7 Bill of material, layout and schematic

Table 5 BOM
Designator
C1, C5, C9, C10, C16, C21
C2, C46
C3, C15
C4, C14
C6, C12, CBS1, CBS2
C7, C11, C13
C8, CV
C55
CC1
CIVCC
CSST
DBS1, DBS2
DZ1, DZ3
IC1
J_DIMM, J_PWMI
L1
L2, L3
LED_EF1
LED_IVCC
Q1, Q2
Q3, Q4
Q5
Q6
REN3
R2
R3
R5
R6, R8
R7, R11
R9
R10
R12, RVH
R14
R1, R4,
R16
R17
User Manual
2021-04-13
Value
10uF
470nF
470pF
10nF
100nF
4.7uF
220uF
1uF
22nF
10uF
22nF
BAT46WJ,115
10V
TLD5191ES
TSM-102-01-S-SV
10uH
1.8uH
Red
Blue
IPZ40N04S5L-7R4
IAUZ30N06S5L140
BSZ086P03NS3 G
BSO615CGXUMA1
10kΩ
44.2kΩ
2.2kΩ
910Ω
4.7Ω
10kΩ
22kΩ
470Ω
47kΩ
5.6kΩ
5.6kΩ
150Ω
1.5kΩ
11 of 14
Footprint
C1210
C1206
C0603
C0603
C0603
C1210
CAPAE830X1050N
C0805
C0805
C0805
C0603
SOD323F
SOD323
TSDSO24
CON-M-SMD-TSM-102-01-S-SV
Coilcraft XAL1010
Coilcraft XAL6030
LED 0805
LED 0805
PG-TSDSON-8-32
PG-TSDSON-8-32
PG-TSDSON-8
PG-DSO-8
R0603
R0805
R0805
R0805
R0603
R0805
R0805
R0805
R0805
R0805
R0603
R0603
R0603
Quantity
6
2
2
2
4
3
2
1
1
1
1
2
2
1
2
1
2
1
1
2
2
1
1
1
1
1
1
2
2
1
1
2
1
2
1
1
Rev.1.00
