4. Design and function
4.6

Sensor connection to model CPU6000-S pressure balance sensor box

EN
Piston temperature sensor, built-in version
Lemo connector
Float position sensor, built-in version
Binder connector
22
2
3
Lemo connector Lemo socket
Sub-D connector
WIKA operating instructions CalibratorUnit, model CPU6000
Pt100 to measure the piston
1
temperature
Ultrasonic sensor for measuring
2
the floating position
3
Built-in or cable version
1
Sub-D
socket
Pt100 probe
Floating position
sensor
