Attention:
The Axxess Updater App can also be used to program the following (3)
sub-sections as well, pending that the interface has been initialized and programmed.

Changing radio type

If the L.E.D. flashes do not match the radio you have connected, you must
manually program the AX-GMCL2-SWC to tell it what radio it is connected to.
1) After (3) seconds of turning the key on, press and hold the Volume-Down button
on the steering wheel until the L.E.D. in the AX-GMCL2-SWC goes solid.
2) Release the Volume-Down button; the L.E.D. will go out indicating we are now
in Changing Radio Type mode.
3) Refer to the Radio Legend to know which radio number you would like to have
programmed.
4) Press and hold the Volume-Up button until the L.E.D. goes solid, and then
release. Repeat this step for the desired radio number you have selected.
5) Once the desired radio number has been selected, press and hold the Volume-
Down button on the steering wheel until the L.E.D. goes solid. The L.E.D. will
remain on for about (3) seconds while it stores the new radio information.
6) Once the L.E.D. goes off, the Changing Radio Type mode will then end. You can
now test the steering control wheel controls.
Note: If at any time the user fails to press any button for a period longer than
(10) seconds, this process will abort.
Steering wheel control extra settings (Cont)
®
AX-GMCL2-SWC
Radio legend
1. Eclipse (Type 1)
2. Kenwood
3. Clarion (Type 1)
4. Sony/Dual
5. JVC

Remapping the steering wheel control buttons

Let's say you have AX-GMCL2-SWC initialized and you want to change the button
assignment for the steering wheel control buttons. For example, you would like Seek-Up
to become Mute. Follow the steps below to remap the steering wheel control buttons
1) Ensure the AX-GMCL2-SWC is visible so you can see the L.E.D. flashes to
confirm button recognition.
Tip: Turning the radio off is recommended.
2) Within the first twenty seconds of turning the ignition on, press and hold the
Volume-Up button on the steering wheel until the L.E.D. goes solid.
3) Release the Volume-Up button, the L.E.D. will then go out; The Volume-Up
button has now been programmed.
4) Follow the list in the Button Assignment Legend to reference the order in which
the steering wheel control buttons need to be programmed.
10
6. Pioneer/Jensen 11. Metra OE
12. Eclipse (Type 2)
7. Alpine
13. LG
8. Visteon
14. Parrot
9. Valor
15. XITE
10. Clarion (Type 2) 16. Philips
Continued on the next page
:
