Peripherals

The Peripherals page varies based on the
selected Network Command mode (See
Network -2 Command Mode).
Photocells
PE1/PE2 Enable or disable debounce on PE1. Used with mechanical switch print triggers. Typical 10-50. If value
Debounce necessary over 200, likely Relay needs replacement.
PE1/PE2 Changes the state that the Photoeye sends a print trigger
Trigger
Rise
Fall
PE 1 Always ON
Option
PE 1 Setup Choose which counters should or should not increment when PE 1 is triggered.
BestCode Next Series 8 Technical Manual
BestCode Command Mode
Print begins when the Photoeye state is up
Print begins when the Photoeye state is down
