PROFITEST H+E EASY CHECK
6

The Instrument

6.1

Functions Description

The instrument presents laypersons with the possibility of safely checking the func-
tionality of AC charging points without the need for the direct involvement of quali-
fied personnel.
Qualified personnel only need to be summoned for further action (e.g. repair) in the
event that a malfunction has actually been confirmed.
6.2

Device Characteristics

• The instrument can only be used to test AC charging points in charging mode 3.
• The instrument simulates the charging socket of the electric vehicle. It can be
connected to the charging socket or the type 2 plug of an AC charging point.
• During the automatic program sequence, the instrument checks values for 20
and 32 A cables.
6.3

Scope of Delivery

Please check for completeness.
1 PROFITEST H+E EASY CHECK (M525F)
1 Charging cable (micro USB plug)
1 Operating instructions
7
