2. Application

For design of a sequence control using pneumatic pressure, delayed operation is necessary as one
of the basic functions. The VR2110 Time Delay Valve is used to delay the operation in a general
industrial pneumatic circuit.

3. Specifications

Fluid
Supply pressure
Input signal pressure
Delayed time
Repeated accuracy *
Ambient and operating air
temperature
Flow rate
characteristics
Port size
ON timing
Output method
Reset
Weight
*) The dispersion is shown excluding the first actuation when actuated 4 times continuously.

4. How to Order

C(dm 3 /(s・bar))
b
VR2110 – 01
Compressed air
0 to 1.0 MPa
0.25 to 0.8 MPa
0.5 to 60 s
+/- 10% F.S. (Representative valve)
o
-5 to 60 C (No freezing)
0.6 [1(P) →2(A)] , 0.5 [2(A)→3(R)]
0.2 [1(P) →2(A)] , 0.15 [2(A)→3(R)]
Rc, NPT, G1/8
ON upon the set delay
Normal close
Resets by exhausting the input signal pressure
480g
Port size
01 Rc1/8
N01 NPT1/8
F01 G1/8
