INSTALLATION OF VEHICLE UPPER ANCHOR POINT
Adjustable top
tether strap.
The shaded areas of this diagram illustrate the possible locations of the upper anchorage
point (car anchor fitting). Within each shaded area is an upper anchorage point showing the
correct way to install the fitting. Ensure the upper anchorage point is aligned as illustrated
unless stated otherwise in the vehicle owner's handbook.
Extension Straps
Length 300mm (Use Britax Safe-n-Sound
Length 600mm (Use Britax Safe-n-Sound
Available from all major child restraint retailers.
45°
part 0035 or 0291).
®
part 0036 or 0290).
®
Measure distance from
restraint upper anchorage
attachment clip to the car
anchor fitting.
Instructions for Installation & Use
83
