Dual assignment instructions (long button press)
The AX-GMLAN11-SWC has the capability to assign (2) functions to a single
button, except Volume-Up and Volume-Down. Follow the steps below to
program the button(s) to your liking.
Note: Seek-Up and Seek-Down come pre-programmed as Preset-Up and
Preset-Down for a long button press.
1. Turn on the ignition but do not start the vehicle.
2. Press and hold down the steering wheel control button that you want to assign
a long press function to for about (10) seconds, or until the L.E.D. flashes
rapidly. At this point release the button; the L.E.D. will then go solid.
3. Press and release the Volume-Up button the number of times corresponding
to the new button number selected. Refer to the Dual Assignment Legend. The
L.E.D. will flash rapidly while the Volume-Up button is being pressed, and then
go back to a solid L.E.D. once released. Go to the next step once the Volume-Up
button has been pressed the desired number of times.
Caution: If more than (10) seconds elapses between pressing the Volume-Up
button, this procedure will abort, and the L.E.D. will go out.
4. To store the long press button in memory, press the button that you assigned a
long press button to (the button held down in Step 2). The L.E.D. will now go off
indicating the new information has been stored.
Note: These steps must be repeated for each button you would like to assign a
dual purpose feature to. To reset a button back to its default state, repeat Step
1, and then press the Volume-Down button. The L.E.D. will go off, and the long
press mapping for that button will be erased.
Steering wheel control extra settings (Cont)
®
AX-GMLAN11-SWC
Dual assignment legend
1. Not allowed
2. Not allowed
3. Seek-Up/Next
4. Seek-Down/
Prev
* Not applicable in this application
Resetting the AX-GMLAN11-SWC
1. With the radio on, turn the potentiometer:
Note: Before proceeding, remember the position the potentiometer is at.
Left......hold for 3 seconds
Right.....hold for 3 seconds
Left......hold for 3 seconds
Back to the initial position
2. The L.E.D. inside the interface will turn off for a couple seconds, then flash
fast, then flash slowly (up to (16) times, indicating which radio is connected
to the interface), and then turn off. Pay close attention as to how many slow
flashes there are. This will help in troubleshooting, if need be. Refer to the
L.E.D. feedback section for more information.
3. Within a few seconds the L.E.D. will turn on, and the radio will turn off.
4. Within a minute the L.E.D. will turn off, and the radio will come back on,
indicating the resetting and initialization process was successful.
9
5. Mode/Source
10. Band
6. ATT/Mute
11. Play/Enter
7. Preset-Up
12. PTT
8. Preset-Down
13. On-Hook
9. Power
14. Off-Hook
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
