Parameter Definition
080-Genset Reverse
Power Loaddump Limit
081-Genset Reverse
Power Fail Timer
082-Genset Overcurrent
Limit
083-Genset Overcurrent
Limit-2
084-Genset Overcurrent
Limit-3
085-Genset Overcurrent
Action
086-Overcurrent Time
Multiplier
087-Genset Overload
Limit
088-Genset Overload
Fail Timer
089-Load Shedding Low
Limit
090-Load Shedding High
Limit
091-Load Add Delay
K96D01-EN
Unit Min Max
kW 0 50000
sec 0 120
Amp 0 50000
Amp 0 50000
Amp 0 50000
- 0 3
0 1 64
kW 0 50000
sec 0 120
kW 0 50000
kW 0 50000
sec 0 240
Factory Description
Set
If the genset power is negative and
0 goes above this limit then a REVERSE
POWER loaddump will be generated.
If the genset power is negative and over
5 limits during this timer, a reverse power
fault will occur.
If one of the genset phase currents goes
over this limit when feeding the load, this
will generate a genset overcurrent fault
0 condition. The action taken upon fault
condition is programmable. If this
parameter is set to 0 then overcurrent
fault is not monitored.
When secondary voltage is selected, if
one of the genset phase currents goes
over this limit when feeding the load, this
will generate a genset overcurrent fault
0
condition. The action taken upon fault
condition is programmable. If this
parameter is set to 0 then overcurrent
fault is not monitored.
When tertiary voltage is selected, if one
of the genset phase currents goes over
this limit when feeding the load, this will
generate a genset overcurrent fault
0
condition. The action taken upon fault
condition is programmable. If this
parameter is set to 0 then overcurrent
fault is not monitored.
0: shutdown alarm
0
1: loaddump alarm
This parameter defines the reaction
speed of the overcurrent detector. A
16 higher number means higher sensitivity.
Detailed explanation is given at chapter:
"Overcurrent Protection"
If the total genset active power goes over
this limit when feeding the load, this will
0 generate a genset overload loaddump
alarm. If this parameter is set to 0 then
overload fault is not monitored.
If the genset active power is over the
3 limit during this timer, an overload fault
will occur.
If the genset power goes below this limit
then the load shedding relay will be
0
deactivated. Review chapter "Load
Shedding" for more details.
If the genset power goes above this
limit then the load shedding relay will be
0
activated. Review chapter "Load
Shedding" for more details.
This is the minimum delay between 2
load_add pulses. Review chapter "Load
0
Shedding" for more details.
