TMS320C5515 eZdsp Stick Quick Start Guide
C5515 eZdsp USB Stick
1.0 SYSTEM REQUIREMENTS
To operate the Spectrum Digital XDS100 JTAG Emulator with your system it needs to meet
the following requirements:
• 2 GB of free hard disk space
TM
• Microsoft Windows
• Min 1 GB ram, 2 GB recommended
• Min 1.5 GHz., dual core recommended
• Color Display
• Internet access
• USB port
• DVD reader
2.0 WHAT'S INCLUDED
The TMS320C5515 eZdsp USB Stick kit includes:
• TMS320C5515 eZdsp USB Stick
• USB extension cable
• TMS320C5515 eZdsp USB Stick DVD with Code Composer Studio (CCS)
• This Quick Start Guide
USB Cable
DVD
Quick Start Guide
XP/Vista
512846-0001 Rev A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spectrum Digital TMS320C5515 eZdsp
Summary of Contents for Spectrum Digital TMS320C5515 eZdsp
- Page 1 USB Cable Quick Start Guide C5515 eZdsp USB Stick 1.0 SYSTEM REQUIREMENTS To operate the Spectrum Digital XDS100 JTAG Emulator with your system it needs to meet the following requirements: • 2 GB of free hard disk space • Microsoft Windows XP/Vista •...
- Page 2 3.0 C5515 eZdsp USB Stick Installation Note: Install ALL software prior to connecting the C5515 eZdsp USB Stick to the computer ! Note: The user MUST be logged onto windows with “Administrative Rights” and any anti-virus software must be disabled during installations. Please contact your system administrator if help is needed in this area.
- Page 3 License Screen 4.0 CCS Configuration Instructions 1. Launch CCS v4 from the shortcut on the desktop. (This was created when CCS v4 was installed). 2. The CCS v4 window will appear. Click the “Target” menu, then select “New Target Configuration File”. 3.
- Page 4 Configuration Screen 5. Click the “Save” button to save the configuration. 6. Click the “View” menu and select “Target Configurations” to expose the configuration(s) that have been built or imported. A new tab labeled “Target Configurations” will become available in the CCS window. 7.
-
Page 5: Support Resources
3. Code Composer Studio support is available via a forum at: http://community.ti.com/forums/138.aspx 4. More information about other Spectrum Digital emulators can be found at: www.spectrumdigital.com 5. Additional development support is available via the online community: www.ti.com/ezdsp5000 512846-0001 Rev A... -
Page 6: Evaluation Board/Kit Important Notice
EVALUATION BOARD/KIT IMPORTANT NOTICE Spectrum Digital, Inc. (SDI) provides the enclosed product(s) under the following conditions: This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by SDI to be a finished end-product fit for general consumer use. - Page 7 Spectrum Digital, Inc. P.O. Box 1559 Sugar Land, TX. 77487-1559 “eZdsp” is a trademark of Spectrum Digital, Inc. FCC Warning This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by SDI to be a finished end-product fit for general consumer use.
- Page 8 SPECTRUM DIGITAL, INC 12502 Exchange Dr., Suite 440, Stafford, TX. 77477 T: 281.494.4505 F: 281.494.5310 e-mail: sales@spectrumdigital.com website: www.spectrumdigital.com © Copyright 2010 Spectrum Digital, Inc. 512846-0001 Rev A...
