TrailFX FCLR003B Assembly, Installation, Operation And Maintenance Instructions

Dealer / Installer:
End User:
WARNING

APPLICATION

: FCLR001B only

HARDWARE PARTS LIST

Sl. No Part Description
A Extension
B M16x35mm Bolts
C M16 Flat Washers
D M16 Lock Nuts

TORQUE SPECIFICATION

Size
16 MM
Integrate the extension with front and rear Side Rails. (Fig 1)
Attach the Extension to front and rear Side Rails using the included (Fig 2)
Visit www.trailfx.com
Assembly, Installation, Operation and
Maintenance Instructions
Contractors Rack Extension
Provide a copy of these instructions to the end user of this product. These instructions
provide important operating and safety information for proper usage of this product.
Demonstrate the proper use of the product with the end user. Have the end user
demonstrate that they understand the proper use of the product.
Read and follow all instructions included in this manual. Ask your Dealer / Installer for
assistance if you do not understand the proper use of the product. Never remove any
decals from the product. Failure to follow these instructions can result in injury or death.
Torque
183 ft/lbs
Fig. 1
or 1 (866) 638-4870 for Warranty Information / Tech Support / Product Updates.
2021 Keystone Automotive Operations Inc. All Rights Reserved. 08/26/2021-R01
Qty
A
2
4
4
4
B
Part Number:
FCLR003B
10 - 15 minutes
D
C
Fig. 2
Page-1-3
