Ubiquiti Dream Machine Pro UDM Manual

Introduction

This Quick Start Guide is designed to guide you through installation and also includes warranty terms.

Package Contents

System Requirement

Either of the following is required:

• iOS or Android^™ Smartphone with UniFi App Installed
• Web Browser: Google Chrome (Other browsers may have limited functionality)

We strongly recommend using UPS backup and power regulation to prevent equipment damage due to stability issues with local AC power.

TERMS OF USE: All Ethernet cabling runs must use CAT5 (or above). It is the professional installer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, indoor cabling requirements, and Dynamic Frequency Selection (DFS) requirements.

Hardware Overview

Ports

System LED

Reset Button

Installation Requirements

Use Category 5 (or above) UTP cabling approved for indoor use.

To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.

Hardware Installation

1. Connect the AC Power Cord to the Power port of the UniFi Dream Machine and a power outlet.

2. Connect an Ethernet cable from a broadband modem or Wide Area Network (WAN) to the Internet port.

3. Connect an Ethernet cable from your computer or host system to port 1. (You can use Bluetooth on your smartphone to set up the UniFi Dream Machine.)

4. Connect additional network devices to the other ports.

Configuration

You have two options:

• Use Bluetooth and the UniFi SDN app on your smartphone.
• Use a computer connected to the UniFi Dream Machine on port 1. Go to "Chrome Instructions".

UniFi SDN App

Download and install the UniFi SDN app to configure the UniFi Dream Machine.

https://itunes.apple.com/us/app/unifi/id1057750338?mt=8

https://play.google.com/store/apps/details?id=com.ubnt.easyunifi&hl=en_US

Note: Ensure that Bluetooth is enabled on your mobile device. You will need to set up the UniFi Dream Machine with your mobile device and be within 1.5 m (5') from where it is installed.

1. Launch the app and tap the + icon to add a new controller.


2. Once detected, the app will automatically connect to the UniFi Dream Machine and the LED will begin to flash blue. If more than one controller is detected, swipe through the app screens horizontally until you locate the correct UniFi Dream Machine. Then follow the on‑screen instructions.

Chrome Instructions

Use the Chrome web browser to set up your UniFi Dream Machine.

1. Ensure that your host system is on the same Layer‑2 network as the UniFi Dream Machine.
2. Launch the Chrome web browser and type the default IP address of your UniFi Dream Machine into the address field. Press enter (PC) or return (Mac).

3. Follow the on‑screen instructions of the Setup Wizard.

After you run the UniFi Setup Wizard, a login screen will appear for the UniFi Controller management interface. Enter the Username and Password that you created in the UniFi Setup Wizard. Then click Sign in.

You can manage your network and view network statistics using the UniFi Controller management interface. For information on using the UniFi Controller software, refer to the User Guide located on our website at: www.ubnt.com/download/unifi

Specifications

Safety Notices

1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.

Do not use this product in a location that can be submerged by water.

Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.

Electrical Safety Information

1. Compliance is required with respect to voltage, frequency, and current requirements indicated on the manufacturer's label. Connection to a different power source than those specified may result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service should be provided only by a qualified service technician.
3. This equipment is provided with a detachable power cord, which has no grounding wire.

Limited Warranty

www.ubnt.com/support/warranty/

The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and, where applicable, specify arbitration instead of jury trials or class actions.

Compliance
FCC
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions.

1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a partic ular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equip ment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

This radio transmitter (FCC ID: SWX‑UDM) has been approved by FCC.

ISED Canada
CAN ICES‑3(B)/NMB‑3(B)
This device complies with ISED Canada licence‑exempt RSS standard(s). Operation is subject to the following two conditions:

1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of the device.

This radio transmitter (IC: 6545A‑UDM) has been approved by ISED Canada.
The device for operation in the band 5150‑5250 MHz is only for indoor use to reduce the potential for harmful interference to co‑channel mobile

RF Exposure Warning
The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter.

Australia and New Zealand

CE Marking
CE marking on this product represents the product is in compliance with all directives that are applicable to it.

Country List

AT BE BG CY CZ DE DK EE EL ES FI FR HR HU IE IT LV LT LU MT NL PL PT RO SE SI SK UK

BFWA (Broadband Fixed Wireless Access) members noted in blue

Note: This device meets Max. TX power limit per ETSI regulations.

The following apply to products that operate in the 5 GHz frequency range:

Note: This device is restricted to indoor use only when operating in the 5150 ‑ 5350 MHz frequency range within all member states.

Note: All countries listed may operate at 30 dBm. BFWA member states may operate at 36 dBm.

Note: Operation in the 5.8 GHz frequency band is prohibited in BFWA member states. Other countries listed may use the 5.8 GHz frequency band.

RoHS/WEEE Compliance Statement

European Directive 2012/19/EU requires that the equipment bearing this symbol on the product and/or its packaging must not be disposed of with unsorted municipal waste. The symbol indicates that this product should be disposed of separately from regular household waste streams. It is your responsibility to dispose of this and other electric and electronic equipment via designated collection facilities appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. For more detailed information about the disposal of your old equipment, please contact your local authorities, waste disposal service, or the shop where you purchased the product.
