PARTS LIST
ITEM QTY REFERENCE
Hardware
1 14 E1-E6, E8-E15
2 4 J1-J4
3 2 J5, J6
4 4 J1-J4
5 8 J1-J4
6 1 JP2
7 4 J1-J4
8 6 MH1-MH6
9 1 XJP2
PART DESCRIPTION
TEST POINT,TURRET,0.094",MTG. HOLE
STUD, FASTENER, #10-32
CONN.,RF , BNC,RCPT JACK,5-PIN,STR, THT,50 Ohms AMPHENOL RF , 112404
RING, LUG, CRIMP ,#10,NON-
INSULATED,SOLDERLESS TERMINALS
NUT,HEX,#10-32,BRASS
CONN.,HDR,MALE,1x3,2mm,STR, THT,NO SUBS.
ALLOWED
WASHER,#10,LOCK,EXT,TIN FINISH
STANDOFF ,NYLON,SNAP-ON,0.625"
CONN.,SHUNT,FEMALE,2 POS,2mm
DEMO MANUAL DC2787A
MANUFACTURER/PART NUMBER
MILL-MAX, 2501-2-00-80-00-00-07-0
PENNENGINEERING, KFH-032-10ET
KEYSTONE, 8205
PENCOM, NU1132
Wurth Elektronik, 62000311121
PENCOM, WA4526
KEYSTONE, 8834
Wurth Elektronik, 60800213421
