2.1 Connector Index
The C5515 eZdsp USB Stick has nine (9) connectors which provide the user access to
various signals on the C5515 Stick. These connectors are shown in the table below.
Table 1: C5515 eZdsp USB Stick Connectors
Connector # Pins
J1 4
J2 6
J3 2
J4 2
J5 14
J6 8
P1 20
P2 20
P4 30 x 2
The following manufacturer and parts numbers can be used to interface to the connectors
on the C5515 eZdsp:
Table 2: C5515 eZdsp Mating Connectors
Connector Manufacturer
J2 PC or laptop
J3
J4
P4
2.1.1 J1, C5515 USB Connector
The USB connector, J1, is attached the C5515 processor for use by C5515 software
applications. The signals on the pins of this connector are shown below.
Table 3: J1, C5515 USB Connector
Schematic
Function
C5515 USB
Emulation USB
Audio In
Audio Out
LCD Interface
Micro SD Interface
Bluetooth Board Interface
Bluetooth Board Interface
Expansion
Part #
CUI Inc CUI SP-3501, Digi-Key CP-3502-ND
CUI Inc CUI SP-3501, Digi-Key CP-3502-ND
Samtec Samtec MEC1-130-02-S-D-A,
Digi-Key SAM8118-ND
Pin # Signal Name
1 USBVDD
2 D-
3 D+
4 ID / NC
5 USBVSS/GND
6-9 GND
Spectrum Digital, Inc
Board
Page Side
3 Top
13 Top
10 Top
10 Top
11 Top
8 Top
7 Top
7 Top
12 Top/Bottom
2-3
