Axxess AX-GMLAN29-SWC Installation Manual

Gm data interface with swc2006-up
Hide thumbs

Advertisement

Table of Contents

GM Data Interface with SWC
*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
INTERFACE FEATURES
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains chimes
• Retains audio controls on the steering wheel
• Retains OnStar / OE Bluetooth
• Adjustable OnStar level
• Retains the factory AUX-IN jack
INTERFACE COMPONENTS
• AX-GMLAN29-SWC interface • AX-GMLAN29-SWC harness
• 16-pin harness with stripped leads • 4-pin to 4-pin resistor pad harness
• Female 3.5mm connector with stripped leads
• Backup camera harness • RSE harness • Antenna adapter
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape • Connectors (example: butt-connectors, bell caps, etc.) • Small flat-blade screwdriver
APPLICATIONS
See inside front cover
AxxessInterfaces.com
2006-up*
• Retains the factory backup camera
• Retains RSE (rear seat entertainment)
• Retains SAT (satellite radio)
• Can be used in non-amplified, or analog/digital amplified models
• Retains balance and fade (excluding digital amplified models)
• Includes an antenna adapter
• Micro "B" USB updatable
© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
AX-GMLAN29-SWC
I N S TA L L AT I O N I N S T R U C T I O N S

TABLE OF CONTENTS

Connections to be made ................................... 3-6
- For models without an amplifier .......................3
Installing the AX-GMLAN29-SWC ..........................6
Programming the AX-GMLAN29-SWC ..................7
Adjusting the AX-GMLAN29-SWC ..........................7
Extra features .........................................................8
Steering wheel control settings .......................9-11
- L.E.D. feedback ....................................................9
- Changing radio type ...........................................9
Troubleshooting ....................................................12
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
REV. 1/5/18 INSTAX-GMLAN29-SWC
