The TPM 2.0 (Trusted Platform Module 2.0) module is a modularized design applying to the
IMB540 and provides enhanced hardware security for the computer. In this appendix you will
learn how to install the TPM 2.0 module into the IMB540. Please read and follow the instructions
below carefully.
Insert TPM module into the SPI interface of motherboard, as illustrated below.
1.
AX93515 TPM
module
There are two ways to confirm whether the TPM Module is installed successfully or not:
2.
a. Enter the BIOS setup menu and go to Trusted Computing. On the first line it will show
"TPM2.0 Device Found".
TPM Module Installation
TPM Module Installation
TPM SPI interface
(In the Advance menu, go to Trusted Computing)
IMB540 User's manual
Appendix A
TPM module Put On
