WORKSURFACES & COUNTERTOPS
Description:
BULLET TOP WORKSURFACE & FLASK WORKSURFACE (XM COLLECTION)
Bullet Top Worksurface - XM Collection (TWBS), Flask Worksurface with
Monoleg - xm Collection (TXFLM), Flask Worksurface with Post Legs - xm
NOTE:
Installation of Flask Worksurface with
Monoleg (xm Collection)TXFLM is
shown
Off-Module Cantilever Kits must be
ordered separately
Collection (TXFLP)
B2
B3
Part and Product Identification
B1
B4 - 1/4"-20 x 5/8"
UNC-2A, Cross/
Square Truss Hd
Machine Screw,
zinc (E01-0098) x4
Date:
May 2018
Page No:
1 of 3
TST_202
Rev. No: 01
A1 - Bullet Top Worksurface
(C05-0934-X) x1
A2 - Worksurface Support Beam
Kit w/ 8xE07-0023 screws
(X05-0027-X) x1
B1 - Flask Worksurface
(C05-0866-X) x1
B2 - Worksurface Support Beam
Kit w/ 8xE07-0023 screws
(X05-0027-X) x1
B3 - Semi-Suspended Monoleg
(TLSM) x1
B5 - #10 - 1" Square
Socket Pan Head
PBD Screw
(E07-0023) x4
C1 - Flask Wqorksurface
(C05-0866-X) x1
C2 - Worksurface Support Beam
Kit w/ 8xE07-0023 screws
(X05-0027-X) x1
C3 - xm Post Leg Assembly
(TXPL) x2
C4 - 1/4"-20 x 3/4" Mash Screw
Quad Truss
(E01-2010) x8
