Getting Started

137.16 cm
½
(4 ft)
304.8 mm
(12 in.)
508 mm
(20 in.)
Printer
Handhold
Power
switch
cover
Power cord
Tray number decals - Optra
T616(n) and T614n models only
304.8 mm
(12 in.)
304.8 mm
(12 in.)
Paper bail
and bracket
Operator panel
overlay
(non-English only)
500-Sheet Drawer - Optra T616(n)
and T614n models only

Turn Off the Printer

Options Compatibility

Troubleshooting

1
Select a well-ventilated place to set up your
printer. Make sure you have a sturdy, low
table or the optional printer stand on which
to set the printer.
2
Remove all items from the box except the
printer. If any items are missing, contact the
CDs
place where you bought the printer.
Save the carton and packing material in
case you need to repack the printer for ser-
vice or storage.
Note: Leave the printer in the box until you are
ready to install it. Then ask someone to
help you lift the printer using the hand-
holds.
If your printer is already set up, make sure the
printer power is off and the power cord and any
cables are unplugged before installing any options.
Options compatible with Optra™ T printers are
labeled with a colored triangle. The location of the
label is shown before each option install section.
If you encounter a problem while setting up the
printer, refer to the User's Guide, available on the
Optra T Publications CD, for more information.
1
