2.1.5 J5, LCD Interface
Connector, J5, is used to interface to an LCD character display. The signals on the pins of
this connector are shown below.
2.1.6 J6, Micro SD Connector
The Micro SD connector, J6, is used to interface the C5515 processor to a Micro SD card.
The signals on the pins of this connector are shown below.
Table 8: J6, Micro SD Connector
2-6
Table 7: J5, LCD Interface
Pin # Signal Name
1 C2P
2 C2N
3 C1P
4 C1N
5 VBAT
6 VBREF
7 GND
8 VCC_3V3
9 TARGET_PWR_GOOD
10 I2C_SCL
11 I2C_SDA/
12 IREF
13 VCOMH
14 V13
Pin # Signal Name
1 DAT2
2 DAT3
3 CMD
4 VDD
5 CLK
6 VSS
7 DAT0
8 DAT1
9 INSERT
10 INSERT_COM
