Inspecting the Drop Breakup
1. Set the starting values for Modulation,
Pressure, and Charge.
3. Run until the Viscosity is within range of
the Target Viscosity. (4.0-5.0cP)
4. Inspect the breakup to visually determine
if the breakup is acceptable.
5. If necessary, adjust the modulation
voltage until Good Breakup is achieved.
Calibrating the Modulation
1. After visual inspection, set the
modulation to the voltage and
frequency with the best breakup.
2. Make a test print using the default
message.
3. Reduce the voltage by 10V and
print again.
4. Repeat until a bad print in achieved.
5. Set the modulation point to 30V
above the lowest acceptable print.
BestCode Next Series 8 Technical Manual
See Calibration Starting Values chart
See Drop Breakup Appearance
October 2022
here
chart on Previous Page.
Acceptable
30V over
20V over
Lowest
