DEMO MANUAL DC2787A
QUICK START PROCEDURE
Figure 7. Thermal performance V
Figure 8. Thermal performance V
6
V (20MHz BW)
OUT
100mV/DIV
50A-75A-50A LOAD
20A/DIV
50 /DIV
Figure 6. Load Step at V
= 48V, V
IN
= 48V, V
IN
2787A F06
= 48V, V = 12V
IN OUT
= 12V, I = 100A T = 23˚C, No Airflow
OUT OUT A
= 12V, I = 100A = 23˚C, 200LFM Airflow
OUT OUT A
Rev. 0
