Spectrum Digital, Inc
2.0 Board Layout
The C5515 eZdsp USB Stick is a 2.85 x 2.65 inch six (6) layer printed circuit board which
is powered off the USB bus of personal computer or laptop computer. This means this
board does not require an external power supply.
JP1
J2
DS2-DS5
SW2
SW1
Figure 2-1, C5515 eZdsp USB Stick (top)
J6
Figure 2-2, C5515 eZdsp USB Stick (bottom)
2-2
J1
DS1 P1
TMS320C5515 eZdsp USB Stick Technical Reference
P2 P4
J3
J4
J5
