Installing an Output Expander

Tray
Labels
Bracket and bail
Warning!
The output expander tray is designed to hold the
weight of print material only. Do not use it as a shelf;
excess weight may cause it to disengage from the
output expander.
10 Install Paper Options and Printer
Optra T label
(colored triangle)
Each output expander consists of the expander
and a removable tray. A paper bail, bracket, and
labels are also included.
After you carefully unpack the output expander,
install it immediately; otherwise, the edges of the
mounting brackets could damage tabletops or fab-
rics.
1
Remove the top cover from the printer or
previously installed output option.
2
Slide the plastic bracket onto the static
brush holder, located near the bottom of the
output expander.
