HEADER PINOUT

The schematic for the ADPA1105-EVALZ is shown in Figure 6.
The ADPA1105-EVALZ contains four headers, P1, P2, P3, and
P4. Table 1 describes the pinout of these headers.
Table 1. P1 to P4 Header Connections on the ADPA1105-EVALZ
Header Header Pin Number
P1 1, 3
2
4
P2 1, 3
2
4
P3 1, 3, 5, 7, 9, 10, 11, 12, 13, 14, 15, 17, 19, 21, 22, 23, 24
2, 16, 18, 20
4, 6
8
P4 1, 2, 3, 4, 5, 7, 9, 11, 12, 13, 14, 15, 16, 17, 19, 21, 23
18, 20, 22
6, 8
10
24
Rev. 0 | Page 4 of 13
ADPA1105-EVALZ
Header Pin Name
GND
DET2_OUT
DET2_BIAS
GND
DET1_OUT
DET1_BIAS
GND
Not connected
VDD2
VDD1
GND
Not connected
VGG1
VGG2
DET2_BIAS
