Radio legend
1. Eclipse (Type 1)
6. Pioneer/Jensen
2. Kenwood
7. Alpine
3. Clarion (Type 1)
8. Visteon
4. Sony/Dual
9. Valor
5. JVC
10. Clarion (Type 2)
Remapping the steering wheel control buttons
Let's say you have AX-GMLAN11-SWC initialized and programmed, and you want to
change the button assignment for the steering wheel control buttons. For example, you
would like Seek-Up to become Mute. Follow the steps below to remap the steering
wheel control buttons:
1. Ensure the AX-GMLAN11-SWC is visible so you can see the L.E.D. flashes to
confirm button recognition.
Tip: Turning the radio off is recommended.
2. Within the first twenty seconds of turning the ignition on, press and hold the
Volume-Up button on the steering wheel until the L.E.D. goes solid.
3. Release the Volume-Up button, the L.E.D. will then go out; The Volume-Up
button has now been programmed.
4. Follow the list in the Button Assignment Legend to reference the order in which
the steering wheel control buttons need to be programmed.
Steering wheel control extra settings (Cont)
11. Metra OE
12. Eclipse (Type 2)
13. LG
14. Parrot
15. XITE
16. Philips
®
AX-GMLAN11-SWC
Note: If the next function on the list is not on the steering wheel, press the
Volume-Up button for (1) second until the L.E.D. comes on, and then release the
Volume-Up button. This will tell the AX-GMLAN11-SWC that this function is not
available and it will move on to the next function.
5. To complete the remapping process, press and hold the Volume-Up button on
the steering wheel until the L.E.D. in the AX-GMLAN11-SWC goes out.
Button assignment legend
1. Volume-Up
2. Volume-Down
3. Seek-Up/Next
4. Seek-Down/Prev
5. Source/Mode
6. Mute
7. Preset-Up
8. Preset-Down
9. Power
* Not applicable in this application
Note: Not all radios will have all of these commands. Please refer to the manual
provided with the radio, or contact the radio manufacturer for specific commands
recognized by that particular radio.
8
10. Band
11. Play/Enter
12. PTT (Push to Talk) *
13. On-Hook *
14. Off-Hook *
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
