Elcometer 345
Coating Thickness Gauge
Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 345 and is the answer not in the manual?

Questions and answers

Related Manuals for Elcometer 345

Summary of Contents for Elcometer 345

  • Page 1 Elcometer 345 Coating Thickness Gauge Operating Instructions...
  • Page 2 (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of Elcometer Limited. A copy of this Instruction Manual is available for download on our Website via www.elcometer.com. Doc No. TMA-0431 Issue 03...

  • Page 3: Table Of Contents

    CONTENTS Section Page About your gauge ............. . . 5 1.1 Gauge features .
  • Page 4 Calibration adjustment ............16 5.1 Calibration Adjustment Error .

  • Page 5: About Your Gauge

    Our products cover all aspects of coating inspection, from development through application to post application inspection. The Elcometer 345 Coating Thickness Gauge is a world beating product. With the purchase of this gauge you now have access to the worldwide service and support network of Elcometer. For more information visit our website: www.elcometer.com...

  • Page 6: Gauge Features

    MCS.215 (82/84), IMO MSC.244(83), ISO 1461, ISO 2063, IS0 2808-7C, ISO 2808-12, ISO 19840, NF T30-124, SSPC- PA2 (2004). For IMO, PSPC , the thickness coating, should be measured and recorded. Your Elcometer 345 can be used for this. 1.3 WHAT THE BOX CONTAINS •...
  • Page 7 Consult your local Environmental Authority for further guidance. To maximise the benefits of your new Elcometer 345 Coating Thickness Gauge please take some time to read these Operating Instructions. Do not hesitate to contact Elcometer or your Elcometer supplier if you have any...

  • Page 8: Getting Started

    Note: Before you use your gauge for the first time, remove the paper strip from the battery compartment. 2.1 FITTING BATTERIES The Elcometer 345 may be used with dry cell batteries or rechargeable batteries. 2 x LR03 (AAA) alkaline batteries are supplied with the gauge. To fit or replace batteries: 1.

  • Page 9: Fitting The Harness

    2.4 CONNECTING THE SEPARATE PROBE The Elcometer 345 separate probe gauge has a 4-pin socket at the base of the gauge. Line up the 2 red marks when inserting the plug.

  • Page 10: Switching The Gauge On/Off

    2.5 SWITCHING THE GAUGE ON/OFF To switch on, press Gauges with an integral probe will switch on automatically by placing the probe against a hard surface. To switch off, press and hold until OFF is displayed. The gauge will switch off automatically after one minute of inactivity. 2.6 DISPLAY The display will show the measurement value.

  • Page 11: Backlight Operation

    2.9 BACKLIGHT OPERATION: Elcometer 345 gauges have a backlit display. The backlight is designed for low light operations and can be turned on and off via the keypad. Turning the backlight off will save battery power. To toggle the backlight on/off, press and release .

  • Page 12: Quick Operation Guide

    3 QUICK OPERATION GUIDE separate gauges Switch on 4 seconds Switch off >>>> >>>> Metric <=> >>>> µm or mm <=> mil English bare metal on foil Calibration >4 seconds adjustment for 4 seconds Smooth >>>> >>>> >>>> >>>> to set. Substrates adjust to foil...
  • Page 13 on thin foil >4 seconds >>>> >>>> >>>> >>>> adjust to foil Calibration adjustment for Rough and on thick foil Special >4 seconds Substrates >>>> to set >>>> >>>> >>>> adjust to foil >>>> to set. >>>> >>>> >>>> keep pressing until first statistic Set User List for Statistical...
  • Page 14 To Turn >>>> >>>> >>>> >>>> until Statistical Data ‘Off’ >>>> >>>> Stats off Align IR’s >>>> >>>> Print Data Output to continue measurements bare metal To Reset >>>> to adjust to 10 µm (0.5 mil) [or 100 µm (4.0 mil) for scales F2 Factory Calibration and F3] >>>>...

  • Page 15: Taking A Measurement

    4 TAKING A MEASUREMENT Before starting to take measurements it is good practice to check the performance of the gauge using the calibration adjustment procedure - see “Calibration adjustment” on page 16. 1. Hold the gauge with the probe pressed Integral firmly against...

  • Page 16: Calibration Adjustment

    5 CALIBRATION ADJUSTMENT The Elcometer 345 should be adjusted before use, or at least checked to ensure that the calibration adjustment is correct for the conditions of use. Calibration adjustment should be carried out with the appropriate probe, on the same type of metal, the same curvature and similar surface finish as that of the item to be measured.

  • Page 17: Calibration Adjustment For Smooth Surfaces

    5.2 CALIBRATION ADJUSTMENT FOR SMOOTH SURFACES Use this calibration adjustment procedure for measurements on smooth, flat surfaces. Note: The key-lock feature requires the keys used to access these routines to be pressed for 4 seconds before any response is made. This is to prevent accidental operation. 1.

  • Page 18: Special Calibration Adjustment

    6. Confirm that the gauge reads correctly at zero and at the calibration foil value. If required the calibration adjustment can be repeated to ensure its accuracy. To re-adjust the gauge, repeat all the steps in Section 5.2. Note: As well as calibration foils, certified coated standards are available - see “Spares and accessories” on page 32.

  • Page 19: The Correction Value Method

    4. Press and hold for more than 5 seconds to adjust this average to the foil value. 5. Press to accept the low calibration or wait 7 seconds to accept the calibration automatically. The display will now show CH1 (= Calibrate High). 6.

  • Page 20: To Recall The Factory Calibration

    The correction value is determined according to the roughness of the surface per ISO 8501, the Surface Roughness Comparator Elcometer 125. If the roughness of the surface under the coating is unknown a default correction value of 25 µm (1.0 mil) is subtracted from each reading. For further details see EN19840 'Paints and Varnishes - Corrosion protection of steel structures by protective paint systems - Measurement and acceptance criteria of the dry film thickness”.

  • Page 21: Statistical Summary

    6.1 STATISTICS The statistics display on the Elcometer 345 shows a preset combination of the five statistical functions which may be shown on the display in any user defined order by pressing one key. The feature is switched on by selecting at least one statistical value to be displayed - see “Setting The User List For Statistical Values”...

  • Page 22: Clearing Statistical Data

    is pressed the gauge displays the next statistical value on the user list for a minimum of 3 seconds. is pressed the gauge displays the previous statistical value on the user list for a minimum of 3 seconds. • To display the rest of the list of values must be pressed while the current value is on the display.

  • Page 23: Setting The User List For Statistical Values

    6.4 SETTING THE USER LIST FOR STATISTICAL VALUES • To create a user list press >>>> >>>> . The display will show CLS to indicate 'Clear Statistics?' • Press to enter the menu for setting the user list of statistical values. The gauge displays the symbol of the first Statistics item on the statistics menu with its numerical position in the user list shown in the top left of the display.

  • Page 24: Example Of Statistical User List

    • To enter the statistical value displayed at the next available position on the list press . If this is the first entry then the current user list is deleted and replaced with a new user list and it appears in the top left of the display.

  • Page 25: Data Output

    Your gauge is fitted with an infrared data output feature. This operates with the Infrared Portable Printer - see “Spares and accessories” on page 32 for sales part number. Ensure the Elcometer 345 is within 500 mm of the printer, and that the Elcometer 345 IR LED is aligned with the IR detector on the printer. PRINTING To print the statistical values, press >>>>...

  • Page 26: Storage

    The gauge does not contain any user-serviceable components. In the unlikely event of a fault, the gauge should be returned to your local Elcometer supplier or directly to Elcometer. The warranty will be invalidated if the instrument has been opened.

  • Page 27: Error Codes

    Gauge over-range reading. Memory hardware fault. Contact Elcometer or your local Elcometer supplier. Gauge is not configured after repair. Contact Elcometer or your local Elcometer supplier. 8 Err The printer is off line, out of paper or printer or cable fault. Correct printer fault or press...

  • Page 28: Technical Specification

    11 TECHNICAL SPECIFICATION Range: 0 µm to 1500 µm (0 mil to 60 mil) Accuracy: ± 3% of the reading or ± 2.5 µm (0.1 mil) whichever is the greater. ± 1% of the reading or ± 2.5 µm (0.1 mil) whichever is the greater when calibrated close to the thickness to be measured.
  • Page 29 Battery Life: 30 to 40 hours continuous with alkaline dry batteries (15 000 to 20 000 readings at an average of 8 readings per minute). Battery life is reduced when using the back light. Minimum Substrate Thickness: 300 µm (12 mil) unless special adjustment is made - see section 5.3. Gauges will have reduced range when adjusted for thin substrates.

  • Page 30: Probes

    12 PROBES Gauges with serial number TA---- onward are fitted with a new design of probes. The part numbers for replacements for separate probes are shown in Table 1 on page 31. Right Angle Probe Telescopic Probe...
  • Page 31 Table 1: Probe part numbers Replacement Original Current Scale Range Resolution Accuracy probe no. probe no. probe types 0 - 1500 µm ±3% or ±2.5 µm 1 µm F1 Standard T3457286- T34515844 ±1% or ±2.5 µm Below 20 µm, 0.1 µm F1 Right Angle T3457650- T34515845...

  • Page 32: Spares And Accessories

    13 SPARES AND ACCESSORIES The following spare parts and optional accessories are available from your local Elcometer supplier or direct from Elcometer. 13.1 CALIBRATION FOIL SETS Set of µm mils Part number for set 8 foils 12, 25, 50, 125, 175, 250, 500, 1020 0.5, 1, 2, 5, 7, 10, 20, 40 T9904199F...
  • Page 33 13.4 COATED THICKNESS STANDARDS INCLUDING CERTIFICATE Ferrous Standard (4 Values): T995111261 13.5 INFRARED PORTABLE PRINTER Infrared Portable Printer: T99913877 Thermal Printer Paper: T99913878 13.6 PROBE ADAPTORS Jumbo Hand Grip: T9997766- V Adaptor for pipes: T9997381-...
  • Page 34 13.7 HOLSTER Integral Probe Version: T9999516- Separate Probe Version: T3459515- 13.8 RAINCOAT Protective gauge covers (pack of 5): T99913537 13.9 WRIST HARNESS Wrist harness: T99916063...

  • Page 35: Related Equipment

    14 RELATED EQUIPMENT Elcometer produces a wide range of coating thickness gauges and associated paint inspection equipment. Users of the Elcometer 345 may also benefit from the following Elcometer products: • Elcometer 456 Coating Thickness Gauge • Elcometer 406L Statistical Mini-Glossmeter For further information contact Elcometer, your Elcometer supplier or visit the Elcometer website, www.elcometer.com...
  • Page 36 15 INDEX Backlight Error codes Outputting data Batteries Fitting Life Factory calibration Print Data Output Low voltage Foils Printer Type Ordering Infrared Blast cleaned surfaces Printing Probe Connecting Gauge features Calibration adjustment Probes Error Adapters for Rough and Special Substrates Wear of Hand grip, Jumbo Protection for gauge...
  • Page 37 Clearing 13, 22 Displaying List of 13, 23 Turning off Storage Substrate thickness Minimum Switching on/off Technical specification Test certificates Thin substrates Units Changing V Adaptor, for pipes...
