SpectraLink IP-DECT Server 200 Interoperability Manual page 14

Spectralink IP-DECT Server Interoperability Guide—Dstny
Field
DECT device
IPEI (Optional)
Access code (Optional)
Configuration group (Optional)
User
Standby text (Optional)
Disabled (Optional)
DECT to DECT (Optional)
SIP
Username/Extension
Secondary username (Optional)
Domain (Optional)
722-0223-000 Rev: A
November 2023
Setting
If a specific handset is being subscribed for this
extension, enter the IPEI number of the actual handset.
(The IPEI number is readable from the label on the
product). If this is not the case this field can be left empty
and it will auto-fill when the handsets subscribe.
Note: A SIP REGISTER will not be sent before there is
an IPEI number present.
Administrators can define a system wide or individual
access code as extra wireless security during the
subscription process.
Note: Some third-party phones may need an Access
code to register to the Spectralink IPDECT/DECT/Virtual
IP-DECT Server.
If using handset configuration, enter the Group ID of the
Configuration Group.
Standby text is a fixed label shown in the top left part of
the screen on the DECT handset when in idle state.
E.g.: Ext 101, John Smith
Note: Disallowed characters: <>\"
Note: This feature is only available if Spectralink DECT
handsets are being used. If third-party DECT handsets
are being subscribed, this feature is not supported.
If enabled, the user is disabled.
Ensure that this is not enabled.
Note: A disabled user cannot make calls from the
handset.
If enabled, the user will only be able to call, and be called
from, other users that are subscribed to the same IP-
DECT server; the user cannot communicate externally.
Enter the Dstny Username provided with the SIP
Settings for the extension.
Note: Allowed characters: a-z, A-Z, 0-9, -_.!~*'()&=+$,;?/
If defined, the Secondary username can be used to
make voice calls in case the connection to the SIP PBX
is lost. The Secondary username must be globally
unique.
Note: Allowed characters: a-z, A-Z, 0-9, -_.!~*'()&=+$,;?/
In some PBXs there is a mapping between username
and number (e.g. Username = hz2539jk, Number =
1234). If the connection to the SIP PBX is lost, then it is
possible to make the mapping internally by defining a
Secondary username.
Enter the domain part of a SIP URI.
Note: Allowed characters: a-z, A-Z, 0-9, .-
14
