too tight Readjust the spring for the brake on the the net diameter tension lever Floor conveyor is slack Very heavy grass with no If the floor conveyor is slipping, use fewer structure (e.g.
Page 348: Malfunctions On The Central Chain Lubrication System
• Clean nozzles Pos: 57.10 /Überschriften/Überschriften 2/F-J/Fehlermeldungen der KRONE Bedienterminals @ 77\mod_1310045429649_78.docx @ 667242 @ 2 @ 1 19.4 Error Messages of KRONE Operation Terminal Pos: 57.11 /BA/Störungen - Ursachen und Behebung/Rundballenpressen/Fehlermeldungen Display ISOBUS, Beta @ 235\mod_1394191586324_78.docx @ 1869861 @ @ 1 The error messages in the display are described depending on how the machine is fitted in the Chapters "KRONE ISOBUS-Terminal"...
Page 349: Disposal Of The Machine
Disposal of the machine Pos: 59 /Überschriften/Überschriften 1/A-E/Entsorgung der Maschine @ 274\mod_1404207309028_78.docx @ 2060455 @ 1 @ 1 Disposal of the machine Pos: 60 /BA/Entsorgung der Maschine/Die Maschine entsorgen @ 274\mod_1404207434449_78.docx @ 2060544 @ 2 @ 1 20.1 Disposal of the machine After the service life of the machine has expired, the individual components of the machine must be disposed of properly.
Page 350: Appendix
Appendix Pos: 62 /Überschriften/Überschriften 1/A-E/Anhang @ 1\mod_1202278612285_78.docx @ 58360 @ 1 @ 1 Appendix Pos: 63 /Überschriften/Überschriften 2/A-E/Elektroschaltplan @ 11\mod_1223544391539_78.docx @ 147914 @ 2 @ 1 21.1 Electrical circuit diagram === Ende der Liste für Textmarke Inhalt ===...
Page 362 Diagnostics - power supply voltages ....119 Baling Pressure Setting (Comprima F125 / F155 Diagnostics Auxiliary Functions (AUX) .... 183 Medium) or Bale Diameter (Comprima V150 / Differing functions to KRONE ISOBUS terminal V180) .............. 70 CCI ............... 190 Basic safety instructions ........21 Display .............
Page 363 Net Wrapping ........... 255 KRONE ISOBUS Terminal ....... 198 Note and messages ......... 127, 186 KRONE operation terminal Alpha ....... 65 Number of net winds ........152 KRONE Operation Terminal Alpha ..... 65 KRONE operation terminal Beta ....80, 195...
Page 364 O Safety Instructions and Accident Prevention Regulations ............ 22 Oil Level Check and Oil Change Intervals Safety Instructions on the Machine ....27 (Gearboxes) ..........307 Safety routines ........... 33 Oil Level Check and Oil Change on the Gearboxes ............ 307 Safety-conscious work practices .......
Page 365 Tying Start Delay ..........158 Tandem Axle ............. 300 Tyres ............25, 303 Technical data ............ 15 Technical Data Comprima F 125/ Comprima F U 125 XC ............15 Unauthorised Conversion/Modification and Spare Technical Data Comprima F 155/ Comprima F Parts Production ..........
Page 366 1 2 3 4 5 6 7 6 8 1 9 5 7 6 1 6 7 9 ! " # $ % " & ' ( ' ( $ " ) * * + , - "...

This manual is also suitable for:

Comprima f 125 xc Comprima f 155 Comprima f 155 xc Comprima v 150 Comprima v 150 xc Comprima v 180 ... Show all

Krone Comprima F 125 Original Operating Instructions

Quick Links

Related Manuals for Krone Comprima F 125

Summary of Contents for Krone Comprima F 125
