Telephone layout

Analog Next Gen Cordless 1-line Hotel Telephone -
Telephone Base
1
2
1 Find Handset button
2 Charging poles
3 Charge LED
4 Message waiting LED
5
Speed dial keys
MESSAGE key
MUTE key
HOLD key
6 EMERGENCY key
7 Numeric dial keys
8 VOLUME – key
9 VOLUME + key
10
SPEAKER key
3
8 9
EN - 8

NG-A3411

4
5
6
7
10
11
11 Telephone line jack
12 Handset connector jack
13 Voicemail voltage detection
13
12
