DEMO MANUAL DC2787A
PARTS LIST
ITEM QTY REFERENCE
25 4 R2, R36, R53, R56
26 43 R5, R10-R12, R14,
R20, R24, R32, R33,
R35, R40, R41, R45,
R47, R50, R51, R76,
R226-R231, R240, R241,
R246, R252, R254-R256,
R258, R264, R266-R268,
R270, R271, R273-R276,
R278, R279
27 1 R6
28 1 R8
29 9 R9, R13, R22, R28, R49,
R60, R62, R272, R277
30 4 R15, R37, R52, R57
31 4 R16, R48, R64, R68
32 4 R17, R43, R70, R71
33 1 R18
34 4 R23, R75, R244, R259
35 4 R25, R66, R245, R248
36 1 R26
37 1 R27
38 1 R29
39 2 R30, R247
40 1 SW1
41 4 U1-U4
42 1 U7
Additional Demo Board Circuit Components
1 0 C16, C46, C48, C51,
C160, C171, C172,
C290-C295
2 0 Q1A, Q1A1, Q11A,
Q11A1, Q22, Q22A,
Q22A1-Q22A3, Q25, Q26,
Q29, Q30, Q33, Q34, Q37
3 0 Q23, Q24, Q27, Q28,
Q31, Q32, Q35, Q36
4 0 R3, R31, R34, R44, R46,
R65, R74, R234, R235,
R250, R251, R253,
R262, R263, R265
5 0 RN1-RN4
8
PART DESCRIPTION
RES.,AEC-Q200,1 OHM,5%,1/10W,0603
RES.,0 OHM,1/10W,0603
RES.,AEC-Q200,1M OHM,1%,1/8W,0805
RES.,34k OHMS,1%,1/10W,0603
RES.,AEC-Q200,10k OHMS,1%,1/10W,0603
RES.,100k OHMS,1%,1/10W,0603
RES.,53.6k OHMS,1%,1/10W,0603,AEC-Q200
RES.,AEC-Q200,6.81k OHMS,1%,1/8W,0805
RES.,3.74k OHMS,1%,1/10W,0603
RES.,AEC-Q200,60.4k OHMS,1%,1/10W,0603
RES.,AEC-Q200,4.32k OHMS,1%,1/10W,0603
RES.,182k OHMS,1%,1/10W,0603,AEC-Q200
RES.,20k OHMS,5%,1/10W,0603,AEC-Q200
RES.,80.6k OHMS,1%,1/10W,0603
RES.,0.2 OHM,1%,1/2W,2010,SENSE, AEC-Q200
SWITCH,SLIDE,DPDT,0.3A,6VDC,PTH
IC, Hybrid Step-Down Synchronous Controller QFN-32 ANALOG DEVICES, LTC7821EUH#PBF
IC, SYNCHRONOUS STEP-DOWN CONVERTER
CAP ., OPTION, 0603
XSTR., OPTION, MOSFET N-CH, PPAK SO-8
XSTR., OPTION, MOSFET N-CH, PG-TDSON-8
RES., OPTION, 0603
THERMISTOR, OPTION, 0603
MANUFACTURER/PART NUMBER
VISHAY, CRCW06031R00JNEA
VISHAY, CRCW06030000Z0EA
PANASONIC, ERJ6ENF1004V
NIC, NRC06F3402T
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060353K6FKEA
VISHAY, CRCW08056K81FKEA
PANASONIC, ERJ3EKF3741V
VISHAY, CRCW060360K4FKEA
VISHAY, CRCW06034K32FKEA
PANASONIC, ERJ3EKF1823V
NIC, NRC06J203TRF
VISHAY, CRCW060380K6FKEA
VISHAY, WSL2010R2000FEA
C&K, JS202011CQN
ANALOG DEVICES, LTC3630AEMSE#PBF
