POINTERS
4.3.1

Softouch Pointer Technical Information

Expected Product Life
When used and stored according to the provided instructions, Softouch has a life expectancy of
at least five years. Depending on the used battery type and frequency of use, the Softouch
pointer can be used for at least one year until the battery must be replaced.
Modification
Warning
Modification of the device is not allowed.
Battery Safety
Warning
Do not use Softouch if it is leaking battery acid. In case of failure, contact Brainlab
Support.
Remove the battery when the pointer is not used over more than six months to prevent the
battery from leaking.
MR Conditional
Dimensions and Weight
Dimension
Height
Length
Width
Weight
Instrument User Guide Rev. 2.6 Cranial/ENT Optical Tracking
Non-clinical testing has demonstrated the Softouch is MR Conditional. It
can be safely used in the MR environment under the following conditions:
• MR environment with 1.5 or 3.0 Tesla scanner.
• To prevent autonomous acceleration, do not move Softouch across the
5 Gauss (0.5 mTesla) line.
• Softouch may only be used in an MR environment with a 5 Gauss (0.5
mTesla) line clearly indicated on the floor surrounding the MR scanner.
• Do not use or activate Softouch during an MRI examination.
MR-induced malfunction testing with device exposure to the clinical level
static field B , the time-varying gradient field (dB/dt) and the RF field (B1,
0
E) in 1.5 Tesla and 3.0 Tesla MR systems passed all tests according to
Brainlab testing procedure.
After use, always store Softouch in the provided storage case outside the
MR environment.
Value
2.9 cm
27.5 cm
3.6 cm
53 g
