Summary of Contents for VTech Analogue Classic Series
Page 1
Analogue Classic Series User’s Guide (EU) Model: Analogue corded lobby hotel telephone - A1100...
Page 2
Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. This product should be installed by a qualified technician. 2. This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS).
Page 3
Parts checklist ..........................4 Telephone layout ..........................5 Installation ............................6 Set up ............................8 Operation ............................9 Appendix .............................10 Troubleshooting ..........................10 VTech Hospitality limited warranty program .................11 Maintenance ..........................12 Important note ..........................13 Environmental notes ........................13 Product disposal instructions ......................13 Technical information ........................13 European Directives ........................13 Declaration of Conformance ......................13...
Page 4
Parts checklist Items contained in the respective telephone package: Model name Model number Parts included Analogue corded lobby A1100 Telephone base with Corded Telephone faceplate and overlay handset line cord...
Page 5
Telephone layout Telephone line jack DATA port Switch hook Wall mount clip RINGER VOL +/- VOLUME...
Page 6
Installation Telephone base installation The telephone comes ready for desktop use. Install the telephone base as shown below. Telephone wall jack If you have High Speed Internet Access service, a DSL filter (not included) is required. Telephone line cord Telephone line jack Coiled handset cord jack...
Page 7
Installation Installation option - converting from desktop to wall mount position To mount the telephone base on the wall: 1. Put the corded handset aside. On the telephone base, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).
Page 8
Set up Default settings are indicated by asterisks (*). Setting Options Adjustable by: Ringer volume Low, Medium*, High User and administrator Ringer tone Tone 1*, Tone 2, Tone 3 Administrator only Ringer tone There are 3 ringer tone options. To change the ringer tone: 1.
Page 9
Operation Receive a call The telephone rings when there is an incoming call. Lift the corded handset from the telephone base to answer. Place a call Lift the corded handset and it automatically connects to the operator. Refer to your PABX user’s manual for automatic dialling.
Page 10
Appendix Troubleshooting If you have difficulty with the telephones, please try the suggestions below. For customer service, visit our website at www.vtechhotelphones.com or contact your local distributor. For corded telephones: telephone does not work at all. • Make sure the telephone line is plugged into the TEL port of the telephone base. •...
Page 11
If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorise the cost of repair and return shipping costs for the repair of Products that not covered by this limited warranty.
Page 12
Maintenance Taking care of the telephone The telephone contains sophisticated electronic parts, so it must be treated with care. Avoid rough treatment Place the handset down gently. Save the original packing materials to protect the telephone if you ever need to ship it. Avoid water The telephone can be damaged if it gets wet.
Page 13
These equipments are compliant with directives 1999/5/EC (R&TTE), 2014/35/EU (LVD), 2014/30/EU (EMC) and 2011/65/EU (ROHS). Declaration of Conformance Hereby, VTech declares that the product Analogue Classic series is in compliance with the essential requirements and other regulations contained in the directives 1999/5/EC (R&TTE), 2002/95/EC (ROHS).
Page 14
Telephone base: 8.66 x 6.02 x 2.56 in (220 x 153 x 65 mm) Size Corded handset: 2.23 x 2.15 (0.99) x 8.24 in (56.74 x 54.56 (25.26) x 209.40 mm) VTech Telecommunications Limited Manufacturer Address: 23/F Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong...
