Part 1 – Introduction
To pass through a thin cable or more than two cables,
it is advised to finish it using silicon to make sure
waterproofed perfectly. (Silicon finishing part — refer
to the bottom image.)
4
Assemble the cable rubber to the bottom cover.
5
Attach the enclosed desiccant in the bottom to
prevent moisture.
Desiccant
14
6
Use the screws, anchor provided with the camera to
secure the install body on a wall or a ceiling.
Use the provided guide pattern to check the
distance between the screws.
7
Connect external devices, the network cable, and
the power adapter.
8
Adjust the angle. For more information, refer to the
Angle Adjustment.
