Lexmark Optra Optra T Setup Manual page 13

Mounting bracket
Mounting slot
Slots
Tabs
3
Insert the mounting brackets into the slots
on top of the printer or output option. Make
sure the output expander is seated securely.
Note: Do not attach the paper bail unless you
are mounting the output expander on
the printer or another output expander.
4
Place the tips of the wire paper bail into the
ends of the plastic bracket so that the bail
curves downward.
The bail rests in the output tray of the
expander below it, or in the printer output
bin.
5
Slide the lower tabs on the tray into the
lower slots on the output expander.
6
Rotate the tray up until the upper tabs click
into the upper slots.
7
Attach the top cover to the output expander.
Install Paper Options and Printer 11
