DEMO MANUAL DC1718A

parts list

ITEM QTY REFERENCE
1 5 C1, C2, C3, C4, C5
2 1 C6
3 4 E1, E2, E3, E4
4 1 JP1
5 1 J1
6 1 R1
7 3 R2, R3, R4
8 1 U1
9 1 U2
10 1 JP1
4
PART DESCRIPTION
CAP , 0402 0.1µF 20% 16V X7R
CAP , 0603 10µF 10% 6.3V X5R
TURRET
HEADER, 3-PIN, 2mm
HEADER, 2×7 2mm
RES, 0402 1kΩ 5% 1/16W
RES, 0402 4.99kΩ 1% 1/16W
2
IC, 16-BIT DELTA SIGMA I C ADC WITH INTEGRATED
PRECISION REFRENCE
IC, IC SERIAL EEPROM 2k
SHUNT, 2mm
MANUFACTURER/PART NUMBER
TDK C1005X7R1C104M
TDK C1608X5R0J106K
MILL MAX 2308-2
SAMTEC TMM-103-02-L-S
MOLEX 87831-1420
NIC NRC04J102TRF
NIC NRC04F4991TRF
LINEAR TECH. LTC2471CDD
MICROCHIP TECH. 24LC025-I/ST
SAMTEC 2SN-BK-G
dc1718afb
