Page 1 Original operating instructions Document number: 150001157_04_en Version: 04/09/2023 RP601-10 Round baler Fortima F 1250 From machine number: 1136331...
Page 2 Contact Maschinenfabrik Bernard Krone GmbH & Co. KG Heinrich-Krone-Straße 10 48480 Spelle Germany Telephone main office + 49 (0) 59 77/935-0 Telefax main office + 49 (0) 59 77/935-339 Telefax spare parts warehouse na- + 49 (0) 59 77/935-239 tional territory...
Page 3 For information on your KRONE machines, also refer to mykrone.green. After you have registered, you can generate and manage your machines via the machine number so that you can view the machine data. Via your personal account, you can also access all KRONE Services.
Page 4: Table Of Contents
Overload protections on the machine .................. 43 Identification plate ........................ 44 Function description net wrapping ..................... 45 Function description 2-fold twine tying .................. 46 Function description 4-fold twine tying .................. 47 Technical data .......................... 48 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 5 Connecting foreign ISOBUS terminal .................. 70 7.13 Connecting joystick ........................ 71 7.14 Connecting the camera to the KRONE ISOBUS terminal CCI 800 or CCI 1200 ....... 74 Operation .......................... 75 Preparation before baling...................... 75 Filling the bale chamber ...................... 76 Improving bale chamber filling ....................
Page 6 Setting user preferences ...................... 127 KRONE Terminal DS 500 ....................... 129 11.1 Touchable display ........................ 129 11.2 Switching terminal on/off ...................... 129 11.3 Design DS 500 ......................... 130 KRONE ISOBUS terminal (CCI 800, CCI 1200) .............. 132 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 7 12.2 Switching terminal on/off ...................... 133 12.3 Design of display........................ 134 12.4 Design of the KRONE machine application ................ 134 12.5 Setting units on the terminal .................... 135 Foreign ISOBUS terminal ...................... 136 13.1 Varying functions to KRONE ISOBUS terminal ............... 136 Terminal machine functions ....................
Page 8 Replacing the hose on the dosing unit .................. 219 18.21 Servicing compressed air brake (for version with "Compressed air brake") ...... 220 18.21.1 Cleaning air filter ........................ 220 18.21.2 Drain condensation water from the compressed air tank............ 221 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 9 Moving the cover sheet of the bale ejector ................ 232 19.10 Car jack contact points...................... 233 Waste disposal ........................ 234 Annex ............................ 235 21.1 Hydraulic diagram ........................ 235 Index............................ 237 Declaration of conformity ..................... 247 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 10: Information On This Document
Information on This Document Validity This document is valid for machines of type: RP601-10 (Fortima F 1250) All information, illustrations and technical data in this document correspond to the latest state at the time of publication. We reserve the right to make design changes at any time and without notification of reasons.
Page 11: Figures
This arrow identifies the result of an action step or sequence of actions. This bullet point identifies an enumeration. If the bullet point is intended, it identifies the second level of the enumeration. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 12 The signal word DANGER warns of a hazardous situation which will result in serious injuries or death if the warning sign is ignored. WARNING The signal word WARNING warns of a hazardous situation which will result in serious injuries or death if the warning sign is ignored. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 13: Conversion Table
Factor Inch-pound units Unit name Abbrevi- Unit name Abbrevi- ation ation Area Hectare 2.47105 Acre acres Volume flow Litres per minute L/min 0.2642 US gallons per minute Cubic metres m³/h 4.4029 per hour Fortima F 1250 Original operating instructions 150001157_04_en...
Page 14 Kilometres per km/h 0.6215 Miles per hour hour Volumes Litres 0.2642 US gallon US gal. Millilitre 0.0338 US ounce US oz. Cubic centi- cm³ 0.0610 Cubic inch in³ metre Weight Kilogram 2.2046 Pound Fortima F 1250 Original operating instructions 150001157_04_en...
Page 15: Safety
• Attachment of unauthorised or unapproved additional equipment • Use of spare parts which are not KRONE original spare parts • Stationary operation of the machine Unauthorised modifications to the machine may affect the properties of the machine or disrupt proper operation.
Page 16: Service Life Of The Machine
He has read the operating instructions and can implement the information in the operating instructions accordingly. • He is familiar with driving vehicles safely. • For road travel he has adequate knowledge of the highway code and has the stipulated driving licence. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 17: Personnel Qualification Of The Technicians
2.4.6 Structural modifications on the machine Structural modifications and extensions that were not approved by KRONE can impair the functionality, operational safety and also the road traffic certification of the machine. As a result, persons can be seriously injured or killed.
Page 18: Jobs On The Machine
„ Determine the cause of damage according to these operating instructions and repair the damage, if possible, Page 222. „ In case of damage which may affect operational safety and cannot be repaired according to these operating instructions: Have damage repaired by a qualified service centre. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 19: Danger Zones
Page 29. This also applies to brief inspection work. „ Consider the information in all relevant operating instructions: • the operating instructions for the tractor • the operating instructions of the machine • the operating instructions of universal shaft Fortima F 1250 Original operating instructions 150001157_04_en...
Page 20 „ In case of dangerous situations, immediately switch off drives and instruct people to leave the danger zone. Danger zone due to trailing machine parts If machine parts are trailing, people may be seriously injured or killed. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 21: Ensuring Functionality Of Safety Devices
„ Use only personal protective equipment which is in proper condition and offers effective protection. „ Adjust personal protective equipment to the person, for example the size. „ Remove unsuitable clothing and jewellery (e.g. rings, necklaces) and cover long hair with a hairnet. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 22: Safety Sign On The Machine
„ Consider the overall width of the combined tractor and machine. „ Consider the larger swivel range when cornering. „ Adjust the driving speed when cornering. „ When turning, watch out for people, oncoming traffic and obstacles. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 23: Parking The Machine Safely
Foreign objects and/or liquids in the hydraulic system and/or fuel system may impair the operational safety of the machine and cause accidents. „ Clean all connections and components. „ Close open connections by means of protective caps. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 24: Dangers Arising From Environment
„ Warn people: Do not approach the machine. Electrical voltage differences on the ground may lead to severe electric shocks. „ Wait for help from professional rescue teams. The overhead line must be switched off. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 25: Sources Of Danger On The Machine
Persons can suffer burns and/or scalding when hot liquids are drained. „ Wear personal protective equipment when hot consumables are drained. „ If necessary, allow liquids and machine parts to cool down before you start repair, maintenance and cleaning work. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 26: Dangers In Connection With Certain Activities: Climbing Up And Down
„ Never jump off the machine when you climb down. „ To climb up and down, use only the steps and platforms specified in these operating instructions, Page 83. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 27: Dangers In Connection With Certain Activities: Working On The Machine
„ Prior to all work on raised machines or machine parts, lower the machine or machine parts. „ Before performing any work under raised machines or machine parts, secure the machine or machine parts with rigid safety support or with hydraulic shut-off device or by supporting against lowering. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 28: Dangers In Connection With Certain Activities: Working On Wheels And Tyres
The fitting of wheels and tyres requires adequate knowledge and approved mounting tools. „ If there is a lack of knowledge, have the wheels and tyres fitted by the KRONE dealer or by a qualified tyre service.
Page 29: Safety Routines
„ Bricks and hollow blocks are not suitable for safely supporting the machine and machine parts. Therefore they must not be used. „ Car jacks are also not suitable for safely supporting the machine and machine parts. They must not be used, as well. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 30: Carrying Out Oil Level Check And Oil And Filter Element Changes Safely
Safety sign on the machine Each safety sign is provided with an order number and can be ordered directly from the KRONE dealer. Immediately replace missing, damaged and unrecognisable safety signs. Fortima F 1250...
Page 31 When attaching safety signs, the contact surface on the machine must be clean and free of dirt, oil and grease to ensure optimum adhesion of the safety signs. Location and meaning of the safety signs RPG000-115 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 32 „ Before carrying out any maintenance work in the area of the tailgate, close the stop cock on the left lifting cylinder. „ Ensure that there is no one under the raised tailgate. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 33 „ Removal of a pressure tank or repairs to a hydraulic system may be carried out by a service centre only. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 34 14. Ord. no. 27 017 775 0 (1x) Danger due to incorrect setting Risk of accident due to incorrect brake setting. „ When driving on public roads, ensure that full load (1/1) is set on the brake force regulator, Page 82. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 35: Information Signs On The Machine
Each information sign is provided with an order number and can be ordered directly from the KRONE dealer. Immediately replace missing, damaged and unrecognisable information signs. When attaching information signs, the contact surface on the machine must be clean and free of dirt, oil and grease to ensure optimum adhesion of the information signs.
Page 36 Safety Information signs on the machine Location and meaning of the information signs RPG000-227 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 37 Resserrer les écrous de fixation de roue après la premièremise en service. Stringere i dadi di fissaggio delle ruote dopo il primo impiego. Wielmoeren na het eerste gebruik natrekken. После первого использования подтянуть гайки колес. 942 134 2 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 38 12. Ord. no. 942 038 1 (2x) The areas marked with this information sign must be protected from splash water. In particular, never direct the water jet of the high-pressure cleaner at bearings and electric/electronic components. 942 038-1 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 39 There are car jacking points on the machine which are marked by this information sign, Page 233. • Ord. no. 27 023 958 0 There are lashing points on the machine which are marked by this information sign, Page 181. 27 023 958 0 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 40: Safety Equipment
• The safety chain is used for the additional protection of trailed machines in case they become unhitched during transport, Page 63. • The country-specific regulations for using the safety chain during transportation of the machine must be observed. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 41: Smv Emblem
The SMV emblem (1) is at the rear in the centre or on left. If the machine is transported on transport vehicles (for example lorry or train), the SMV emblem must be covered or dismounted. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 42: Data Memory
- can be related to persons. Additional functions, which are contractually agreed with the customer (e.g. teleservice), allow the transmission of certain machine data from the machine. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 43: Machine Description
„ To avoid early wear of the overload protection, switch the PTO shaft off if the overload protection responds for a longer period of time. „ Shut down and safeguard the machine, Page 29. „ Remedy the malfunction, Page 222. The following components are protected by overload protections against damages. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 44: Identification Plate
Type plate RPG000-007 The machine data is specified on a type plate (1). It sits on the right side of the machine, below the storage compartment. KRONE Agriculture SE e24*167/2013*00165 Heinrich-Krone-Str. 10, D-48480 Spelle Series T/V/V Model Year Construction Year DVG000-004...
Page 45: Function Description Net Wrapping
The machine number results from the last 7 digits of the vehicle identification number (5). To ensure that the data is always available, KRONE recommends that you enter it in the boxes on the front cover of these operating instructions.
Page 46: Function Description 2-Fold Twine Tying
From here, the twine is routed via the twine tying mechanism (7) between rubber roll (6) and pressure roll (4) into the area of the cutting unit (5). When a wrapping process starts, the rubber roll (6) is driven and conveys the twine into the area of the Fortima F 1250 Original operating instructions 150001157_04_en...
Page 47: Function Description 4-Fold Twine Tying
At the same time, the twine tying mechanism leads the other twines from outside to inside and back again over the round bale. A sensor on the twine tying mechanism signals the completion of the tying cycle, so that the twine is cut. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 48: Technical Data
Technically permitted maximum speed (road travel) 40 km/h Airborne noise emission Airborne noise emission Emissions value (sound pressure level) 73.1 dB Measurement device Bruel & Kjaer, Type 2236 Accuracy class Measurement uncertainty (according to DIN EN ISO 11201) 4 dB Fortima F 1250 Original operating instructions 150001157_04_en...
Page 49: Ambient Temperature
Twine wrapping and tying material Run length plastic twine 400-1,000 m/kg Run length sisal 150-300 m/kg Maximum diameter of the spool of twine 270 mm Maximum height of the spool of twine 270 mm Fortima F 1250 Original operating instructions 150001157_04_en...
Page 50: Net Wrapping And Tying Material
12 volt, 9-pin socket 5.14 Requirements for tractor – brake system Requirements for tractor – brake system Compressed-air connection for "compressed air brake" ver- sion Maximum operating pressure for "hydraulic brake" version 100 bars Fortima F 1250 Original operating instructions 150001157_04_en...
Page 51: Consumables
If oils, which have different specifications, are mixed with each other, the machine may be damaged. „ Never mix oils, which have different specifications, with each other. „ Contact your KRONE service partner before using an oil with a different specification after changing the oil. Biodegradable consumables can be used on request.
Page 52: Initial Operation
ü The protective cap of the universal shaft is mounted, Page 56. ü The universal shaft is mounted, Page 57. ü The cable ties, which were mounted to secure the storage box flap and the side hood, were removed. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 53: Scope Of Delivery
The machine is delivered together with the following additional parts that can be found in the storage compartment or in the bale chamber. RPG000-108 1 Test roll KRONE excellent net wrap 4 Hose and cable support 2 Protective cap 5 Fixing material...
Page 54: Preparing The Brake Disc Of The Wrapping Material Brake
Prior to aligning the machine and adjusting the height of the drawbar, the tyre pressure was checked and, if necessary, adjusted to the value recommended for the installed tyre type in the tyre pressure table, Page 204. RP000-577 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 55: Universal Shaft
„ To prevent damage to the machine, check the length of the universal shaft whenever you change tractors. Have it corrected by a KRONE service partner if necessary. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 56: Mounting Protective Cap Of Universal Shaft
„ Slip the auger thread clamp (2) onto the adapter ring at the protective cap (3). „ Slip the protective cap (3) onto the transfer gearbox housing and tighten the screw (1) at the auger thread clamp (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 57: Mounting The Universal Shaft On The Machine
„ Mount the cover (6). „ To prevent the supporting chain (5) from rotating, hook it into the eye (4) on the protective cap (3). INFO More details can be found in the operating instructions for the universal shaft. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 58: Commissioning
(e.g. ball-head hitch) must be in a horizontal position (+/- 3°) with respect to the ground so as not to obstruct the operational swivel angle between the mechanical connection devices. RP000-098 Example image Fortima F 1250 Original operating instructions 150001157_04_en...
Page 59: Mounting The Universal Shaft On The Tractor
„ To prevent damage to the machine, check the length of the universal shaft whenever you change tractors. Have it corrected by a KRONE service partner if necessary. ü The machine has been shut down and secured, Page 29.
Page 60: Adjusting Drawbar Eye
„ Remove the screw connection (2). „ Rotate the drawbar eye into the desired position (I) or (II) and use the screw connection (2) to mount it on the drawbar (1). „ Ensure that the toothed disc connections mesh. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 61: Connecting Hydraulic Hoses
Additional explanations of the markings on the handles can be found on the label (2) on the machine. „ Depressurise the tractor hydraulics. „ Shut down and safeguard the machine, Page 29. „ Clean and dry the connections of the hydraulic quick connector. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 62: Connecting Hydraulic Brake (Export)
„ Connect the 7-pin plug of the lighting cable (2) to the 7-pin socket (3) of the tractor. „ Route the lighting cable (2) so that it does not come into contact with the tractor wheels or other moving parts of the machine. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 63: Mounting Safety Chain
The safety chain should have enough play when driving around curves. ü The machine has been shut down and secured, Page 29. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 64: Mounting The Catch Loop
The catch loop (1) is pre-mounted at the drawbar in position (I). ü The machine has been shut down and secured, Page 29. „ Fasten the catch loop (1) at a suitable position at the rear of the tractor, e.g. position (II). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 65: Connecting The Krone Ds 100 Operation Unit
Commissioning Connecting the KRONE DS 100 operation unit Connecting the KRONE DS 100 operation unit NOTICE Short circuit caused by impurities and moisture in the plug connection The machine may be damaged by a short circuit. „ Make sure that the plugs and sockets are clean and dry.
Page 66: Connecting Krone Terminal Ds 500
EQG003-124 ü The machine has been shut down and secured, Page 29. ü The accessories kit B290 “KRONE tractor retrofitting” is mounted. Connection terminal to tractor „ Connect the 9-pin plug (1) of the terminal to the 9-pin socket (2) (In-cab).
Page 67 Commissioning Connecting KRONE terminal DS 500 7.10 Tractors with integrated ISOBUS system EQ003-251 ü The machine has been shut down and secured, Page 29. Connection terminal to tractor „ Connect the 9-pin plug (2) of the cable (1) to the 9-pin socket (3) (In-cab).
Page 68: Connecting The Krone Isobus Terminal (Cci 800, Cci 1200)
EQ003-252 ü The machine has been shut down and secured, Page 29. ü The accessories kit B290 “KRONE tractor retrofitting” is mounted. Connection terminal to tractor „ Connect the 9-pin plug (2) of the cable (1) to the 9-pin socket (3) (In-cab). Connection tractor to machine INFO The cable (6) can be ordered by quoting the order number 20 086 886 *.
Page 69 Commissioning Connecting the KRONE ISOBUS terminal (CCI 800, CCI 1200) 7.11 Tractors with integrated ISOBUS system CCI 1200 CCI 800 EQ001-173 ü The machine has been shut down and secured, Page 29. Connection terminal to tractor „ Connect the 12-pin plug (2) of the cable (3) to the 12-pin socket (1) of the terminal.
Page 70: Connecting Foreign Isobus Terminal
EQ001-181 ü The machine has been shut down and secured, Page 29. ü The accessories kit B290 “KRONE tractor retrofitting” is mounted. Connection terminal to tractor „ Connect the 12-pin plug (2) of the cable (3) to the 12-pin socket (1) of the terminal.
Page 71: Connecting Joystick
INFO For further details on terminal connection, observe operating instructions of ISOBUS terminal manufacturer. 7.13 Connecting joystick INFO Follow the supplied joystick operating instructions for attachment of the joystick in the tractor cabin. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 72 Commissioning 7.13 Connecting joystick KRONE ISOBUS terminal on tractors with integrated ISOBUS system EQ001-150 ü The machine has been shut down and secured, Page 29. „ Connect the 9-pin plug (2) of the cable (1) to the 9-pin socket (3) of the joystick.
Page 73 ü The machine has been shut down and secured, Page 29. ü The accessories kit B290 “KRONE tractor retrofitting” is mounted. „ Connect the 9-pin plug (2) of the cable (1) to the 9-pin socket (3) of the joystick. „ Connect the 9-pin plug (4) of the joystick to the 9-pin socket (5) (In-cab).
Page 74: Connecting The Camera To The Krone Isobus Terminal Cci 800 Or Cci 1200
CCI 800 CCI 1200 EQ000-212 „ Insert the plug (4) on the camera (2) cable (3) into the connection C (1) of the KRONE ISOBUS terminal CCI 800 or CCI 1200 . „ To connect the plug (4) correctly, ensure that it is aligned with the marked points (5). Fortima F 1250...
Page 75: Operation
ü When used in straw: The splash guard is removed, Page 102. ü When used in silage or hay: The splash guard is installed, Page 102. ü The tailgate is closed. ü The working screen has been selected, Page 143. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 76: Filling The Bale Chamber
RP000-062 „ Travel longer sections on the left respectively right side of the swath (1). Observe a length of roughly X=20 m on one side. „ Avoid swerving (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 77: Improving Bale Chamber Filling
„ To largely prevent short, brittle straw from falling out of the bale chamber when driving from one swath to the next swath, switch off the PTO shaft in the meantime. Driving speed KRONE recommends a driving speed of 5 ... 12 km/h. The driving speed while working must be adapted to the following circumstances: •...
Page 78: Completing The Baling Process, Starting Tying Cycle And Ejecting Round Bales
„ Pull out the securing pin (4), extend the parking support (2) and secure the position using the securing pin (4). „ Turn the support jack (2) anti-clockwise firmly down onto the ground using the crank handle (1) until the drawbar is relieved. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 79: Using The Stop Cock Of The Tailgate
„ Lift the stop cock (1) and turn into position (I). Æ The tailgate can be closed. Closing the stop cock „ Lift the stop cock (1) and turn into position (II). Æ The tailgate cannot be closed. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 80: Releasing/Applying The Parking Brake
„ Attach the other end of the safety cable (3) to a suitable point at the rear of the tractor. „ Ensure that the safety cable (3) cannot come loose and does not come into contact with moving parts, for example the tractor tyres. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 81: Fitting Wheel Chocks
Removing/mounting the safety device which prevents unauthorised The safety device is used to prevent unauthorised use when the machine has been switched off. ü The machine has been parked, Page 175. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 82: Operating Brake Force Regulator
(I). The following positions are possible: Position Brake force Full load (1/1) (II) Half load (1/2) (III) switched off (0) „ Turn the brake force regulator (1) in the direction of the arrow to the required position. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 83: Ladder For Working On The Tying Mechanism
„ For the other terminals: To preselect the pick-up, press the key on the terminal, Page 137. ð The key switches to „ To lower the pick-up into the working position, actuate the control unit on the tractor (yellow, 3+). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 84: Setting The Pick-Up Working Height
„ Check whether the distance between the tines and the ground is 20 ... 30 mm. „ If required, re-adjust the perforated bar (1). „ Check whether the drawbar height of the machine must be adjusted to the tractor, Page 54. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 85 „ Set the guide wheels (4) upwards. „ Loosen the screw connections (2). „ Push the depth limiter (1) in direction of the arrow until the pick-up (3) has reached the desired working height. „ Tighten the screw connections (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 86: Replacing The Shear Bolt On The Pick-Up Drive
The crop press roller unit (3) guides the crops at the intake via the pick-up. The height of the crop press roller unit (3) must be set so that the operating crop press roller (2) continuously touches the swath. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 87: Setting The Baffle Sheet On The Crop Press Roller Unit
• Insert the coach screw (5) into the rectangular borehole (6) and secure it with spacer tube, disc and locknut, and • place the bracket (2) on the bolt (3) and secure it with the linch pin (3). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 88: Removing/Mounting The Baffle Sheet On The Crop Press Roller Unit
„ Cut off any soiled section of twine or use a new twine spool. „ Clean the components of the twine tying before inserting the twine. ü The machine has been shut down and secured, Page 29. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 89 „ Feed the end of the twine on the spool of twine (A2) through the eye above and connect it using a reef knot (1) to the beginning of the twine on the spool of twine (A3). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 90 „ Route the two twines (3) between the spring compressors (7) and the screws (6). RP001-041 „ Swivel the net spreader (2) upwards to the top position. „ Ensure that the net spreader (2) is held in the guide track of the guide iron (1). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 91: Inserting Tying Twine
„ Cut off any soiled section of twine or use a new twine spool. „ Clean the components of the twine tying before inserting the twine. ü The machine has been shut down and secured, Page 29. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 92 „ Feed the end of the twine on the spool of twine (A1 or B1) through the eye above and connect it using a reef knot (1) to the beginning of the twine on the spool of twine (A2 or B2). „ Shorten the twine ends of all reef knots (1) to X=15-20 mm. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 93 „ Feed 2 twines through each eye (2) of the two twine brakes (4). „ Route the twines between the screws (3) and the spring compressors (1). „ Feed the two twines from the upper twine brake to the stepped pulley (5). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 94 „ Thread the twines from the lower twine brake directly through the distributor eyes (2) and then further on through the distributor eyes (3). „ Lay the twine ends at least 25 cm over the rubber roll (5). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 95: Net Wrapping
Also observe the information on the package provided by the tying material manufacturer. INFO For trouble-free use in the field, KRONE recommends one of the "KRONE excellent" nets, see label on the machine with the number 27 016 326 *. RPG000-016 ü...
Page 96: Insert Net
„ Spread the net (3) to a width of approx. 500 mm so that the drivers of the feed roller can pick the net up over its full width. „ After you have inserted the net, set the spreading bracket to net wrapping, Page 97. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 97: Adjusting The Spreading Bracket To Net Wrapping Or Twine Tying
CAUTION! Risk of injury due to sharp parts! Always wear appropriate protective gloves when removing crop blockages. „ Remove the accumulated crops manually. „ After remedying the crop blockage, increase the speed to the rated speed again. „ Resume baling. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 98: Crop Blockage Under Feed Rotor
Operating the reversing device with crop blockages In the case of crop blockages the reversing device can be turned back manually or hydraulically using the feed rotor. This allows the crop blockage to be removed more easily. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 99 „ Reverse the machine. „ Shut down and safeguard the machine, Page 29. „ Close the cover (1). „ Manually remove the crops which are still in the feed rotor or in the pick-up. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 100 „ Close the stop cock (3) in the control valve hydraulic hose line. „ Manually remove any remaining crop from the feed rotor (1) or the pick-up. „ Start the engine and turn on the PTO shaft. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 101: Operating The Central Chain Lubrication System
The central chain lubrication system is located on the left side of the machine behind the side hood. The rails with the dosing units (1) and (4) are located on the right and left sides of the machine. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 102: Mounting / Dismounting The Splash Guard
Mounting / dismounting the splash guard RP000-861 Mounting the splash guard: Mount the splash guard (3) for use in silage or hay: „ On both sides of the splash guard, insert a spring cotter pin (1) into the bolt (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 103 Mounting / dismounting the splash guard 8.21 Dismounting the splash guard: When working in straw, dismount the splash guard (3): „ On both sides of the splash guard, pull the spring cotter pin (1) out of the bolt (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 104: Krone Medium Operation Panel
KRONE Medium operation panel Overview KRONE Medium operation panel NOTICE Penetration of water in the operation unit could lead to malfunction. As a result, the machine can no longer be operated safely. „ Protect the operation unit from water. „ If the machine is not used for an extended period of time (for example in winter), the terminal must be stored in a dry place.
Page 105: Switching Operation Panel On/Off
KRONE Medium operation panel Switching operation panel on/off Switching operation panel on/off RP000-582 „ Using the magnet, attach the operation panel in the tractor within the driver's field of vision. „ Connect the operation panel to the power supply (12 V). „ Set the switch (1) to 1 to switch on the operation panel.
Page 106: Operating The Bale Counter
KRONE Medium operation panel Operating the bale counter Operating the bale counter RPG000-178 The bale counter (1) is actuated every time the tailgate is opened. The bale counter (1) is located on the left side of the machine behind the side hood.
Page 107: Display Filling
KRONE Medium operation panel Display filling With switched on zero setting of blades RP000-587 The indicator for zero setting of blades (1) on the front right machine side indicates whether the cutting unit is switched on or switched off. Position (I): Cutting unit switched off Position (II): Cutting unit switched on The indicator for zero setting of blades (1) also indicates during the baling process whether the...
Page 108: Start Tying
KRONE Medium operation panel Start tying Start tying 9.7.1 Starting tying manually (manual mode) RP000-589 A horn sounds and the two indicator lamps (1) go out when the round bale reaches the preselected baling pressure. In manual mode, the tying cycle must be started manually: „...
Page 109: Checking And Adjusting The Sensors
KRONE Medium operation panel Checking and adjusting the sensors ü The operation panel is switched off. „ Press and hold the momentary switch (2) in the direction of the arrow and switch on the operation panel at the same time. ð A brief beep sounds.
Page 110 KRONE Medium operation panel Checking and adjusting the sensors RP000-590 ü The ignition is switched on. Checking sensor B05 "Filling indicator right" „ Raise the baling pressure indicator (1) on the left at the front of the round baler. ð The indicator lamp (3) must go out.
Page 111: Krone Operation Unit Ds 100
KRONE operation unit DS 100 Overview 10.1 KRONE operation unit DS 100 For version with "Net wrapping" NOTICE Penetration of water in the operation unit could lead to malfunction. As a result, the machine can no longer be operated safely.
Page 112 KRONE operation unit DS 100 10.1 Overview Pos. Icon/designation Explanation Direction display arrows, see Page 114 LEDs A-H The LEDs indicate the direction or the progress of the tying cycle on the working screen. Additionally, the LEDs can indicate different set- tings.
Page 113: Switching The Operation Unit On/Off
KRONE operation unit DS 100 Switching the operation unit on/off 10.2 Pos. Icon/designation Explanation • Start tying process in manual mode • Switch the automatic mode of tying on/off, Page 115 Switching working lights on/off, see Page 116 Switching warning beacon on/off, see Page 116...
Page 114: Accessing The Working Screen
KRONE operation unit DS 100 10.4 Accessing the working screen 10.4 Accessing the working screen The working screen can show the following data: • The display shows the actual baling pressure as a %. • During filling of the bale chamber, the LEDs A-H serve as direction display, Page 114.
Page 115: Start Tying
KRONE operation unit DS 100 Start tying 10.6 Icon Explanation Step 2: The bale chamber is filled too much on the right side. Steer the tractor to the right to pick up the swath on the left of the bale chamber.
Page 116: Switching The Working Lights On/Off
KRONE operation unit DS 100 10.7 Switching the working lights on/off 10.7 Switching the working lights on/off For "Working lights" version „ To switch on the working lights, press the key. Æ The indicator lamp above the key emits light.
Page 117: Setting The Sensitivity Of The Direction Display
KRONE operation unit DS 100 Setting the sensitivity of the direction display 10.10 ð The display (2) shows the set advance signaling as a %. „ To change the value, press the keys (4). Æ The value is saved automatically. „ To return to the working screen, press the key (3) again.
Page 118: Setting The Baling Pressure
KRONE operation unit DS 100 10.11 Setting the baling pressure 10.11 Setting the baling pressure EQG003-116 At the operation unit, the baling pressure in % can be set for the round bale in the working screen. „ Press the key (3) to call the "Baling pressure" menu.
Page 119: Setting The Tying Start Delay
KRONE operation unit DS 100 Setting the tying start delay 10.13 ð The display (2) shows the set number of net layers. „ To change the value, press the keys (4). Æ The value is saved automatically. „ To return to the working screen, press the key (3) once more.
Page 120: Displaying The Customer Counter
KRONE operation unit DS 100 10.14 Displaying the customer counter 10.14 Displaying the customer counter EQ003-250 The customer counter shows the number of the pressed round bales in the display (1). 8 different customer counters can be indicated and saved. Each LED from A-H corresponds to one customer counter.
Page 121: Sensor Test For Digital And Analogue Sensors
KRONE operation unit DS 100 Sensor test for digital and analogue sensors 10.15 10.15 Sensor test for digital and analogue sensors WARNING Danger of injury in the danger zone of the machine If the PTO shaft runs during the sensor test, machine parts may start to move unintentionally.
Page 122: Calibrating Sensors
KRONE operation unit DS 100 10.16 Calibrating sensors Designation Sensor type Tying process active digital Filling display left analogue Filling display right analogue Tailgate lock hook left digital Tailgate lock hook right digital Tying 2 (active) digital An overview of the position of the sensors, actuators and control units is provided in the circuit diagram.
Page 123 KRONE operation unit DS 100 Calibrating sensors 10.16 Sensor Additional Filling display left Filling display right Tying 1 (passive) Set feed position of the feed rocker arm Tying 1 (passive) Set end position of the feed rocker arm „ To switch between the sensor calibrations, press the key to scroll up and the...
Page 124: Actuator Test For Digital And Analogue Actuators
KRONE operation unit DS 100 10.17 Actuator test for digital and analogue actuators Set end position of the feed rocker arm ü The LED D is lit. „ To move the feed rocker arm in the direction of the end position, press the ...
Page 125: Error Messages
KRONE operation unit DS 100 Error messages 10.18 Status Display Actuator status Is lit Actuator ON Is lit Actuator OFF Flashes Short circuit Flashes Cable break Flashes General fault The following actuators can be displayed: Designation Pick-up Tying coupling Motor tying 1 (passive) An overview of the position of the sensors, actuators and control units is provided in the circuit diagram.
Page 126: Manual Operation Of The Tying System
KRONE operation unit DS 100 10.19 Manual operation of the tying system Acknowledging error message „ Note down the error number. „ Press the key. Æ The acoustic signal stops and the error message is no longer indicated. „ Eliminate the fault. See Chapter "Error list" in the supplement to the operating instructions "Error messages".
Page 127: Setting User Preferences
KRONE operation unit DS 100 Setting user preferences 10.20 Display Explanation The feed rocker arm is in the limit position. The feed rocker arm is in the feed position. The feed rocker arm is between the limit and feed position. This display is also shown while the feed rocker arm is moving.
Page 128 KRONE operation unit DS 100 10.20 Setting user preferences Number of the set- Setting type Value range (3) ting (2) Volume 0-10 Background lighting day design 0-10 Background lighting night design 0-10 Display lighting day design 1-10 Display lighting night design...
Page 129: Krone Terminal Ds 500
KRONE Terminal DS 500 Touchable display 11.1 KRONE Terminal DS 500 NOTICE Penetration of water in the terminal could lead to malfunction. As a result, the machine can no longer be operated safely. „ Protect the terminal from water. „ If the machine is not used for an extended period of time (for example in winter), the terminal must be stored in a dry place.
Page 130: Design Ds 500
11.3 Design DS 500 11.3 Design DS 500 EQ003-254 The KRONE machine application is divided into the following areas: Status line (1) The status line (1) indicates current states of the machine (depending on how it is equipped), Page 137. Keys (2) The machine is operated by pressing the keys (2) via touch function,...
Page 131 KRONE Terminal DS 500 Design DS 500 11.3 Keys (6) The keys (6) can be used to open the main menu or the working screen and to confirm the error messages and set the brightness. Icon Designation Explanation Main menu Open the main menu of the terminal.
Page 132: Krone Isobus Terminal (Cci 800, Cci 1200)
KRONE machines, which have ISOBUS equipment, are coordinated with this system. EQG000-057 The electronic equipment of the machine consists essentially of the job computer (1), the terminal (2) and the control and function elements.
Page 133 KRONE ISOBUS terminal (CCI 800, CCI 1200) Switching terminal on/off 12.2 12.2 Switching terminal on/off EQ001-174 KRONE ISOBUS terminal CCI 1200 KRONE ISOBUS terminal CCI 800 „ Before switching on the terminal for the first time, check that the connections are correct and tight.
Page 134 „ For more details on how the terminal functions, follow the terminal operating instructions. 12.4 Design of the KRONE machine application EQG000-059 The KRONE machine application is divided into the following areas: Status line (1) The status line (1) indicates current states of the machine (depending on how it is equipped), Page 137.
Page 135 KRONE ISOBUS terminal (CCI 800, CCI 1200) Setting units on the terminal 12.5 Keys (2) The machine is operated by pressing the keys (2) via touch function, Page 137. Main window (3) Values (figures) shown in blue in the main window can be selected using the touch function.
Page 136 KRONE ISOBUS terminal. Before commissioning, refer to the mode of operation of the KRONE ISOBUS terminal in the operating instructions. A major difference to the KRONE ISOBUS terminal is the arrangement and number of keys with functions determined by the selected external ISOBUS terminal.
Page 137 If error messages are ignored and the malfunction is not remedied, people may be injured and/or the machine may be damaged seriously. „ Remedy the malfunction when the error message is displayed, Page 227. „ If the malfunction cannot be remedied, consult a KRONE service partner. 14.1 Status line INFO Using a terminal with a resolution of less than 480x480 pixels.
Page 138 Press the key to open Menu 13 "Counters", Page 159. Scrolling display pages. 14.3 Displays on the working screen EQG003-009 The available icons comply with the equipment of the machine. The following represented icons are not always available. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 139 The feed rotor floor (4) can show the following positions: The feed rotor floor is in the top position. The feed rotor floor is in the bottom position. Crop blockages can be removed, Page 97. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 140 In addition, the progress of the net wrapping or twine tying is displayed as a percentage under the icon. 14.4 Displays on the information bar EQG003-111 The available icons comply with the equipment of the machine. The following represented icons are not always available. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 141 Arrow flashes Step 1: The bale chamber is filled slightly too much on the right side. Steer the tractor to the right to pick up the swath on the left of the bale chamber. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 142 ISOBUS Shortcut Button, at least one ISOBUS Shortcut Button must be available. The ISOBUS Shortcut Button can be integrated both in/on the terminal or can be available as an external momentary switch in the ISOBUS system. The KRONE Machine Controller (KMC) reads out the information whether an ISOBUS Shortcut Button is available in the ISOBUS system.
Page 143 Terminal machine functions Accessing the working screen 14.7 EQG000-022 If the KRONE Machine Controller (KMC) detects an ISOBUS Shortcut Button, the icon displayed when the terminal starts. If the KRONE Machine Controller (KMC) detects no ISOBUS Shortcut Button, the icon displayed when the terminal starts. Actuating ISOBUS Shortcut Button EQG001-009 „...
Page 144 The terminal switches automatically to the Road travel screen after roughly five minutes when the following requirements are met: ü The PTO shaft is switched off. ü The tailgate is closed. ü The machine is in field mode. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 145 A programmable key can be assigned with several different functions. If key assignments are saved, the display shows corresponding menus when switching on the terminal. The following functions are available in the “Auxiliary” (AUX) menu: Fortima F 1250 Original operating instructions 150001157_04_en...
Page 146 The examples below represent a recommendation. The assignment of the joystick can be adapted to own desires. For further information, please refer to the operating instructions of the used terminal. Recommended assignment of an AUX joystick EQG003-040 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 147 Recommended configuration of an AUX joystick CCI A3 EQG003-143 The indicator lamp (2) shines, showing that operating level 1 is active. „ Actuate the switch (1) on the rear of the joystick to display the next operating level. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 148 (for version with "net wrapping and twine tying"), Page 156 Manual operation, see Page 157 Counter, see Page 159 13-1 Customer counter, see Page 160 13-2 Total counter, see Page 162 ISOBUS, see Page 163 14-5 KRONE SmartConnect, see Page 163 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 149 Move left to select something. Disk Save the setting. Leave the menu without saving. By pressing the key a little longer, the pre- viously viewed working screen is selected. Reset to factory setting. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 150 By means of the scroll wheel „ Select the desired menu by means of scroll wheel. ð The selected menu is highlighted in colour. „ To call up the menu, press the scroll wheel. Æ The menu opens. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 151 ð An input mask opens. „ Turn the scroll wheel to increase or reduce the value. „ Press scroll wheel to save the value. Æ The setting is saved and the input mask closes. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 152 „ To leave the menu, press 15.7 Tying in the menu level ü For The menu level is active, Page 150. For the “Net wrapping” version EQG003-008 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 153 Menu 1 "Number of net layers" (net wrapping) 10,0 EQG003-000 ü For The menu level is active, Page 150. „ To open the menu, press Æ The display shows the "Number of tying material layers" menu. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 154 15.10 Menu 3 “Advance signalling” Pre-signalling is used to warn if the round bale in the bale chamber is near completion. On the terminal you can set the filling for which pre-signalling starts. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 155 „ To open the menu, press Æ The display shows the "Tying start delay" menu. Setting the tying start delay „ Increase or reduce the value, Page 151. „ In order to save the value, press Fortima F 1250 Original operating instructions 150001157_04_en...
Page 156 Menu 8 "Select type of tying" (for the "Net wrapping and twine tying" version) EQG003-005 ü For The menu level is active, Page 150. „ To open the menu, press Æ The display shows the "twine tying type selection" menu. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 157 Actuator for wrapping process (net) is in feed position. Actuator for wrapping process (net) is in tying position. Actuator for wrapping process (net) is in end position. The position is not defined. Use the keys on the sides to operate the following functions: Fortima F 1250 Original operating instructions 150001157_04_en...
Page 158 Explanation Actuator for wrapping process (twine) is in feed position. Actuator for wrapping process (twine) is in central position. Actuator for wrapping process (twine) is in end position. The position is not defined. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 159 Menu 13 "Counters" EQG003-011 ü For The menu level is active, Page 150. „ To open the menu, press Æ The display shows the menu "Counter ". The "Counter" menu is divided into the following submenus: Fortima F 1250 Original operating instructions 150001157_04_en...
Page 160 „ To activate a customer counter, navigate to the required customer and press Æ The required customer counter is shown as: „ To open the detailed view of a customer, navigate to the required customer and press Fortima F 1250 Original operating instructions 150001157_04_en...
Page 161 The number of bales can be manually changed in the customer counter. The particular customer counter does not have to be activated for this. „ To increase the number of bales, press „ To reduce the number of bales, press Fortima F 1250 Original operating instructions 150001157_04_en...
Page 162 Total of pressed round bales Operating hours counter Use the keys on the sides of the terminal to operate the following functions: Icon Explanation Setting season counter 1 to zero Setting season counter 2 to zero Fortima F 1250 Original operating instructions 150001157_04_en...
Page 163 Designation ISOBUS, see Page 163 14-5 KRONE SmartConnect, see Page 163 14-9 Switching between terminals, see Page 164 15.17.1 Menu 14-5 "KRONE SmartConnect" The access data for the KRONE SmartConnect (KSC) can be seen in this menu. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 164 00011501 WLAN-KEY: afbb2bfac5 PRODUCT-CODE: C0060000600011501 EQG000-064 ü One or more KRONE SmartConnects have been installed. ü The menu 14 “ISOBUS” has been selected, Page 163. „ To open the menu, press Æ The display shows the "SmartConnect" menu. 15.17.2 Menu 14-9 "Switching between terminals"...
Page 165 In the sensor test, the sensors installed on the machine are checked for faults. Furthermore the sensors can be correctly set in the sensor test. There is no guarantee the machine is working correctly until after the sensors have been adjusted. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 166 Possible sensors (depending on the machine configuration) An overview of the sensors, actuators and control units is in the circuit diagram. Sensor Designation Tying process active Filling display left Filling display right Tailgate lock hook left Fortima F 1250 Original operating instructions 150001157_04_en...
Page 167 5,0V 1,5V 1,0V 4,0V 4,6V EQG003-041 The sensor (3) is located behind the rear side guard: • B09 on the left side of the machine • B10 on the right side of the machine. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 168 The B62 sensor “tying 2 (active)” is on the right side of the machine above the V-belt. ü The machine has been shut down and secured, Page 29. „ Loosen the nut on the sensor (1). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 169 ð A warning opens which refers to the operating instructions. „ Observe the safety routine "Run actuator test", Page 30. „ Confirm with Æ The display shows the "Actuator test" menu. The following keys can be available in the menu: Fortima F 1250 Original operating instructions 150001157_04_en...
Page 170 Tying coupling Warning beacon (for certain countries) Motor tying 2 (active) Possible status displays of the actuators Icon Designation Actuator ON Actuator OFF General actuator error No supply voltage Possible cause: Fuse defective. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 171 The actuator for wrapping process M02 can be tested by moving it into the feed or cutting position. „ To move the actuator for wrapping process into the feed position, press „ To move the actuator for wrapping process into the cutting position, press Fortima F 1250 Original operating instructions 150001157_04_en...
Page 172 15-4 KMC - 520192- 19 CAN1 1475 min EQG000-060 ü Menu 15 “Settings” is called, Page 165. „ To open the menu, press Æ The display shows menu "Error list". Fortima F 1250 Original operating instructions 150001157_04_en...
Page 173 Only non-active errors (highlighted grey) can be deleted. „ To select the error to be deleted, press „ To delete the error, press Delete all errors Only non-active errors (highlighted grey) can be deleted. „ To delete all errors, press Fortima F 1250 Original operating instructions 150001157_04_en...
Page 174 In addition, using an automatic anti-jack-knife brake system can lead to a significantly higher wear on the machine brakes. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 175 „ Disconnect the hydraulic hose lines and hook them into the support at the machine. „ Drive the tractor away carefully. „ Fit the safety device which prevents unauthorised use and keep the key in a safe place, Page 81. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 176 Make the following setting on the right and left side of the pick-up in the same way: „ Loosen the screw connections (2). „ Push the depth limiter (1) in the direction of the arrow. „ Tighten the screw connections (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 177 „ Clean the 4 reflectors (1) on the left and on the right side of the machine. 16.6 Disconnecting the supply lines RP000-638 „ Disconnect the hydraulic hoses and the electrical connection cable and suspend them from the holder (1) at the storage compartment. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 178 ü The operation unit or the terminal is stowed away in a safe and dry place. ü For "SMV emblem" version: The SMV emblem is covered or removed, Page 41. 16.7.2 Securing the side hoods Left side of machine RP000-593 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 179 RP000-595 „ Pass a cable tie (2) at the top through the eye on the side hood (1) and at the bottom around the guard tube for the drive shaft (3). „ Tighten the cable tie (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 180 „ If work has to be performed under the machine, securely support the machine, Page 29. The machine is equipped with 3 suspension points. RPG000-216 There are 2 suspension points (1) at the top, next to the bale formation conveyor. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 181 „ Before transporting the machine, secure it properly to the designated lashing points using suitable lashing material. The lashing points on the machine are marked by an information sign, Page 35. RPG000-219 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 182 Driving and transport 16.7 Preparing the machine for shipment 1 2 lashing points at the front RPG000-220 1 2 lashing points at the rear (one on the left and one on the right machine side) Fortima F 1250 Original operating instructions 150001157_04_en...
Page 183 If the relevant safety routines are not observed, persons may be seriously injured or killed. „ The safety routines must be read and observed to avoid accidents, Page 29. 17.1 Setting the baling pressure The following pressure ranges are recommended by KRONE: Type of crop Recommended pressure range Straw medium/high...
Page 184 Setting the number of net layers With "Operation panel medium" version RP000-584 The setting screw (1), which is used to select the number of net layers, sits on the right side of the machine behind the side guard. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 185 The twine limiters (1) must be set independently of the length and type of crops to prevent the twine from slipping off the round bale. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 186 Brake force of the twine setting screws (2) sion springs (3) brake (1) Clockwise higher higher Anti-clockwise lower lower It may be necessary to adjust the compression springs (3) differently so that the cut twine ends have the same length. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 187 The twine tying slides no longer stop during the start and end phase of the tying cycle, but continue moving; or • the slides do not move after the start phase, but remain stopped. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 188 To ensure that the twine is not always started or cut at the same point, the sensor (2) can be moved to the left or right. ü The machine has been shut down and secured, Page 29. „ Loosen the screw (1). „ Move the sensor support (3). „ Tighten the screw (1). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 189 If the net was wrapped around the round bale too loosely or too tightly, the brake force can be set with the nut (4) on the eyelet bolt (5). Default dimension set by KRONE: X=35 mm The setting of the wrapping material brake depends on the net type being used. Adjust the wrapping material brake such that the net hangs into the channel Y=0-50 mm above the...
Page 190 The wrapping material can be pulled with difficulty. central medium The wrapping material can be pulled with medium strength. KRONE re- commends this setting as an op- timum brake force release during the feeding of the wrapping material. bottom strong The wrapping material can be pulled easily.
Page 191 Y=2 mm, or the distance between the bearing (3) and the bearing pipe (4) must be X=8 mm. To adjust the distances: „ Loosen the screw (6). „ Move the spring rail (5) until Y=2 mm or X=8 mm. „ Tighten the screw (6). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 192 This applies in particular to safety-relevant work. „ Have specially designated work performed by a qualified service centre only. INFO If new components need to be ordered for maintenance, use only KRONE original spare parts. 18.1 Observe the service record booklet A service record booklet is enclosed with the machine.
Page 193 Page 78 Check hydraulic hoses see Page 206 Check the electrical connection cables and, if necessary, have them repaired or changed by a KRONE service partner Remove corrosion from the spreading bracket see Page 209 18.2.2 Maintenance – After the season Components Clean the machine see Page 207...
Page 194 Page 210 Check tyre pressure see Page 204 Check the hydraulic hoses for leaks and, if ne- see Page 206 cessary, have them replaced by a KRONE service partner. Cleaning bushing and drawbar eye see Page 208 18.2.4 Maintenance – once after 50 hours The manual for service technicians contains other maintenance items which must also be carried out.
Page 195 The information on maintenance intervals is based on average load of the machine. In case of an increased load and under extreme working conditions, the time periods must be reduced. The types of lubrication are marked by means of icons in the lubrication chart, refer to table. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 196 „ Remove excess lubricating grease at the grease nipple. Oils Plant-based oils, unless spe- „ Apply the oil evenly. cified otherwise. Left side of machine RPG000-113 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 197 Service & maintenance Lubrication chart 18.3 Every 20 operating hours (2) Without "Central chain lub- rication" version (9) Without "Central chain lub- (10) Without "Central chain rication" version lubrication" version Fortima F 1250 Original operating instructions 150001157_04_en...
Page 198 Service & maintenance 18.3 Lubrication chart Every 100 operating hours Right side of machine RPG000-114 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 199 (6) Without "Central chain lub- rication" version (7) Without "Central chain lub- (8) Without "Central chain lub- (9) Without "Central chain lub- rication" version rication" version rication" version (10) (11) (12) Fortima F 1250 Original operating instructions 150001157_04_en...
Page 200 The following table provides information about the lubricant quantity and the lubrication interval per lubrication point. Item Lubricant quantity Lubrication interval with friction disc clutch with cam clutch 13 g 10 g 50 hours 60 g 30 g Fortima F 1250 Original operating instructions 150001157_04_en...
Page 201 The table does not apply to countersunk screws with hexagon socket in case the countersunk screw is tightened via hexagon socket. DV000-001 Thread size Strength class on screw head Strength class 10.9 12.9 Tightening torque (Nm) Fortima F 1250 Original operating instructions 150001157_04_en...
Page 202 1,914 M30 x 1.5 2,100 2,650 Metric thread screws with countersunk head and hexagon socket INFO The table applies only to countersunk screws with hexagon socket and metric thread tightened via hexagon socket. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 203 Bleed valve made of brass copper ring Ventilation/breather filter made of Ventilation/breather filter made of brass steel Steel and cast Aluminium Steel and cast Aluminium Maximum tightening torque (Nm) (±10%) M10x1 M12x1.5 G1/4“ M14x1.5 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 204 Inspect the tyres visually „ Visually inspect tyres for cuts or breaks. Æ If there are cuts or breaks in the tyres, have the tyres repaired or replaced by a KRONE service partner. Maintenance intervals for visual inspection of the tyres, Page 192.
Page 205 8 units — 350 ... 380 Nm M22x1.5 30 mm 8/10 units — 450 ... 510 Nm Hub centring M18x1.5 27 mm 6 units — 270 ... 290 Nm M22x1.5 32 mm 8/10 units — 450 ... 510 Nm M24x1.5 36 mm 10 units — 550 ... 610 Nm Fortima F 1250 Original operating instructions 150001157_04_en...
Page 206 The date of manufacture appears on the hydraulic hoses. This way the age can be ascertained quickly. Replacement of the hydraulic hoses is recommended after a lifetime of six years. „ Use original spare parts when replacing hoses. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 207 The dirt particles may hit the eyes and hurt them. „ Keep persons away from working range. „ When performing cleaning work with compressed air or with high-pressure cleaner, wear suitable working clothes (for example eye protection). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 208 (1) in the drawbar eye (2) is X=43 mm. If the dimension X is exceeded, the drawbar eye (1) must be replaced by a KRONE service partner. „ To minimize wear, clean the bushing (1) and the drawbar eye (2) several times a day and coat with grease.
Page 209 Protecting brake disc of the wrapping material brake from corrosion RPG000-222 „ To prevent corrosion on the brake disc of the wrapping material brake, mask the brake surface of the brake disc (2) with adhesive protection film (1) or insulating tape. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 210 „ Check that the screw connections (1) and (2) have been tightened to the correct tightening torque. „ Tighten the screw connections (1) on the drawbar to the tightening torque 210 Nm. „ Tighten the screw connections (2) on the drawbar eye to the tightening torque 800 Nm. Maintenance interval, Page 192. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 211 Adjust the spring rail (1) if the round bales are not wrapped optimally with the net: „ Completely extend the electric motor (3). „ Loosen the screws (6). „ Move the guide tip (4) in the oblong hole (5) until the spring rail (1) is above the setting screw (2). „ Tighten the screws (6). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 212 ü The machine has been shut down and secured, Page 29. ü The left side hood is open. „ Loosen the counter nut (3). „ Turn the nut (4) until X=80 ... 90 mm. „ Tighten the counter nut (3). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 213 „ To increase the chain tension, turn the nut at the compression spring (1,2) clockwise until X=30 mm is reached. „ To reduce the chain tension, turn the nut on the compression spring (1, 2) anti-clockwise until the dimension X=30 mm has been set. 18.19.3 Drive chain of the rollers RPG000-203 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 214 „ When working on the central chain lubrication unit, use clean and suitable tools. „ Use authorised lubricants only. „ Ensure that dirt or dirty lubricant cannot get into the central chain lubrication unit. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 215 ü The reservoir (3) is mostly empty. „ Remove the cover (4). „ Remove the filter (5) from the reservoir (3). „ Mount a new filter (5). „ Mount the cover (4). „ Fill the reservoir (3) with oil, Page 215. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 216 To adjust the oil volume, Page 101. Right side of machine RPG000-272 Item Designation Bale formation conveyor (2x) Main drive (2x) Units drive (1x) Pick-up drive (1x) Spur wheel (1x) Starter roller drive (1x) Fortima F 1250 Original operating instructions 150001157_04_en...
Page 217 Pick-up (1x) 18.20.3 Position of the dosing units Left side of machine RPG000-212 The dosing units on the rail on the left side of the machine oil the chains of the following machine components: Fortima F 1250 Original operating instructions 150001157_04_en...
Page 218 Pick-up drive Pick-up 18.20.4 Cleaning the dosing units RP000-231 If individual dosing units (2) on the central chain lubrication system are blocked, clean these dosing units and the surrounding area, see also Maintenance table, Page 192. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 219 „ Pull the defective hose (4) out of the cap nut (1) and dispose of. „ Screw the cap nut (1) onto the dosing unit (2) hand-tight. „ Insert the new end of the hose (4). Ensure that the hose (4) has been completely inserted into the cap nut (1). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 220 „ In the case of stubborn dirt, clean the components with water. Installing filter element ü The machine is shut down and safeguarded, Page 29. „ Insert the filter element (3) with the spring (2). „ Insert the spacer (4). „ Insert the spring (5). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 221 „ Visually inspect the drain valve (2) to ensure that it is not defective or soiled. Æ If the drain valve (2) is defective and is no longer sealed, immediately have the drain valve (2) replaced by a KRONE service partner. Æ If the drain valve (2) is soiled, clean the drain valve (2).
Page 222 Possible cause Remedy „ Check the setting of the drawbar. The machine is hooked in too low at the front. „ If required, have the drawbar height adjusted by the KRONE service partner, Page 54. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 223 Page 153. The wrapping material is torn. „ Use only wrapping material of the designated quality. KRONE recommends one of the "KRONE excellent" products, see label on the machine with the number 27 016 326 *. Malfunction: The round bale is barrel-shaped. This causes the wrapping material to tear open in the middle.
Page 224 Possible cause Remedy „ Remove deposits from the cutting unit. The cutting unit is blunt. „ If required, have the cutting unit replaced by a KRONE service partner. The actuator for wrapping pro- „ Check the actuator for wrapping process.
Page 225 Disturbance: The twine is too far away from the edge of the round bale. Possible cause Remedy The twine limiters are not set „ Position the twine limiter at the tying start unit further to the correctly. outside, Page 185. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 226 Malfunction: The oil consumption is too high. Possible cause Remedy „ Have the main tube repaired or replaced changed by a The main tube is torn. KRONE service partner. „ Use recommended oil, The oil is too thin. Page 51. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 227 „ When an error message is displayed, eliminate the disturbance; see chapter "Error list" in the supplement to operating instructions "Error messages". „ If the fault cannot be rectified, contact KRONE service partner. KMC - 521202- 5 EQG000-034 If the machine malfunctions, the display shows an error message.
Page 228 There is an abnormal update rate. There is an abnormal rate of change. The error cause is unknown. There is an internal error. The values of the calibration are outside the value range. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 229 KMC A10 ECU PWR 7.5 A A1.F4 Reserve 15 A A1.F10 Reserve 7.5 A A1.F5 Reserve 15 A A1.F11 Reserve 7.5 A A1.F6 Reserve 15 A 19.6.3 Remedying sensor/actuator error Only a qualified specialist workshop is allowed to repair or to replace components. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 230 ü The guard (5) is dismounted. „ Loosen the counter nut (2). „ Rotate the piston rod (3) until the distance between the lock hook (4) and the roll pin (1) is X=5 mm. „ Tighten the counter nut (2). „ Mount the guard (5). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 231 „ Check whether the distance between lock hook latch (2) and stop (1) is X=2 ... 5 mm. To adjust the distance: „ Loosen the nuts (3). „ Move the stop (1) in the oblong holes (4) until the distance is X=2 ... 5 mm. „ Tighten the nuts (3). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 232 ü The machine has been shut down and secured, Page 29. „ Remove the 4 screw connections (1). „ Move the cover sheet (3) rearwards. „ Mount the 4 screw connections (1) in the boreholes (2). Fortima F 1250 Original operating instructions 150001157_04_en...
Page 233 1 Car jack contact point at rear left 2 Car jack contact point at rear right Example image of a tandem axle: RP000-869 1 Car jack contact point at rear left 2 Car jack contact point at rear right Fortima F 1250 Original operating instructions 150001157_04_en...
Page 234 All synthetic materials must be taken to a recycling centre for synthetic materials. Rubber • All rubber parts (e.g. hoses, tyres) must be taken to a rubber recycling centre. Electronic components • All electronic components must be taken to a disposal point for electronic scrap. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 235 Icon Actuator Explanation Pick-up Swinging the blades in and out (for "cutting unit" version) – Tailgate on the bale chamber For "hydraulic reversing device" version >>> 2 150 102 343 00 [} 236] Fortima F 1250 Original operating instructions 150001157_04_en...
Page 237 Airborne noise emission ........48 Ambient temperature .......... 49 Annex ............... 235 Applicable documents ........10 Automatic call of the Road travel screen ..144 Auxiliary assignment of a joystick..... 146 Auxiliary functions (AUX)........145 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 238 Central chain lubrication system terminal CCI 800 or CCI 1200 ......74 Cleaning the dosing units ....... 218 Connecting the KRONE DS 100 operation unit .. 65 Replacing the hose on the dosing unit ... 219 Connecting the KRONE ISOBUS terminal Central chain lubrication unit (CCI 800, CCI 1200) ...........
Page 239 Design DS 500 ..........130 Actuator test ........... 124 Design of display ..........134 Call road travel screen mode....113 Design of the KRONE machine application..134 Direction display ........114 Diagnostics for digital actuators ....... 171 Displaying the customer counter .... 120 Dimensions............
Page 240 KRONE ISOBUS terminal (CCI 800, CCI 1200) ................132 Hydraulic diagram ..........235 KRONE Medium operation panel ..... 104 KRONE operation unit DS 100 ......111 KRONE SmartConnect (Terminal)....163 KRONE Terminal DS 500 ......... 129 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 241 Malfunctions on the chain lubrication unit..226 Manual operation (twine tying, terminal)... 158 Manual operation of the tying system ....126 Means of representation ........11 Medium operation box Setting the number of net layers..... 184 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 242 Menu 13-2 "Total counter"........ 162 Menu 14 "ISOBUS" .......... 163 Observe the service record booklet ....192 Menu 14-5 "KRONE SmartConnect" ....163 Oils..............51 Menu 14-9 "Switching between terminals" ..164 Only perform work when the machine is at Menu 15 "Settings"...
Page 243 Protecting brake disc of the wrapping material Requirements for tractor – electrics....50 brake from corrosion ........209 Requirements for tractor - power ......50 Road safety............22 Road travel screen (automatic call-up) ..... 144 Running actuator test.......... 30 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 244 Setting sensor B62 “Tying 2 (active)” ....168 Switching the working lights on/off....116 Setting the baffle sheet on the crop press roller unit Switching warning beacon on/off ...... 116 ................87 Setting the baling pressure....... 118, 183 Fortima F 1250 Original operating instructions 150001157_04_en...
Page 245 Direction display sensitivity ....156 Error list ..........172 Validity ..............10 ISOBUS settings ........163 Varying functions to KRONE ISOBUS terminal 136 Manual operation (twine tying) ....158 Vehicle identification number......45 Number of net layers ......153 Number of twine layers ......154 Pre-signalling .........
Page 246 This page has been left blank deliberately. Fortima F 1250 Original operating instructions 150001157_04_en...
Page 247 Declaration of conformity Declaration of conformity EC Declaration of Conform- KRONE Agriculture SE Heinrich-Krone-Straße 10, D-48480 Spelle hereby declare, as manufacturer of the product named below, under our sole responsibility, that the Machine: Round baler Series: RP601-10 to which this declaration refers is in compliance with the following relevant provisions of: •...
Page 248 Maschinenfabrik Bernard Krone GmbH & Co. KG * Heinrich-Krone-Straße 10 D-48480 Spelle * Postfach 11 63 D-48478 Spelle ' +49 (0) 59 77 / 935-0 6 +49 (0) 59 77 / 935-339 ü www.landmaschinen.krone.de...

Krone Fortima F 1250 Original Operating Instructions

Quick Links

Need help?

Questions and answers

Related Manuals for Krone Fortima F 1250

Summary of Contents for Krone Fortima F 1250

Table of Contents
